Page 9 of 586
![MAZDA MODEL 3 4-DOOR 2014 Owners Manual 1–3
Pictorial Index
Interior Overview
Interior Equipment (View B)
Audio control switches..................................................\
........................................ page 5-](/img/28/41000/w960_41000-8.png "MAZDA MODEL 3 4-DOOR 2014 Owners Manual 1–3
Pictorial Index
Interior Overview
Interior Equipment (View B)
Audio control switches..................................................\
........................................ page 5-")
1–3
Pictorial Index
Interior Overview
Interior Equipment (View B)
Audio control switches..................................................\
........................................ page 5-58
SRS air bags ........................................................................\
.................................. page 2-40
Cruise control switches ........................................................................\
......page 4-100 , 4-95
Steering shift switches ........................................................................\
.................. page 4-33
Climate control system..................................................\
.......................................... page 5-2
Audio system............................................................\
............................................. page 5-16
Navigation system (if equipped) ............................................. Refer to the separate manual
Seat warmer switches ........................................................................\
...................... page 2-7
Rear window defroster switch............................................\
................................... page 4-56
CD player ........................................................................\
...................................... page 5-54
Manual transaxle shift lever ........................................................................\
.......... page 4-27
Automatic transaxle selector lever ........................................................................\
page 4-30
Drive selection switch ........................................................................\
................... page 4-89
Lock release lever ........................................................................\
......................... page 3-32
Hood release handle ........................................................................\
...................... page 6-24
Remote fuel-fi ller lid release ........................................................................\
......... page 3-30
Trunk release button ........................................................................\
...................... page 3-22
The equipment and installation position varies by vehicle
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 127 of 586
*Some models.4–1
4When Driving
Information concerning safe driving and stopping.
Start/Stop Engine ................................ 4-4 Ignition Switch ............................... 4-4
Starting the Engine ......................... 4-5
Turning the Engine Off ................ 4-10
Instrument Cluster and Display ...... 4-12 Meters and Gauges ....................... 4-12
Active Driving Display
* ............... 4-19
Warning/Indicator Lights ............. 4-21
Transaxle ............................................ 4-27 Manual Transaxle Operation ........ 4-27
Automatic Transaxle Controls ...... 4-30
Switches and Controls ...................... 4-41 Lighting Control ........................... 4-41
High Beam Control System
(HBC)
* ......................................... 4-48
Fog Lights* ................................... 4-51
Turn and Lane-Change Signals ...... 4-51
Windshield Wipers and Washer ...... 4-52
Rear Window Wiper and
Washer
* ........................................ 4-56
Rear Window Defroster ............... 4-56
Horn ............................................. 4-58
Hazard Warning Flasher ............... 4-58
HomeLink Wireless Control
System
* ......................................... 4-59
Forward Sensing Camera ................. 4-63 Forward Sensing Camera
* ............ 4-63
Radar Sensor ..................................... 4-65 Radar Sensor ................................ 4-65 Brake .................................................. 4-68
Brake System ............................... 4-68
Hill Launch Assist (HLA) ............ 4-70
Smart City Brake Support
(SCBS)
* ........................................ 4-72
ABS/TCS/DSC ................................... 4-79
Antilock Brake System (ABS) ...... 4-79
Traction Control System (TCS) ...... 4-80
Dynamic Stability Control
(DSC) ........................................... 4-81
i-ELOOP ............................................ 4-83 i-ELOOP
* ..................................... 4-83
Fuel Economy Monitor ..................... 4-86 Fuel Economy Monitor
* ............... 4-86
Drive Selection ................................... 4-88 Drive Selection
* ........................... 4-88
Power Steering................................... 4-90 Power Steering ............................. 4-90
Mazda Radar Cruise Control
(MRCC) ............................................. 4-91 Mazda Radar Cruise Control
(MRCC) ....................................... 4-91
Cruise Control ................................. 4-100 Cruise Control
* ........................... 4-100
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 138 of 586
4–12
When Driving
Instrument Cluster and Display
Meters and Gauges
Type A
Type B
Type C
Steering Switch (Digital Speed Meter Type)
(Analog Speed Meter Type (With Tachometer))
(Analog Speed Meter Type (Without Tachometer))
Some models.
Instrument Cluster
Speedometer ........................................................................\
.................................. page
4-13
Odometer, Trip Meter and Trip Meter Selector .................................................... page 4-13
Tachometer ........................................................................\
.................................... page 4-14
Fuel Gauge ........................................................................\
.................................... page 4-15
Dashboard Illumination..................................................\
....................................... page 4-16
Outside Temperature Display ........................................................................\
........ page 4-16
Cruise Control Set Vehicle Speed Display ............................................................ page 4-17
Active Driving Display ........................................................................\
................. page 4-19
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 143 of 586
*Some models.4–17
When Driving
Instrument Cluster and Display
1. Press the INFO button with the ignition switched off and continue pressing the
INFO button for 5 seconds or longer
while switching the ignition ON. The
outside temperature display fl ashes.
2. Press the up
or down part of the
INFO switch to change the outside
temperature unit.
3. Press and hold the INFO button for 3 seconds or longer while the outside
temperature display is fl ashing. The
outside temperature display illuminates.
Cruise Control Set Vehicle Speed Display*
The vehicle speed preset using the cruise
control is displayed.
Trip Computer and INFO Switch *
The following information can be selected
by pressing the up
or down part of the
INFO switch with the ignition switched
ON.
y Approximate distance you can travel on
the available fuel
y Average fuel economy y Current fuel economy y Average vehicle speed
If you have any problems with your trip
computer, consult an Authorized Mazda
Dealer.
Distance-to-empty mode
This mode displays the approximate
distance you can travel on the remaining
fuel based on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.
NOTE
y Even though the distance-to-empty
display may indicate a suffi cient
amount of remaining driving distance
before refueling is required, refuel
as soon as possible if the fuel level is
very low or the low fuel warning light
illuminates.
y The display may not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
y The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
(indicating the remaining fuel supply)
disappear.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 146 of 586
4–20
When Driving
Instrument Cluster and Display
The active driving display indicates the following information:
y Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control (MRCC) on page 4-91 . y Lane Departure Warning System (LDWS) Operation Conditions and Warnings Refer to Lane Departure Warning System (LDWS) on page 4-119 . y Smart City Brake Support (SCBS) Operation Conditions and Warnings Refer to Smart City Brake Support (SCBS) on page 4-72 . y Forward Obstruction Warning (FOW) Operation Conditions and Warnings Refer to Forward Obstruction Warning (FOW) on page 4-116 . y Vehicle Speed Setting Using Cruise Control Refer to Cruise Control on page 4-100 . y Turn-by-Turn (TBT) (Direction and Distance) and Lane Guidance y Vehicle Speed
Each setting/adjustment for the active driving display can be performed \
on the Type B audio
display.
1. Select the (
) icon on the home screen and display the Settings screen.
2. Select the AD-Disp tab.
3. Select the desired item and perform the setting/adjustment.
y Height : Active driving display position y Brightness Control : Method for adjusting screen brightness (Automatically/Manually) y Calibration : Brightness initialization setting (when selecting automatic adjustment\
) y Brightness : Brightness adjustment (when selecting manual adjustment) y Navigation : On/Off y Active Driving Display : On/Off y Reset
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 149 of 586
*Some models.4–23
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light 7-24
(Red)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Warning Light *1 4-78 ,
4-118
(Amber)
* Lane Departure Warning System (LDWS) Warning Light *1*3 7-24
(Amber)
* High Beam Control System (HBC) Warning Light *1 7-24
(Amber)
* Mazda Radar Cruise Control (MRCC) Warning Light *1 7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
*3 The light turns on when the system on stand-by. The light fl ashes when the system has a malfunction.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 151 of 586
*Some models.4–25
When Driving
Instrument Cluster and Display
Signal Indicator Lights Page
* Shift Position Indication 4-31
* SPORT Mode Indicator Light 4-89
Headlight High-Beam Indicator Light 4-45 ,
4-45
Turn Signal/Hazard Warning Indicator Lights 4-51 ,
4-58
Security Indicator Light *1 3-42
(Green)
* Mazda Radar Cruise Control (MRCC) Indicator Light 4-95
(Amber)
* Cruise Main Indicator Light 4-101
(Green)
* Cruise Set Indicator Light 4-101
Lights-On Indicator Light 4-41
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 191 of 586
4–65
When Driving
Radar Sensor
Radar Sensor
Your vehicle is equipped with a radar sensor.
The following systems also use the radar sensor.
y Mazda Radar Cruise Control (MRCC) y Forward Obstruction Warning (FOW)
The radar sensor functions by detecting the radio waves refl ected off a vehicle ahead or an
obstruction sent from the radar sensor.
The radar sensor is mounted behind the front emblem.
Radar Sensor
If the Forward Obstruction Warning (FOW) indicator light (amber) is illuminated, the area
around the radar sensor may be dirty. Refer to “Warning Guidance” in the type B audio
display.
Refer to If a Warning Light Turns On or Flashes on page 7-24 .
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 215 of 586
4–89
When Driving
Drive Selection
Drive Selection Switch
The SPORT mode indicator light in the
instrument cluster is illuminated while in
SPORT mode.
NOTE
y If the SET/ SET Switch of the
Mazda Radar Cruise Control (MRCC)
system/cruise control is pressed while
in SPORT mode, SPORT mode is
automatically switched off.
y When the ignition is switched off,
SPORT mode is also switch off.
y When SPORT mode is selected, the
transaxle may automatically shift down
or the vehicle speed may accelerate
depending on the vehicle speed.
SPORT Mode Indicator Light
Type A
Type B
The light is illuminated while in SPORT
mode.
NOTE
The indicator light fl ashes a few times to
indicate that the mode cannot be switched
to SPORT mode even if the drive select
switch is pressed under the following
conditions:
y The vehicle is driven on a slippery road
surface such as an icy or snow-bound
road.
y The Mazda Radar Cruise Control
(MRCC) system/cruise control is
operating.
y The vehicle is making a turn or driving
on a curved road.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 217 of 586
4–91
When Driving
Mazda Radar Cruise Control (MRCC)
Mazda Radar Cruise Control (MRCC)
The Mazda Radar Cruise Control (MRCC) system is designed to maintain headway control *1
according to the vehicle speed using a radar sensor to detect the distan\
ce to a vehicle ahead,
and by presetting the vehicle speed between 30 km/h (19 mph) and 145 k\
m/h (90 mph) the
driver is freed from having to constantly use the accelerator or brake p\
edals.
*1 Headway Control: Control of the distance between your vehicle and the ve\
hicle ahead detected by the Mazda Radar Cruise Control (MRCC) system.
Additionally, if your vehicle starts closing in on the vehicle ahead because, for ex\
ample, the
vehicle ahead brakes suddenly, a warning sound and a warning indication in the display are
activated simultaneously to alert you to maintain a suffi cient distance between the vehicles.
Use the Mazda Radar Cruise Control (MRCC) system on expressways and ot\
her highways
which do not require a lot of repeated acceleration and deceleration.
WARNING
Do not rely completely on the Mazda Radar Cruise Control (MRCC) system and always
drive carefully: The Mazda Radar Cruise Control (MRCC) system is designed to reduce load on the
driver, and although it maintains a constant vehicle speed, or specifi cally, it maintains
a constant distance between your vehicle and the detected vehicle ahead according to
the vehicle speed, the system has detection limitations depending on the type of vehicle
ahead and its conditions, the weather conditions, and the road conditions. Additionally,
the system may be unable to decelerate suffi ciently to avoid hitting the vehicle ahead
if the vehicle ahead applies the brakes suddenly or another vehicle cuts into the driving
lane, which could result in an accident. Always verify the safety of the surrounding area
and depress the brake pedal or accelerator pedal while keeping a safe distance from
vehicles ahead or on-coming vehicles.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
