stop start MAZDA MODEL 3 4-DOOR 2018 Owner's Guide

4. Select the icon to display the
content list.
Selection of other destinations from
the list can be made.
Shout
Some social stations, such as Facebook or
Caraoke, support the ability to record and
share voice messages using the “Shout”
function.
1. Select the
icon and start the
countdown (3, 2, 1 , 0). Recording
starts when the countdown reaches
zero.
2. Records voice.
3. Select
and store/post the
recording.
NOTE
Recordable time varies depending on
the station (Max. 30 seconds).
Recording stops automatically when the
recordable time has elapsed. You can
then post or delete the recording.
Interior Features
Bluetooth®
5-122
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Overheating
If the high engine coolant temperature
warning light turns on, the vehicle loses
power, or you hear a loud knocking or
pinging noise, the engine is probably too
hot.
WA R N I N G
Pull over to a safe location, then switch
the ignition off and make sure the fan is not
running before attempting to work near
the cooling fan:
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if the
engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.
Do not remove either cooling
system cap when the engine and radiator
are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot out
under pressure and cause serious injury.
Open the hood ONLY after steam is no
longer escaping from the engine:
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.
If the high engine coolant temperature
warning light turns on:

1. Drive safely to the side of the road and
park off the right-of-way.
2. Put a vehicle with an automatic transaxle in park (P), a manual
transaxle in neutral.
3. Apply the parking brake.
4. Turn off the air conditioner.
5. Check whether coolant or steam is
escaping from the engine
compartment.

If steam is coming from the engine
compartment:
Do not go near the front of the vehicle.
Stop the engine.
Wait until the steam dissipates, then
open the hood and start the engine.

If neither coolant nor steam is
escaping:
Open the hood and idle the engine
until it cools.
CAUTION
If the cooling fan does not operate
while the engine is running, the engine
temperature will increase. Stop the
engine and call an Authorized Mazda
Dealer.
6. Make sure the cooling fan is operating, then turn off the engine after the
temperature has decreased.
7. When cool, check the coolant level. If it is low, look for coolant leaks from
the radiator and hoses.

If Trouble Arises
Overheating
7-20
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

If a Warning Light Turns On or Flashes
If any warning light turns on/flashes, take appropriate action for each light. There is no
problem if the light turns off, h owever if the light does not turn off or turns on/flashes again,
consult an Authorized Mazda Dealer.
(Vehicles with type B audio)
The details for some warnings can be viewed on the center display.
1. If the warning light is turned on, select
icon on the home screen to display the
application screen.
2. Select “Vehicle Status Monitor”.
3. Select “Warning Guidance” to display the current warnings.
4. Select the applicable warni ng to view the warning details.
▼Stop Vehicle in Safe Place Immediately
If any of the following warning
lights turns on, the system may have a malfunction. Stop the
vehicle in a safe place immediately and contact an Authorized M azda Dealer.
SignalWarning
Brake System Warning
Light Without Electric Parking Brake (EPB)
This warning has the
following functions:
Parking brake warning/Warning light inspection
The light illuminates when the par king brake is applied with the ignition switched to
START or ON. It turns off when the parking brake is fully relea sed.
Low brake fluid level warning
If the brake warning light remains illuminated even though the parking brake is re-
leased, the brake fluid may be l ow or there could be a problem with the brake system.
Park the vehicle in a safe place immediately and contact an Aut horized Mazda Dealer.
WA R N I N G
Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.
CAUTION
In addition, the effectiveness of the brakin g may diminish so you may need to depress
the brake pedal more strongly than normal to stop the vehicle.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-25
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

SignalWarning
Brake System Warning
Light With Electric Parking Brake (EPB)
This warning has the following functions:
Parking brake warning/Warning light inspection
The light illuminates when the electric parking brake (EPB) is
applied with the igni-
tion switched to START or ON. It turns off when the electric pa rking brake (EPB) is
released.
When the light turns on
If the brake system warning light remains turned on even though the electric parking
brake (EPB) is released, the brak e fluid may be low or there could be a problem with
the brake system. Park the vehicle in a safe place immediately and contact an Author-
ized Mazda Dealer.
When the light is flashing
The light flashes if the electric parking brake (EPB) has a mal function.
If the light remains flashing ev en if the electric parking brake (EPB) switch is operat-
ed, consult an Authorized Mazd a Dealer as soon as possible.
WARNING
Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.
CAUTION
In addition, the effectiveness of the braking may diminish so you may need to depress
the brake pedal more strongly than normal to stop the vehicle.
Electronic Brake Force Distribution System Wa r n i n g If the electronic brake force di
stribution control unit determines that some compo-
nents are operating incorrectly , the control unit may illuminate the brake system
warning light and the ABS warni ng light simultaneously. The problem is likely to be
the electronic brake force distribution system.
WARNING
Do not drive with both the ABS warning light and brake warning light illuminated.
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as
soon as possible:
Driving when the brake system warning ligh t and ABS warning light are illuminated si‐
multaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an emer‐
gency stop than under normal circumstances.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-26
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

SignalWarning
Charging System Warn-
ing Light If the warning light illuminates
while driving, it indicates a malfunction of the alter-
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Co nsult an Authorized
Mazda Dealer.CAUTION
Do not continue driving when the charging system warning light is illuminated be‐
cause the engine could stop unexpectedly.
Engine Oil Warning Light This warning light indicates
low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the warning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way o n level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
3. Inspect the engine oil level (page 6-24). If it's low, add th e appropriate amount of
engine oil while being careful not to overfill.
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.

If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
(Red)
High Engine Coolant
Temperature Warning Light The light flashes when the engine coolant temperature is extrem
ely high, and illumi-
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine l oad until you can find a safe place to stop the vehicle
and wait for the engine to cool down.
Illuminated light
This indicates the possibility of overheating. Park the vehicle in a safe place immedi-
ately and stop the engine.
Refer to Overheating on page 7-20.
CAUTION
Do not drive the vehicle with the high engi ne coolant temperature warning light illumi‐
nated. Otherwise, it could result in damage to the engine.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-27
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

SignalWarning
Power Steering Mal-
function Indicator Light The light illuminates/flashes if the electric power steering ha
s a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe pl ace and do not operate the
steering wheel. There is no problem if the light turns off afte r a while. Contact an Au-
thorized Mazda Dealer if the lig ht illuminates/flashes continuously.
NOTE
If the indicator light illuminates/flashes, the power steering will not operate normal-
ly. In this happens, the st eering wheel can still be oper ated, however, the operation
may feel heavy compar ed to normal, or the steering wheel could vibrate when turn-
ing.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem. If
this occurs, park the vehicle safely and wait several minutes for the system to return
to normal.
▼ Contact Authorized Mazda Deal
er and Have Vehicle Inspected
If any of the following warning lights o r the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.
SignalWarning
ABS Warning LightIf the ABS warning light stays on while you're driving, the ABS
control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an A uthorized Mazda Dealer as soon as possible.
NOTE
When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
The brake assist system does not operate while the ABS warning light is illuminated.
Master Warning
Light
(Vehicles with type B audio)
The light turns on when the system has a malfunction.
Operate the center display and verify the content.
Refer to If a Warning Light Turns On or Flashes on page 7-25.
(Vehicles without type B audio)
The light illuminates continuously if any one of the following occurs. Consult an Au-
thorized Mazda Dealer.
There is a malfunction in the battery management system.There is a malfunction in the brake switch.
Electric Parking
Brake (EPB) Warn-
ing Light
*
The warning light illuminates when the system has a malfunction . Have your vehicle in-
spected at an Authorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-28*Some models.
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Safety Practices
The way you drive has a great deal to do with your tire mileage
and safety. So cultivate
good driving habits for your own benefit.
Observe posted speed limits and drive at speeds that are safe f or the existing weather
conditions
Avoid fast starts, stops and turns
Avoid potholes and objects on the road
Do not run over curbs or hit the tire against the curb when parking
CAUTION
If you feel a sudden vibration or ride disturbance while driving or you suspect your tire or
vehicle has been damaged, immediately reduce your speed. Drive with caution until you can
safely pull off the road. Stop and inspect the tire for damage. If the tire is under-inflated or
damaged, deflate it, remove the tire and rim and replace it with your spare tire. If you cannot
detect a cause, have the vehicle towed to the nearest vehicle or tire dealer to have the vehicle
inspected.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-35
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
Viewing the display................... 4-153
Rear Window Defogger. ................... 4-53
Rear Window Washer....................... 4-53
Rear Window Wiper.... ..................... 4-53
Recommended Oil.............................6-23
Recording of Vehicle Data................ 8-22
Recreational Towing......................... 3-52
Registering Your Vehicle in A Foreign
Country.............................................. 8-18
Replacement Fuse..............................................6-57
Key battery.................................. 6-35
Light Bulbs.................................. 6-42
Tires............................................. 6-40
Wheel........................................... 6-41
Wiper........................................... 6-29
Rocking the Vehicle.......................... 3-47
S
Safety Defects, Reporting................. 8-14
Satellite Radio................................... 5-44
Saving Fuel and Protection of the
Environment...................................... 3-45
Scheduled Maintenance...................... 6-4
Seats Front seat....................................... 2-5
Head restraint.............................. 2-10
Rear seat........................................ 2-7
Seat warmer................................... 2-6
Seat Belt System Automatic locking....................... 2-14
Emergency locking...................... 2-14
Extender....................................... 2-18
Pregnant women.......................... 2-14
3-point type................................. 2-15
Seat belt warning beep...................... 7-38
Security System Immobilizer system..................... 3-41
Theft-deterrent system................. 3-43
Smart Brake Support (SBS)............ 4-128
Collision warning...................... 4-130
Smart Brake Support (SBS) indicator
light (red)................................... 4-130
Stopping the Smart Brake Support
(SBS) system operation............. 4-130
Smart City Brake Support
(SCBS)............................................ 4-124
Collision warning...................... 4-126
Smart City Brake Support (SCBS)
Indicator Light (Red).................4-126
Stopping the Smart City Brake
Support (SCBS) System
Operation................................... 4-127
Spare Tire............................................ 7-5
Specifications...................................... 9-4
Speedometer...................................... 4-13
Speed Unit Selector.......................... 4-13
SRS Air Bags Front passenger occupant
classification system.................... 2-61
How the SRS air bags work........ 2-53
Limitations to SRS air bag.......... 2-59
Monitoring................................... 2-65
SRS air bag deployment
criteria.......................................... 2-58
Supplemental restraint system
components.................................. 2-51
Starting the Engine..............................4-5
Steering Wheel.................................. 3-30
Horn............................................. 4-55
Storage Compartments.................... 5-136
Center console........................... 5-136
Glove compartment................... 5-136
Overhead console...................... 5-136
Rear coat hooks......................... 5-138
Sunshade............................................3-40
Sunvisors......................................... 5-129
T
Tachometer........................................ 4-15
10-7
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
Theft-Deterrent System..................... 3-43
TiedownHook.............. .............................. 7-23
Tires................................................... 6-38
Flat Tire......................................... 7-3
Replacing a Tire.......................... 6-40
Replacing a Wheel...................... 6-41
Snow tires.................................... 3-48
Specifications...............................9-10
Temporary Spare Tire..................6-40
Tire chains................................... 3-49
Tire Inflation Pressure................. 6-38
Tire Rotation................................6-39
Uniform tire quality grading system
(UTQGS)..................................... 8-23
Tire inflation pressure warning
beep................................................... 7-40
Tire Information................................ 8-25
Tire Pressure Monitoring System.... 4-146
To w i n g
Recreational towing.....................3-52
Trailer Towing............................. 3-52
Towing Description........................... 7-22
Traction Control System (TCS)........ 4-67 TCS/DSC Indicator Light............4-67
Traffic Sign Recognition System
(TSR)................................................. 4-90
Transmitter.......................................... 3-4
Trip Computer................................... 4-18
Trip Meter......................................... 4-13
Trouble Battery runs out........................... 7-16
Emergency Starting..................... 7-19
Emergency Towing......................7-22
Flat Tire......................................... 7-3
Overheating................................. 7-20
Parking in an Emergency.............. 7-2
When liftgate/trunk lid cannot be
opened..........................................7-43
Trunk Lid.......................................... 3-20
Inside trunk release lever............ 3-24When liftgate/trunk lid cannot be
opened..........................................7-43
V
Vanity Mirrors................................. 5-129
Vehicle Information Labels................. 9-2
W
Warning Lights.................................. 4-24
Warning Message Indicated on
Display.............................................. 7-36
Warning Sound is Activated............. 7-38
Advanced Key removed from vehicle
warning beep............................... 7-39
Air Bag/Front Seat Belt Pretensioner
System Warning Beep................. 7-38
Blind Spot Monitoring (BSM)
warning beep............................... 7-41
Collision warning...... .................. 7-41
Electric Parking Brake (EPB)
Warning Beep.............................. 7-42
Excessive speed warning.............7-41
Ignition not switched off (STOP)
warning beep............................... 7-39
i-ELOOP warning beep............... 7-40
Key left-in-luggage compartment
warning beep (With the advanced
keyless function)..........................7-40
Key left-in-vehicle warning beep
(With the advanced keyless
function).......................................7-40
Key removed from vehicle warning
beep..............................................7-39
Lane Departure Warning sound... 7-40
Lights-on reminder...................... 7-38
Mazda Radar Cruise Control
(MRCC) System warnings.......... 7-41
Over Rev. buzzer......................... 7-41
Power steering warning buzzer....7-41
Seat belt warning beep................ 7-38
10-8
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
