adding oil LINCOLN MKS 2012 Owners Manual

5. Locate and carefully remove the
engine oil level dipstick.
6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again.
•If the oil level iswithin this
range,the oil level is acceptable.
DO NOT ADD OIL.
•If the oil level isbelow this
mark,engineoil must be added
to raise the level within the
normal operating range.
•If required, add engine oil to the engine. Refer toAdding engine oil
in this chapter.
•Do not overfill the engine
with oil. Oil levels above this
mark may cause engine
damage.If the engine is
overfilled, some oil must be
removed from the engine by an
authorized dealer.
7. Put the dipstick back in and ensure it is fully seated.
Adding engine oil
1. Check the engine oil. For instructions, refer toChecking the engine
oilin this chapter.
Maintenance and Specifications
311
2012 MKS(mks)
Owners Guide, 1st Printing
USA(fus)

•Always dispose of automotive
batteries in a responsible manner.
Follow your local authorized
standards for disposal. Call your
local authorized recycling center
to find out more about recycling
automotive batteries.
ENGINE COOLANT
Checking engine coolant
The concentration and level of engine coolant should be checked at the
intervals listed inscheduled maintenance information.The coolant
concentration should be maintained at 50/50 coolant and distilled water.
For best results, coolant concentration should be tested with a
refractometer such as Rotunda tool 300-ROB75240E available from your
dealer. Ford does not recommend the use of hydrometers or coolant test
strips for measuring coolant concentration. The level of coolant should
be maintained at the FULL COLD level or within the COLD FILL RANGE
in the coolant reservoir. If the level falls below, add coolant per the
instructions in theAdding engine coolantsection.
Your vehicle was factory-filled with a 50/50 engine coolant and water
concentration. If the concentration of coolant falls below 40% or above
60%, the engine parts could become damaged or not work properly.A
50/50 mixture of coolant and water provides the following:
•Improved freeze protection.
•Improved boiling protection.
•Protection against rust and other forms of corrosion.
•Proper function of calibrated gauges.
L
E
A
D
RETURN
RECYCLE
Maintenance and Specifications
316
2012 MKS(mks)
Owners Guide, 1st Printing
USA(fus)

recommendations ...................171
Child safety seats - booster
seats ...........................................182
Cleaning your vehicle
engine compartment ..............299
instrument panel ....................301
interior .....................................302
plastic parts ............................300
washing ....................................297
waxing .....................................298
wheels ......................................298
wiper blades ............................300
Climate control (see Air
conditioning or Heating) ......49, 52
Clock ............................................33
Collision Warning System .........247
Compass, electronic ....................73
calibration .................................74
set zone adjustment .................74
Console
overhead ....................................72
Controls
power seat ...............................130
steering column ........................91
Coolant
checking and adding ..............316
refill capacities ................319, 345
specifications ..........................345
Cooled Seats ..............................133
Cross Traffic Alert ....................252
Cruise control
(see Speed control) ....................81
Cupholder(s) .............................138
Customer Assistance ................265
Ford Extended Service
Plan ..................................355, 358Getting assistance outside the
U.S. and Canada .....................293
Getting roadside assistance ...265
Getting the service you
need .........................................288
Ordering additional owner’s
literature .................................295
Utilizing the
Mediation/Arbitration
Program ...................................293
D
Daytime running lamps
(see Lamps) ................................63
Defrost
rear window ..............................49
rear window and rearview
mirrors .......................................52
windshield ...........................49, 52
Dipstick
automatic transmission
fluid ..........................................335
engine oil .................................310
Doors
central unlocking ....................107
Driving under special
conditions ..........................260, 262
sand .........................................261
snow and ice ...........................263
through water .................261, 264
E
Electronic message center .........18
Emergencies, roadside
jump-starting ..........................282
running out of fuel .........282, 327
Emission control system ..........331
Engine ........................................349
Index
379
2012 MKS(mks)
Owners Guide, 1st Printing
USA(fus)

cleaning ...................................299
coolant .....................................316
fail-safe cooling .......................320
lubrication specifications .......345
refill capacities ........................345
service points ..................307–308
Engine block heater .................222
Engine oil ..................................310
checking and adding ..............310
dipstick ....................................310
filter, specifications ................344
refill capacities ........................345
specifications ..........................345
Event data recording ....................7
Exhaust fumes ..........................222
F
Fail safe cooling ........................320
Fleet MyKey programming ......101
Floor mats .............................98–99
Fluid capacities .........................345
Fog lamps ....................................59
Four-Wheel Drive vehicles
driving off road .......................259
Fuel ............................................322
calculating fuel
economy ............................20, 328
cap ...........................................324
capacity ...................................345
choosing the right fuel ...........325
detergent in fuel .....................326
filler funnel .............................327
filling your vehicle with
fuel ...........................322, 324, 328
filter, specifications ........322, 344
fuel pump shut-off ..................266
improving fuel economy ........328
octane rating ...................326, 349quality ......................................326
running out of fuel .........282, 327
safety information relating to
automotive fuels .....................322
Fuses ..........................................267
G
Garage door opener ....................94
Gas cap (see Fuel cap) ............324
Gas mileage
(see Fuel economy) .................328
Gauges .........................................17
H
Hazard flashers .........................266
Headlamps ...................................57
aiming ........................................63
autolamp system .......................58
bulb specifications ....................67
daytime running lights .............63
flash to pass ..............................62
high beam .................................59
turning on and off ....................57
Heated Seats .....................133–134
Heating
heating and air conditioning
system .................................49, 52
Homelink wireless control
system ..........................................94
Hood ..........................................306
I
Ignition ...............................218, 349
Illuminated visor mirror .............72
Index
380
2012 MKS(mks)
Owners Guide, 1st Printing
USA(fus)
