an automatic transmission application requiring MERCON  may
cause transmission damage. Use of any fluid other than the
recommended fluid may cause transmission damage. 2
Indicates only approximate dry-fill capacity. Some applications may vary
based on cooler size and if equipped with an in-tank cooler. The amount
of transmission fluid and fluid level should be set by the indication on
the dipstick ’ s normal operating range.3
Add the coolant type originally equipped in your vehicle. 4
Your vehicle ’ s rear axle is filled with a synthetic rear axle lubricant and
is considered lubricated for life. These lubricants are not to be checked
or changed unless a leak is suspected, service is required or the axle has
been submerged in water. The axle lubricant should be changed any time
the axle has been submerged in water.
Service refill capacities are determined by filling the rear axle 23mm (0.9
inch) below the bottom of the filler hole. 5
Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent
meeting Ford specification EST-M2C118 – A for complete refill of Limited
Slip axles. For complete refills, fill using the Additive Friction Modifier
first. 6
Use of synthetic or synthetic blend motor oil is not mandatory. Engine
oil need only meet the requirements of Ford specification
WSS-M2C153 – H and the API Certification mark.
LUBRICANT SPECIFICATIONS
Item Ford part
name Ford part
number Ford
specification
Hinges, latches,
striker plates
and rotors, seat
tracks, fuel filler
door hinge and
spring Multi-Purpose
Grease XG-4 or XL-5 ESR-M1C159-A
or ESB-M1C93-B
Lock cylinders Penetrating and
Lock Lubricant Motorcraft XL-1 ESB-M2C75-B
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
351

Item Ford part
name Ford part
number Ford
specification
Brake fluid Motorcraft High
Performance
DOT 3 Motor
Vehicle Brake
Fluid PM-1 ESA-M6C25-A
and DOT 3
Driveshaft, slip
spline, double
Cardan joint
center ball Premium Long
Life Grease XG-1-C or
XG-1-K ESA-M1C75 – B
Engine coolant Motorcraft
Premium Gold
Engine Coolant
(yellow-colored) VC-7 – A WSS-M97B51-A1
Engine oil Motorcraft SAE
5W-20 Premium
Synthetic Blend
Motor Oil
Motorcraft SAE
5W-20 Super
Premium Motor
Oil (Canada) XO-5W20-QSP
(US)
CXO-5W20 – LSP12
(Canada) WSS-M2C153-H
and API
Certification Mark
4x4 front wheel
bearings, 4x4
spindle needle
bearings, spindle
thrust bearings
& front drive
axle u-joint/slip
spline High
Temperature
4x4 Front Axle
& Wheel Bearing
Grease E8TZ-19590-A ESA-M1C198-A
Automatic
transmission 1
Motorcraft
MERCON  AT F XT-2-QDX MERCON
Power steering
fluid Motorcraft
MERCON  AT F XT-2-QDX MERCON
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
352

Item Ford part
name Ford part
number Ford
specification
Rear axle Motorcraft SAE
75W-90 Fuel
Efficient High
Performance
Synthetic Rear
Axle Lube XY-75W90 – QFEHP meets API GL-5
Motorcraft SAE
75W-140 High
Performance
Synthetic Rear
Axle Lube 2
XY-75W140 – QL WSL-M2C192-A
Front axle
(4X4) Motorcraft SAE
75W-90 Fuel
Efficient High
Performance
Synthetic Rear
Axle Lube XY-75W90 – QFEHP meets API GL-5
Transfer case
(4X4) Motorcraft
MERCON  AT F XT-2-QDX MERCON
Windshield
washer fluid Motorcraft
Premium
Windshield
Washer
Concentrate ZC-32 – A WSB-M8B16 – A21
Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. Check the container to verify the fluid being added is of the
correct type. Refer to your scheduled maintenance guide to determine
the correct service interval.
Some transmission fluids may be labeled as dual usage, such as
MERCON  and MERCON  V. These dual usage fluids are not to be used
in an automatic transmission that requires use of the MERCON  type
fluid. However, these dual usage fluids may be used in transmissions that
require the MERCON  V type fluid.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
353

MERCON  and MERCON  V type fluids are not interchangeable.
DO NOT mix MERCON  and MERCON  V. Use of a transmission
fluid that indicates dual usage (MERCON  and MERCON  V) in
an automatic transmission application requiring MERCON  may
cause transmission damage. Use of any fluid other than the
recommended fluid may cause transmission damage. 2
Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent
meeting Ford specification EST-M2C118-A for complete refill of Ford
Limited Slip rear axles.
ENGINE DATA
Engine 5.4L 4V V8 engine
Cubic inches 330
Required fuel 91 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-0.056 inch)
Ignition system Coil on plug
Compression ratio 9.5:1
VEHICLE DIMENSIONS
Vehicle dimensions 4x2 and 4x4 mm (in)
(1) Overall length 5232.0 (206)
(2) Vehicle width
(Body) 2000.0 (78.7)
(2) Vehicle width
with power running boards,
mirrors folded 2029 (79.9)
(2) Vehicle width
with fixed running boards 2088 (82.2)
(3) Overall height 1975.0 (77.8)
(4) Wheelbase 3018.0 (118.8)
(5) Track - Front 1701.0 (67.0)
(5) Track - Rear 1704.0 (67.1)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
354

2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
355

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety
Administration Regulations require
that a Certification label be affixed
to a vehicle and prescribe where the
Certification label may be located.
The Certification label is located on
the front door latch pillar on the
driver ’ s side.
Vehicle identification number (VIN)
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel. (Please note that
in the graphic XXXX is
representative of your vehicle
identification number.)
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block and transmission. XXXXXXXXXXXXXXXXX
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
356

Transmission/Transaxle code designations
You can find a transmission/transaxle code on the vehicle certification
label which is located on the door pillar. The following table tells you
which transmission or transaxle each code represents.
Truck application:
Code Transmission Description
Manual transmission
M Manual 5 – speed overdrive (Mazda R2)
C Manual 5 – speed overdrive (Close ratio)
W Manual 5 – speed overdrive (Dana ZF)
G Manual 6 – speed ZF
Automatic transmission
U Automatic 4 – speed overdrive (4R70W)
T Automatic 4 – speed overdrive (4R44E)
E Automatic 4 – speed overdrive (4R100)
J Automatic 5 – speed overdrive (5R55E)
Electric
H One speed electric
D Automatic 5 – speed overdrive (5R44E)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Maintenance and Specifications
357

Code Transmission Description
R Automatic 5 – speed overdrive (5R55S)
Passenger car application:
Code Transmission/Transaxle Description
Front wheel drive manual transaxle
R5 – speed overdrive (MTX75)
W5 – speed overdrive (M5)
Front wheel drive automatic transaxle
E4 – speed overdrive (4FE)
J3 – speed (Mazda)
L4 – speed overdrive (AX4S)
P4 – speed overdrive (4F20E)
X4 – speed overdrive (4F50N)
Y4 – speed overdrive (CD4E)
Rear wheel drive manual transaxle
55 – speed (Mazda M5)
Rear wheel drive automatic transmission
U4 – speed overdrive (4R70W)
A5 – speed overdrive (5R55N)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Maintenance and Specifications
358

LINCOLN ACCESSORIES FOR YOUR VEHICLE
A wide selection of genuine Lincoln accessories are available for your
vehicle through your local authorized Lincoln or Ford of Canada dealer.
These quality accessories have been specifically engineered to fulfill your
automotive needs; they are custom designed to complement the style
and aerodynamic appearance of your vehicle. In addition, each accessory
is made from high quality materials and meets or exceeds Lincoln ’ s
rigorous engineering and safety specifications. Ford Motor Company will
repair or replace any properly dealer-installed Lincoln accessory found to
be defective in factory-supplied materials or workmanship during the
warranty period, as well as any component damaged by the defective
accessory. The accessory will be warranted for whichever provides you
the greatest benefit:
• 12 months or 20,000 km (12,000 miles) (whichever occurs first), or
• the remainder of your new vehicle limited warranty.
This means that genuine Lincoln accessories purchased along with your
new vehicle and installed by the dealer are covered for the full length of
your New Vehicle ’ s Limited Warranty — 3 years or 60,000 km (36,000
miles) (whichever occurs first). Contact your dealer for details and a
copy of the warranty.
Not all accessories are available for all models.
Following is a list of several Lincoln Genuine Accessory products. Not all
accessories are available for all models. To find out what accessories are
available for your vehicle, please contact your dealer or visit our online
store at: www.lincolnaccessories.com.
Exterior style
Bug shields
Deflectors
Front end covers
Headlamps, fog lights and Daytime Running Lamps (DRLS)
Splash guards
Wheels
Interior style
Floor mats
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Accessories
Accessories
359

Lifestyle
Bike racks
Cargo organization and management
Engine block heaters and blankets
Rear seat entertainment systems
Trailer hitches, wiring harnesses and accessories
Peace of mind
Airbag anti-theft locks
First aid and safety kits
Full vehicle covers
Locking gas cap
Remote start
Vehicle security systems
For maximum vehicle performance, keep the following information in
mind when adding accessories or equipment to your vehicle:
• When adding accessories, equipment, passengers and luggage to your
vehicle, do not exceed the total weight capacity of the vehicle or of
the front or rear axle (GVWR or GAWR as indicated on the Safety
Compliance Certification label). Consult your dealer for specific weight
information.
• The Federal Communications Commission (FCC) and Canadian Radio
Telecommunications Commission (CRTC) regulate the use of mobile
communications systems — such as two-way radios, telephones and
theft alarms - that are equipped with radio transmitters. Any such
equipment installed in your vehicle should comply with FCC or CRTC
regulations and should be installed only by a qualified service
technician.
• Mobile communications systems may harm the operation of your
vehicle, particularly if they are not properly designed for automotive
use.
