spark plug LINCOLN CONTINENTAL 2002 Owners Manual

MOTORCRAFT PART NUMBERS
Component 4.6L DOHC V8 engine
Engine air filter element FA-1615
Cabin Air filter element FP-5
Fuel filter FG-800A
Battery BXT-65-750
Oil filter FL-820-S
PCV valve EV-111
Spark plugs* AWSF-32E
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
REFILL CAPACITIES
Fluid Ford Part
NameApplication Capacity
Engine oil
(includes filter
change)Motorcraft SAE
5W-20 Super
Premium
Motor OilAll 5.7L (6.0 quarts)
Engine
coolant
1Motorcraft
Premium
Engine Coolant
(green-colored)
orMotorcraft
Premium Gold
Engine Coolant
(yellow-colored)All 15.0L (15.8
quarts)
Brake fluid
2Motorcraft
High
Performance
DOT 3 Motor
Vehicle Brake
Fluid
2
All Fill to line on
reservoir
Maintenance and Specifications
224

ItemFord Part
Name or
equivalentFord Part
NumberFord
Specification
Power steering
fluidMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Windshield
washer fluidUltra-clear
Windshield
Washer
ConcentrateC9AZ-19550-AC ESR-M17P5-A
1Use only brake fluids certified to meet Ford specifications. DOT 3 fluid
is recommended. However, if DOT 3 is not available, DOT 4 fluid can be
used.
ENGINE DATA
Engine 4.6L DOHC V8 engine
Cubic inches 281
Recommended fuel 91 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-0.056 inch)
Ignition system Coil on plug
Compression ratio 9.8:1
VEHICLE DIMENSIONS
Vehicle dimensions mm (in)
(1) Overall length 5 294.7 (208.4)
(2) Overall width 1 870.3 (73.6)
(3) Overall height 1 421.9 (55.9)
(4) Wheelbase 2 769.8 (109.0)
(5) Track - Front 1 600.2 (63.0)
(5) Track - Rear 1 562.1 (61.5)
Maintenance and Specifications
227

system check button ................78
warning messages .....................79
Mirrors .........................................55
automatic dimming rearview
mirror ........................................59
heated ........................................59
programmable memory ............93
side view mirrors (power) .......58
Moon roof ....................................68
Motorcraft parts ................209, 224
O
Octane rating ............................207
Odometer .....................................15
Oil (see Engine oil) ..................194
Overdrive ...................................144
P
Panic alarm feature, remote
entry system ................................91
Parking brake ............................139
Parts (see Motorcraft parts) ....224
Power distribution box (see
Fuses) ........................................162
Power door locks ........................87
Power steering ..........................141
fluid, checking and adding ....214
fluid, refill capacity ................224
fluid, specifications .........226±227
R
Rear window defroster ...............39
Relays ................................156, 163
Remote entry system ...........90±91illuminated entry ......................93
locking/unlocking doors .....90±91
opening the trunk .....................91
panic alarm ...............................91
replacement/additional
transmitters ...............................93
replacing the batteries .............92
S
Safety belts (see Safety
restraints) ....................13, 106±110
Safety defects, reporting ..........183
Safety restraints ................106±110
belt minder .............................112
cleaning the safety
belts .................................116, 189
extension assembly ................111
for adults .........................107±109
for children .............................125
lap belt ....................................110
warning light and
chime ................... 12±13, 111±112
Safety seats for children ..........126
Seat belts (see Safety
restraints) ..................................106
Seats ..........................................103
child safety seats ....................126
cleaning ...................................188
easy access/easyout feature ..106
heated ......................................105
memory seat .............................93
SecuriLock passive anti-theft
system ............................97±98, 100
Servicing your vehicle ..............191
Spark plugs,
specifications .....................224, 227
Index
238
