relay LINCOLN NAVIGATOR 2004 Owners Manual

Seating and Safety Restraints 169Seating 169
Safety restraints 183
Air bags 195
Child restraints 203
Driving 217Starting 217
Brakes 221
Air suspension 225
Transmission operation 231
Vehicle loading 252
Trailer towing 254
Roadside Emergencies 262Getting roadside assistance 262
Hazard flasher switch 263
Fuel pump shut-off switch 263
Fuses and relays 265
Changing tires 275
Jump starting 282
Wrecker towing 288
Customer Assistance 290Reporting safety defects (U.S. only) 298
Cleaning 299
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Table of Contents
2

Do not alter or modify your vehicle ’ s suspension or steering; the
resulting changes to the vehicle ’ s handling can adversely affect
the Roll Stability Control system. Also, do not install a stereo
loudspeaker near the front center console or under either front
seat. The speaker vibrations can adversely affect the Roll
Stability Control sensors located in this area.
Note: Pressing the Roll Stability Control button will disable the Roll
Stability Control.
Aggressive driving in any road conditions can cause you to lose
control of your vehicle increasing the risk of severe personal
injury or property damage. The occurrence of an Roll Stability Control
event is an indication that at least some of the tires have exceeded
their ability to grip the road; this may lead to an increased risk of loss
of vehicle control, vehicle rollover, personal injury and death. If you
experience a severe road event, SLOW DOWN.
AUTOMATIC TRANSMISSION OPERATION
Brake-shift interlock
This vehicle is equipped with a brake-shift interlock feature that prevents
the gearshift lever from being moved from P (Park) when the ignition is
in the ON position unless brake pedal is depressed.
If you cannot move the gearshift lever out of P (Park) with ignition in
the ON position and the brake pedal depressed, it is possible that a fuse
has blown or the vehicle ’ s brakelamps are not operating properly. Refer
to Fuses and relays in the Roadside emergencies chapter.
If the fuse is not blown, perform the following procedure:
1. Apply the parking brake, turn the ignition to LOCK, then remove the
key.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Driving
231

The fuel pump shut-off switch has a
red reset button on top of it and is
located beneath the air suspension
switch (if equipped). If the vehicle
is not equipped with air suspension,
the fuel pump shut-off switch ’ s red
reset button will still be visible
behind this access panel.
Use the following procedure to reset the fuel pump shut-off switch.
1. Turn the ignition to the OFF position.
2. Check the fuel system for leaks.
3. If no fuel leak is apparent, reset the fuel pump shut-off switch by
pushing in on the reset button.
4. Turn the ignition to the ON position. Pause for a few seconds and
return the key to the OFF position.
5. Make a further check for leaks in the fuel system.
FUSES AND RELAYS
Fuses
If electrical components in the
vehicle are not working, a fuse may
have blown. Blown fuses are
identified by a broken wire within
the fuse. Check the appropriate
fuses before replacing any electrical
components. 15
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
265

The fuses are coded as follows.
Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
1 10A* Run/Accessory - Instrument cluster, Front
wiper motor, Rear wiper motor, Tire
Pressure Monitor System (TPMS) module
2 20A* Brake On/Off (stoplamp) switch, Turn
signal/Hazard flasher, AdvanceTrac

stoplamps relay, Stoplamps, Center
High-Mounted Stoplamp (CHMSL), Turn
signal lamps
3 7.5A* Power mirror switch, Memory module (logic
power), Driver seat switch (memory)
4 15A* Rear seat audio controls, Navigation module,
DVD player
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
268

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
5 7.5A* Brake On/Off (stoplamp) switch, Powertrain
Control Module (PCM) (keep alive power),
EATC control head, Body Security Module
(BSM) (keep alive power), Speed control
deactivation switch, Speed control servo,
SecuriLock LED, 3rd row seat relay coils,
Power liftgate module, Clock, Brake Shift
Interlock (BSI) solenoid
6 15A* Headlamp switch (parklamps and switch
backlighting feed), Parklamps, License
lamps, Foglamp relay coil, Trailer tow
electric brake controller (illumination), BSM
(autolamp parklamps), Floor console gear
selector lighting, Switch backlighting
module, Foglamp indicator
7 7.5A* Radio (Start signal)
8 10A* Rear window defroster switch, Heated
outside mirrors, Rear window defroster
indicator (climate control head)
9 — Not used
10 20A* Trailer tow back-up lamps relay, Trailer tow
7 – wire connector (back-up lamps), Trailer
tow parklamps relay, Trailer tow 7 – and
4 – wire connectors (parklamps)
11 10A* A/C compressor clutch relay, A/C
compressor clutch solenoid, Air suspension
compressor relay, 4x4 Integrated Wheel
Ends (IWE) solenoid
12 10A* Speed control relay, Speed control servo
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
269

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
13 10A* Rear window defroster relay coil, A/C
refrigerant containment switch, A/C
compressor thermistor, DEATC control
head, DEATC solenoids, DEATC blower
controller, Trailer tow battery charge relay
coil
14 10A* Daytime Running Lamps (DRL) ignition
relay coil, Digital Transmission Range Sensor
(DTRS back-up lamps), Trailer tow back-up
lamps relay coil, Elctrochromatic mirror
15 5A* AdvanceTrac
switch, Instrument cluster
(Run/Start feed)
16 10A* ABS/AdvanceTrac
module (Run/Start
feed)
17 15A* Foglamps
18 10A* Auxiliary A/C temperature blend door
actuator, Auxiliary A/C front auxiliary
control, Park brake release relay coils, Turn
signal flasher, Electrochromatic mirror,
Auxiliary mode motor, Climate controlled
seat modules
19 10A* Restraints Control Module (RCM)
20 30A* 4x4 module, Air suspension module (air
spring solenoids and height sensors)
21 15A* Instrument cluster (B+), Interior (courtesy)
lamps, TPMS module, Park brake release
relays, Park brake release motor, Puddle
lamps (outside mirrors)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
270

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
22 10A* Moonroof switch illumination, Flip window
switch, Flip window relays, Flip window
motors, Electronic Hidden Antenna Module
(EHAM) antenna amplifier (navigation
radio), Radio (delayed accessory feed), Left
front window motor, Navigation radio
amplifier
23 10A* RH low beam
24 15A* Interior demand lamps (front map/dome
lamps, glove compartment lamp, cargo lamp,
roof rail lamps, vanity mirror lamps),
Battery saver relay coil, Battery saver relay
power
25 10A* LH low beam
26 20A* Horn relay, Horns
27 5A* BSI solenoid, Overdrive cancel switch,
Reverse park aid system module, Air
suspension module (Run/Start), Compass
module
28 5A* PCM relay coil, Speed control relay coil,
SecuriLock transceiver
29 30A* Trailer tow electric brake controller, Trailer
tow 7 – wire connector (electric brake)
30 30A* BSM (door locks, liftgate glass release
relay), Liftgate glass release motor, Left
front window motor, Door/Liftgate lock
motors
31 20A* Radio (B+), Subwoofer, Navigation radio
audio amplifier
32 15A* Catalyst Monitor Sensors (CMS),
Transmission solenoids
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
271

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
33 20A* HEGO sensors, EGR vacuum regulator
(EVR) solenoid, Intake Manifold Tuning
valve (IMTV) solenoid, Canister vent
solenoid, Vapor Management valve (VMV)
solenoid, A/C compressor clutch relay coil
34 20A* PCM, Idle Air Control (IAC) solenoid, Mass
Air Flow (MAF) sensor, Fuel injectors, Fuel
pump relay, Fuel pump shut-off switch, Fuel
pump motor
35 20A* High beam headlamps, Instrument cluster
high beam indicator
36 10A* Trailer tow right turn/stop lamps
37 20A* Cargo area power point
38 25A* Rear wiper motor, Washer pump (rear
window wash)
39 20A* Console power points
40 20A* DRL relays, DRL foglamps, DRL headlamp
relay coil, Headlamp switch (headlamps),
Multifunction switch (flash-to-pass), BSM
(autolamp headlamps relay), High beam
relay coil, Fuse 25 (LH low beam), Fuse 23
(RH low beam)
41 20A* Cigar lighter, OBD II diagnostic connector
42 10A* Trailer tow left turn/stop lamps
101 30A** Starter motor relay, Starter motor solenoid
102 30A** Ignition switch power
103 30A** ABS/AdvanceTrac
module (pump motor)
104 30A** LH 3rd row seat relay, LH 3rd row seat
switch, LH 3rd row seat motor
105 30A** Power liftgate module, Power liftgate
motors, Power running boards control
106 30A** Trailer tow battery charge relay, Trailer tow
7 – wire connector (battery charge)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
272

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
107 30A** Auxiliary A/C blower relay, Auxiliary A/C
blower motor
108 30A** Passenger seat motor switch, Passenger seat
lumbar switch and motor
109 30A** Driver seat lumbar switch and motor,
Memory module, Power memory mirrors,
Adjustable pedals switch and motor
110 30A** Power running boards
111 50A** Air suspension compressor relay, Air
suspension compressor
112 30A** ABS/AdvanceTrac
module (valves)
113 30A** Front wiper motor, Washer pump
(windshield wash)
114 40A** Rear window defroster relay, Rear window
defroster grid, Heated mirrors (Fuse 8)
115 30A** 4x4 module, Transfer case shift motor
116 40A** Front blower motor relay, Front blower
motor
117 30A** RH 3rd row seat relay, RH 3rd row seat
switch, RH 3rd row seat motor
118 30A** Driver and passenger climate control seat
module
401 30A** Power windows (circuit breaker), Main
window switch, Window motors, Window
switches, Moonroof module
R01 Starter relay Starter motor solenoid
R02 Delayed
accessory
relay Fuse 22, CB 401, Power windows, Moonroof,
Flip windows, Radio, DVD, Navigation radio
amplifier, Navigation antenna amplifier
R03 Hi-beam
relay Fuse 35, Hi-beam headlamps, Hi-beam
indicator
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
273

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
R04 Rear window
defrost relay Fuse 8 (heated mirrors), Rear window
defroster, Heated outside mirrors, Rear
window defroster indicator (climate control
head)
R05 Trailer tow
battery
charge relay Trailer tow 7 – wire connector (battery
charge)
R06 Front blower
relay Front blower motor
R201 Trailer tow
park lamp
relay Trailer tow 7 – and 4 – wire connectors (park
lamps)
R202 Foglamp
relay Front foglamps
R203 PCM relay Fuse 32, Fuse 33, Fuse 34, Fuel pump relay,
Fuel pump, PCM solenoids and sensors
R301 Trailer tow
back-up lamp
relay Trailer tow 7 – wire connector (back-up
lamps)
R302 Speed
control relay Speed control servo
R303 Fuel pump
relay Fuel pump shut-off switch, PCM (fuel pump
monitor), Fuel pump
R304 Battery saver
relay Roof rail lamps, Vanity mirror lamps,
Map/Dome lamp, Glove box lamp, Cargo
area lamp, Outside mirror puddle lamps,
Instrument cluster (interior lamps)
R305 Horn relay Dual note horn
* Mini Fuses ** Maxi Fuses
Note: Relays R301 – R305 are not serviceable components; see your
dealer or a qualified technician for assistance.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
274
