washer fluid MAZDA MODEL 3 4-DOOR 2014 Owners Manual

*Some models.4–23
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light 7-24
(Red)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Warning Light *1 4-78 ,
4-118
(Amber)
* Lane Departure Warning System (LDWS) Warning Light *1*3 7-24
(Amber)
* High Beam Control System (HBC) Warning Light *1 7-24
(Amber)
* Mazda Radar Cruise Control (MRCC) Warning Light *1 7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
*3 The light turns on when the system on stand-by. The light fl ashes when the system has a malfunction.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

6–1
6Maintenance and Care
How to keep your Mazda in top condition.


Essential Information ........................................................................\
6-2 Introduction ........................................................................\
........... 6-2
Scheduled Maintenance ..................................................................... 6-4 Scheduled Maintenance (U.S.A., Canada, and Puerto Rico) ........ 6-4
Scheduled Maintenance (Mexico) .............................................. 6-13
Maintenance Monitor .................................................................. 6-20
Owner Maintenance ........................................................................\
. 6-22 Owner Maintenance Precautions ................................................ 6-22
Hood ........................................................................\
.................... 6-24
Engine Compartment Overview ................................................. 6-26
Engine Oil ........................................................................\
........... 6-27
Engine Coolant ........................................................................\
.... 6-29
Brake/Clutch Fluid ...................................................................... 6-31
Washer Fluid ........................................................................\
....... 6-31
Body Lubrication ........................................................................\
6-32
Wiper Blades ........................................................................\
....... 6-33
Battery ........................................................................\
................. 6-37
Battery Replacement ................................................................... 6-39
Tires........................................................................\
..................... 6-41
Light Bulbs ........................................................................\
.......... 6-45
Fuses ........................................................................\
................... 6-58
Appearance Care........................................................................\
...... 6-63 Exterior Care ........................................................................\
....... 6-63
Interior Care ........................................................................\
........ 6-69
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

6–26
Maintenance and Care
Owner Maintenance
Engine Compartment Overview
Windshield washer fluid reservoirBrake/Clutch fluid reservoir
Engine oil dipstick Battery
Fuse block
Cooling system cap Engine coolant reservoir Engine oil-filler cap
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

6–31
Maintenance and Care
Owner Maintenance
Brake/Clutch Fluid
Inspecting Brake/Clutch Fluid Level
WARNING
If the brake/clutch fl uid level is low, have
the brakes inspected: A low brake/clutch fl uid level is
dangerous.
A low level could indicate brake lining
wear or a brake system leak which
could cause the brakes to fail and lead
to an accident.
The brakes and clutch draw fl uid from the
same reservoir.
Inspect the fl uid level in the reservoir
regularly. It should be kept between the
MAX and MIN lines.
The level normally drops with
accumulated distance, a condition
associated with wear of brake and clutch
linings. If it is excessively low, have
the brake/clutch system inspected by an
Authorized Mazda Dealer.
Washer Fluid
Inspecting Washer Fluid Level
WARNING
Use only windshield washer fl uid or
plain water in the reservoir: Using radiator antifreeze as washer
fl uid is dangerous. If sprayed on the
windshield, it will dirty the windshield,
aff ect your visibility, and could result in
an accident.

Using Washer Fluid Without Anti-freeze
Protection in Cold Weather: Operating your vehicle in temperatures
below 4 degrees C (40 degrees F)
using washer fl uid without anti-freeze
protection is dangerous as it could
cause impaired windshield vision and
result in an accident. In cold weather,
always use washer fl uid with anti-
freeze protection.
NOTE
State or local regulations may restrict the
use of volatile organic compounds (VOCs),
which are commonly used as anti-freeze
agents in washer fl uid. A washer fl uid with
limited VOC content should be used only
if it provides adequate freeze resistance
for all regions and climates in which the
vehicle will be operated.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.7–32
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
Low Washer
Fluid Level Warning Light This warning light indicates that little washer
fl
uid remains. Add washer fl
uid (page 6-31 ).
Tire
Pressure
Monitoring System
Warning Light
*
When the warning light illuminates, and the
warning beep sound is heard (about 3 seconds),
tire pressure is too low in one or more tires.
WARNING
If the tire pressure monitoring system
warning light illuminates or fl ashes, or the
tire pressure warning beep sound is heard,
decrease vehicle speed immediately and
avoid sudden maneuvering and braking: If the tire pressure monitoring system
warning light illuminates or fl ashes, or the
tire pressure warning beep sound is heard,
it is dangerous to drive the vehicle at high
speeds, or perform sudden maneuvering
or braking. Vehicle drivability could worsen
and result in an accident.
To determine if you have a slow leak or a
fl at, pull over to a safe position where you
can check the visual condition of the tire
and determine if you have enough air to
proceed to a place where air may be added
and the system monitored again by an
Authorized Mazda Dealer or a tire repair
station.

Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is
dangerous, even if you know why it is
illuminated. Have the problem taken care of
as soon as possible before it develops into
a more serious situation that could lead to
tire failure and a dangerous accident. Inspect the tires and adjust to the specifi
ed
infl ation pressure (page 6-41 ).
NOTE
yPerform tire pressure adjustment when the tires
are cold. Tire pressure will vary according
to the tire temperature, therefore let the
vehicle stand for 1 hour or only drive it 1.6
km (1 mile) or less before adjusting the tire
pressures. When pressure is adjusted on hot
tires to the cold infl ation pressure, the TPMS
warning light/beep may turn on after the tires
cool and pressure drops below specifi cation.
Also, an illuminated TPMS warning light,
resulting from the tire air pressure dropping
due to cold ambient temperature will remain
illuminated even if the ambient temperature
rises. In this case, it will also be necessary
to adjust the tire air pressures. If the TPMS
warning light illuminates due to a drop in tire
air pressure, make sure to check and adjust the
tire air pressures.
yTires lose air naturally over time and the TPMS cannot tell if the tires are getting too
soft over time or you have a fl at. However,
when you fi nd one low tire in a set of four-that
is an indication of trouble; you should have
someone drive the vehicle slowly forward
so you can inspect any low tire for cuts and
any metal objects sticking through tread or
sidewall. Put a few drops of water in the valve
stem to see if it bubbles indicating a bad
valve. Leaks need to be addressed by more
than simply reinfl ating the tire as leaks are
dangerous — take it to an Authorized Mazda
Dealer.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–4
Index
F
Flasher Hazard warning ............................. 4-58
Headlights ..................................... 4-41
Flat Tire ................................................. 7-3 Mounting the Spare Tire................ 7-11
Removing a Flat Tire ....................... 7-7
Floor Mat ............................................ 3-46
Fluid Brake/Clutch ................................. 6-31
Washer ........................................... 6-31
Fluids Classifi cation ................................... 9-4
Fog Lights ........................................... 4-51
Foot Brake ........................................... 4-68
Forward Obstruction Warning
(FOW) ............................................... 4-116 Collision Warning ....................... 4-118
Rader Sensor ............................... 4-118
Forward Sensing Camera .................... 4-63
Front Seat .............................................. 2-5
Fuel Filler lid and cap............................ 3-30
Gauge ............................................ 4-15
Requirements................................. 3-27
Tank capacity .................................. 9-5
Fuel Consumption Display ................. 4-86
Fuel Economy Monitor ....................... 4-86 Control status display .................... 4-87
Ending screen display ................... 4-87
Fuel consumption display ............. 4-86
G
Gauges ................................................. 4-12
Glove Compartment .......................... 5-139
H
Hazard Warning Flasher ...................... 4-58
Hazardous Driving .............................. 3-46
Head Restraint ..................................... 2-10 Headlights
Control........................................... 4-41
Flashing ......................................... 4-45
High-low beam .............................. 4-45
Leveling......................................... 4-45
High Beam Control System (HBC) .... 4-48
Hill Launch Assist (HLA) ................... 4-70
HomeLink Wireless Control System ... 4-59
Hood Release ...................................... 6-24
Horn .................................................... 4-58
I
i-ELOOP ............................................. 4-83 Control status display .................... 4-85
Display .......................................... 4-83
i-ELOOP indicator light ................ 4-85
i-ELOOP warning beep ....................... 7-38
If a Warning Light Turns On or
Flashes................................................. 7-24
If the Active Driving Display (ADD)
does not operate .................................. 7-42
Ignition Switch .............................................. 4-4
Ignition not switched off (STOP)
warning beep ....................................... 7-37
Immobilizer System ............................ 3-41
Indicator Lights ................................... 4-24 AFS OFF ....................................... 4-46
BSM OFF .................................... 4-114
Low engine coolant temperature ... 4-26
Wrench .......................................... 4-26
Inside Trunk Release Lever ................ 3-25
Inspecting Brake/Clutch Fluid Level .. 6-31
Inspecting Coolant Level .................... 6-29
Inspecting Engine Oil Level ............... 6-28
Inspecting Washer Fluid Level............ 6-31
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
