keyless MAZDA MODEL 3 HATCHBACK 2018 (in English) Owner's Manual

Personalization Features
The following personalization features can be set or changed by the customer or an Author-
ized Mazda Dealer. Consult an Authorized Mazda Dealer for detai ls.
Additionally, some of the personalization features can be chang ed by the customer depend-
ing on the feature.
Personalization features and settings which can be changed diff er depending on the market
and specification.
Settings Change Method
Settings can be changed by oper ating the center display screen.
A: Refer to Settings on page 5-50.
B: Refer to Fuel Economy Monitor on page 4-72.
C: Refer to Active Driving Display on page 4-20.
Settings can be changed by op erating the vehicle switches.
D: Refer to Auto Lock/Unlock Function on page 3-16.
E: Refer to Transmitter on page 3-4.
F: Refer to Locking, Unlocking with Request Switch (With the ad vanced keyless function)
on page 3-13.
Settings can be changed by an Authorized Mazda Dealer.
Item FeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Safety
Smart Brake
Support (SBS)
(page 4-128) The system can be ch
anged so that Smart
Brake Support (SBS) does not operate.
*1On On/Off A ―
The distance at which the collision warning ac-
tivates can be changed. Med Far/Med/Near A ―
The volume of the collision warning can be
changed.High High/Low/Off A ―
Smart City
Brake Support
(SCBS) (page
4-124)The system can be chan
ged so that Smart City
Brake Support (SCBS) does not operate.
*1On On/Off A ―
Specifications
Personalization Features
9-12
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Traffic Sign
Recognition
System (TSR)
*3
(page 4-90) The Traffic Sign Recognition System (TSR)
can be set to inoperable.
*1On On/Off A ―
The warning pattern of the excessive speed
warning can be changed.
OffOff/
Vis u a l /
Audio & Visual A―
The activation timing fo
r the excessive speed
warning can be changed.00/5/10 A―
Ve h i c l e
Door locks
(page 3-16) Operation condition of a
uto lock/unlock func-
tion Lock: When
Driving, Un- lock: IGN OFF Off/
Lock When Driving/
Lock: Driving, Unlock: IGN Off/
Lock When
Shifting Out Of P/
Lock: Shift
From P, Unlock: In P/
Lock: Driving, Unlock: In P AD
Keyless entry
system (page 3-
3)
Method for unlocking door using transmitter
Once: Driv-
er's, Twice: All Doors Touch Once: All
Doors/
Once: Driver's, Twice: AllDoors AE
Time for locking door automatically
60 seconds90 seconds/
60 seconds/
30 seconds A―
Specifications
Personalization Features
9-14
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Index
A
Accessory Socket............................ 5-132
Active Driving Display..................... 4-20
Adaptive Front Lighting System
(AFS)................................................. 4-80
Add-On Non-Genuine Parts and
Accessories........................................ 8-19
Advanced Key
Advanced keyless entry system..... 3-9
Operational range........................ 3-10
Advanced Key removed from vehicle
warning beep..................................... 7-39
Air Bag Systems............................... 2-44
Air Bag/Front Seat Belt Pretensioner
System Warning Beep....................... 7-38
Ambient Temperature Display.......... 4-17
Antilock Brake System (ABS).......... 4-66
Audio Control Switch
Adjusting the Volume.................. 5-53
Mute switch................................. 5-54
Seek Switch................................. 5-53
Audio System.................................... 5-16 Antenna........................................5-16
Audio Control Switch................. 5-53
Audio set [Type A (non-
touchscreen)]............................... 5-26
Audio set [Type B
(touchscreen)].............................. 5-32
AUX/USB mode..........................5-54
Operating Tips for Audio
System......................................... 5-17
Satellite Radio........ ..................... 5-44
Automatic Transaxle......................... 4-32 Active Adaptive Shift (AAS)...... 4-34
Automatic transaxle controls....... 4-32
Direct mode................................. 4-41
Driving tips..................................4-42
Manual shift mode.......................4-35
Shift-lock system......................... 4-33
Transaxle ranges.......................... 4-33
B
Battery............................................... 6-33
Maintenance.................................6-35
Replacement................................ 6-35
Specifications.................................9-4
Battery runs out.................................7-16 Jump-Starting...............................7-16
Blind Spot Monitoring (BSM).......... 4-84
Canceling operation of Blind Spot
Monitoring (BSM).......................4-89
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-41
Bluetooth®........................................ 5-69 Bluetooth® audio (Type A)....... 5-111
Bluetooth® audio (Type B)....... 5-114
Bluetooth® Hands-Free (Type
A)................................................. 5-94
Bluetooth® Hands-Free (Type
B)............................................... 5-101
Troubleshooting........... .............. 5-125
Body Lubrication.............................. 6-28
Bottle Holder................................... 5-135
Brakes Brakes assist................................ 4-64
Electric parking brake (EPB)...... 4-61
Foot brake....................................4-60
Pad wear indicator....................... 4-63
Parking brake...............................4-61
Warning light............................... 4-63
Break-In Period................................. 3-45
C
Capacities............................................ 9-5
Carbon Monoxide......... .................... 3-27
Cell Phones....................................... 8-20
Center Console................................ 5-136
Child Restraint Categories of child-restraint
systems.........................................2-25
10-2
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
Inspecting Engine Oil Level............. 6-24
Inspecting Washer Fluid Level......... 6-27
Interior Care...................................... 6-69Active driving display
maintenance................................. 6-71
Cleaning the floor mats............... 6-72
Cleaning the window interiors.....6-71
Instrument panel top (Soft pad)
maintenance................................. 6-71
Leather upholstery
maintenance................................. 6-70
Panel maintenance....................... 6-71
Plastic part maintenance.............. 6-71
Seat belt maintenance..................6-69
Upholstery and synthetic leather
maintenance................................. 6-70
Vinyl upholstery maintenance..... 6-69
Interior Lights................................. 5-130 Luggage Compartment Light.....5-130
Map Lights................................ 5-130
Overhead Lights........................ 5-130
i-ACTIVSENSE................................ 4-77
Active safety tec hnology............. 4-77
Adaptive Front Lighting System
(AFS)........................................... 4-80
Blind Spot Monitoring (BSM).....4-84
Camera and sensors..................... 4-78
Distance Recognition Support System
(DRSS).........................................4-96
Forward Sensing Camera
(FSC)......................................... 4-131
High Beam Control System
(HBC).......................................... 4-81
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-113
Mazda Radar Cruise Control
(MRCC)..................................... 4-102
Pre-crash safety technology.........4-78
Radar sensors (rear)...................4-139
Radar sensor (front)...................4-136Rear Cross Traffic Alert
(RCTA)........................................ 4-98
Smart Brake Support (SBS)...... 4-128
Smart City Brake Support
(SCBS)....................................... 4-124
Traffic Sign Recognition System
(TSR)........................................... 4-90
i-ELOOP............................................4-70 Control status display.................. 4-70
Display......................................... 4-70
i-ELOOP indicator l ight.............. 4-70
i-ELOOP warning beep .....................7-40
J
Jack...................................................... 7-4
Jump-Starting.................................... 7-16
K
Keyless Entry System......................... 3-3
Keys.....................................................3-2
Key suspend function.................... 3-8
Transmitter.............. .......................3-4
Key left-in-luggage compartment
warning beep (With the advanced keyless
function)............................................ 7-40
Key left-in-vehicle warning beep (With
the advanced keyless function)......... 7-40
Key removed from vehicle warning
beep................................................... 7-39
Key Suspend Function........................ 3-8
L
Label Information............................... 9-2
Lane Departure Warning sound........ 7-40
Lane-Change Signals........................ 4-49
Lane-keep Assist System (LAS) & Lane
Departure Warning System
(LDWS)........................................... 4-113
Leaving Home Light......................... 4-47
Liftgate.............................................. 3-20
10-5
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
Theft-Deterrent System..................... 3-43
TiedownHook.............. .............................. 7-23
Tires................................................... 6-38
Flat Tire......................................... 7-3
Replacing a Tire.......................... 6-40
Replacing a Wheel...................... 6-41
Snow tires.................................... 3-48
Specifications...............................9-10
Temporary Spare Tire..................6-40
Tire chains................................... 3-49
Tire Inflation Pressure................. 6-38
Tire Rotation................................6-39
Uniform tire quality grading system
(UTQGS)..................................... 8-23
Tire inflation pressure warning
beep................................................... 7-40
Tire Information................................ 8-25
Tire Pressure Monitoring System.... 4-146
To w i n g
Recreational towing.....................3-52
Trailer Towing............................. 3-52
Towing Description........................... 7-22
Traction Control System (TCS)........ 4-67 TCS/DSC Indicator Light............4-67
Traffic Sign Recognition System
(TSR)................................................. 4-90
Transmitter.......................................... 3-4
Trip Computer................................... 4-18
Trip Meter......................................... 4-13
Trouble Battery runs out........................... 7-16
Emergency Starting..................... 7-19
Emergency Towing......................7-22
Flat Tire......................................... 7-3
Overheating................................. 7-20
Parking in an Emergency.............. 7-2
When liftgate/trunk lid cannot be
opened..........................................7-43
Trunk Lid.......................................... 3-20
Inside trunk release lever............ 3-24When liftgate/trunk lid cannot be
opened..........................................7-43
V
Vanity Mirrors................................. 5-129
Vehicle Information Labels................. 9-2
W
Warning Lights.................................. 4-24
Warning Message Indicated on
Display.............................................. 7-36
Warning Sound is Activated............. 7-38
Advanced Key removed from vehicle
warning beep............................... 7-39
Air Bag/Front Seat Belt Pretensioner
System Warning Beep................. 7-38
Blind Spot Monitoring (BSM)
warning beep............................... 7-41
Collision warning...... .................. 7-41
Electric Parking Brake (EPB)
Warning Beep.............................. 7-42
Excessive speed warning.............7-41
Ignition not switched off (STOP)
warning beep............................... 7-39
i-ELOOP warning beep............... 7-40
Key left-in-luggage compartment
warning beep (With the advanced
keyless function)..........................7-40
Key left-in-vehicle warning beep
(With the advanced keyless
function).......................................7-40
Key removed from vehicle warning
beep..............................................7-39
Lane Departure Warning sound... 7-40
Lights-on reminder...................... 7-38
Mazda Radar Cruise Control
(MRCC) System warnings.......... 7-41
Over Rev. buzzer......................... 7-41
Power steering warning buzzer....7-41
Seat belt warning beep................ 7-38
10-8
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
