DRIVER’S VIEW
Always check the Owner’s Manual for more operating information and safety features
1. Power window
switches*,see Switches
2. Door locks*, see Locks
3. Mirror controls*, see Switches
4. Xenon headlight leveling
switch*,see Getting Started
5. Air vents
6. Turn signal/lighting
control lever, see
Getting Started
7. Fog light switch*,see Getting Started8. Audio control switches*,see Getting Started
9. Horn/Air bag
To beep: Press
10. Cruise control*, see Getting Started11. Wiper/washer control
lever,see Getting Started
12. Hazard warning
switch
Push to activate/ deactivate
13. NAVI display*,see Owner’s Manual14. Information display,see Owner’s Manual15. Audio system,see Audio Systems
16. Passenger air bag
17. Bottle holder
CAUTION: Use plastic
bottles with caps, cups may
spill when door is closed
18. Passenger junction box19. NAVI DVD*20. Climate control panel,
see Climate Controls
21. Cigarette lighter
22. Ashtray
23. NAVI remote control*24. Parking-brake lever
To engage: Pull up
To release: Pull up slightly, while
depressing button at front of
lever, lower parking brake lever
Driver’s
View
Quick Tips Mazda MAZDA3 page 2
page 3
231
33
17
3426
28
27
2322
21
20
545166711513129108
29303231
21
17
1415
2524
1819
25. Center console
26. Cup holder
27. Gearshift lever,
see Transaxle
28. Passenger air bag
off indicator,
see Getting Started29. Tilt/telescopic steering
wheel lever,
see Getting Started
30. Hood release handle
Pull release handle to unlock
31. Instrument cluster
lighting,
see Getting Started
32. Storage
33. Fuel-filler lid release
To open: Pull lever up
34. Remote trunk-lid
release (4-Door only)
To open: Pull lever up
*If equipped

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Getting Started
MAZDA3 Quick Tips®are
designed to quickly familiarize
you with some important
features of your MAZDA3
The Driver’s View tab is your
index to the Quick Tips
®, locate
the item you would like to
learn more about and then
turn to the listed tab
This Getting Started section
contains important operating
tips about your MAZDA3
Items identified in blue text
call out important informationRemote
entry system*
Functions only
with ignition key
not inserted
To lock doors: Press
LOCK (1); pressing again within 5
seconds causes doors/liftgate to
re-lock, horn to beep onceand
hazard warning lights to flash
once if doors/liftgate properly closed
To unlock: Press UNLOCK (2) for
driver’s door, hazard warning
lights will flash twice, press again
within 5 seconds for all other doors
Panic alarm: Press (3); horn sounds,
parking lights flash; press any
button on transmitter to stop
After unlocking with the transmitter,
all doors or the liftgate will auto-
matically lock if a door or the liftgate
is not opened within about 30 seconds
Instrument panel lighting
With headlights ON:
To brighten/dim
turn thumbwheel
up/down
Headlights/parking lights
ON, ignition key must
be ON: Illumination
changes brightness
when dimmer switch (4) is pressed
(if equipped with black-out meter)
With headlights OFF
†, key ON:
Press instrument cluster dimmer
select button (4) to select
between 5 brightness settings
for instrument cluster
HID headlights leveling switch
Adjusts headlight angle
to compensate for
weight of passengers
and cargo, see
Owner’s Manual
approximately 66 lb., front
passenger air bag deactivation
indicator light illuminates,
air bag/pretensioner will not
deploy/activate in an accident
If the total seated weight
is greater than approximately
93 lb., light does not illuminate,
and the air bag/pretensioner will
deploy/activate in an appropriate
accident, see Owner’s Manual
for additional information on this
feature and the air bag system
Passenger sensing
operation
See Driver’s View
PAD indicator on dash will illuminate
when passenger side air bag is
deactivated, child-restraint seat
with child 66 lbs. or less will
deactivate front passenger side
air bag/pretensioner
See Owner’s Manual
Getting
Started
Getting
Started
Quick Tips Mazda MAZDA3 page 4
page 5
4
* If equipped †See Owner’s Manual
WARNINGS: Never place
rear-facing infant-safety
seat in front of any air bag,
an infant is in serious danger
of being injured or killed
If you must install a forward-
facing child-safety seat in the
front seating position, move
vehicle seat as far back as possible
Tire Pressure Monitoring
System (TPMS)*
Warning light illuminates for a
few seconds after ignition is on
If tire pressure is too high or too
low, or tire temperature is too
high warning light will illuminate
and beeper will sound
Fuel filler doorLocated on
passenger side
LOCK
UNLOCK1
2
3
Tilt/telescopic
steering-
wheel lever
Pull lever (5)
down to unlock
column, position
tilt angle and
length of steering
column position
Tip: Telescopic function allows
steering wheel to be adjusted
closer or farther according to
driver’s reach
WARNING: Do not adjust
steering-wheel while driving
Passenger air bag deactivation
indicator light
Front air bag deactivation indicator
light provides current status of
front passenger air bag and
pretensioner system
If total seated weight on front
passenger seat is less than
5


INSTRUMENT CLUSTER
Always check the Owner’s Manual for more operating information and safety features
WARNING LIGHTS
• Cruise control on*,see Getting Started
• Cruise control main
power on*,see Getting Started
• Tire Pressure Monitoring
System (TPMS)*,
see Getting Started
• Turn signals/hazard
warning on
• High beams on
• Engine oil-pressure
warning light
Stop car when safe and turn
off engine; check oil level
• Brake system
Parking brake on/low brake fluid
• Always fasten seat belts
• Security indicator light*
GAUGES
1. Fuel gauge
14.5-gallon/55-liter tank
(2.0L and 2.3L engines)
2. Odometer/Trip meter
3. Gear indicator (A/T only)*
Displays current gear
position
4. Tachometer
• Lights on
• Charging system
warning light
Charging system malfunction;
dealer inspection required
• Air bag/front seat belt
pretensioner system
If light flashes or stays on, the air
bags/front seat belt pretensioners
may not operate in an accident;
dealer inspection required
• Door-ajar
• Power steering
malfunction
Dealer inspection required if light
remains on
• Check engine
Dealer inspection required
• OLow fuel5. Instrument cluster
dimmer select button*,
see Getting Started
6. Speedometer
7. Odometer/Trip meter
selector
Press to view odometer; press
again to reset trip odometer
A/B settings
Instrument
Cluster
Instrument
Cluster
Quick Tips Mazda MAZDA3 page 8
page 9
nim/0001x
H
0 1 2 3 4567
8
P
TRIPA80.0
RNDM8
C
F
E
5748
6
1 32
hpm0 20 40
km/h6080100120
140
220 200 180
160
140
120
100
80
60
40
20
0
• Automatic
transaxle warning light
Automatic transaxle malfunction;
dealer inspection required
• Anti-lock Brake
System (ABS)*
ABS malfunction, normal brakes
only; dealer inspection required
When brake pedal is pressed,
ABS automatically reduces
hydraulic pressure to any wheel
on the verge of locking up
You may feel a slight pulsing
of the brake pedal and hear a
clicking noise; this tells you the
ABS is functioning properly;
increase pressure on pedal
for maximum braking
Tips: Maintain constant
pressure on the brake pedal
Do not pump the brakes
8. Engine coolant
temperature gauge
Stop car if above normal
range, turn off engine, let
vehicle cool; check coolant
level when safe
*If equipped
CRUISE
MAIN CRUISE

SEATS
Always check the Owner’s Manual for more operating information and safety features
Seat controls
1. Fore-aft adjustment
Lift lever and hold, slide seat,
release lever
2. Raise/lower seat
(Driver’s seat only)
Pull/push lever and release
3. Seat back angle
To adjust: Lift and hold lever,
lean forward or backward
to tilt seat, release lever4. Lumbar support
adjustment*
(Driver’s seat only)
Pull lever forward
5. Head restraint
To raise/lower: Pull up/hold
release button (6) and
push down
Tip: Side-impact air bags*
deploy from outboard
side of front seatbacks
Seats
Seats
Quick Tips Mazda MAZDA3 page 14
page 15
*If equipped
Shoulder belt
height
adjustment
To raise/
lower belt:
Pull button (7),
slide up/down,
release button
WARNING: Make sure
adjuster locks in one of
its positions
Safety belt emergency
locking mode
Belts lockonly on hard acceleration,
braking, cornering or impacts of
about 5 mph or more
Automatic locking mode
(front passenger and all
rear safety belts only)
Must be used when installing
child-safety seat
To activate: Pull webbing fully
out of retractor until click is heard;
belt will only tighten
To disengage: Unbuckle belt and
allow webbing to retract fullyWARNINGS: Do not adjust
seats while driving
Safety belts must always be
worn when vehicle is in motion
Air bags are supplemental
and do not replace safety
belt usage
Always wear your safety belt
and properly secure children
12 and under in the rear seat
Never place rear-facing
infant-safety seat in front
of any air bag, an infant is
in serious danger of being
injured or killed
If you must install a forward-
facing child-safety seat in the
front seating position, move
vehicle seat as far back as possible
4
6
21
3
5
7

SEATS
Always check the Owner’s Manual for more operating information and safety features
1. Air flow selections
= air to dash
= air to dash and floor
= air to floor
= air to floor and windshield
= defrost, air to windshield
2. Fan control
Rotate knob right/left to
increase/decrease speed, turn
to 0to shut system off
3. Temperature control
Rotate knob to blue for cool,
red for warm
4. Air Conditioning*
Press to activate/deactivate
Tip: Floor position
and both defrost positions
/ : A/C turns ON, air
intake switches to fresh air
5. Air Intake Control
Push switch to select
= recirculate inside air;
use for maximum heating/
cooling or to keep odors out
= fresh air
WARNING: Do not use
position in cold weather;
windows will fog and
hamper vision
6. Rear window defogger
Press to activate/deactivate
Child-safety seat
To install in rear outboard
seats: Use dual locking mode
retractor seat belts; see
Owner’s Manual for proper
installation and child seat
tether and LATCH system
instructions
Control positions for
maximum defrost
Fan to maximum, temperature to
maximum hot, air flow selector
knob to
Tips: When selected, air is
dried when temperature is
above 39°F
To prevent moisture buildup,
never drive with system off
Objects placed under the front
seats may interfere with air
flow to the rear
WARNING: Use age
appropriate child restraints,
see Owner’s Manual and
state or province laws
Seats
Climate
Controls
Quick Tips Mazda MAZDA3 page 16
page 17
MODE
04132
A/C
546
123
*If equipped
Split fold-down
rear seatbacks
To fold: Push release knob (1),
push seatback down
To return and lock: Push
seatback firmly until latched,
make sure seatbelts are returned
to original positionsTip: 4-Door has seatback
locks as part of trunk
security
11


TRUNK/CARGO AREA
Always check the Owner’s Manual for more operating information and safety features
Trunk/
Cargo Area
Trunk/
Cargo Area
Quick Tips Mazda MAZDA3 page 20
page 21
Luggage
compartment
internal safety
release
Allows you to escape
should you become locked in trunk
Slide illuminated release lever in
direction of arrow; lever will glow
if it has been exposed to light
Located on interior trunk lid MAZDA3 5-Door
1. Temporary spare tire
Stored under panel in trunk;
to change flat tire: Follow
instructions in Owner’s Manual
WARNING: Do not exceed
50 mph with temporary spare
Tip: Do not use temporary
spare tire for long periods
of time
Tire economy and tips
Check pressure at least monthly
when tires are cold
Tires should be of the same
make, kind and dimension
Maintain correct front-end
alignment and tire balance;
rotate tires at 7,500-mile
intervals; see Owner’s Manual
for rotation chartTire pressure
Decal on driver’s door provides
tire pressure information
Tire chains*
†Use only SAE Class “S” chains;
install on front tires as tightly
as possible and re-tighten
periodically; do not use chains
on dry roads, aluminum wheels,
or with tire pressure monitor
system, damage may occur,
use on steel wheels only2. Lug wrench
3. Jack handle
4. Cargo securing loops
5. Jack
6. Cargo light
7. Front tiedown eyelet
8. Cargo area cover
MAZDA3 4-Door
1. Temporary spare tire
Stored under panel in trunk;
to change flat tire: Follow
instructions in Owner’s Manual
WARNING: Do not exceed
50 mph with temporary spare
Tip: Do not use temporary
spare tire for long periods
of time
2. Lug wrench
3. Front tiedown eyelet
4. Jack
5. Jack handle
6. Cargo securing loops
7. Rear seatback lock
(4-Door only)
Lock or unlock: Move lever
8. Cargo light
164432587
2
8
415
76 76
3
*If equipped†See Owner’s Manual


UNDER HOOD
Always check the Owner’s Manual for more operating information and safety features
Under Hood
Quick Tips Mazda MAZDA3 page 22
page 23
1. Engine coolant reservoir
Level should be between COLD
FILL RANGE indicator marks
WARNING: Never remove
coolant reservoir cap while
engine is running or hot;
remove only when safe
2. Engine oil filler cap
See Owner’s Manual for
recommended engine oil viscosity
Break-in period
First 600 miles: Avoid heavy
braking and acceleration; drive at
varying road and engine speeds
Tip: Follow the same procedures
with newly overhauled engine
or when brakes are replaced
Tip: For additional service
intervals and complete details,
see Owner’s Manual
3. Brake/clutch fluid reservoir
Fill to MAX mark with DOT 3
fluid; check with cap on
Tip: Clutch uses same
reservoir as brakes
4. Automatic transaxle
fluid dipstick*
Check with transaxle in park,
engine on and at operating
temperature
Maintenance notes:
Rotate tires every 7,500
miles or sooner if needed
A. Replace: Engine oil/filter
B. Inspect: Cooling system, fuel
lines and hoses, brake lines,
hoses and connections,
steering operation and linkages,
front and rear suspension
and ball joints, drive-shaft
dust boots
Replace: Air filter
C. Inspect: Drive belts (tension)
D. Inspect: Hoses and tubes for
emission system
Replace: Engine coolant
E. Inspect: Engine valve clearance
Replace: Spark plugs
F. Inspect: Disc brakes
G. Inspect: Exhaust system and
heat shields 5. Battery
6. Fuse panel
Push latch in, lift cover must
be between the indicator
marks on the dipstick
7. Air filter
8. Hood latch
Pull up to release hood
9. Engine oil dipstick
Fluid should be between F and
L on dipstick; do not fill above F
10. Power steering fluid
reservoir
Level should be between
MIN and MAX lines
11. Windshield washer reservoir
Fill with windshield
washer fluidTip: Check all fluids with
vehicle parked on a level
surface and engine off
unless otherwise stated
12345
81110976
2.0/2.3-liter Engine
*If equipped†See Owner’s Manual
NORMAL SERVICE INTERVALS
5,000 miles†
7,500 miles
15,000 miles
22,500 miles
30,000 miles
37,500 miles
45,000 miles
52,500 miles
60,000 miles
67,500 miles
75,000 miles
82,500 miles
90,000 miles
A BF G A
A
C E F A A
B D F A A
F G A C A
BF A
A F A
A
