remote start MAZDA MODEL 3 HATCHBACK 2006 Quick Tips (in English)

DRIVER’S VIEW
Always check the Owner’s Manual for more operating information and safety features
1. Power window switches*,
see Switches
2. Door locks*, see Locks
3. Mirror controls*, see Switches
4. Xenon headlight leveling
switch*,see Getting Started
5. Air vents
6. Turn signal/lighting control
lever, see Getting Started7. Fog light switch*,see Getting Started8. Audio control switches*,see Getting Started
9. Horn/Air bag
To beep: Press
10. Cruise control*, see Getting Started11. Wiper/washer control
lever,see Getting Started
12. Hazard warning switch
Push to activate/deactivate
13. NAVI display*,see Owner’s Manual
14. Information display,see Information Display15. Audio system,see Audio Systems
16. Passenger air bag
17. Bottle holder
CAUTION: Use plastic
bottles with caps, cups may
spill when door is closed
18. Passenger junction box19. NAVI DVD*20. Climate control panel,
see Climate Controls
21. Cigarette lighter
22. Passenger air bag
off indicator,
see Getting Started
23. Ashtray
24. NAVI remote control*25. Parking-brake lever
To engage: Pull up
To release: Pull up slightly, while
depressing button at front of
lever, lower parking brake lever
Driver’s
View
231
34
17
3527
28
2423
20
545166711513129108
30313332
21
17
1415
2625
1819212229
26. Center console
27. Cup holder
28. Gearshift lever,
see Transaxle
29. Heated seats*,Press on/off
30. Tilt/telescopic steering
wheel lever,
see Getting Started
31. Hood release handle
Pull release handle to unlock
32. Instrument cluster
lighting,
see Getting Started
33. Storage
34. Fuel-filler lid release
To open: Pull lever up
35. Remote trunk-lid
release (4-Door only)
To open: Pull lever up
*Denotes optional equipment

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Getting Started
MAZDA3 Quick Tips®are
designed to quickly familiarize
you with some important
features of your MAZDA3
The Driver’s View tab is your
index to the Quick Tips
®, locate
the item you would like to
learn more about and then
turn to the listed tab
This Getting Started section
contains important operating
tips about your MAZDA3
Items identified in blue text
call out important informationRemote
entry system*
Functions only
with ignition key
not inserted
To lock doors: Press
LOCK (1); pressing again within 5
seconds causes doors/liftgate to
re-lock, horn to beep onceand
hazard warning lights to flash
once if doors/liftgate properly closed
To unlock: Press UNLOCK (2) for
driver’s door, hazard warning
lights will flash twice, press again
within 5 seconds for all other doors
Panic alarm: Press (3); horn sounds,
parking lights flash; press any
button on transmitter to stop
After unlocking with the transmitter,
all doors or the liftgate will auto-
matically lock if a door or the liftgate
is not opened within about 30 seconds
Instrument panel lighting
With headlights ON:
To brighten/dim
turn thumbwheel
up/down
Headlights/parking lights
ON, ignition key must
be ON: Illumination
changes brightness
when dimmer switch (4) is pressed
(if equipped with black-out meter)
With headlights OFF
†, key ON:
Press instrument cluster dimmer
select button (4) to select
between 5 brightness settings
for instrument cluster
HID headlights leveling switch
Adjusts headlight angle
to compensate for
weight of passengers
and cargo, see
Owner’s Manual
approximately 66 lb., front
passenger air bag deactivation
indicator light illuminates,
air bag/pretensioner will not
deploy/activate in an accident
If the total seated weight
is greater than approximately
93 lb., light does not illuminate,
and the air bag/pretensioner will
deploy/activate in an appropriate
accident, see Owner’s Manual
for additional information on this
feature and the air bag system
Passenger sensing
operation
See Driver’s View
PAD indicator on dash will
illuminate when passenger air
bag is deactivated, child-restraint
seat with child that weighs a
combined total of 66 lbs. or less
will deactivate front passenger
air bag/pretensioner
See Owner’s Manual
Getting
Started
Getting
Started
4
WARNINGS: Never place
rear-facing infant-safety
seat in front of any air bag,
an infant is in serious danger
of being injured or killed
If you must install a forward-
facing child-safety seat in the
front seating position, move
vehicle seat as far back as possible
Tire Pressure Monitoring
System (TPMS)*
Warning light illuminates for
a few seconds with ignition on
If tire pressure is low, warning
light illuminates with audible
beep sound, adjust tire pressure
to correct specifications, perform
tire pressure adjustment before
driving, a digital tire pressure
gauge is recommended
Flashing warning light may indicate
malfunction, dealer inspection required
LOCK
UNLOCK1
2
3
Tilt/telescopic
steering-
wheel lever
Pull lever (5)
down to unlock
column, position
tilt angle and
length of steering
column position
Tip: Telescopic function allows
steering wheel to be adjusted
closer or farther according to
driver’s reach
WARNING: Do not adjust
steering-wheel while driving
Passenger air bag deactivation
indicator light
Front air bag deactivation indicator
light provides current status of
front passenger air bag and
pretensioner system
If total seated weight on front
passenger seat is less than
5
*Denotes optional equipment†See Owner’s Manual

LOCKS
Always check the Owner’s Manual for more operating information and safety features
Power windows*
Ignition must be on
All windows controlled from the
driver’s armrest; passenger doors
have separate switches
1.Driver’s window: One-touch-
down; push down firmly and
release, window goes down
all the way; pull switch back
briefly to stop; press lightly and
hold for normal operation2.Passenger window
switches: Push down
and hold to open, pull
back and hold to close
3.Power window lockout switch:
Press down until it clicks, only
driver’s window operates;
press again and passenger
window switches function again
Locks
Switches
AUTO
1
3
2
Dual power mirrors*
Ignition must be in ACC or ON
To adjust left/right mirror:
Press control switch (1) left/right,
press switch (2) in direction of
desired mirror movement
Tip: To lock mirrors in
place, move control switch
to center position
Manual
mirrors
To adjust:
Move knob (3)
on door
1
23
Key
Operates ignition and
all locks
Tip: Use key number
plate to purchase a new
key; store in safe place
separate from vehicle
Remote
entry
system*,
see Getting
Started
Illuminated entry system
Activates interior lights when dome
light switch set to DOOR position;
lights off after driver’s door is
locked or ignition in ON positionPower door
locks*
Master
front door
locks
switches
To lock/unlock all doors:
Press bottom/top of switch (1)
To lock doors without key:
With door open, press bottom
of door lock switch, exit car,
close doors
To unlock: Use key to unlock
driver’s front door, rotate key to
counterclockwise position for
more than one second to unlock
other doors
Manual door locks
Lock button
To lock: Press front of button
(2) toward door handle
To unlock: Pull front of button
away from door handleChild-safety locks
Located at the edge of rear doors
To activate: Rotate childproof lock
(3) in direction of arrow using key
tip (doors open from outside only);
rotate in opposite direction
to deactivateWARNINGS: Since children
may access either rear door,
child-safety locks for both rear
doors should be activated
Never leave a child in car
with key in ignition
LOCKFERME3
LOCK UNLOCK
12
LOCK
UNLOCK
*Denotes optional equipment
