engine coolant LINCOLN NAVIGATOR 2004 User Guide

Do not add engine coolant when the engine is hot. Steam and
scalding liquids released from a hot cooling system can burn you
badly. Also, you can be burned if you spill coolant on hot engine parts.
Do not put engine coolant in the windshield washer fluid
container. If sprayed on the windshield, engine coolant could
make it difficult to see through the windshield.
• Add Motorcraft Premium Gold Engine Coolant
(yellow-colored), VC-7 – A (VC-7 – B in Oregon), meeting Ford
Specification WSS-M97B51 – A1.
Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may
darken the color of Motorcraft Premium Gold Engine Coolant from
yellow to golden tan.
• Do not add/mix an orange-colored, extended life coolant such
as Motorcraft Speciality Orange Engine Coolant, VC-2 (US) or
CXC-209 (Canada), meeting Ford specification WSS-M97B44 – D
with the factory-filled coolant. Mixing Motorcraft Speciality Orange
Engine Coolant or any orange-colored extended life product with your
factory filled coolant can result in degraded corrosion protection.
• A large amount of water without engine coolant may be added, in case
of emergency, to reach a vehicle service location. In this instance, the
cooling system must be drained and refilled with a 50/50 mixture of
engine coolant and distilled water as soon as possible. Water alone
(without engine coolant) can cause engine damage from corrosion,
overheating or freezing.
• Do not use alcohol, methanol, brine or any engine coolants
mixed with alcohol or methanol antifreeze (coolant). Alcohol
and other liquids can cause engine damage from overheating or
freezing.
• Do not add extra inhibitors or additives to the coolant. These
can be harmful and compromise the corrosion protection of the engine
coolant.
For vehicles with overflow coolant systems with a non-pressurized cap
on the coolant recovery system, add coolant to the coolant recovery
reservoir when the engine is cool. Add the proper mixture of coolant and
water to the “ cold full ” level. For all other vehicles, which have a coolant
degas system with a pressurized cap, or if it is necessary to remove the
coolant pressure relief cap on the radiator of a vehicle with an overflow
system, follow these steps to add engine coolant.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
315

To reduce the risk of personal injury, make sure the engine is
cool before unscrewing the coolant pressure relief cap. The
cooling system is under pressure; steam and hot liquid can come out
forcefully when the cap is loosened slightly.
1. Before you begin, turn the engine off and let it cool.
2. When the engine is cool, wrap a thick cloth around the coolant
pressure relief cap on the coolant reservoir (a translucent plastic bottle).
Slowly turn cap counterclockwise (left) until pressure begins to release.
3. Step back while the pressure releases.
4. When you are sure that all the pressure has been released, use the
cloth to turn it counterclockwise and remove the cap.
5. Fill the coolant reservoir slowly with the proper coolant mixture (see
above), to within the “ cold fill range ” or the “ cold full ” level on the
reservoir. If you removed the radiator cap in an overflow system, fill the
radiator until the coolant is visible and radiator is almost full.
6. Replace the cap. Turn until tightly installed. (Cap must be tightly
installed to prevent coolant loss.)
After any coolant has been added, check the coolant concentration, refer
to Checking Engine Coolant section. If the concentration is not 50/50
(protection to – 34 ° F/ – 36 ° C), drain some coolant and adjust the
concentration. It may take several drains and additions to obtain a 50/50
coolant concentration.
Whenever coolant has been added, the coolant level in the coolant
reservoir should be checked the next few times you drive the vehicle. If
necessary, add enough 50/50 concentration of engine coolant and
distilled water to bring the liquid level to the proper level.
If you have to add more than 1.0 liter (1.0 quart) of engine coolant per
month, have your dealer check the engine cooling system. Your cooling
system may have a leak. Operating an engine with a low level of coolant
can result in engine overheating and possible engine damage.
Recycled engine coolant
Ford Motor Company does NOT recommend the use of recycled engine
coolant in vehicles originally equipped with Motorcraft Premium Gold
Engine Coolant since a Ford-approved recycling process is not yet
available.
Used engine coolant should be disposed of in an appropriate
manner. Follow your community ’ s regulations and standards for recycling
and disposing of automotive fluids.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
316

Coolant refill capacity
To find out how much fluid your vehicle ’ s cooling system can hold, refer
to Refill capacities in this chapter.
Fill your engine coolant reservoir as outlined in Adding engine coolant
in this chapter.
Severe climates
If you drive in extremely cold climates (less than – 36 ° C[ – 34 ° F]):
• It may be necessary to increase the coolant concentration
above 50%.
• NEVER increase the coolant concentration above 60%.
• Increased engine coolant concentrations above 60% will
decrease the overheat protection characteristics of the engine
coolant and may cause engine damage.
• Refer to the chart on the coolant container to ensure the
coolant concentration in your vehicle will provide adequate
freeze protection at the temperatures in which you drive in the
winter months.
If you drive in extremely hot climates:
• It is still necessary to maintain the coolant concentration
above 40%.
• NEVER decrease the coolant concentration below 40%.
• Decreased engine coolant concentrations below 40% will
decrease the corrosion protection characteristics of the engine
coolant and may cause engine damage.
• Decreased engine coolant concentrations below 40% will
decrease the freeze protection characteristics of the engine
coolant and may cause engine damage.
• Refer to the chart on the coolant container to ensure the
coolant concentration in your vehicle will provide adequate
protection at the temperatures in which you drive.
Vehicles driven year-round in non-extreme climates should use a 50/50
mixture of engine coolant and distilled water for optimum cooling system
and engine protection.
What you should know about fail-safe cooling
If the engine coolant supply is depleted, this feature allows the vehicle to
be driven temporarily before incremental component damage is incurred.
The “ fail-safe ” distance depends on ambient temperatures, vehicle load
and terrain.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
317

How fail-safe cooling works
If the engine begins to overheat:
• The engine coolant temperature
gauge will move to the red (hot)
area.
• The and the symbol
will illuminate.
• The “ Service Engine Soon ”
indicator light will illuminate.
If the engine reaches a preset over-temperature condition, the engine
will automatically switch to alternating cylinder operation. Each disabled
cylinder acts as an air pump and cools the engine.
When this occurs the vehicle will still operate. However:
• The engine power will be limited.
• The air conditioning system will be disabled.
Continued operation will increase the engine temperature:
• The engine will completely shut down.
• Steering and braking effort will increase.
Once the engine temperature cools, the engine can be re-started. Take
your vehicle to a service facility as soon as possible to minimize engine
damage.
When fail-safe mode is activated
You have limited engine power when in the fail-safe mode, so drive the
vehicle with caution. The vehicle will not be able to maintain high speed
operation and the engine will run rough. Remember that the engine is
capable of completely shutting down automatically to prevent engine
damage, therefore:
1. Pull off the road as soon as safely possible and turn off the engine.
2. Arrange for the vehicle to be taken to a service facility.
3. If this is not possible, wait a short period for the engine to cool.
4. Check the coolant level and replenish if low.
Never remove the coolant reservoir cap while the engine is
running or hot.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
318

1. Start the engine and let it run
until it reaches normal operating
temperature (the engine coolant
temperature gauge indicator will be
near the center of the normal area
between H and C).
2. While the engine idles, turn the
steering wheel left and right several
times.
3. Turn the engine off.
4. Check the fluid level in the
reservoir. It should be between the
MIN and MAX lines. Do not add
fluid if the level is in this range.
5. If the fluid is low, add fluid in
small amounts, continuously
checking the level until it reaches
the range between the MIN and
MAX lines. Be sure to put the cap
back on the reservoir.
BRAKE FLUID RESERVOIR
The fluid level will drop slowly as
the brakes wear, and will rise when
the brake components are replaced.
Fluid levels between the “ MIN ” and
“ MAX ” lines are within the normal
operating range, there is no need to
add fluid. If the fluid levels are
outside of the normal operating range, the performance of your brake
system could be compromised, seek service from your dealer
immediately. MAX
MIN
MAX
MIN
MAX
MIN
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
329

Component 5.4L 4V V8 engine
Spark plugs* AGSF-32PM
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
REFILL CAPACITIES
Fluid Ford Part
Name Application Capacity
Brake fluid Motorcraft High
Performance
DOT 3 Motor
Vehicle Brake
Fluid All Fill to line on
reservoir
Engine oil
(includes filter
change) 6
Motorcraft SAE
5W-20 Premium
Synthetic Blend
Motor Oil (US)
Motorcraft SAE
5W-20 Super
Premium Motor
Oil (Canada) All 6.6L (7.0
quarts)
Fuel tank N/A All 106 L (28
gallons)
Power steering
fluid Motorcraft
MERCON  AT F All Fill to line on
reservoir
Transmission
fluid 1
Motorcraft
MERCON  AT F 4 x 2 vehicles 15.0L (15.9
quarts) 2
4 x 4 vehicles 15.5L (16.4
quarts) 2
Transfer case
fluid Motorcraft
MERCON  AT F 4 x 4 vehicles 1.9L (2.0
quarts)
Engine coolant 3
Motorcraft
Premium Gold
Engine Coolant
(yellow-colored) without aux rear
heat 21.0L (22.2
quarts)
with aux rear
heat 23.0L (24.3
quarts)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
349

an automatic transmission application requiring MERCON  may
cause transmission damage. Use of any fluid other than the
recommended fluid may cause transmission damage. 2
Indicates only approximate dry-fill capacity. Some applications may vary
based on cooler size and if equipped with an in-tank cooler. The amount
of transmission fluid and fluid level should be set by the indication on
the dipstick ’ s normal operating range.3
Add the coolant type originally equipped in your vehicle. 4
Your vehicle ’ s rear axle is filled with a synthetic rear axle lubricant and
is considered lubricated for life. These lubricants are not to be checked
or changed unless a leak is suspected, service is required or the axle has
been submerged in water. The axle lubricant should be changed any time
the axle has been submerged in water.
Service refill capacities are determined by filling the rear axle 23mm (0.9
inch) below the bottom of the filler hole. 5
Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent
meeting Ford specification EST-M2C118 – A for complete refill of Limited
Slip axles. For complete refills, fill using the Additive Friction Modifier
first. 6
Use of synthetic or synthetic blend motor oil is not mandatory. Engine
oil need only meet the requirements of Ford specification
WSS-M2C153 – H and the API Certification mark.
LUBRICANT SPECIFICATIONS
Item Ford part
name Ford part
number Ford
specification
Hinges, latches,
striker plates
and rotors, seat
tracks, fuel filler
door hinge and
spring Multi-Purpose
Grease XG-4 or XL-5 ESR-M1C159-A
or ESB-M1C93-B
Lock cylinders Penetrating and
Lock Lubricant Motorcraft XL-1 ESB-M2C75-B
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
351

Item Ford part
name Ford part
number Ford
specification
Brake fluid Motorcraft High
Performance
DOT 3 Motor
Vehicle Brake
Fluid PM-1 ESA-M6C25-A
and DOT 3
Driveshaft, slip
spline, double
Cardan joint
center ball Premium Long
Life Grease XG-1-C or
XG-1-K ESA-M1C75 – B
Engine coolant Motorcraft
Premium Gold
Engine Coolant
(yellow-colored) VC-7 – A WSS-M97B51-A1
Engine oil Motorcraft SAE
5W-20 Premium
Synthetic Blend
Motor Oil
Motorcraft SAE
5W-20 Super
Premium Motor
Oil (Canada) XO-5W20-QSP
(US)
CXO-5W20 – LSP12
(Canada) WSS-M2C153-H
and API
Certification Mark
4x4 front wheel
bearings, 4x4
spindle needle
bearings, spindle
thrust bearings
& front drive
axle u-joint/slip
spline High
Temperature
4x4 Front Axle
& Wheel Bearing
Grease E8TZ-19590-A ESA-M1C198-A
Automatic
transmission 1
Motorcraft
MERCON  AT F XT-2-QDX MERCON
Power steering
fluid Motorcraft
MERCON  AT F XT-2-QDX MERCON
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
352

A
ABS (see Brakes) .....................221
Accessory delay ........................122
Air bag supplemental restraint
system ................................195, 199
and child safety seats ............197
description ......................195, 199
disposal ....................................202
driver air bag ..................197, 200
indicator light .................199, 202
operation .........................197, 200
passenger air bag ...........197, 200
side air bag ..............................199
Air cleaner filter ...............332, 348
Air conditioning
auxiliary heater and air
conditioner ................................97
Air suspension ...........................225
description ..............................225
Antifreeze
(see Engine coolant) ................313
Anti-lock brake system
(see Brakes) ......................221 – 222
Audio system (see Radio) ...16, 21
Automatic transmission
driving an automatic
overdrive .................................233
fluid, adding ............................330
fluid, checking ........................330
fluid, refill capacities ..............349
fluid, specification ..................354
Auxiliary power point ...............118
Axle
lubricant specifications ..351, 354
refill capacities ........................349
B
Battery .......................................311 acid, treating emergencies .....311
jumping a disabled battery ....282
maintenance-free ....................311
replacement, specifications ...348
servicing ..................................311
BeltMinder .................................191
Brakes ........................................221
anti-lock ...........................221 – 222
anti-lock brake system (ABS)
warning light ...........................222
fluid, checking and adding ....329
fluid, refill capacities ..............349
fluid, specifications .........351, 354
lubricant specifications ..351, 354
parking ....................................223
shift interlock ..........................231
Bulbs ..........................................103
C
Calculating load ........................254
Capacities for refilling fluids ....349
Cassette tape player ...................21
CD-single premium .....................16
Cell phone use ..........................148
Certification Label ....................356
Changing a tire .........................275
Child safety restraints ..............203
child safety belts ....................203
Child safety seats ......................206
in front seat ............................208
in rear seat ..............................208
Cleaning your vehicle
engine compartment ..............300
instrument panel ....................302
interior .............................302 – 303
interior trim ............................303
plastic parts ............................301
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Index
Index
361

safety belts ..............................302
washing ....................................299
waxing .....................................299
wheels ......................................300
wiper blades ............................301
Clock ..........................................117
Compass, electronic
set zone adjustment ...............138
Console ......................................148
overhead ..........................114 – 116
rear ..........................................149
Controls
power seat ...............................170
steering column ......................129
Coolant
checking and adding ..............313
refill capacities ................317, 349
specifications ..................351, 354
Cruise control
(see Speed control) ..................126
Customer Assistance ................262
Ford accessories for your
vehicle .....................................304
Ford Extended Service
Plan ..........................................292
Getting assistance outside the
U.S. and Canada .....................296
Getting roadside assistance ...262
Getting the service you
need .........................................290
Ordering additional owner ’ s
literature .................................297
The Dispute Settlement
Board .......................................292
Utilizing the
Mediation/Arbitration
Program ...................................295 D
Daytime running lamps
(see Lamps) ..............................100
Defrost
rear window ..............................98
Dipstick
automatic transmission
fluid ..........................................330
engine oil .................................308
Doors
lubricant specifications ..........351
Driveline universal joint and
slip yoke ....................................332
Driving under special
conditions ..................238, 245, 248
sand .........................................247
snow and ice ...........................249
through water .................247, 251
E
Electronic message center .......136
Emergencies, roadside
jump-starting ..........................282
Emission control system ..........326
Engine ........................................354
cleaning ...................................300
coolant .....................................313
fail-safe coolant ......................317
idle speed control ...................311
lubrication
specifications ..................351, 354
refill capacities ........................349
service points ..........................307
starting after a collision .........263
Engine block heater .................220
Engine oil ..................................308
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Index
362
