child restraint MAZDA MODEL 3 HATCHBACK 2018 (in English) Owner's Guide

LATCH lower anchor location
WA R N I N G
Always remove the head restraint and set
the tether strap (except when installing a
backless booster seat):
Routing the tether strap on top of the head
restraint is dangerous. In a collision the
tether strap could slide off the head
restraint and loosen the child-restraint
system. The child-restraint system could
move which may result in death or injury to
the child.
Anchor bracket
Tether strap
(4-Door)
Tether strap
Forward
(5-Door)
Always attach the tether strap to the
correct tether anchor position:
Attaching the tether strap to the incorrect
tether anchor position is dangerous. In a
collision, the tether strap could come off
and loosen the child-restraint system. If the
child-restraint system moves it could result
in death or injury to the child.
Always install the head restraint and adjust
it to the appropriate position after
removing the child-restraint system:
Driving with the head restraint removed is
dangerous as impact to the occupant's
head cannot be
prevented during
emergency braking or in a collision, which
could result in a serious accident, injury or
death.
Refer to Head Restraints on page 2-10.
Essential Safety Equipment
Child-Restraint
2-43
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

If your vehicle is also equipped with a front passenger occupant classification system,
refer to the Front Pas senger Occupant Classi fication System (page 2-61) for details.
If your vehicle is equipped with a front passenger occupant classification system, the front
passenger air bag deactivation i ndicator light illuminates for a specified time after the
ignition is switched ON.


Small children mu st be protected by a child-restraint system as stipulated by law in every
state and province. In certain s tates and provinces, larger children must use a child-restraint
system (page 2-20).

Carefully consider which child-restraint system is necessary fo r your child and follow the
installation directions in this Owner's Manual as well as the c hild-restraint system
manufacturer's instructions.
WA R N I N G
Seat belts must be worn in air bag equipped vehicles:
Depending only on the air bags for protection during an accident is dangerous. Alone, air
bags may not prevent serious injuries. The appr opriate air bags can be expected to inflate
only in the first accident, such as frontal, near frontal or side collisions or roll-over accidents
that are at least moderate. Vehicle occu pants should always wear seat belts.

Children should not ride in the front passenger seat:
Placing a child, 12 years or under, in the front seat is dangerous. The child could be hit by a
deploying air bag and be seriously injured or even killed. A sleeping child is more likely to lean
against the door and be hit by the side air ba g in moderate collision to the front-passenger
side of the vehicle. Whenever possible, alwa ys secure a child 12 years and under on the rear
seats with an appropriate child-restraint system for the child's age and size.
Essential Safety Equipment
SRS Air Bags
2-45
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Never use a rear-facing child-restraint system in the front seat with an air bag that could
deploy:
Rear-facing child-restraint systems on the front seat are particularly dangerous even though
you may feel assured that a front passenger air ba g will not deploy based on the fact that the
front passenger air bag deactivation indicator ligh t illuminates. The child-restraint system can
be hit by a deploying air bag and moved violen tly backward resulting in serious injury or
death to the child.
Do not sit too close to the driver and front passenger air bags:
Sitting too close to the driver and front passenger air bag modules or placing hands or feet on
them is extremely dangerous. The driver and fr ont passenger air bags inflate with great force
and speed. Serious injuries could occur if someone is too close. The driver should always hold
onto only the rim of the steering wheel. The front seat passenger should keep both feet on the
floor. Front seat occupants should adjust their seats as far back as possible and always sit
upright against the seatbacks wi th seat belts worn properly.
Sit in the center of the seat and wear seat belts properly:
Sitting too close to the side air bag modules or placing hands on them, or sleeping up against
the door or hanging out the windows is extrem ely dangerous. The side and curtain air bags
inflate with great force and speed directly expanding
along the door on the side the car is hit.
Serious injury could occur if someone is sitting too close to the door or leaning against a
window, or if rear seat occupants grab the sides of the front seatbacks. Give the side and
curtain air bags room to work by sitting in th e center of the seat while the vehicle is moving
with seat belts worn properly.
Do not attach objects on or around the area where driver and front passenger air bags
deploy:
Attaching an object to the driver and front passenger air bag modules or placing something
in front of them is dangerous. In an accide nt, an object could interfere with air bag
inflation
and injure the occupants.
Essential Safety Equipment
SRS Air Bags
2-46
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Properly dispose of the air bag system:
Improper disposal of an air bag or a vehicle with live air bags in it can be extremely
dangerous. Unless all safety procedures are followed, injury could result. Have an Authorized
Mazda Dealer safely dispose of the air bag sy stem or scrap an air bag equipped vehicle.
NOTE
If it becomes necessary to have the components or wiring system for the supplementary
restraint system modified to accommodate a person with certain medical conditions in
accordance with a certified physician, contact an Authorized Mazda Dealer, refer to
“Customer Assistance (U.S.A.)” (page 8-2).
When an air bag deploys, a loud inflation noise can be heard and some smoke will be
released. Neither is likely to cause injury, however, the text ure of the air bags may cause
light skin injuries on body parts not covered with clothing through friction.
Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and
that familiarization with all instructions about them, from the Owner's Manual, is
important.
This highly-visible label is displayed wh ich warns against the use of a rear-facing
child-restraint system on the front passenger seat.

(Except Mexico) (Mexico)
Essential Safety Equipment
SRS Air Bags
2-50
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Front passenger air bag deactivation indicator light on/off condition chart
Condition detected by the front
passenger occupant classifica- tion system Front passenger air
bag deactivation indi- cator light Front passenger front
and side air bags Front passenger seat
belt pretensioner sys- tem
Empty (Not occupied) On Deactivated Deactivated
A child less than 1 year old is
seated in a child-restraint system On Deactivated Deactivated
Child
*1On or off Deactivated or ready Deactivated or ready
Adult
*2Off Ready Ready
*1 The occupant classification sens or may not detect a child seated on the seat, in a child-restraint system, or a
junior seat depending on the ch ild's physical size and seated posture.
*2 If a smaller adult sits on the front passenger seat, the sensors might detect the person as being a child
depending on the person's physique.
The curtain air bag is ready for inflating regardless of what the front passenger air bag
deactivation indicator light on/off condition chart indicates.
If the front passenger air bag deactivation indicator light doe s not turn on when the ignition
is switched ON and does not turn on as indicated in the front p assenger air bag deactivation
indicator light on/off condition chart, do not allow an occupan t to sit in the front passenger
seat and consult an Authorized M azda Dealer as soon as possible. The system may not work
properly in an accident.
WA R N I N G
Do not allow an occupant in the front passenger's seat to sit with a posture which makes it
difficult for the front passenger occupant classification sensor to detect the occupant
correctly:
Sitting in the front passenger's seat with a posture which makes it difficult for the front
passenger occupant classification sensor to detect the occupant correctly is dangerous. If the
front passenger occupant classification sensor cann ot detect the occupant sitting on the front
passenger's seat correctly, the front passenger front and side air bags and pretensioner system
may not operate (non-deploy) or they may oper ate (deploy) accidentally. The front passenger
will not have the supplementary protection of the air bags or the accidental operation
(deployment) of the air bags could result in serious injury or death.
Under the following conditions, the front passe nger occupant classification sensor cannot
detect a passenger sitting on the front pa ssenger's seat correctly and the deployment/
non-deployment of the air bags cannot be controlled as indicated in the front passenger air
bag deactivation indicator light on/off condition chart. For example:
Essential Safety Equipment
SRS Air Bags
2-62
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

A front passenger is seated as shown in the following
figure:
A rear passenger pushes up on the front passenger seat with their feet.
 Luggage or other items placed under the front passenger seat or between the front
passenger seat and driver seat that pu sh up the front passenger seat bottom.
 An object, such as a seat cushion, is put on the front passenger's seat or between the
passenger's back and the seatback.
 A seat cover is put on the front passenger's seat.
 Luggage or other items are placed on the seat with the child in the child-restraint system.
 A rear passenger or luggage push or pull down on the front passenger seatback.
 Luggage or other items are placed on the seatback or hung on the head restraint.
 The seat is washed.
 Liquids are spilled on the seat.
 The front passenger seat is moved backward, pushing into luggage or other items placed
behind it.
 The front passenger seatback contacts the rear seat.
 Luggage or other items are placed between the front passenger seat and driver seat.
 An electric device is put on the front passenger's seat.
 An additional electrical device, such as a seat warmer is installed to the surface of the front
passenger seat.
Essential Safety Equipment
SRS Air Bags
2-63
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

The front passenger front and side air bags and seat belt pretensioner systems will deactivate
if the front passenger air bag deactivation indicator light turns on.
CAUTION
To assure proper deployment of the front air bag and to prevent damage to the sensor in
the front seat cushion:
 Do not place sharp objects on the front seat cushion or leave heavy luggage on them.
 Do not spill any liquids on the front seats or under the front seats.
 To allow the sensors to function pr operly, always perform the following:
 Adjust the front seats as far back as possibl e and always sit upright against the seatbacks
with seat belts worn properly.
 If you place your child on the front passenger seat, secure the child-restraint system
properly and slide the fron t passenger seat as far back as possible (page 2-33).
NOTE
The system requires about 10 seconds to alte rnate between turning the front passenger
front and side air bags and seat belt pretensioner system on or off.
The front passenger air bag deactivation indicato r light may turn on repeatedly if luggage
or other items are put on the front passenger seat, or if the temperature of the vehicle's
interior changes suddenly.
The front passenger air bag deactivation indicato r light may turn on for 10 seconds if the
electrostatic capacity on the front passenger seat changes.
The air bag/front seat belt pretensioner system warning light might turn on if the front
passenger seat receives a severe impact.
If the front passenger air bag deactivation indicator light does not turn on after installing
a child-restraint system on the front passenger seat, first, re-install your child-restraint
system according to the procedure in this owner's manual. Then, if the front passenger air
bag deactivation indicator light still does not tu rn on, install the child-restraint system on
the rear seat and consult an Authorized Mazda Dealer as soon as possible.
If the front passenger air bag deactivation i ndicator light turns on when an occupant is
seated directly in the front passenger seat, have the passenger re-adjust their posture by
sitting with their feet on the floor, and th en re-fastening the seat belt. If the front
passenger air bag deactivation i ndicator light remains turned on, move the passenger to
the rear seat. If sitting in the rear seat is no t possible, slide the front passenger seat as far
back as possible. Consult an Authorized Mazda Dealer as soon as possible.
Essential Safety Equipment
SRS Air Bags
2-64
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
A
Accessory Socket............................ 5-132
Active Driving Display..................... 4-20
Adaptive Front Lighting System
(AFS)................................................. 4-80
Add-On Non-Genuine Parts and
Accessories........................................ 8-19
Advanced Key
Advanced keyless entry system..... 3-9
Operational range........................ 3-10
Advanced Key removed from vehicle
warning beep..................................... 7-39
Air Bag Systems............................... 2-44
Air Bag/Front Seat Belt Pretensioner
System Warning Beep....................... 7-38
Ambient Temperature Display.......... 4-17
Antilock Brake System (ABS).......... 4-66
Audio Control Switch
Adjusting the Volume.................. 5-53
Mute switch................................. 5-54
Seek Switch................................. 5-53
Audio System.................................... 5-16 Antenna........................................5-16
Audio Control Switch................. 5-53
Audio set [Type A (non-
touchscreen)]............................... 5-26
Audio set [Type B
(touchscreen)].............................. 5-32
AUX/USB mode..........................5-54
Operating Tips for Audio
System......................................... 5-17
Satellite Radio........ ..................... 5-44
Automatic Transaxle......................... 4-32 Active Adaptive Shift (AAS)...... 4-34
Automatic transaxle controls....... 4-32
Direct mode................................. 4-41
Driving tips..................................4-42
Manual shift mode.......................4-35
Shift-lock system......................... 4-33
Transaxle ranges.......................... 4-33
B
Battery............................................... 6-33
Maintenance.................................6-35
Replacement................................ 6-35
Specifications.................................9-4
Battery runs out.................................7-16 Jump-Starting...............................7-16
Blind Spot Monitoring (BSM).......... 4-84
Canceling operation of Blind Spot
Monitoring (BSM).......................4-89
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-41
Bluetooth®........................................ 5-69 Bluetooth® audio (Type A)....... 5-111
Bluetooth® audio (Type B)....... 5-114
Bluetooth® Hands-Free (Type
A)................................................. 5-94
Bluetooth® Hands-Free (Type
B)............................................... 5-101
Troubleshooting........... .............. 5-125
Body Lubrication.............................. 6-28
Bottle Holder................................... 5-135
Brakes Brakes assist................................ 4-64
Electric parking brake (EPB)...... 4-61
Foot brake....................................4-60
Pad wear indicator....................... 4-63
Parking brake...............................4-61
Warning light............................... 4-63
Break-In Period................................. 3-45
C
Capacities............................................ 9-5
Carbon Monoxide......... .................... 3-27
Cell Phones....................................... 8-20
Center Console................................ 5-136
Child Restraint Categories of child-restraint
systems.........................................2-25
10-2
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
Child-restraint precautions.......... 2-20
Child-restraint system suitability for
various seat positions table..........2-27
Installing child-restraint
systems.........................................2-31
LATCH child-restraint systems... 2-40
Child Safety Locks fo r Rear Doors... 3-19
Climate Control System...................... 5-2 Automatic Climate Control........... 5-9
Dual-Zone Automatic Climate
Control......................................... 5-12
Gas specifications.......................... 9-9
Manual Climate Control................5-5
Operating Tips............................... 5-2
Vent Operation...............................5-3
Clock................................................. 5-29
Collision warning.............................. 7-41
Coming Home Light......................... 4-46
Control Status Display ...................... 4-73
Cruise Control................................. 4-141 Cruise Control Switch............... 4-141
Cruise Control Set Vehicle Speed
Display.............................................. 4-17
Cup Holder...................................... 5-134
Customer Assistance.... ....................... 8-2
D
Dashboard Illumination. ....................4-16
Daytime Running Lights................... 4-47
Defogger Mirror...........................................4-54
Rear window........... .................... 4-53
Dimensions.......................................... 9-6
Distance Recognition Support System
(DRSS).............................................. 4-96 Indication on display................... 4-97
Door Locks........................................ 3-11
Drive selection.................................. 4-74
Driving In Flooded Ar ea...................3-50
Driving on Uneven Road.................. 3-51
Driving Tips
Automatic transaxle.....................4-42
Break-in period............................ 3-45
Driving in flooded a rea............... 3-50
Driving on uneven road...............3-51
Floor mat..................................... 3-46
Hazardous driving.. ..................... 3-46
Overloading............. .................... 3-50
Rocking the vehicle. .................... 3-47
Winter driving............................. 3-48
Dynamic Stability Control (DSC)..... 4-68 DSC OFF Indicator Light............4-69
DSC OFF Switch.........................4-69
TCS/DSC Indicator Light............4-68
E
Electric parking brake (EPB)............ 4-61
Electric Parking Brake (EPB) Warning
Beep...................................................7-42
Emergency StartingPush-Starting............................... 7-19
Starting a Flooded Engine........... 7-19
Emergency Towing Tiedown Hooks........................... 7-23
Towing Description..................... 7-22
Emission Control System..................3-26
Ending Screen Display......................4-73
Engine Coolant.........................................6-25
Engine Compartment
Overview..................................... 6-22
Exhaust gas..................................3-27
Hood release................................ 6-20
Oil................................................ 6-23
Starting...........................................4-5
Essential information.......................... 6-2
Event Data Recorder......................... 8-21
Excessive Speed Warning................. 7-41
Exhaust Gas...................................... 3-27
Exterior Care..................................... 6-63
10-3
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
