Page 148 of 592
*Some models.4–22
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
* Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light
*1
7-24
(Amber)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Warning Light *1 7-24
(Amber)
* Lane Departure Warning System (LDWS) Warning Light *1*3 7-24
* Headlight Auto-Leveling Malfunction Indicator Light *1 7-24
(Amber)
* High Beam Control System (HBC) Warning Light *1 7-24
(Amber)
* Mazda Radar Cruise Control (MRCC) Warning Light *1 7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
*3 The light turns on when the system on stand-by. The light fl ashes when the system has a malfunction.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 149 of 592
*Some models.4–23
When Driving
Instrument Cluster and Display
Indicator Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Indicator Lights Page
* BSM OFF Indicator Light 4-113
(Green)
* Lane Departure Warning System (LDWS) Indicator Light 4-121
(Green) KEY Indicator Light 3-9
(Green)
* High Beam Control System (HBC) Indicator Light
4-49
Wrench Indicator Light *1 4-25
TCS/DSC Indicator Light *1 4-79 ,
4-80
DSC OFF Indicator Light *1 4-81
* AFS OFF Indicator Light *1 4-45
(Red)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Indicator Light *1 4-117 , 4-77
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS) OFF
Indicator Light *1 4-77
* i-ELOOP Indicator Light 4-84
(Blue) Low Engine Coolant Temperature Indicator Light 4-25
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 169 of 592
![MAZDA MODEL 3 5-DOOR 2015 Owners Manual *Some models.4–43
When Driving
Switches and Controls
Xenon fusion headlight bulbs *
The low-beam bulbs of the headlights have xenon fusion bulbs that produc\
e a bright white
beam over a wide](/img/28/40996/w960_40996-168.png "MAZDA MODEL 3 5-DOOR 2015 Owners Manual *Some models.4–43
When Driving
Switches and Controls
Xenon fusion headlight bulbs *
The low-beam bulbs of the headlights have xenon fusion bulbs that produc\
e a bright white
beam over a wide")
*Some models.4–43
When Driving
Switches and Controls
Xenon fusion headlight bulbs *
The low-beam bulbs of the headlights have xenon fusion bulbs that produc\
e a bright white
beam over a wide area.
WARNING
Do not replace the xenon fusion bulbs yourself: Replacing the xenon fusion bulbs yourself is dangerous, because the xenon fusion
bulbs require high voltage. You could receive an electric shock if the bulbs are handled
incorrectly. Consult an Authorized Mazda Dealer when replacement is necessary.
NOTE
If the headlights fl icker or the brightness weakens, the bulb-life may be depleted and a
replacement is necessary. Consult an Authorized Mazda Dealer.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 170 of 592
*Some models.4–44
When Driving
Switches and Controls
Headlight High-Low Beam
The headlights switch between high and
low beams by moving the lever forward or
backward.
High beam
Low beam
When the headlight high-beams are on,
the headlight high-beam indicator light is
turned on.
Flashing the Headlights
T o fl ash the headlights, pull the lever fully
towards you (the headlight switch does not
need to be on).
OFF
Flashing
The headlight high-beam indicator light
in the instrument cluster illuminates
simultaneously. The lever will return to the
normal position when released.
Headlight Leveling *
The number of passengers and weight of
cargo in the luggage compartment change
the angle of the headlights.
Auto type
The angle of the headlights will be
automatically adjusted when turning on
the headlights.
The warning/indicator light turns on when
the system has a malfunction.
Refer to Warning/Indicator Lights on page
4-20 .
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 171 of 592
*Some models.4–45
When Driving
Switches and Controls
Manual type
The headlight leveling switch is used
to adjust the angle of the headlights
manually.
Select the proper headlight angle from the
following chart.
Front seat Rear
seat Load Switch
Position
Driver Passenger
× — — — 0
× × — — 0
× × × — 2
× × × × 2.5
(Between 2 and 3)
× — — × 3.5
(Between 3 and 4)
× : Y e s
—: No
Adaptive Front Lighting System (AFS)*
The adaptive front lighting system (AFS)
automatically adjusts the headlight beams
to the left or right in conjunction with the
operation of the steering wheel after the
headlights have been turned on.
AFS OFF Indicator Light
When illuminated
This indicator light illuminates briefl y
when the ignition is switched ON, and
then turns off. Pressing the AFS OFF
switch cancels the AFS function and
illuminates the indicator light.
When fl ashing
The indicator light fl ashes continuously if
the system is malfunctioning. Consult an
Authorized Mazda Dealer.
NOTE
y Even if the AFS is not operating due to
some malfunction, the normal headlight
function is still operable.
y If there is a malfunction with the
headlight auto-leveling function, the
indicator light fl ashes.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 173 of 592
![MAZDA MODEL 3 5-DOOR 2015 Owners Manual *Some models.4–47
When Driving
Switches and Controls
High Beam Control System (HBC) *
The High Beam Control System (HBC) determines the conditions in front \
of the vehicle
using the F](/img/28/40996/w960_40996-172.png "MAZDA MODEL 3 5-DOOR 2015 Owners Manual *Some models.4–47
When Driving
Switches and Controls
High Beam Control System (HBC) *
The High Beam Control System (HBC) determines the conditions in front \
of the vehicle
using the F")
*Some models.4–47
When Driving
Switches and Controls
High Beam Control System (HBC) *
The High Beam Control System (HBC) determines the conditions in front \
of the vehicle
using the Forward Sensing Camera (FSC) while driving in darkness to au\
tomatically switch
the headlights between high and low beams.
Refer to Warning/Indicator Lights on page 4-20 .
While driving the vehicle at a speed of about 30 km/h (18 mph), the he\
adlights are switched
to high beams when there are no vehicles ahead or approaching in the opp\
osite direction.
The system switches the headlights to low beams when one of the followin\
g occurs:
y The system detects a vehicle or the headlights/lights of a vehicle appro\
aching in the
opposite direction.
y The vehicle is driven on roads lined with streetlamps or on roads in wel\
l-lit cities and
towns.
y The vehicle is driven at less than about 20 km/h (12 mph).
Forward Sensing
Camera (FSC)
The recognition distance of the
Forward Sensing Camera (FSC)
varies according to the
surrounding conditions.
The warning light fl
ashes when the system has a malfunction.
Refer to Warning Lights on page 4-21 .
CAUTION
Page 174 of 592
![MAZDA MODEL 3 5-DOOR 2015 Owners Manual 4–48
When Driving
Switches and Controls
NOTE
The timing in which the system switches the headlights changes under the\
following
conditions. If the system does not switch the headlights appro](/img/28/40996/w960_40996-173.png "MAZDA MODEL 3 5-DOOR 2015 Owners Manual 4–48
When Driving
Switches and Controls
NOTE
The timing in which the system switches the headlights changes under the\
following
conditions. If the system does not switch the headlights appro")
4–48
When Driving
Switches and Controls
NOTE
The timing in which the system switches the headlights changes under the\
following
conditions. If the system does not switch the headlights appropriately, manually switch
between high and low beams according to the visibility as well as road and traffi c
conditions.
y When there are sources of light in the area such as street lamps, illuminated signboards,
and traffi c signals.
y When there are refl ective objects in the surrounding area such as refl ective plates and
signs.
y When visibility is reduced under rain, snow and foggy conditions. y When driving on roads with sharp curves or hilly terrain. y When the headlights/rear lamps of vehicles in front of you or in the opposite lane are dim
or not illuminated.
y When there is suffi cient darkness such as at dawn or dusk. y When the luggage compartment is loaded with heavy objects or the rear passenger seats
are occupied.
y When visibility is reduced due to a vehicle in front of you spraying water from its tires
onto your windshield.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 175 of 592
4–49
When Driving
Switches and Controls
To Operate the System
The High Beam Control System (HBC)
operates to switch the headlights
automatically between high and low
beams after the ignition is switched ON
and the headlight switch is in the AUTO
and high beam position. At the same time,
the High Beam Control System (HBC)
indicator light (green) in the instrument
cluster illuminates.
The High Beam Control System (HBC)
determines that it is dark based on the
brightness of the surrounding area.
NOTE
y When the vehicle speed is 30 km/h
(18 mph) or higher, the headlights
automatically switch to high beams
when there are no vehicles ahead or
approaching in the opposite direction.
When the vehicle speed is less than about 20 km/h (12 mph), the High Beam
Control System (HBC) switches the
headlights to low beams.
y The low beams may not switch to high
beams when cornering.
y Operation of the High Beam Control
System (HBC) function can be disabled.
Refer to Personalization Features on
page 9-12 .
Manual Switching
Switching to low beams
Shift the lever to the low beam position.
The High Beam Control System (HBC)
indicator light (Green) turns off.
Switching to high beams
Turn the headlight switch to the
position.
The High Beam Control System (HBC)
indicator light (Green) turns off and the
is illuminated.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 176 of 592
*Some models.4–50
When Driving
Switches and Controls
Fog Lights *
Use this switch to turn on the fog lights.
The fog lights will improve visibility at
night and during foggy conditions.
To turn the fog lights on, rotate the fog
light switch to the
position.
Fog light switch
The headlight switch must be in the
position before turning on the fog lights.
To turn the fog lights off, do any of the
following:
y Rotate the fog light switch to the
position. y Turn the headlight switch to the or
position.
NOTE
y The fog lights will turn off when the
headlights are set at high beams.
y (With auto-light control) If the fog light switch is in the
position and the headlight switch is in
the
position, the fog lights will
turn on when the headlights, the
exterior lights and dashboard
illumination turn on.
Turn and Lane-Change
Signals
The ignition must be switched ON to use
the turn and lane-change signals.
Turn Signals
Move the signal lever down (for a left
turn) or up (for a right turn) to the stop
position. The signal will self-cancel after
the turn is completed.
If the indicator light continues to fl ash
after a turn, manually return the lever to its
original position.
Right turn
Left turn
Right lane change
Left lane change OFF
The turn signal indicators (green) in the
instrument cluster fl
ash according to the
operation of the turn signal lever to show
which signal is working.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 188 of 592
*Some models.4–62
When Driving
Forward Sensing Camera
Forward Sensing Camera *
Your vehicle is equipped with a Forward Sensing Camera (FSC). The Forward Sensing
Camera (FSC) is positioned near the rearview mirror and used by the fo\
llowing systems.
y High Beam Control System (HBC) y Lane Departure Warning System (LDWS)
The Forward Sensing Camera (FSC) determines the conditions ahead of th\
e vehicle while
traveling at night and detects traffi c lanes. The distance in which the Forward Sensing
Camera (FSC) can detect objects varies depending on the surrounding co\
nditions.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
