Page 241 of 592
*Some models.4–115
When Driving
Forward Obstruction Warning (FOW)
Forward Obstruction Warning (FOW) *
Forward Obstruction Warning (FOW) is a system which alerts the driver of a possible
collision using an indicator and warning sound in the instrument cluster\
while the vehicle
is being driven at about 15 km/h or faster (10 mph or faster) and the \
system's radar sensor
determines that your vehicle may hit a vehicle or obstruction ahead.
WARNING
Do not rely completely on the Forward Obstruction Warning (FOW) system and always
drive carefully: Forward Obstruction Warning (FOW) is only designed to reduce damage in the event of
a collision. The ability to detect an obstruction is limited depending on the obstruction,
weather conditions, or traffi c conditions. Therefore, if the accelerator pedal or brake
pedal is mistakenly operated it could result in an accident. Always verify the safety of the
surrounding area and depress the brake pedal or accelerator pedal while keeping a safe
distance from vehicles ahead or on-coming vehicles.
NOTE
y The Forward Obstruction Warning (FOW) system operates when all of the following
conditions are met:
y The ignition is switched ON. y The Forward Obstruction Warning (FOW) system is on. y The vehicle speed is about 15 km/h (10 mph) or faster. y The relative speed between your vehicle and the vehicle or obstruction ahead \
is about
15 km/h (10 mph) — 145 km/h (90 mph).
y The Forward Obstruction Warning (FOW) system may not operate under the following
conditions:
y If there is the possibility of hitting only a part of a vehicle or obstruction \
ahead. y If the vehicle is accelerated rapidly and it comes close to a vehicle ah\
ead. y The DSC is malfunctioning. y The vehicle is driven at the same speed as the vehicle ahead. y The accelerator pedal is depressed. y The brake pedal is depressed. y The steering wheel is being operated. y The selector lever is being operated. y The turn signal is being used.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 242 of 592
4–116
When Driving
Forward Obstruction Warning (FOW)
y Although the objects which activate the system are 4-wheeled vehicles, the radar sensor
could detect the following objects, determine them to be an obstruction,\
and operate the
Forward Obstruction Warning (FOW) system.
y Objects on the road at the entrance to a curve (including guardrails and snow banks). y A vehicle appears in the opposite lane while cornering or rounding a curve. y When crossing a narrow bridge. y When passing under a low gate or through a tunnel or narrow gate. y When entering an underground parking area. y Metal objects, bumps, or protruding objects on the road. y If you suddenly come close to a vehicle ahead. y When driving in areas where there is high grass or forage. y Two-wheeled vehicles such as motorbikes or bicycles. y Pedestrians or non-metallic objects such as standing trees.
y When the system operates, the user is notifi ed by the fl ashing Forward Obstruction
Warning (FOW) indicator light (red) and the active driving display.
y The Forward Obstruction Warning (FOW) warning light (amber) turns on when the
system has a malfunction.
(page 4-21 )
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 243 of 592
4–117
When Driving
Forward Obstruction Warning (FOW)
Forward Obstruction Warning (FOW) Indicator Light (Red)
If the Forward Obstruction Warning
(FOW) is operating, the indicator light
(red) fl ashes.
Collision Warning
If there is the possibility of a collision
with a vehicle or obstruction ahead, the
beep sounds continuously and a warning is
indicated in the display.
Stopping The Forward
Obstruction Warning (FOW)
System Operation
The Forward Obstruction Warning (FOW)
system can be deactivated.
Refer to Personalization Features on page
9-12 .
When the Forward Obstruction Warning
(FOW) system is turned off, the Forward
Obstruction Warning (FOW) OFF
indicator light turns on.
Radar Sensor Handling
The Forward Obstruction Warning (FOW)
radar sensor is installed on the backside of
the radiator grille.
Refer to Radar Sensor on page 4-64 .
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 244 of 592
*Some models.4–118
When Driving
Lane Departure Warning System (LDWS)
Lane Departure Warning System (LDWS) *
The LDWS notifi es the driver that the vehicle may be deviating from its lane.
The system detects the white or yellow lines on the traffi c lane using the Forward Sensing
Camera (FSC). If it determines that the vehicle may be deviating from \
its lane, it notifi es
the driver by fl ashing the LDWS indicator light (green) and operating the LDWS warning\
sound.
Refer to Forward Sensing Camera on page 4-62 .
Use the LDWS when you drive the vehicle on roads with white or yellow li\
nes.
Forward Sensing Camera (FSC)
LDWS warning light (Amber)/
LDWS indicator light (Green)
The warning light fl ashes when the system has a malfunction.
Refer to Warning Lights on page 4-21 .
WARNING
Do not use the LDWS under the following conditions: The system may not operate adequately according to the actual driving conditions,
resulting in an accident.
Page 245 of 592
4–119
When Driving
Lane Departure Warning System (LDWS)
CAUTION
Do not modify the suspension. If the vehicle height or the damping force of the
suspensions is changed, the LDWS may not operate correctly.
NOTE
y If your vehicle deviates from its traffi c lane, the LDWS operates (warning sound and
indicator light). Steer the vehicle adequately to drive the vehicle to \
the center of the lane.
y When the turn signal lever is operated for a lane change, the LDWS warni\
ng is
automatically canceled. The LDWS warning becomes operable when the turn \
signal lever
is returned and the system detects the white or yellow lines.
y If the steering wheel, accelerator pedal, or brake pedal is operated abr\
uptly and the
vehicle moves close to a white or yellow line, the system determines tha\
t the driver is
making a lane change and the LDWS warning is automatically canceled.
y The LDWS may not operate during the period immediately after the vehicle\
has deviated
from its lane and the LDWS has operated, or the vehicle deviates from its lane repeatedly
within a short period of time.
y The LDWS does not operate if it does not detect the white or yellow line\
s of the traffi c
lane.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 246 of 592
![MAZDA MODEL 3 5-DOOR 2015 Owners Manual 4–120
When Driving
Lane Departure Warning System (LDWS)
y Under the following conditions, the LDWS may not be able to detect white\
or yellow lines
correctly and the LDWS may not op](/img/28/40996/w960_40996-245.png "MAZDA MODEL 3 5-DOOR 2015 Owners Manual 4–120
When Driving
Lane Departure Warning System (LDWS)
y Under the following conditions, the LDWS may not be able to detect white\
or yellow lines
correctly and the LDWS may not op")
4–120
When Driving
Lane Departure Warning System (LDWS)
y Under the following conditions, the LDWS may not be able to detect white\
or yellow lines
correctly and the LDWS may not operate correctly.
y If an object placed on the dashboard is refl ected in the windshield and picked up by the
camera.
y Heavy luggage is loaded in the luggage compartment or on the rear seat and the
vehicle is inclined.
y The tire pressures are not adjusted to the specifi ed pressure. y When the vehicle is driven on the entry and exit to or from the rest area or tollgate of a
highway.
y The white or yellow lines are less visible because of dirt or paint fl aking. y The vehicle ahead is running near a white or yellow line and the line is\
less visible. y A white or yellow line is less visible because of bad weather (rain, fog\
, or snow). y The vehicle is driven on a temporary lane or section with a closed lane \
due to
construction.
y A misleading line is picked up on the road such as a temporary line for construction,
or because of shade, lingering snow, or grooves fi lled with water.
y The surrounding brightness suddenly changes such as when entering or exiting a
tunnel.
y The illumination of the headlights is weakened because of dirt or the op\
tical axis is
deviated.
y The windshield is dirty or foggy. y Back-light is refl ecting from the road surface. y The road surface is wet and shiny after rain, or there are puddles on the road. y The shade of a guardrail parallel to a white or yellow line is on the road. y The width of a lane is excessively narrow or wide. y The road is excessively uneven. y The vehicle is shaken after hitting a road bump. y There are two or more adjacent white or yellow lines. y There are various road markings or lane markings of various shapes near an
intersection.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 247 of 592
4–121
When Driving
Lane Departure Warning System (LDWS)
When The System Operates
1. Press the LDWS switch. The LDWS goes on stand-by and the LDWS
warning light (amber) illuminates.
The lane indication (bordered line) is
indicated in the active driving display
(Type A instrument cluster
*1 ) or the
multi information display (Type B
instrument cluster
*1 ).
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-11 .
Indication on display
2. Drive the vehicle near the center of the lane and the LDWS indicator light
(green) illuminates in the instrument
cluster when all of the following
conditions are met.
y The vehicle is driven near the center of the lane with the white or yellow line
on the left and right sides, or on either
side.
y The vehicle speed is about 70 km/h (44 mph) or more
y The vehicle is driven on a straight road or road with gentle curves
The lane indication is indicated in the active driving display (Type A
instrument cluster
*1 ) or the multi
information display (Type B instrument
cluster
*1 ).
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-11 .
Indication on display
NOTE
y The LDWS remains on stand-by until it
detects white or yellow lines on both the
left and right sides, or on either side.
y When the system detects a white or
yellow line on one side only, the system
will operate the warning only when the
vehicle deviates to the side the white or
yellow line detected.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 248 of 592
4–122
When Driving
Lane Departure Warning System (LDWS)
Auto cancel
Under the following conditions, the
LDWS is automatically canceled and
kept on stand-by, and the LDWS warning
light (amber) in the instrument cluster
illuminates.
y The system cannot detect white or
yellow lines.
y The vehicle speed is less than about 65
km/h (40 mph).
y The vehicle is making a sharp turn. y The vehicle is making a turn at an
inadequate speed.
y The temperature inside the camera is
high or low.
y The windshield around the camera is
foggy.
y The windshield around the camera is
blocked by an obstruction, causing poor
forward visibility.
The lane indication (bordered line) is
indicated in the active driving display
(Type A instrument cluster
*1 ) or the multi
information display (Type B instrument
cluster
*1 ).
The LDWS is automatically enabled when
the condition changes and the system is
operable.
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-11 .
Auto cancel of warning
Under the following conditions, the
LDWS determines that the driver is
making lane changes and the warning is
automatically canceled.
The LDWS is automatically enabled after
the operation.
y The steering wheel is operated abruptly. y The brake pedal is depressed abruptly. y The accelerator pedal is depressed
abruptly.
y A turn signal lever is operated (after the
turn signal lever is returned, the LDWS
warning may not operate for about 3
seconds which is the period of time
required to make a lane correction).
NOTE
y After about 5 seconds have elapsed
with the turn signal lever left operating,
the LDWS warning may operate if the
vehicle is close to a white or yellow line.
y The sensitivity of the warning
(sensitivity with which the system
determines the driver's intentional lane
change) can be changed.
Refer to Personalization Features on page 9-12 .
Canceling The System
To cancel the LDWS, press the LDWS
switch. The LDWS indicator light (Green/
Amber) in the instrument cluster turns off.
The lane indication displayed in the
active driving display (Type A instrument
cluster
*1 ) or the multi information display
(Type B instrument cluster *1 ) turns off.
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-11 .
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 249 of 592
4–123
When Driving
Lane Departure Warning System (LDWS)
LDWS Warning
If the system determines that the vehicle
may be deviating from its lane while the
system is operating, the LDWS warning
sounds and the LDWS indicator light
(green) fl ashes.
Refer to Lane Departure Warning System
(LDWS) Warning Sound on page 7-37 .
In the active driving display (Type
A instrument cluster
*1 ) or the multi
information display (Type B instrument
cluster
*1 ), the direction in which the
system determined that the vehicle may
be deviating from its lane is indicated.
Operate the steering wheel adequately and
drive in the center of the lane.
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-11 .
Indication on display
NOTE
y If the LDWS warning sound is set to
rumble, the sound will be heard from
the vehicle speaker on the side which
the system determined the vehicle may
be deviating from its lane.
y The LDWS warning sound may not be
heard depending on the surrounding
conditions such as outside noise.
y The warning timing with which the
system determines the vehicle may be
deviating from its lane can be changed.
Refer to Personalization Features on page 9-12 .
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 250 of 592
![MAZDA MODEL 3 5-DOOR 2015 Owners Manual *Some models.4–124
When Driving
Rear View Monitor
Rear View Monitor *
The rear view monitor provides visual images of the rear of the vehicle \
when reversing.
WARNING
A](/img/28/40996/w960_40996-249.png "MAZDA MODEL 3 5-DOOR 2015 Owners Manual *Some models.4–124
When Driving
Rear View Monitor
Rear View Monitor *
The rear view monitor provides visual images of the rear of the vehicle \
when reversing.
WARNING
A")
*Some models.4–124
When Driving
Rear View Monitor
Rear View Monitor *
The rear view monitor provides visual images of the rear of the vehicle \
when reversing.
WARNING
Always drive carefully confi rming the safety of the rear and the surrounding conditions
by looking directly with your eyes: Reversing the vehicle by only looking at the screen is dangerous as it may cause an
accident or a collision with an object. The rear view monitor is only a visual assist device
when reversing the vehicle. The images on the screen may be diff erent from the actual
conditions.
CAUTION
