Resetting the power liftgate:
The power liftgate may not operate under these conditions. If any of
these conditions occur, the power liftgate must be reset.
• a low voltage or dead battery
• disconnected battery
• the liftgate has been left open, or in the partially latched position, for
more than six (6) hours.
To reset the power liftgate:
1. Manually close and fully latch the liftgate.
2. Power open the liftgate by using the keyfob or overhead console
button.
3. Once the liftgate is fully open, close the liftgate using the keyfob or
overhead console button.
Note: If the power liftgate system is turned in the message
center, the system can not be activated with any switches or with the
liftgate handle. The system will need to be turned for any power
operation to occur.
Liftgate ajar signal
If the liftgate or liftgate glass are not fully latched, you will receive a
“ LIFTGATE AJAR ” message on the instrument panel. If you see this
message, check both the liftgate glass and liftgate door to insure they are
fully latched.
Make sure the liftgate is closed to prevent exhaust fumes from
being drawn into the vehicle. If you must drive with the liftgate
open, keep the vents open so outside air comes into the vehicle.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Driver Controls
151

LUGGAGE RACK
The rear cross-bar can be adjusted to fit the item being carried. The
front cross-bar does not move.
To adjust cross-bar position:
1. Loosen the thumbscrews at both
ends of the rear cross-bar.
2. Slide the cross-bar to the desired
location.
3. Tighten the thumbscrews at both
ends of the cross-bar.
Load luggage at the front cross-bar and adjust the rear cross-bar as
necessary.
• Do not exceed 90.7 kg (200 lb) of luggage if the weight is placed
directly on the cross-bars.
• Do not exceed 68 kg (150 lb) if the weight is resting directly on the
roof.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Driver Controls
152

KEYS
The key operates all locks on your vehicle. In case of loss, replacement
keys are available from your dealer.
You should always carry a second key with you in a safe place in case
you require it in an emergency.
Refer to SecuriLock
Passive Anti-Theft System for more information.
POWER DOOR LOCKS
If the door does not unlock when the control is pressed, see Power door
lock disable feature in the Remote entry section in this chapter.
Press control to unlock all doors.
Press control to lock all doors.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Locks and Security
Locks and Security
153

Childproof door locks
When these locks are set, the rear
doors cannot be opened from the
inside. The rear doors can be
opened from the outside when the
doors are unlocked.
The childproof locks are located on
rear edge of each rear door and
must be set separately for each
door. Setting the lock for one door
will not automatically set the lock
for both doors.
Move lock control up to engage the childproof lock. Move control down
to disengage childproof locks.
REMOTE ENTRY SYSTEM
This device complies with part 15 of the FCC rules and with RS-210 of
Industry Canada. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user ’ s authority to
operate the equipment.
The remote entry system allows you to lock or unlock all vehicle doors
and liftgate and open the liftgate window without a key.
The remote entry lock/unlock feature operates in any ignition position.
The liftgate glass features operate as long as the vehicle ’ s speed is less
than 5 km/h (3 mph). The panic feature operates with the key in the
OFF or ACC position.
If there is any potential remote keyless entry problem with your vehicle,
ensure ALL remote entry transmitters are brought to the dealership, to
aid in troubleshooting.
Unlocking the doors/liftgate
Press this control to unlock the driver ’ s door. The interior lamps will
illuminate with the ignition OFF.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Locks and Security
154

• 4 – button remote
• 5 – button remote
Press the control a second time within three seconds to unlock all doors
and liftgate.
Locking the doors/liftgate
Press this control to lock all doors and liftgate.
To confirm all doors are closed and locked, press the control a second
time within three seconds and the horn will chirp.
• 4 – button remote
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Locks and Security
155

• 5 – button remote
If any of the doors or liftgate are ajar, the horn will make two quick
chirps, reminding you to properly close all doors.
Unlocking the liftgate window
Press the control to unlatch the liftgate window.
• 4 – button remote
• 5 – button remote
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Locks and Security
156

Opening the power liftgate (if equipped)
Press the control twice to fully
unlatch and open the liftgate.
Make sure all persons are clear of the liftgate area before using
power liftgate control.
In order to fully lower and latch the liftgate, press the control twice.
If the liftgate stops mid travel, it may have detected an obstacle, Check
to ensure the liftgate swing zone is free from obstruction and reset the
power assist by manually closing the liftgate. Normal operation can then
be resumed.
Make sure the liftgate is closed to prevent exhaust fumes from
being drawn into the vehicle. This will also prevent passengers
and cargo from falling out. If you must drive with the liftgate open,
keep the vents open so outside air comes into the vehicle.
Sounding a panic alarm
Press this control to activate the alarm.
The personal panic alarm will cycle the horn and parking lamps on/off.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Locks and Security
157

• 4 – button remote
• 5 – button remote
To deactivate the alarm, press the control again or turn the ignition to
ACC or ON.
Memory feature
The remote entry system can also control the memory feature.
Press the control once to unlock the driver ’ s door. Pressing the control
will automatically move the seat, rearview mirrors, and adjustable pedals
to the desired memory position (the memory position corresponds to the
transmitter being used).
• 4 – button remote
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Locks and Security
158

• 5 – button remote
Activating the memory feature
To activate this feature:
1. Position the seat, rearview mirror, and adjustable pedals to the
positions you desire.
2. Press the SET control on the driver ’ s door panel.
3. Within 5 five seconds, press one control on the remote transmitter and
then press the 1 or 2 control on the driver ’ s door panel to which you
would like to associate with Driver 1 or Driver 2 positions.
4. Repeat this procedure for another remote transmitter if desired.
Deactivating the memory seat feature
To deactivate this feature:
1. Press the SET control on the
driver ’ s door panel.
2. Within 5 five seconds, press any
control on the remote transmitter
which you would like to deactivate
and then press the SET control on
the driver ’ s door panel.
3. Repeat this procedure for another remote transmitter if desired.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Locks and Security
159

Replacing the battery
The remote entry transmitter uses one coin type three-volt lithium
battery CR2032 or equivalent. The typical operating range for your
remote entry transmitter is approximately 10 meters (33 feet). A
decrease in the operating range could be caused by:
• weather conditions,
• nearby radio towers,
• structures around the vehicle and
• other vehicles parked next to the vehicle.
To replace the battery:
1. Twist a thin coin between the two
halves of the remote entry
transmitter near the key ring. DO
NOT TAKE THE RUBBER COVER
AND CIRCUIT BOARD OFF THE
FRONT HOUSING OF THE
REMOTE ENTRY TRANSMITTER.
2. Do not wipe off any grease on the
battery terminals on the back
surface of the circuit board.
3. Remove the old battery.
4. Insert the new battery. Refer to the diagram inside the remote entry
transmitter for the correct orientation of the battery. Press the battery
down to ensure that the battery is fully seated in the battery housing
cavity.
5. Snap the two halves back together.
Note: Replacement of the battery will not cause the remote transmitter
to become deprogrammed from your vehicle. The remote transmitter
should operate normally after battery replacement.
