MAZDA MODEL 3 5-DOOR 2014 Owners Manual

5–125
Interior Features
Bluetooth®
Add to your favorites
If the current program has not been
registered to your favorites, it can be
registered to your favorites.
1. Select the
icon to display the
favorites station which the registration
can be added.
2. Select the station name which you want to register.
3. Select the
button to add the
program to the selected favorites
station.
NOTE
 y  Multiple favorites stations can be
selected and registered.
 y Favorites stations registered by
oneself as well those set by default are
displayed.
Delete from your favorites
If the current program has already been
registered to your favorites, the program
can be deleted from your favorites.
1. Select the
icon.
2. The program is automatically deleted from the favorites station.
.B[EB@%$&""@&EJUJPOJOEC







*Some models.5–126
Interior Features
Bluetooth®
Troubleshooting (Type A/Type B) *
Mazda Bluetooth ® Hands-Free Customer Service
If you have any problems with Bluetooth
® , contact with our toll-free customer service
center.
 y U.S.A. Phone: 800-430-0153 (Toll-free) Web: www.MazdaUSA.com/bluetooth yCanada Phone: 800-430-0153 (Toll-free) Web: www.mazdahandsfree.ca yMexico Center of Attention to Client (CAC) Phone: 01-800-01-MAZDA (Toll-free) Web: www.mazdamexico.com.mx
Bluetooth
® Device pairing, connection problems
Symptom Cause Solution method
Unable to perform pairing — First make sure the device is
compatible with the Bluetooth
®
unit, and then check whether the
Bluetooth® function and the Find
Mode/Visible setting *1 on the device
are turned on. If pairing is still
not possible after this, contact an
Authorized Mazda Dealer or Mazda
Bluetooth
® Hands-Free Customer
Service.
Pairing cannot be performed again The pairing information paired to
the Bluetooth
® unit or device is not
recognized correctly. Perform pairing using the following
procedure.y Clear “Mazda” stored in the device. y Perform pairing again.
Unable to perform pairing The Bluetooth
® function and the
Find Mode/Visible setting *1 on the
device may turn off automatically
after a period of time has elapsed
depending on the device. Check whether the Bluetooth ®
function and the Find Mode/Visible
setting*1 on the device are turned on
and pairing or reconnect.
Does not connect automatically
when starting the engine
Automatically connects, but then
disconnects suddenly
Disconnects intermittently
The device is in a location in which
radio wave interference can occur
easily, such as inside a bag in a rear
seat, in a rear pocket of a pair of
pants. Move the device to a location in
which radio wave interference is less
likely to occur.
Does not connect automatically
when starting the engine The pairing information is updated
when the device OS is updated.
Perform pairing again.
*1 Setting which detects the existence of a device external to the Bluetoot\
h
® unit
.B[EB@%$&""@&EJUJPOJOEC







5–127
Interior Features
Bluetooth®
NOTE
 y When you update the operating system of your mobile device the pairing i\
nformation may
be invalidated. Therefore, the device may need to be re-paired to the hands-free unit.
 y If you pair your phone which has already been paired to your vehicle more than once
in the past, you need to delete “Mazda” on your mobile device. Th\
en, execute the
Bluetooth
® search on your mobile device once again, and pair to a newly detected
“Mazda”.
 y  Before you pair your device, make sure that Bluetooth ® is “ON”, both on your phone and
on the vehicle.
Voice recognition related problems
Symptom Cause Solution method
Poor voice recognition
y Excessive, slow speech. y Excessive, forceful speech
(shouting).
y Speaking before the beep sound has ended.
y Loud noise (speaking or noise from outside/inside vehicle).
y Airfl ow from A/C is blowing
against the microphone.
y Speaking in off-standard expressions (dialect). Regarding the causes indicated
on the left, be careful with how
you speak. In addition, when
numbers are spoken in a sequence,
recognition ability will improve
if no stop is placed between the
numbers.
False recognition of numbers
Poor voice recognition
There is a malfunction in the
microphone. A poor connection or malfunction
with the microphone may have
occurred. Consult an Authorized
Mazda Dealer.
Phone-related voice recognition is
disabled There is a problem with the
connection between the Bluetooth
®
unit and the device. If there is any malfunction after
checking the pairing situation, check
for device pairing or connection
problems.
Names in the phonebook are not
easily recognized The Bluetooth
® system is under a
condition in which recognition is
diffi cult. By carrying out the following
measures, the rate of recognition
will improve. y Clear memory from the phonebook
which is not used very often.
y Avoid shortened names, use full names. (Recognition improves the
longer the name is. By not using
names such as “Mom”, “Dad”,
recognition will improve.)
When operating the audio, a song
name is not recognized Song names cannot be recognized
by voice.
—
You want to skip guidance — Guidance can be skipped by quickly
pressing and releasing the Talk
button.
.B[EB@%$&""@&EJUJPOJOEC







5–128
Interior Features
Bluetooth®
Regarding problems with calls
Symptom Cause Solution method
When starting a call, vehicle noise
from the other party can be heard For about three seconds after
starting a call, the Bluetooth
®
unit's Noise Suppression function
requires time to adapt to the call
environment. This does not indicate a problem
with the device.
The other party cannot be heard or
the speaker's voice is quiet The volume is set at zero or low. Increase the volume.
Other problems
Symptom
Cause Solution method
The indication for the remaining
battery is different between the
vehicle and the device The indication method is different
between the vehicle and the device.
—
When a call is made from the
vehicle, the telephone number is
updated in the incoming/outgoing
call record but the name does not
appear The number has not been registered
into the phonebook. If the number has been registered
into the phonebook, the incoming/
outgoing call record is updated by
the name in the phonebook when the
engine is restarted.
The cell phone does not synchronize
with the vehicle regarding the
incoming/outgoing call record Some types of cell phones do not
synchronize automatically.
Operate the cell phone for
synchronization.
It takes a long time to complete the
function for changing the language A maximum of 60 seconds is
required.
—
.B[EB@%$&""@&EJUJPOJOEC







*Some models.5–129
Interior Features
Interior Equipment
Sunvisors
When you need a sunvisor, lower it for use
in front or swing it to the side.
Sunvi sor
Side Extension Sunvisors *
The visor extender extends the sunvisor's
range of sun shading.
To use, pull it out.
CAUTION
When moving the sunvisor, retract the
visor extender to its original position.
Otherwise, the visor extender could hit
the rearview mirror.
Vanity Mirrors
To use the vanity mirror, lower the
sunvisor.
If your vehicle is equipped with a vanity
mirror light, it will illuminate when you
open the cover.
To prevent the battery from being
discharged, the vanity mirror will only
illuminate in the tilt range shown below.
off
off
on
.B[EB@%$&""@&EJUJPOJOEC







*Some models.5–130
Interior Features
Interior Equipment
Interior Lights
Overhead Lights
Switch
Position Overhead Lights
Light off
y Light is on when any door is open y Light is on or off when the
illuminated entry system is on
Light on
With Map Lights
F ront
R ear
Without Map Lights
NOTE
(With map lights)
The map lights and rear overhead light
also turn on and off when the front
overhead light switch is operated.
Map Lights
*
When the overhead light switch is in the
door or off position, press the lens to
illuminate the map lights, and then press
the lens again to turn them off.
NOTE
The map lights will not turn off even if the
lens is pressed in the following cases:
 y  The overhead light switch is in the ON
position.
 y The overhead light switch is in the door
position with the door open.
 y The illuminated entry system is on.
.B[EB@%$&""@&EJUJPOJOEC







5–131
Interior Features
Interior Equipment
Luggage Compartment Lights (5–door)
Switch
Position Luggage Compartment Light
Light off
Light on when the liftgate is open
Trunk Light (4–door)
The trunk light is on when the lid is open
and off when it's closed.
NOTE
To prevent the battery from being
discharged, do not leave the trunk open
for a long period when the engine is not
running.
Illuminated Entry System
When the illuminated entry system
operates, the overhead light (switch is in
the DOOR position) turn on for:
 y
 About 30 seconds after the driver's door
is unlocked and the ignition is switched
off.
 y  About 15 seconds after all doors are
closed and the ignition is switched off.
 y  About 5 seconds after all doors are
closed and the ignition is switched off
when the key is out of the vehicle.
 y  Illuminates for about 15 seconds when
the ignition is returned from ACC to
OFF.
The light also turns off when:
 y  The ignition is switched on and all doors
are closed.
 y  The driver's door is locked.
NOTE
 yBattery saver If any door is left open with the
overhead light switch in the DOOR
position, or the liftgate/trunk lid is left
open, the overhead light or luggage
compartment light/trunk light turns
off after about 30 minutes to prevent
battery depletion.
 y The operation of the illuminated entry
system can be changed.
 Refer to Personalization Features on page 9-10 .
.B[EB@%$&""@&EJUJPOJOEC







*Some models.5–132
Interior Features
Interior Equipment
Accessory Sockets
Only use genuine Mazdaaccessories or the
equivalent requiring no greater than 120 W
(DC 12 V, 10 A).
Type A
The accessory sockets can be used
regardless of whether the ignition is on or
off.
Type B *
The ignition must be switched to ACC or
ON.
With CD Player
Without CD Player
.B[EB@%$&""@&EJUJPOJOEC







5–133
Interior Features
Interior Equipment
CAUTION


*Some models.5–134
Interior Features
Interior Equipment
Cup Holder
WARNING
Never use a cup holder to hold hot
liquids while the vehicle is moving: Using a cup holder to hold hot
liquids while the vehicle is moving is
dangerous. If the contents spill, you
could be scalded.

Do not put anything other than cups or
drink cans in cup holders: Putting objects other than cups
or drink cans in a cup holder is
dangerous.
During sudden braking or
maneuvering, occupants could be
hit and injured, or objects could be
thrown around the vehicle, causing
interference with the driver and the
possibility of an accident. Only use a
cup holder for cups or drink cans.
Front
Rear *
The rear cup holder is on the rear center
armrest.
.B[EB@%$&""@&EJUJPOJOEC
