dashboard MAZDA MODEL 3 4-DOOR 2016 User Guide

4–20
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications.
Warning/Indicator lights will appear in any of the highlighted areas
Type A
Type B
Type C
Center of Dashboard
(Digital Speedometer Type)
(Analog Speedometer Type (With
Tachometer))
(Analog Speedometer Type (Without Tachometer))
Instrument Cluster
Mazda3_8FA4-EA-15G_Edition1.indb 202015/05/11 14:00:38

4–40
When Driving
Switches and Controls
Lighting Control
Headlights
Turn the headlight switch to turn the headlights, other exterior lights a\
nd dashboard
illumination on or off.
When the lights are turned on, the lights-on indicator light in the inst\
rument cluster turns on.
NOTE
 If the light switch is left on, the lights will automatically switch off\
approximately 30
seconds after switching the ignition off.
The time setting can be changed.
Refer to Personalization Features on page 9-12. To prevent discharging the battery, do not leave the lights on while the engine is off unless
safety requires them.
Without auto-light control
Switch Position
Ignition PositionON OFF ONOFF ONOFF
Headlights OffOffOffOff OnOn
Daytime running lights OnOff OnOff OffOff
Taillights
Parking lights
License lights
Side-marker lights
Dashboard illumination Off
Off OnOnOnOn
Mazda3_8FA4-EA-15G_Edition1.indb 402015/05/11 14:00:48

4–41
When Driving
Switches and Controls
With auto-light control
Switch Position
Ignition PositionONOFF ONOFF ONOFF ONOFF
Headlights OffOffAuto*1Off OffOff OnOn
Daytime running lights OnOffAuto*1Off OnOff OffOff
Taillights
Parking lights
License lights
Side-marker lights
Dashboard illumination Off
OffAuto
*1Off OnOnOnOn
*1 The headlight and other light settings switch automatically depending on\
the surrounding brightness detected by the sensor.
Mazda3_8FA4-EA-15G_Edition1.indb 412015/05/11 14:00:49

4–42
When Driving
Switches and Controls
Auto-light control
When the headlight switch is in the
position and the ignition is switched ON, the light
sensor senses the surrounding lightness or darkness and automatically tu\
rns the headlights,
other exterior lights and dashboard illumination on or off (see chart above).
CAUTION
 Do not shade the light sensor by adhering a sticker or a label on the windshield. Otherwise
the light sensor will not operate correctly.

 The light sensor also works as a rain sensor for the auto-wiper control. Keep hands and
scrapers clear of the windshield when the wiper lever is in the position and the
ignition is switched ON as fingers could be pinched or the wipers and wiper blades could be
damaged when the wipers activate automatically. If you are going to clean the windshield,
be sure the wipers are turned off completely when it is particularly tempting to leave the
engine running. This is particularly important when clearing ice and snow.
NOTE
 The headlights, other exterior lights and dashboard illumination may not turn off
immediately even if the surrounding area becomes well-lit because the light sensor
determines that it is night time if the surrounding area is continuously dark for several
minutes such as inside long tunnels, traffic jams inside tunnels, or in indoor parking lots.
In this case, the lights turn off if the light switch is turned to the position. (Without auto headlight off function)
When the headlight switch is in the position and the ignition is switched to ACC or
the ignition is switched off, the headlights, other exterior lights and \
dashboard
illumination will turn off.
 The dashboard illumination can be adjusted by rotating the knob in the instrument cluster.
Also, the day/night mode can be changed by rotating the knob until a beep sound is heard.
To adjust the brightness of the dashboard illumination:
Refer to Dashboar d Illumination on page 4-15. The sensitivity of the AUTO lights may be changed by an Authorized Mazda Dealer.
Refer to Personalization Featur es on page 9-12.
Mazda3_8FA4-EA-15G_Edition1.indb 422015/05/11 14:00:49

4–46
When Driving
Switches and Controls
*Some models.
Fog Lights*
Use this switch to turn on the fog lights.
The fog lights will improve visibility at
night and during foggy conditions.
To turn the fog lights on, rotate the fog
light switch to the
position.
Fog light switch
The headlight switch must be in the
position before turning on the fog lights.
To turn the fog lights off, do any of the
following:
 Rotate the fog light switch to the
position. Turn the headlight switch to the or
position.
NOTE
 The fog lights will turn off when the
headlights are set at high beams. (With auto-light control)
If the fog light switch is in the
position and the headlight switch is in
the
position, the fog lights will
turn on when the headlights, the
exterior lights and dashboard
illumination turn on.
Turn and Lane-Change
Signals
The ignition must be switched ON to use
the turn and lane-change signals.
Turn Signals
Move the signal lever down (for a left
turn) or up (for a right turn) to the stop
position. The signal will self-cancel after
the turn is completed.
If the indicator light continues to flash
after a turn, manually return the lever to its
original position.
Right turn
Left turn
Right lane change
Left lane changeOFF
The turn signal indicators (green) in the
instrument cluster flash according to the
operation of the turn signal lever to show
which signal is working.
Mazda3_8FA4-EA-15G_Edition1.indb 462015/05/11 14:00:51

4–82
When Driving
i-ACTIVSENSE
 Under the following conditions, the LDWS may not be able to detect white\
or yellow lines
correctly and the LDWS may not operate correctly.
 If an object placed on the dashboard is reflected in the windshield and picked up by the
camera. Heavy luggage is loaded in the luggage compartment or on the r ear seat and the
vehicle is inclined. The tire pressures are not adjusted to the specified pressure. When the vehicle is driven on the entry and exit to or from the rest area or tollgate of a
highway. The white or yellow lines are less visible because of dirt or paint flaking. The vehicle ahead is running near a white or yellow line and the line is\
less visible. A white or yellow line is less visible because of bad weather (rain, fog\
, or snow). The vehicle is driven on a temporary lane or section with a closed lane \
due to
construction. A misleading line is picked up on the road such as a temporary line for construction,
or because of shade, lingering snow, or grooves filled with water. The surrounding brightness suddenly changes such as when entering or exiting a
tunnel. The illumination of the headlights is weakened because of dirt or the op\
tical axis is
deviated. The windshield is dirty or foggy . Back-light is reflecting from the road surface. The road surface is wet and shiny after rain, or there are puddles on the road. The shade of a guar drail parallel to a white or yellow line is on the road. The width of a lane is excessively narr ow or wide. The road is excessively uneven. The vehicle is shaken after hitting a road bump. There are two or more adjacent white or yellow lines. There are various road markings or lane markings of various shapes near an
intersection.
Mazda3_8FA4-EA-15G_Edition1.indb 822015/05/11 14:01:01

4–90
When Driving
i-ACTIVSENSE
Function for cancelling illumination dimmer
When the headlight switch is in the
or position, the brightness of the Blind Spot
Monitoring (BSM) warning lights is dimmed.
If the Blind Spot Monitoring (BSM) warning lights are difficult to see due to glare from
surrounding brightness when traveling on snow-covered roads or under fog\
gy conditions,
press the dimmer cancellation button to cancel the dimmer and increase t\
he brightness of
Blind Spot Monitoring (BSM) warning lights when they turn on.
Refer to Dashboard Illumination on page 4-15.
Blind Spot Monitoring (BSM) warning beep
The Blind Spot Monitoring (BSM) warning beep is activated simultaneously with the
flashing of a Blind Spot Monitoring (BSM) warning light.
Mazda3_8FA4-EA-15G_Edition1.indb 902015/05/11 14:01:03

4–112
When Driving
i-ACTIVSENSE
CAUTION
Heed the following cautions to assure the correct operation of the Forward Sensing
Camera (FSC).
 Do not remove the Forward Sensing Camera (FSC) cover. Do not place objects on the dashboard which reflect light. Do not apply accessories, stickers or film to the windshield nea r the Forward
Sensing Camera (FSC). If there are objects in front of the Forward Sensing Camera
(FSC) lens, even a transparent sticker, they will cause the system to not operate
correctly.
 Always keep the windshield glass around the camera clean by removing dirt or
fogging. Use the windshield defroster to remove fogging on the windshield. When cleaning the windshield, do not allow glass cleaners or similar cle\
aning
agent to get on the Forward Sensing Camera (FSC) lens. In addition, do not touch
the Forward Sensing Camera (FSC) lens.
 Consult an Authorized Mazda Dealer regarding cleaning the interior side of the
windshield around the Forward Sensing Camera (FSC). Be careful not to scratch the Forward Sensing Camera (FSC) lens or allow it to get
dirty. Also, do no take the camera apart. Otherwise, it could result in damage or
malfunction.
 Consult an Authorized Mazda Dealer before performing repairs around the
Forward Sensing Camera (FSC). The Forward Sensing Camera (FSC) is installed to the windshield. Consult an
Authorized Mazda Dealer for windshield repair and replacement. When performing r epairs around the rearview mirror, consult an Authorized Mazda
Dealer. Consult an Authorized Mazda Dealer regarding cleaning of the Forward Sensing
Camera (FSC) lens. Do not hit or apply str ong force to the Forward Sensing Camera (FSC) or the area
around it. If strong force is applied, stop using the Lane Departure Warning System
(LDWS) and the High Beam Control System (HBC), and consult an Authorized
Mazda Dealer.
 The direction in which the Forward Sensing Camera (FSC) is pointed has been
finely adjusted. Do not change the installation position of the Forward Sensing
Camera (FSC) or remove it. Otherwise, it could result in damage or malfunction.
Mazda3_8FA4-EA-15G_Edition1.indb 1122015/05/11 14:01:08

5–4
Interior Features
Climate Control System
Selecting the Airflow Mode
Dashboard Vents
Dashboard and Floo\
r Vents
Floor Vents Defroster and Floo\
r Vents
Defroster Vents
Mazda3_8FA4-EA-15G_Edition1.indb 42015/05/11 14:01:17

9–2
Specifications
Identification Numbers
Vehicle Information Labels
Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
For vehicle identification number
beginning with JM1*1
For vehicle identification number
beginning with 3MZ*1
*1 Check the vehicle identification number
on the vehicle identification number
plate. Refer to Vehicle Identification
Number on page 9-2.
Chassis Number
Open the cover shown in the figure to
check the chassis number.
Mazda3_8FA4-EA-15G_Edition1.indb 22015/05/11 14:02:58
