LINCOLN MARK VIII 1998 Owners Manual
Manufacturer: LINCOLN, Model Year: 1998, Model line: MARK VIII, Model: LINCOLN MARK VIII 1998Pages: 170, PDF Size: 1.37 MB
Page 161 of 170
REFILL CAPACITIES
Fluid Ford Part Name Capacity
Engine oil
(includes filter
change)Motorcraft 5W30 Super
Premium Motor Oil 5.7L (6.0 quarts)
Brake fluid Ford High Performance DOT
3 Brake FluidFill to line in
reservoir
Power steering
fluidMotorcraft MERCONtATF Fill to line in
reservoir
Transmission fluid Motorcraft MERCONtV ATF 12.0L (12.8 quarts)
Engine coolant Ford Premium Cooling
System Fluid15.1L (16.0 quarts)
Fuel tank N/A 68.1L (18.0
gallons)
Rear axle fluid
1Motorcraft SAE 80W90 Rear
Axle Lubricant1.4-1.5L (2.9-3.1
pints)
Windshield washer
fluidUltra-Clear Windshield
ConcentrateFill to line in
reservoir
1Service refill capacities are determined by filling the rear axle 6 mm
(1/4 inch) below the bottom of the filler hole.
Rear axles are considered lubricated for life when the vehicle is used for
normal service. See your ªService Guideº for Severe Duty requirements.
Capacities and specifications
162
Page 162 of 170
LUBRICANT SPECIFICATIONS
Item Ford part name Ford part
numberFord
specification
Brake master
cylinderHigh Performance
DOT 3 Motor
Vehicle Brake FluidC6AZ-
19542-ABESA-M6C25-A,
DOT 3
Door
weatherstripsSilicone Lubricant C0AZ-19553-
AA and
D7AZ-
19553-AAESR-M13P4-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-
19549-AAESE-M97B44-A
Engine oil Motorcraft 5W-30
Super Premium
Motor OilXO-5W30-
QSPWSS-M2C153-G
with API
Certification
Mark
Hinges, latches
and striker
platesMulti-Purpose
GreaseDOAZ-
19584-AAESR-M1C159-A
and
ESB-M1C93-B
Lock cylinders Penetrating
LubricantE8AZ-
19A501-BN/A
Power steering
reservoirMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Automatic
transmission
(4R70W)Motorcraft
MERCONtVATFXT-5-QM
MERCONtV
Windshield
washer fluid
reservoirUltra-Clear
Windshield Washer
ConcentrateC9AZ-19550-
AC or BCESR-M17P5-A
Rear axle Motorcraft Premium
Rear Axle LubricantXY-80W90-QL WSL-M2C197-A
Capacities and specifications
163
Page 163 of 170
ENGINE DATA
Engine 4.6L DOHC engine
Cubic inches 281
Horsepower (except LSC) 280 @ 5750 rpm
Horsepower (LSC) 290 @ 5750 rpm
Torque (except LSC) 285 lb. ft. @ 4500 rpm
Torque (LSC) 290 lb. ft. @ 4500 rpm
Recommended fuel grade 91 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-.056 inch)
Ignition system EDIS
Compression ratio 9.8:1
VEHICLE DIMENSIONS
Vehicle dimensions mm (in)
(1) Overall length 5 263 (207.2)
(2) Overall width 1 900 (74.8)
(3) Overall height 1 361 (53.6)
(4) Wheelbase 2 870 (113.0)
(5) Track - Front 1 565 (61.6)
(5) Track - Rear 1 530 (60.2)
Capacities and specifications
164
Page 164 of 170
2
3
5
1
4
Capacities and specifications
165
Page 165 of 170
IDENTIFYING YOUR VEHICLE
Safety compliance label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the front door latch pillar
on the driver's side.
Vehicle identification number
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if so equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
166
Page 166 of 170
REPORTING SAFETY DEFECTS (U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash, or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Ford Motor Company.
If NHTSA receives similar complaints, it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer or Ford Motor Company.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
at 1±800±424±9393 (202±366±0123 in the Washington D.C. area) or write
to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other information about motor vehicle safety from
the Hotline.
Reporting safety defects
167
Page 167 of 170
Aiming headlamps ....................154
Air bag supplemental restraint
system ..........................................77
and child safety seats ..............78
description ................................77
disposal ......................................81
indicator light ...........................80
passenger air bag .....................79
Air suspension
description ................................97
Anti-lock brake system (ABS)
description ................................93
Anti-theft system ........................63
Battery .......................................135
Brake fluid
checking and adding ..............128
Brakes ..........................................93
anti-lock .....................................93
anti-lock brake system (ABS)
warning light .............................94
fluid, checking and adding ....128
Brake-shift interlock ...................97
Break-in period .............................2
Bulbs, replacing ........................145
specifications ..........................154
Changing a tire .........................115
Child safety seats ........................82
Chime
headlamps on ............................11
Cleaning your vehicle ...............156
engine compartment ..............157
fabric ........................................158
instrument panel ....................158
plastic parts ............................158
safety belts ..............................158
tail lamps .................................158
washing ....................................156
waxing .....................................156
wheels ......................................157
windows ..................................160
woodtone trim ........................160Climate control system
automatic temperature
control ..............34,35,36,37,38,39
Compass, electronic ...............22,23
Controls ..................................57,58
Defrost
rear window ..............................40
Emission control system ..........144
Engine ........................................164
service points ..........................125
Engine block heater ...................91
Engine coolant
checking and adding ..............130
disposal ....................................131
refill capacities ........................131
Engine oil ...........................126,127
changing oil and oil filter .......128
checking and adding .......126,127
Exhaust fumes ............................92
Floor mats ...................................58
Fuel
calculating fuel economy .......143
improving fuel economy ........106
octane rating ...........................142
quality ......................................142
running out of fuel .................143
safety information relating to
automotive fuels .....................141
Fuel gauge ...................................14
Fuel pump shut-off switch .......107
Fuse panels
instrument panel ....................109
power distribution box ...........113
Fuses ...................................108,109
Gauges, Mechanical ....................12
engine coolant temperature
gauge .........................................12
Hazard flashers .........................107
Headlamps ...................................32
daytime running lights .............32
flashing ......................................33
high beam .................................32
Index
168
Page 168 of 170
Heating ........................................34
High beams
indicator light .............................8
Hood
release lever ............................124
Ignition
positions of the ignition ...........40
Instrument panel
lighting up panel
and interior ...............................33
Jump-starting
your vehicle ........................119,120
attaching cables ......................120
disconnecting cables ..............121
Keyless entry system
autolock .....................................63
keypad .......................................60
programming entry code ....61,62
Keys
key in ignition chime ...............12
Lamps
headlamps ........................146,151
interior lamps ...........................52
map lamps .................................52
Lights, warning and indicator
air bag ........................................10
anti-lock brakes (ABS) ..............6
anti-theft ...................................11
brake ............................................6
charging system ..........................7
check engine ..........................9,10
cruise indicator ...........................8
oil pressure .................................7
overdrive off ..............................11
safety belt ...................................9
turn signal indicator ...................8
Lubricant specifications ...........163
Message center ...........................14
reset button ..............................20
Mirrors
cleaning ...................................160
side view mirrors (power) .......54Moon roof ....................................51
Panic alarm feature, remote
entry system ................................60
Parking brake ..............................94
Parts (see Motorcraft parts) ....161
Power door locks ........................54
Power steering
fluid, checking and adding ....132
Refill capacities for fluids ........162
Relays ........................................108
Remote entry system .................58
locking/unlocking doors ......58,59
Reporting safety defects ..........167
Safety restraints
automatic locking mode
(retractor) ............................73,74
extension assembly ..................75
for children ...............................81
lap and shoulder belts .............72
maintenance ..............................76
proper use .................................71
warning light and chime .....11,76
Safety seats for children
attaching with tether straps ....86
automatic locking mode
(retractor) .................................83
in rear seat ................................86
tether anchorage hardware .....87
Seats ............................................66
adjusting the seat, power ........66
auto-glide ..................................69
heated seats ..............................67
lumbar support .........................68
rear seat access ........................70
Servicing your vehicle ..............123
precautions when servicing ...123
Speed control ..............................43
canceling a set speed ...............46
indicator light ...........................47
resuming a set speed ...............47
tap up/tap down .......................45
turning off .................................43
Index
169
Page 169 of 170
Speedometer ...............................13
Starting your vehicle .............88,91
Sunvisor .......................................51
Tachometer
mechanical cluster ...................13
Tilt steering wheel ......................42
Tires ....................................137,139
changing ..................................115
checking the pressure ............139
replacing ..................................140
rotating ....................................139
snow tires and chains ............140
treadwear ................................138
Traction control ..........................96
active light ..................................7
check traction control
message ................................25,31
how to enable/disable ..............15
off light ......................................11
Trailer towing ............................104
tips ...........................................106
Transmission .............................133
automatic
operation ...........97,98,99,100,102
fluid, checking and
adding (automatic) ................133Trunk
using the remote entry
system to open .........................59
Turn signal
lever ...........................................41
Universal transmitter ..................47
erasing channels .......................50
operating ...................................49
programming .............................48
Vehicle dimensions ...................164
Vehicle Identification
Number (VIN) ...........................166
Vehicle loading ..........................103
Ventilating your vehicle .............92
Warning chimes .............................6
Wheels
anti-theft lug nuts ..................118
Windows
power windows, operating .......52
Windshield washer fluid and
wipers
checking and adding fluid .....129
checking and replacing
wiper blades ............................136
operation ...................................41
Wrecker towing .........................122
Index
170
Page 170 of 170
Recommended fuel Unleaded fuel only -
91 octane (R+M/2)
Fuel tank capacity 68.1L (18.0 gallons)
Engine oil capacity (with filter
change)5.7L (6.0 quarts). Use Motorcraft
5W30 Super Premium Motor Oil,
Ford Specification WSS-M2C153-G
Automatic transmission fluid
capacity12.0L (12.8 quarts). Use
Motorcraft MERCONtVATF
(part# XT-5-QM), Ford
Specification WSS-M2C202-B
Tire pressure and size 30 psi (measured cold). Refer to
the label located on the front face
of the passenger's door jamb
Hood release Pull handle under the left side of
the instrument panel
Coolant capacity 15.1L (16.0 quarts)
Power steering fluid capacity Fill to line in reservoir. Use
Motorcraft MERCONtAT F
Ensure correct automatic transmission fluid is used for a specific
application. Check the container to verify the fluid is MERCONtand/or
MERCON Vtapproved. Some fluids have been approved as meeting both
MERCONtand MERCONtV requirements and will be labeled as such.
Fluids labeled as meeting only MERCONtor only MERCONtV
requirements must not be used interchangeably. DO NOT mix MERCONt
and MERCONtV. Transmission fluid requirements are indicated on the
dipstick or on the dipstick handle. Refer to your ªService Guideº to
determine the correct service interval.
Filling station information
176
