set clock MAZDA MODEL 3 5-DOOR 2014 User Guide

5–83
Interior Features
Bluetooth®
6. If the link to the desired device is successful, the
symbol is displayed
again, together with “ LINK
CHANGED ”. “ LINK CHANGED ” is
displayed for three seconds, then it
returns to the normal display.
NOTE
 y  Some Bluetooth ® audio devices need a
certain amount of time before the
symbol is displayed. y  If a hands-free type mobile phone has
been the most recently paired device,
the Bluetooth
® unit links this device.
If you would like to use a Bluetooth ®
audio type device which has been
previously paired to the Bluetooth ® unit,
the link must be changed to this device.
 y  If an error occurs while trying to link
a device, “ Err ” fl ashes in the audio
display for three seconds, and the
display returns to “ LINK CHANGE ”.
If this occurs, check the pairing status
of the Bluetooth
® audio device and the
location of the device in the vehicle (not
in the trunk or a metal-type box), and
then try the link operation again.
 y  Device selection can also be done using
voice recognition.
How to confi rm the device currently
linked
Switch to the link-change mode. (Refer to
“Changing the link to a Bluetooth
® audio
device”)
The device name displayed fi rst is the
device which is currently linked.
Deleting a device
1. Using the audio control dial, select the pairing delete mode “ PAIR DELETE ”
in the “ BT SETUP ”mode. (Refer to
“Bluetooth
® audio device set-up” for
details.) 2. Press the audio control dial to
determine the mode.
3. The name of the fi rst device among the
paired devices is displayed.
4. Rotate the audio control dial and select the name of the paired device you
would like to delete.
De v ic e n a m e 1
De v ic e n a m e 2
De v ic e n a m e 3
De v ic e n a m e 4
De v ic e n a m e 5
De v ic e n a m e 6
De v ic e n a m e 7
NOTE
Only the names of paired devices can be
displayed. If only one device is paired,
only the name for this device is displayed.
5. If a selection other than “ GO BACK ” is made and the audio control dial is
pressed, “ SURE ? NO ” is displayed.
6. Rotate the audio control dial clockwise and switch the display to “ SURE ?
YES ”.
NOTE
The display changes as follows depending
on whether the audio control dial is
rotated clockwise or counterclockwise.
-Clockwise: “ SURE ? YES ” displayed
-Counterclockwise: “ SURE ? NO ”
displayed
.B[EB@%$&""@&EJUJPOJOEC







7–7
If Trouble Arises
Flat Tire
1. Park on a level surface off the right-of-way and fi rmly set the parking brake.
2. Put a vehicle with an automatic transaxle in Park (P), a manual
transaxle in Reverse (R) or 1, and turn
off the engine.
3. Turn on the hazard warning fl asher.
4. Have everyone get out of the vehicle and away from the vehicle and traffi c.
5. Remove the jack, tool, and spare tire (page 7-3 ).
6. Block the wheel diagonally opposite the fl at tire. When blocking a wheel,
place a tire block both in front and
behind the tire.
NOTE
When blocking a tire, use rocks or wood
blocks of suffi cient size if possible to hold
the tire in place.
Removing a Flat Tire
1. If your vehicle is equipped with a wheel cover, pry off the wheel cover
with the beveled end of the jack lever.
NOTE
Force the end of the jack lever fi rmly
between wheel and cover, or removal will
be diffi cult.
2. Loosen the lug nuts by turning them counterclockwise one turn each, but do
not remove any lug nuts until the tire
has been raised off the ground.
3. Place the jack on the ground.
.B[EB@%$&""@&EJUJPOJOEC







10–3
Index
Climate Control System ........................ 5-2 Automatic Climate Control ............. 5-9
Dual-Zone Automatic Climate
Control........................................... 5-12
Gas specifi cations ............................ 9-7
Manual Climate Control .................. 5-5
Operating Tips ................................. 5-2
Vent Operation ................................ 5-3
Clock ................................................... 5-28
Cruise Control ..................................... 4-57 Cruise Control Switch ................... 4-57
Cruise Control Set Vehicle Speed
Display ................................................ 4-14
Cup Holder ........................................ 5-134
Customer Assistance ............................. 8-2
D
Dashboard Illumination ...................... 4-12
Daytime Running Lights ..................... 4-37
Defogger Rear window ................................. 4-43
Mirror ............................................ 4-44
Dimensions ........................................... 9-5
Door Locks .......................................... 3-11
Driving In Flooded Area ..................... 3-49
Driving Tips Automatic transaxle ...................... 4-32
Break-in ......................................... 3-45
Driving in fl ooded area.................. 3-49
Driving on uneven road ................. 3-51
Floor mat ....................................... 3-46
Hazardous driving ......................... 3-46
Money-saving suggestions ............ 3-45
Overloading ................................... 3-50
Rocking the vehicle ....................... 3-47
Winter driving ............................... 3-47
Driving on Uneven Road .................... 3-51
Dynamic Stability Control (DSC) ....... 4-52 DSC OFF Indicator Light.............. 4-53
DSC OFF Switch........................... 4-53
TCS/DSC Indicator Light ............. 4-52
E
Emergency Starting Push-Starting ................................. 7-18
Starting a Flooded Engine ............. 7-18
Emergency Towing Tiedown Hooks ............................. 7-22
Towing Description ....................... 7-21
Emission Control System .................... 3-28
Ending Screen Display ........................ 4-55
Engine Coolant .......................................... 6-29
Engine Compartment Overview .... 6-26
Exhaust gas.................................... 3-29
Hood release .................................. 6-24
Oil .................................................. 6-27
Starting ............................................ 4-3
Essential information ............................ 6-2
Event Data Recorder ........................... 8-20
Exhaust Gas ........................................ 3-29
Exterior Care ....................................... 6-63
Aluminum Wheel Maintenance .... 6-68
Bright-Metal Maintenance ............ 6-67
Maintaining the Finish .................. 6-65
Plastic Part Maintenance ............... 6-68
F
Flasher Hazard warning ............................. 4-45
Headlights ..................................... 4-33
Flat Tire ................................................. 7-3 Mounting the Spare Tire................ 7-11
Removing a Flat Tire ....................... 7-7
Floor Mat ............................................ 3-46
Fluid
Brake/Clutch ................................. 6-31
Washer ........................................... 6-31
Fluids Classifi cation ................................... 9-4
Fog Lights ........................................... 4-37
Foot Brake ........................................... 4-46
Front Seat .............................................. 2-5
