change time LINCOLN MKC 2015 Quick Reference Guide

Quick Reference Guide
2015 MKC
Preproduction model shown
This Quick Reference Guide is not
intended to replace your vehicle Owner’s
Manual which contains more detailed
information concerning the features of
your vehicle, as well as important safety
warnings designed to help reduce the
risk of injury to you and your occupants.
Please read your entire Owner’s Manual
carefully as you begin learning about
your new vehicle and refer to the
appropriate chapters when questions
arise. All information contained in this
Quick Reference Guide was accurate at
the time of duplication. We reserve the
right to change features, operation and/
or functionality of any vehicle specification
at any time. Your Lincoln dealer is the best
source for the most current information. For
detailed operating and safety information,
please consult your Owner’s Manual.
Lincoln MKC
March 2014
First Printing
Quick Reference Guide
Litho in U.S.A.
FJ7J 19G217 AA
WARNING
Driving while distracted can result in loss of vehicle control, crash an\
d
injury. We strongly recommend that you use extreme caution when
using any device that may take your focus off the road. Your primary
responsibility is the safe operation of your vehicle. We recommend
against the use of any hand-held device while driving and encourage
the use of voice-operated systems when possible. Make sure you are
aware of all applicable local laws that may affect the use of electronic
devices while driving.
United States
Lincoln Customer Relationship Center
1-800-521-4140
(TDD for the hearing impaired 1-800-232-5952)
lincolnowner.com
Canada
Lincoln Customer Relationship Centre
1-800-387-9333
lincolncanada.comPreproduction model shown

*if equipped*if equipped13
2015 MKC
12
Liftgate
Manual Liftgate
To Open the Liftgate
1. Unlock the liftgate with the remote control
or power door control. If the intelligent
access transmitter* is within 3 feet (1 meter)
of the liftgate, the liftgate will unlock when
you press the liftgate release button.
2. Unlock all the vehicle doors.
3. Press the button located inside the liftgate
pull-cup handle to unlatch the liftgate.
4. Pull on the outside handle to raise the liftgate.
Power Liftgate*
To Open Using the Outside Liftgate Button
1. Unlock the liftgate with the remote control
or power door control. If the intelligent
access transmitter* is within 3 feet (1 meter)
of the liftgate, the liftgate will unlock when
you press the liftgate release button.
2. Press the button located in the top
of the liftgate pull-cup handle.
3. Allow the power system to open the
liftgate after pressing the control.
4. To close, press and release the
control pictured below. To Open Using the Remote Transmitter
Open or close the liftgate with your remote
control by pressing the
button twice within
three seconds. You will hear a tone when the
liftgate is activated. You can also open or close
the liftgate from inside the vehicle by pressing
the
button on the instrument panel.
Setting the Liftgate Open Height
Once you open the power liftgate, you can move
it manually to a desired height. If the previously
programmed liftgate height is lower than the fully
opened position, you can manually push it upward. To Program a New Height
1. Open the liftgate.
2. Manually move the liftgate to your desired height.
3. Press and hold the control button on the liftgate
until you hear a tone, indicating that your
programming of the liftgate height is successful.
The next time you use the power feature to open the
liftgate, it will open to its newly programmed height.
To change the programmed height, repeat the
process above.
Obstacle Detection*
When you use the power open or close feature and the liftgate detects a \
problem, you will hear a warning tone and the liftgate will stop.
The Liftgate Will Not Power Open or Close When
It detects an object in its opening or closing path.
The 12-volt battery does not have enough charge to power the liftgate.
The ignition is on and the transmission is not in park (P).
You are traveling at speeds at or above 3 mph (5 km/h).
Note: Entering the vehicle while the liftgate is closing could cause the
vehicle to bounce and activate obstacle detection.
Hands-free Liftgate Operation*
1. Make sure you have your intelligent access transmitter within
3 feet (1 meter) of the liftgate.
2. Move your foot under and back from the rear bumper, similar to a kicking
(front-to-back) motion. Do not move your foot sideways or the sensors \
may
not detect the motion.
Note: In vehicles equipped with the towing package, you must kick your
foot between the trailer hitch and the exhaust system. Do not kick under
the hitch.
Built-in Storage
Cargo tie-downs, located in key areas of the rear cargo area, fold out o\
f the way
when not in use.
Umbrella tray, located on the outboard side of the driver seat, lets you\
store a wet
umbrella and keeps it within easy reach.
Toll-ticket holder, located between the headliner and the sunvisor hinge\
: slide
your toll ticket in the space provided.
Liftgate and Built-in Storage
Preproduction model shown Preproduction model shown

1514*if equipped
Function
BLIS® (Blind Spot Information System)
with Cross Traffic Alert*
BLIS uses radar sensors to help you
determine if a vehicle may be in your blind
spot zone. The cross traffic alert feature
warns you of vehicles approaching from the
sides when the transmission is in reverse
(R). BLIS and cross traffic alert will display a
yellow indicator light in your exterior mirrors
and the cross traffic alert will also sound
tones and display messages to warn you
which direction vehicles are approaching.
Refer to the Driving Aids chapter in your
Owner’s Manual for more information.
Note: Visibility aids do not replace the need
to watch where the vehicle is moving. Refer
to the Owner’s Manual for safety information,
more details and system limitations.
Lincoln Drive Control
This feature intelligently integrates
chassis and powertrain systems for
personalized ride comfort, steering,
handling, powertrain response and
sound. Choose between two default
settings or customize your own.
Factory default settings include Normal
Handling and Normal Performance
while you are in drive (D). Select
sport (S) to engage Sport Handling
and Sport Performance settings.
Customize your Handling and
Performance settings through the
information display by navigating
through the menu to Settings >
Vehicle > Drive Control to configure:
Handling
Comfort: Provides lower steering
efforts and a more fluid suspension.
Normal: Delivers an engaging drive
experience with confident handling.
Sport: Increases handling and
control with a sporty feel. Performance

Normal: Provides smooth power
delivery and a refined sound.
Sport: Increases engine and
transmission responsiveness,
while adding a more powerful
engine tone.
Active Park Assist and
Park Out Assist*
Active Park Assist detects an
available parallel parking space
and automatically steers the
vehicle into the space (hands-free)
while you control the accelerator,
gearshift and brakes. The system
visually and audibly instructs
you to park your vehicle. To
use active park assist, press the
button located near the shifter.
To stop the parking procedure,
grab the steering wheel or press the
control again. Active Park Out Assist determines the
clearance to the front and rear of your
vehicle and automatically steers your
vehicle out of a parallel parking space
(hands-free) while you control the
accelerator, gearshift and brakes.
The system visually and audibly
instructs you to enter traffic.
For complete information, refer
to the Parking Aids chapter
of your Owner’s Manual.
Note: The driver is always
responsible for controlling the
vehicle, supervising the system,
and intervening, if required.
SelectShift Automatic®
Transmission
The transmission gives you the
ability to manually change gears, if
you like. To use SelectShift, press
sport (S). Use the paddle shifters,
located on the steering wheel, to
manually select gears. Pull (+) to
upshift, pull (–) to downshift. The
system will stay in manual control
until you make another shift button
selection, for example, drive (D).
Lane Keeping System*
The system detects unintentional drifting toward the outside of the lane and alerts or aids the driver to stay in the
lane through the steering system and information display. The system automatically detects and tracks the road lane
markings using a camera that is mounted behind the interior mirror.
Rear View Camera
This system provides a video image of the area behind the vehicle. The d\
isplay
automatically appears in the touchscreen when the vehicle is in reverse (R) and
uses green, yellow and red guides to alert you of your proximity to obje\
cts.
Forward Sensing System*
This system sounds an audible warning tone if there is an obstacle near \
the vehicle’s front bumper. As the
vehicle moves closer to the obstacle, the rate of the warning tone incre\
ases in frequency. The front sensors are
automatically activated when the gearshift is in any position other than\
park (P) or neutral (N) and the vehicle speed
is below 6 mph (10 km/h). See the Parking Aids chapter in your Owner’s Manual for complete information.
Configurable Daytime Running Lamps*
When you start your vehicle with your headlamp control in the autolamps \
position , the configurable daytime
running lamps turn on automatically. You can configure the daytime running lamps ON or OFF using your information
display controls. See the Lighting chapter in your Owner’s Manual for complete information.
Preproduction model shown
*if equipped*if equipped
2015 MKC

19
2015 MKC
*if equipped
*if equipped
Congratulations on your decision to drive a Lincoln. The Lincoln Pledge \
provides
you with valuable support so you can handle the challenges of the road w\
ith
confidence and ease.
The following information is for United States clients. Canadian Roadside
coverage and benefits may differ from the United States coverage. Canadian
clients should refer to the Lincoln Roadside Assistance section of the Warranty
Guide, call 1-800-387-9333 or visit the website at www.LincolnCanada.com
for more details.
Lincoln Complimentary Maintenance
As part of our commitment to providing a new ownership experience, your
vehicle comes with Lincoln Complimentary Maintenance. This maintenance
plan is available on most vehicles sold in the United States and begins on your
purchase date and at 0 miles (0 kilometers). It is limited based on mi\
leage,
time or number of service visits, whichever occurs first. That means when your
information display alerts you when it is time for an oil change, you should bring in
your vehicle for complimentary service. Visit www.LincolnOwner.com
for full details.
Roadside AssistanceContact Roadside Assistance 1-800-521-4140, any time, 24 hours a day, 365 days
a year. As part of the Lincoln Pledge, you will receive 24/7 Roadside Assistance
nationwide (including Canada and Mexico), that begins from the warrant\
y start
date and lasts the life of the vehicle for the original owner only. Subsequent
owners are eligible for an extended powertrain warranty coverage period \
of six
years or 70,000 miles (112,655 kilometers) whichever occurs first. Roadside Assistance Services Include

Towing: Lincoln eligible vehicles will be towed to the client’s selling or
preferred dealer within 100 miles (161 kilometers) of the disablement \
location
or to the nearest Lincoln dealer. If you request to be towed to a selling
or preferred dealer that is more than 100 miles (161 kilometers) from \
the
disablement location, you shall be responsible for any mileage costs in \
excess
of 100 miles (161 kilometers).
Flat tire change: Replacement of a flat tire with a usable spare available in
your vehicle.
Battery jump start Lock-out assistance: If you lose your key or intelligent transmitter, key
replacement is your responsibility
Fuel delivery: 2 gallons (7.5 liters) of gasoline, limited to two, no-charge
occurrences within a 12-month period.
Winch out services: Includes pulling a vehicle within 100 feet of a paved or
county maintained road. No recoveries.
Lincoln Customer Relationship CenterIf you have questions about your vehicle or the Lincoln Pledge, please contact
your dealer. For additional help, you’re invited to call our Lincoln Customer
Relationship Center: 1-800-521-4140 (TDD for the hearing impaired
1-800-232-5952) Monday through Friday, 8 a.m. – 8 p.m. and Saturday
9 a.m. – 5:30 p.m. EST.
Vehicle WarrantyFor a detailed description of what is covered by your vehicle’s New Vehicle
Limited Warranty, refer to the Warranty Guide that is provided to you along
with your Owner’s Manual.
Climate Controlled Front Seats*
To use, press the heated or the
cooled seat symbol located on the
touchscreen to cycle through the
various settings and off. Warmer or
cooler settings are indicated by more
lights. The climate controlled seats will
function only when the engine
is running.
Heated Steering Wheel*
Your vehicle may be equipped with a
heated steering wheel. Press the icon
in your touchscreen to turn this feature
on and off.
Note: The wood trim* will not heat
between the 10 and 2o’clock positions.
Rear Heated Seats* The rear heated seat controls are on
the rear of the center console. To use,
press the heated seat button to cycle
through the various heat settings and
off. Warmer settings are indicated by
more indicator lights. The rear heated
seats will function only when the
engine is running.
Tilting Head Restraints
You can adjust the front-row head
restraints by pulling up to raise the
head restraint. To lower, press the
head restraint down while pressing
and holding the guide sleeve adjust/
release button. Tilt the head restraint
forward for additional comfort by
gently pulling the top of the head
restraint. Once it is in the forward-most
position, tilting it forward once more
will release it to the upright position.
Note: Do not attempt to force the head
restraint backward after it is tilted.
Instead, continue tilting it forward until
the head restraint releases to the
upright position.
Second-row Seat Functionality
Fold the Seatback Down
Fold the outboard head restraints
and lower the center head restraint
first. With the seat empty, pull
the lever up to fold the seatback
forward. Pull the seatback upward
to unfold the seatback.
Recline the Seatback Down
With the seat occupied, pull the
lever up to recline the seatback.
Panoramic Vista Roof ®
with Power Sunscreen*
To open the moonroof, press the
open button. It will stop short of the
fully opened position. To open the
moonroof fully, press the
open
button again. To close, press the
close button. To vent the moonroof,
press the
vent button.
The sunscreen will automatically open
with the moonroof, but if the moonroof
is closed, you can open the sunscreen
by pressing the
button. To close it,
press the close button.
Comfort The Lincoln Pledge
Preproduction model shown18
