Page 147 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual *Some models.4–21
When Driving
Instrument Cluster and Display
Warning Lights
These lights turn on or ﬂ ash to notify the user of the system operation status or a system
malfunc

Page 166 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual 4–40
When Driving
Switches and Controls
Lighting Control
Headlights
Turn the headlight switch to turn the headlights, other exterior lights and dashboard
illumination

Page 489 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual 7–17
If Trouble Arises
Battery Runs Out
1. Remove the battery cover.
2. Make sure the booster battery is 12 V and that its negative terminal is
grounded.
3. If the booster batte

7–17
If Trouble Arises
Battery Runs Out
1. Remove the battery cover.
2. Make sure the booster battery is 12 V and that its negative terminal is
grounded.
3. If the booster battery is in another vehicle, do not allow both vehicles
to touch. Turn off the engine of the
vehicle with the booster battery and
all unnecessary electrical loads in both
vehicles.
4. Connect the jumper cables in the exact sequence as in the illustration.
y Connect one end of a cable to the positive terminal on the discharged
battery (1).
y Attach the other end to the positive terminal on the booster battery (2).
y Connect one end of the other cable to the negative terminal of the booster
battery (3).
y Connect the other end to the ground point indicated in the illustration away
from the discharged battery (4).
5. Start the engine of the booster vehicle and run it a few minutes. Then start the
engine of the other vehicle. 6. (With i-ELOOP system)
The i-ELOOP indicator light may ﬂ
ash
after the engine is started. The indicator
light turns off when the engine is
running and the charging is completed.
Make sure the i-ELOOP indicator light
is turns off before driving.
NOTE
y If the vehicle is driven with the
i-ELOOP indicator light ﬂ ashing, a
beep sound is heard.
y If the steering wheel is operated with
the i-ELOOP indicator light ﬂ ashing, it
may feel heavier than normal, however,
this does not indicate a malfunction.
The steering operation will return to
normal when the i-ELOOP indicator
light turns off.
y Do not remove the jumper cables while
the i-ELOOP indicator light is ﬂ ashing.
7. When ﬁ nished, carefully disconnect the
cables in the reverse order described in
the illustration.
8. If the battery cover has been removed, install it in the reverse order of
removal.
NOTE
Verify that the covers are securely
installed.
.B[EB@%9&"'@&EJUJPOJOEC.B[EB@%9&"'@&EJUJPOJOEC

Page 497 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual 7–25
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning
Electronic Brake Force
Distribution System Warning If the electronic brake force distribution control unit d

7–25
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning
Electronic Brake Force
Distribution System Warning If the electronic brake force distribution control unit determines that \
some components
are operating incorrectly, the control unit may illuminate the brake system warning
light and the ABS warning light simultaneously. The problem is likely to be the
electronic brake force distribution system.WARNING
Do not drive with both the ABS warning light and brake warning light illuminated.
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes
inspected as soon as possible:
Driving when the brake system warning light and ABS warning light are
illuminated simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an
emergency stop than under normal circumstances.
Charging System Warning Light If the warning light illuminates while driving, it indicates a malfuncti\
on of the
alternator or of the charging system.
Drive to the side of the road and park off the right-of-way. Consult an Authorized
Mazda Dealer.CAUTION
Do not continue driving when the charging system warning light is illuminated
because the engine could stop unexpectedly.
Engine Oil Warning
Light This warning light indicates low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the warning indication is displayed while dr\
iving:
1. Drive to the side of the road and park off the right-of-way on level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil p\
an.
3. Inspect the engine oil level 6-28 . If it's low, add the appropriate amount of engine oil while being careful not to overﬁ ll.
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.
If the light remains illuminated even though the oil level is normal or \
after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
.B[EB@%9&"'@&EJUJPOJOEC.B[EB@%9&"'@&EJUJPOJOEC

Page 505 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual *Some models.7–33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated on Display *
If a message is displayed in the center display (Type B audio), take appro

Page 506 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual 7–34
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Make Sure the Message is No Longer Displayed
Displays in the following cases:
Display Indicated Condition/Action to be t

Page 509 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual *Some models.7–37
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Key Left-in-vehicle Warning Beep (With the advanced keyless
function)
If a key is left in the v

*Some models.7–37
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Key Left-in-vehicle Warning Beep (With the advanced keyless
function)
If a key is left in the vehicle cabin and all
the doors and the trunk are locked using
a separate key, a beep sound is heard for
about 10 seconds to remind the driver
that the key has been left in the vehicle
cabin. If this happens, open the door and
remove the key. A key removed from the
vehicle this way may not function because
its functions may have been temporarily
suspended. Perform the applicable
procedure to restore the functions of the
key (page 3-8 ).
i-ELOOP Warning Beep *
The beep will activate if you attempt to
drive the vehicle under the following
conditions.
y The i-ELOOP indicator light is ﬂ ashing
green.
y “i-ELOOP Charging” is indicated in the
center display (Type B audio).
The beep will stop when the vehicle is
stopped. Make sure the indicator light is
no longer illuminated and the message
is no longer displayed before driving the
vehicle.
Tire Inﬂ ation Pressure Warning
Beep*
The warning beep sound will be heard
for about 3 seconds when there is any
abnormality in tire inﬂ ation pressures
(page 4-103 ).
Lane Departure Warning System (LDWS) Warning Sound *
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
y The volume of the LDWS warning sound
can be changed.
Refer to Personalization Features on page 9-12 .
y The type of the LDWS warning sound
can be changed.
Refer to Personalization Features on page 9-12 .
Blind Spot Monitoring (BSM) System Warning Beep *
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Monitoring (BSM) warning
light is illuminated.
NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Personalization Features on page
9-12 .
Reversing
If a moving object such as a vehicle or
two-wheeled vehicle approaches on the
left or right from behind your vehicle, the
Blind Spot Monitoring (BSM) warning
sound is activated.
.B[EB@%9&"'@&EJUJPOJOEC.B[EB@%9&"'@&EJUJPOJOEC

Page 574 of 592

MAZDA MODEL 3 4-DOOR 2015 Owners Manual 9–8
Speciﬁ cations
Speciﬁ cations
Mexico
SKYACTIV-G 2.0
Item Weight
Manual transaxle Automatic transaxle
GVW (Gross Vehicle Weight) Total 1,815 kg (4,001 lbs) 1,835 kg (4
