Page 71 of 592
2–59
Essential Safety Equipment
SRS Air Bags
WARNING
Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated
weight on the front passenger seat required for air bag deployment is dangerous. The
front passenger seat weight sensors will detect the reduced total seated weight condition
and the front passenger front and side air bags and seat belt pretensioner system will
not deploy during an accident. The front passenger will not have the supplementary
protection of the air bag, which could result in serious injury. Decreasing the total seated
weight on the front passenger seat could result in an air bag not deploying under the
following conditions, for example:
Page 72 of 592
2–60
Essential Safety Equipment
SRS Air Bags
Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated
weight on the front passenger seat is dangerous. The front passenger seat weight sensors
will detect the increased total seated weight, which could result in the unexpected
deployment of the front passenger front and side air bags and seat belt pretensioner
system in an accident and may cause serious injury. Increasing the total seated weight on
the front passenger seat could result in the front passenger front and side air bags and
seat belt pretensioner system deployment in an accident under the following conditions,
for example:
Page 73 of 592
2–61
Essential Safety Equipment
SRS Air Bags
NOTE
y The system requires about 10 seconds to alternate between turning the front passenger
front and side air bags and seat belt pretensioner system on or off.
y The front passenger air bag deactivation indicator light may illuminate repeatedly if
luggage or other items are put on the front passenger seat, or if the temperature of the
vehicle's interior changes suddenly.
y The front passenger air bag deactivation indicator light may illuminate for 10\
seconds if
the total seated weight on the front passenger seat changes.
y The air bag/front seat belt pretensioner system warning light might illuminate if the front
passenger seat receives a severe impact.
y If the front passenger air bag deactivation indicator light does not illuminate a\
fter
installing a child-restraint system on the front passenger seat, fi rst, re-install your child-
restraint system according to the procedure in this owner's manual. Then, if the front
passenger air bag deactivation indicator light still does not illuminate\
, install the child-
restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as
possible.
y If the front passenger air bag deactivation indicator light illuminates when an a\
dult is
seated in the front passenger seat, have the passenger re-adjust their posture by sitting
with their feet on the fl oor, and then re-fastening the seat belt. If the front passenger air
bag deactivation indicator light still illuminates, move the passenger t\
o the rear seat.
If sitting in the rear seat is not possible, slide the front passenger seat as far back as
possible. Consult an Authorized Mazda Dealer as soon as possible.
Driver and Front Passenger Buckle Switches
The buckle switches on the front seat belts detect whether or not the fr\
ont seat belts are
securely fastened and further control the deployment of the air bags.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 74 of 592
![MAZDA MODEL 3 4-DOOR 2015 Manual PDF 2–62
Essential Safety Equipment
SRS Air Bags
Constant Monitoring
The following components of the air bag systems are monitored by a diagn\
ostic system:
y Crash sensors,](/img/28/40995/w960_40995-73.png "MAZDA MODEL 3 4-DOOR 2015 Manual PDF 2–62
Essential Safety Equipment
SRS Air Bags
Constant Monitoring
The following components of the air bag systems are monitored by a diagn\
ostic system:
y Crash sensors,")
2–62
Essential Safety Equipment
SRS Air Bags
Constant Monitoring
The following components of the air bag systems are monitored by a diagn\
ostic system:
y Crash sensors, and diagnostic module (SAS unit) y Front air bag sensors y Air bag modules y Side crash sensors y Air bag/Front seat belt pretensioner system warning light y Front seat belt pretensioners y Related wiring
(With Front Passenger Occupant Classifi cation System)
y Front passenger air bag deactivation indicator light y Front passenger seat weight sensors y Front passenger seat weight sensor control module y Front passenger seat belt buckle switches
The diagnostic module continuously monitors the system's readiness. This begins when the
ignition is switched ON and continues while the vehicle is being driven.\
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 75 of 592
*Some models.3–1
3Before Driving
Use of various features, including keys, doors, mirrors and windows.
Keys ...................................................... 3-2 Keys ............................................... 3-2
Keyless Entry System .................... 3-3
Advanced Keyless Entry System ........ 3-9
Advanced Keyless Entry
System
* ........................................... 3-9
Operational Range ....................... 3-10
Doors and Locks ................................ 3-11 Door Locks ................................... 3-11
Liftgate/Trunk Lid ........................ 3-20
Inside Trunk Release Lever
(4-Door)
* ...................................... 3-25
Fuel and Emission ............................. 3-27 Fuel and Engine Exhaust
Precautions ................................... 3-27
Fuel-Filler Lid and Cap ................ 3-30
Steering Wheel................................... 3-32 Steering Wheel ............................. 3-32
Mirrors ............................................... 3-33 Mirrors ......................................... 3-33
Windows ............................................. 3-36 Power Windows ........................... 3-36
Moonroof
* ................................... 3-39 Security System ................................. 3-41
Modifi cation and Add-On
Equipment .................................... 3-41
Immobilizer System ..................... 3-41
Theft-Deterrent System
* ............... 3-43
Driving Tips ....................................... 3-45 Break-In Period ............................ 3-45
Saving Fuel and Protection of the
Environment ................................. 3-45
Hazardous Driving ....................... 3-46
Floor Mat ..................................... 3-46
Rocking the Vehicle ..................... 3-47
Winter Driving ............................. 3-47
Driving In Flooded Area .............. 3-49
Overloading .................................. 3-50
Driving on Uneven Road ............. 3-51
Towing ................................................ 3-52 Trailer Towing .............................. 3-52
Recreational Towing .................... 3-52
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 76 of 592
3–2
Before Driving
Keys
Keys
WARNING
Do not leave the key in your vehicle with
children and keep them in a place where
your children will not fi nd or play with
them: Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. Children may fi nd these keys to
be an interesting toy to play with and
could cause the power windows or
other controls to operate, or even make
the vehicle move.
CAUTION
Page 77 of 592
3–3
Before Driving
Keys
NOTE
The driver must carry the key to ensure the
system functions properly.
Auxiliary key
Transmitter
Key code number plate
To use the auxiliary key, pull it out of the
key (transmitter).
Keyless Entry System
This system uses the key buttons to
remotely lock and unlock the doors and
the liftgate, and opens the trunk lid.
The system can start the engine without
having to take the key out of your purse or
pocket.
It can also help you signal for attention.
Operating the theft-deterrent system is
also possible on theft-deterrent system-
equipped vehicles.
Press the buttons slowly and carefully.
System malfunctions or warnings are
indicated by the following warning lights
or beeps.
y KEY Warning Light (Red) Refer to Warning/Indicator Lights on
page 4-20 .
y Ignition Not Switched Off (STOP)
Warning Beep
Refer to Ignition Not Switched Off (STOP) Warning Beep on page 7-36 .
y Key Removed from Vehicle Warning
Beep
Refer to Key Removed from Vehicle Warning Beep on page 7-36 .
If you have a problem with the key,
consult an Authorized Mazda Dealer.
If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to make the
lost or stolen key inoperative.
CAUTION
Radio equipment like this is governed
by laws in the United States.
Changes or modifi cations not expressly
approved by the party responsible
for compliance could void the user's
authority to operate the equipment.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 78 of 592
3–4
Before Driving
Keys
NOTE
y The keyless entry system operation may
vary due to local conditions.
y The keyless entry system is fully
operational (door/liftgate lock/unlock)
when the push button start is switched
off. The system does not operate if the
push button start is switched to any
position other than off.
y If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be dead. To install a new battery,
refer to Replace Electrical Battery
(page 6-39 ).
y Battery life is about one year. Replace
the battery with a new one if the KEY
indicator light (green) fl ashes in the
instrument cluster. Replacing the battery
about once a year is recommended
because the KEY warning light/
indicator light may not illuminate or
fl ash depending on the rate of battery
depletion.
y Additional keys can be obtained at
an Authorized Mazda Dealer. Up to
6 keys can be used with the keyless
functions per vehicle. Bring all keys
to an Authorized Mazda Dealer when
additional keys are required.
Transmitter
Operation buttons
Operation indicator light
NOTE
y
(With theft-deterrent system) The hazard warning lights fl ash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page 3-43 .
y (With the advanced keyless function) A beep sound can be heard for
confi rmation when the doors and
liftgate are locked/unlocked using the
key. If you prefer, the beep sound can be
turned off.
The volume of the beep sound can also be changed.
Refer to Personalization Features on page 9-12 .
Use the following procedure to change the setting.
1. Switch the ignition off and close all of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 79 of 592
3–5
Before Driving
Keys
3. Within 30 seconds of opening the driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.
All of the doors and the liftgate lock and the beep sound activates at the
currently set volume. (If the beep
sound is currently set to not activate,
it will not activate.) The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)
4. The setting change is completed by doing any one of the following:
y Switching the ignition to ACC or
ON.
y Closing the driver's door. y Opening the liftgate/trunk lid. y Not operating the key for 10
seconds.
y Pressing any button except the
LOCK button on the key.
y Pressing a request switch.
The operation indicator light fl ashes when
the buttons are pressed.
Lock button
To lock the doors and the liftgate, press the
lock button and the hazard warning lights
will fl ash once.
(With the advanced keyless function)
A beep sound will be heard once.
To confi rm that all doors and the liftgate
have been locked, press the lock button
again within 5 seconds. If they are closed
and locked, the horn will sound.
NOTE
y The doors and the liftgate can be locked
by pressing the lock button while any
other door or the liftgate/trunk lid is
open. The hazard warning lights will
not fl ash.
When the lock button is pressed while any door is open and then the door is
closed, all the doors and the liftgate are
locked.
y Confi rm that all doors and the liftgate
are locked visually or audibly by use of
the double click.
y Make sure all doors and the liftgate are
locked after pressing the button.
y (With theft-deterrent system) When the doors are locked by pressing
the lock button on the key while the
theft-deterrent system is armed, the
hazard warning lights will fl ash once to
indicate that the system is armed.
Unlock button
To unlock the driver's door, press the
unlock button and the hazard warning
lights will fl ash twice.
(With the advanced keyless function)
A beep sound will be heard twice.
To unlock all doors and the liftgate, press
the unlock button again within 3 seconds
and two more beep sounds will be heard.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 80 of 592
3–6
Before Driving
Keys
NOTE
y The system can be set to unlock all
doors by performing a single operation.
Refer to Personalization Features on page 9-12 .
Use the following procedure to change the setting.
1. Switch the ignition off and close all of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer. The sound of
the doors locking/unlocking can be
heard.
After this, the system switches the setting each time the UNLOCK
button is pressed (the sound of the
doors locking/unlocking can be
heard).
4. The setting change is completed by doing any one of the following:
y Switching the ignition to ACC or
ON.
y Closing the driver's door. y Opening the liftgate/trunk lid. y Not operating the key for 10
seconds.
y Pressing any button except the
UNLOCK button on the key.
y Pressing a request switch.
y (Auto re-lock function) After unlocking with the key, all doors
and the liftgate will automatically lock
if any of the following operations are
not performed within about 60 seconds.
If your vehicle has a theft-deterrent
system, the hazard warning lights will
fl ash for confi rmation.
The time required for the doors to lock automatically can be changed.
Refer to Personalization Features on page 9-12 .
y A door or the liftgate/trunk lid is
opened.
y The push button start is switched to
any position other than off.
y (With theft-deterrent system) When the doors are unlocked by
pressing the unlock button on the key
while the theft-deterrent system is
turned off, the hazard warning lights
will fl ash twice to indicate that the
system is turned off.
Trunk button (4–door)
To open the trunk lid, press and hold the
trunk button until the trunk lid opens.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
