Engine Oil
NOTE
Changing the engine oil should be
performed by an Authorized Mazda
Dealer.
Refer to Introduction (page 6-2) for
owner's responsibility in protecting your
investment.
▼Recommended Oil
U.S.A., Canada, and Puerto Rico
Use SAE 0W-20 engine oil.
Mazda Genuine Oil is used in your Mazda
vehicle. Mazda Genuine 0W-20 Oil is
required to achie
ve optimum fuel
economy.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol
® (U.S.A. only).


(ILSAC)
Only use SAE 0W-20 oil “Certified For
Gasoline Engines” by the American
Petroleum Institute (API).
Oil with this tradem ark symbol conforms
to the current engine and emission system
protection standards and fuel economy
requirements of the International
Lubricant Standardization and Approval
Committee (ILSAC), comprised of U.S.
and Japanese automobile manufacturers.

80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
Except U.S.A., Canada, and Puerto Rico
Use SAE 5W-30 engine oil.
Oil container labels provide important
information.
A chief contribution th
is type of oil makes
to fuel economy is reducing the amount of
fuel necessary to overcome engine
friction.

Maintenance and Care
Owner Maintenance
6-23
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol
® (Mexico only).


(ILSAC)
(Mexico)
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 5W-20
engine oil.

The quality designation SM, or ILSAC
must be on the label.

80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
▼ Vehicle Engine Control Unit Reset
Procedure
After replacing the engine oil, it is
recommended to have a repair shop such
as an Authorized Mazda Dealer perform
the initialization (engin
e oil data resetting)
of the recorded value. If the value
recorded by the computer is not initialized,
the wrench indicator light may not turn off
or it may turn on earlier than normal.
Refer to Maintenance Monitor on page
6-16.
▼ Inspecting Engine Oil Level
1. Be sure the vehicle is on a level
surface.
2. Warm up the engine to normal operating temperature.
3. Turn it off and wait at least 5 minutes for the oil to retur n to the oil pan.
4. Pull out the dipstic k, wipe it clean, and
reinsert it fully.

MAX
OK
MIN
Maintenance and Care
Owner Maintenance
6-24
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Battery Maintenance
To get the best service from a battery:
Keep it securely mounted.
Keep the top clean and dry.
Keep terminals and connections clean,
tight, and coated with
petroleum jelly or
terminal grease.
Rinse off spilled electrolyte immediately
with a solution of water and baking
soda.
If the vehicle will not be used for an
extended time, disconnect the battery
cables and charge the battery every six
weeks.
▼ Battery Replacement
Contact an Authorized Mazda Dealer for a
battery replacement purchase.
Key Battery Replacement
If the buttons on the transmitter are
inoperable and the operation indicator
light does not flash, the battery may be
dead.
Replace with a new b
attery before the
transmitter becomes unusable.
CAUTION
 Make sure the battery is installed
correctly. Battery leakage could occur if it
is not installed correctly.
 When replacing the battery, be careful
not to touch any of the internal circuitry
and electrical terminals, bend the
electrical terminals, or get dirt in the
transmitter as the transmitter could be
damaged.
 There is the danger of explosion if the
battery is not correctly replaced.
 Dispose of used batteries according to
the following instructions.
 Insulate the plus and minus terminals
of the battery using cellophane or
equivalent tape.
 Never disassemble.
 Never throw the battery into fire or
water.
 Never deform or crush.
 Replace only with the same type battery
(CR2025 or equivalent).
Maintenance and Care
Owner Maintenance
6-35
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Jump-Starting
Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel
unsure about jump-starting, we strongly recommend that you have a competent service
technician do the work.
WA R N I N G
Follow These Precautions Carefully:
To ensure safe and correct handling of the ba ttery, read the following precautions carefully
before using the battery or inspecting it.
Do not allow the positive () terminal to contact any other metal object that could
cause sparks:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during
normal battery operation, could ignite and caus e the battery to explode. An exploding battery
can cause serious burns and injuries. When working near a battery, do not allow metal tools
to contact the positive (
) or negative () terminal of the battery.
Keep all flames, including cigarettes, and sparks away from open battery cells:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during
normal battery operation, could ignite and caus e the battery to explode. An exploding battery
can cause serious burns and injuries.
Do not jump-start a frozen battery or one with a low fluid level:
Jump-starting a frozen battery or one with a lo w fluid level is dangerous. It may rupture or
explode, causing serious injury.
Connect the negative cable to a good ground point away from the battery:
Connecting the end of the second jumper cable to the negative (
) terminal of the discharged
battery is dangerous.
A spark could cause the gas around the battery to explode and injure someone.
Route the jumper cables away from parts that will be moving:
Connecting a jumper cable near or to moving pa rts (cooling fans, belts) is dangerous. The
cable could get caught when the engine starts and cause serious injury.
If Trouble Arises
Battery Runs Out
7-16
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Towing Description
We recommend that towing be done only
by an Authorized Mazda Dealer or a
commercial tow-truck service.

Proper lifting and towing are necessary to
prevent damage to the vehicle.
Government and local laws must be
followed.

A towed vehicle usually should have its
drive wheels (front wheels) off the ground.
If excessive damage or other conditions
prevent this, use wheel dollies.
Wheel dollies

When towing with the rear wheels on the
ground, release the parking brake.
Refer to Parking Brake on page 4-61.
Refer to Electric Parking Brake (EPB) on
page 4-61.
CAUTION
 Do not tow the vehicle pointed backward
with driving wheels on the ground. This
may cause internal damage to the
transaxle.
Do not tow with sling-type equipment.
This could damage your vehicle. Use
wheel-lift or flatbed equipment.
If Trouble Arises
Emergency Towing
7-22
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Customer Assistance (U.S.A.)
Your complete and permanent satisfaction is our business. We are here to serve you. All
Authorized Mazda Dealers have the knowledge and the tools to ke ep your Mazda vehicle in
top condition.
If you have any questions or recommendations for improvement re garding the service of
your Mazda vehicle or servicing by Mazda Dealer personnel, we r ecommend that you take
the following steps:
NOTE
If it becomes necessary to have the components or wiring system for the supplementary
restraint system modified to accommodate a person with certain medical conditions in
accordance with a certified physician, contact an Authorized Mazda Dealer. For more
information, go to NHTSA website www.safercar.gov (VEHICLE SHOPPERS > Air Bags >
Air Bag FAQs > Air Bag Deactivation).
▼ STEP 1: Contact Your Mazda Dealer
Discuss the matter wi
th an Authorized Mazda Dealer. This is the quickest and best way to
address the issue.
If your concern has not been resolved by the CUSTOMER RELATIONS , SALES,
SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of
the dealership or the OWNER.
If it becomes necessary to have the components or wiring system for the supplementary
restraint system modified to accommodate a person with certain medical conditions in
accordance with a certified physician, go to STEP 2.
▼STEP 2: Contact Mazda No
rth American Operations
If for any reason you feel the need for further a ssistance after contacting your dealership
management or it becomes necessary to have the components or wi ring system for the
supplementary restrai nt system modified to accommodate a person with certain medical
conditions in accordance with a certified physician, you can re ach Mazda North American
Operations by one of the following ways.

Log on: at www.MazdaUSA.com

Answers to many questions, including how to locate or contact a local Mazda dealership in
the U.S., can be found here.

E-mail: click on "Contact Us" loc ated on the bottom of the page at www.mazdausa.com
under "Help"

Customer Information and Reporting Safety Defects
Customer Assistance
8-2
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

6. You are required to use BBB AUTO LINE before asserting in court any rights or
remedies conferred by California Civil Code Section 1793.22. Yo u are also required to
use BBB AUTO LINE before exercising rights or seeking remedies created by Title I of
the Magnuson-Moss Warranty Act, 15 U.S.C. sec. 2301 et seq. If you choose to seek
redress by pursuing rights and remedies not created by Californ ia Civil Code Section
1793.22 or Title I of the Magnuson-Moss Warranty Act, resort to BBB AUTO LINE is
not required by those statutes.
7. California Civil Code Section 1793.2 (d) requires that, if Ma zda or its representative is
unable to repair a new motor vehicle to conform to the vehicle' s applicable express
warranty after a reasonable number of attempts, Mazda may be re quired to replace or
repurchase the vehicle. Califor nia Civil Code Section 1793.22 ( b) creates a presumption
that Mazda has had a reasonable number of attempts to conform t he vehicle to its
applicable express warranties if, within 18 months from deliver y to the buyer or 18,000
miles on the vehicle's odometer, whichever occurs first, one or more of the following
occurs:
The same nonconformity [a failure to conform to the written warranty that
substantially impairs the use, value or safety of the vehicle] results in a condition that
is likely to cause death or serious bodily injury if the vehicl e is driven AND the
nonconformity has been subject to repair two or more times by M azda or its agents
AND the buyer or lessee has directly notified Mazda of the need fo r the repair of the
nonconformity; OR
The same nonconformity has been subject to repair 4 or more times by Mazda or its
agents AND the buyer has notified Mazda of the need for the repair of the
nonconformity; OR
The vehicle is out of service by reason of repair of nonconformities by Mazda or its
agents for a cumulative total of more than 30 calendar days aft er delivery of the
vehicle to the buyer.

NOTICE TO Mazda AS REQUIRED ABOVE SHALL BE SENT TO THE
FOLLOWING ADDRESS:
Mazda North American Operations
200 Spectrum Center Drive
Irvine, California 92618
ATTN: Customer Mediation

8. The following remedies may be sought in BBB AUTO LINE: repair s, reimbursement for
money paid to repair a vehicle or other expenses incurred as re sult of a vehicle
nonconformity, repurchase or replacement of your vehicle, and c ompensation for
damages and remedies available under Mazda's written warranty o r applicable law.
Customer Information and Reporting Safety Defects
Customer Assistance
8-5
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Customer Assistance (Canada)
▼Satisfaction Review Process
Your complete and permanent satisfaction is of primary concern
to Mazda. All Authorized
Mazda Dealers have both the knowledge and tools to keep your Ma zda in top condition. In
our experience, any questions, pro blems, or complaints regarding the operation of your
Mazda or any other general service transactions are most effect ively resolved by your
dealer. If the cause of your dissatisfaction cannot adequately be addressed by normal
dealership procedures, we recommend that you take the following steps:
▼STEP 1: Contact the Mazda Dealer
Discuss the matter with a member of dealership management. If t
he Service Manager has
already reviewed your concerns, contact the owner of the dealership or its General Manager.
▼STEP 2: Contact the
Mazda Regional Office
If you feel that you still requ ire assistance, ask the dealer S ervice Manager to arrange for
you to meet the local Mazda Service Representative. If more exp edient, contact Mazda
Canada Inc. Regional Office nearest you for such arrangements. Regional Office address
and phone numbers are shown (page 8-9).
▼ STEP 3: Contact the Mazda Cu
stomer Relations Department
If still not substantially satisfied, contact the Customer Rela tions Department, Mazda
Canada Inc., 55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Ca nada TEL: 1 (800)
263-4680.
Provide the Department wit h the following information:

1. Your name, address and telephone number
2. Year and model of vehicle
3. Vehicle Identification Number ( VIN). Refer to the Vehicle Identification Number on
page 9-2 for the location of the VIN.
4. Purchase date
5. Present odometer reading
6. Your dealer's name and location
7. The nature of your problem and/or cause of dissatisfaction

The Department, in cooperation wi th the local Mazda Service Representative, will review
the case to determine if everything possible has been done to e nsure your satisfaction.

Please recognize that the resolution of service problems in mos t cases requires the use of
your Mazda dealer's service facilities, personnel and equipment . We urge you to follow the
above three steps in sequenc e for most effective results.
Customer Information and Reporting Safety Defects
Customer Assistance
8-7
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Mediation/Arbitration Program
Occasionally a customer concern cannot be resolved through Mazd
a's Customer Satisfaction
Program. If after exhausting the procedures in this manual your concern is still not resolved,
you have another option.

Mazda Canada Inc. participates in an arbitration program admini stered by the Canadian
Motor Vehicle Arbitration Plan (CAMVAP). CAMVAP will advise you about how your
concern may be reviewed and resolved by an independent third pa rty through binding
arbitration.

Your complete satisfaction is the goal of Mazda Canada Inc. and our dealers.
Mazda's participation in CAMVAP makes a valuable contribution t o our achieving that goal.
There is no charge for using CAMVAP. CAMVAP results are fast, f air and final as the
award is binding on both you and Mazda Canada Inc.
▼ Canadian Motor Vehicle A
rbitration Plan (CAMVAP)
If a specific item of concern arises, where a solution cannot b e reached between an owner,
Mazda, and/or one of its dealers (that all parties cannot agree upon), the owner may wish to
use the services offered by the Canadian Motor Vehicle Arbitrat ion Plan (CAMVAP).

CAMVAP uses the services of Prov incial Administrators to assist consumers in scheduling
and preparing for their arbitration hearings. However, before y ou can proceed with
CAMVAP you must follow your Mazda dispute resolution process as outlined previously.

CAMVAP is fully imple mented in all provinces and territories.
Consumers wishing to obtain further information about the Progr am should contact the
Provincial Administrator at 1 ( 800) 207-0685, or by contacting the Canadian Motor Vehicle
Arbitration Plan Office at:

Canadian Motor Vehicle Arbitration Plan
235 Yorkland Boulevard, suite 300
North York, Ontario
M2J 4Y8
http://camvap.ca
Provincial Administrators may be reached locally:
Province/Territory CAMVAP Number
British Columbia & Yukon Te rritories 1 (800) 207-0685
Alberta & Northwest Territories 1 (800) 207-0685
Saskatchewan 1 (800) 207-0685
Manitoba 1 (800) 207-0685
Customer Information and Reporting Safety Defects
Customer Assistance
8-8
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Customer Assistance (Puerto Rico)
Your complete and permanent satisfaction is our business. That is why all Authorized
Mazda Dealers have the knowledge and the tools to keep your Maz da vehicle in top
condition.
If you have any questions or recommendations for improvement re garding the service of
your Mazda vehicle or servicing by Mazda Dealer personnel, we r ecommend that you take
the following steps:
▼ STEP 1
Discuss the matter wi
th an Authorized Mazda Dealer. This is the quickest and best way to
address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS,
SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL
MANAGER of the dealership or the OWNER.
▼ STEP 2
If, after following STEP 1, you feel the need for further assis
tance, please contact your
area's Mazda representative.
Refer to Importer/Distributor on page 8-13.

Please help us by providing t he following information:

1. Your name, address, and telephone number
2. Year and model of vehicle
3. Vehicle Identification Number ( 17 digits, noted on your registration or title or located on
the upper driver's side corner of the dash)
4. Purchase date and current mileage
5. Your dealer's name and location
6. Your question(s)
Customer Information and Reporting Safety Defects
Customer Assistance
8-10
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
