â–¼Locking, Unlocking with Auxiliary
Key
Turn the auxiliary key
toward the front to
lock, toward the back to unlock.
To l o c k
All doors and the liftgate/trunk lid lock
automatically when th e driver's door is
locked using the auxiliary key.
To u n l o c k
The driver’s door unlocks when the
auxiliary key is turned briefly to the
unlock position and then immediately
returned to the center position.
All doors and the liftgate/trunk lid unlock
when the driver's door is unlocked and the
auxiliary key is held i n the unlock position
for one second or longer.
Lock Unlock
â–¼
Locking, Unlocking with Request
Switch (With the advanced keyless
function)
All doors and the liftgate/trunk lid can be
locked/unlocked by pressing the request
switch on the front d
oors while the key is
being carried.
(5–door)
The request switch on the liftgate can only
be used to lock all doors and the liftgate.
Front doors
Request switch
Liftgate (5-door Lock only)
Request switch
To l o c k
To lock the doors and the liftgate/trunk lid,
press the request switch and the hazard
warning lights will flash once.
A beep sound will be heard once.
To unlock
Driver's door request switch
To unlock the driver's door, press the
request switch. A beep sound will be heard
twice and the hazard warning lights will
flash twice.
To unlock all doors and the liftgate/trunk
lid, press the reques t switch again within
three seconds and two more beep sounds
will be heard.
Before Driving
Doors and Locks
3-13
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Front passenger door request switch
To unlock all doors and the liftgate/trunk
lid, press the request switch. A beep sound
will be heard twic e and the hazard
warning lights will flash twice.
NOTE
ï‚·The system can be set to unlock all
doors by performing a single operation.
Refer to Personalization Features on
page 9-12.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all
of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer (the sound of the
doors locking/unlocking can be
heard).
After this, the system switches the
setting of pressing the driver's
request switch once or twice to
unlock all doors and the liftgate/
trunk lid each time the UNLOCK
button is pressed (the sound of the
doors locking/unlocking can be
heard).
4. The setting change is completed by
doing any one of the following:
ï‚·Switching the igni tion to ACC or
ON.
ï‚·Closing the driver's door.
ï‚·Opening the liftgate/trunk lid.
ï‚·Not operating the key for ten
seconds.
ï‚·Pressing any button except the
UNLOCK button on the key.
ï‚·Pressing a request switch.
ï‚·Confirm that all doors and the liftgate/
trunk lid are securely locked.
For the liftgate/trunk lid, move it
without pressing the electric liftgate/
trunk lid opener to verify that the
liftgate/trunk lid has not been left ajar.
ï‚·All doors and the liftgate/trunk lid
cannot be locked when any door or the
liftgate is open.
ï‚·It may require a few seconds for the
doors to unlock after the request switch
is pressed.
ï‚·A beep sound is heard for confirmation
when the doors and the liftgate/trunk lid
are locked/unlocked using the request
switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also
be changed. Refer to Personalization
Features on page 9-12.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all
of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
Before Driving
Doors and Locks
3-14
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

3. Within 30 seconds of opening thedriver's door, press and hold the
LOCK button on the key for 5
seconds or longer (All of the doors
and the liftgate are locked and
unlocked when the LOCK button on
the key is pressed and held for 5
seconds.).
The beep sound activates at the
currently set volume. The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)
4. The setting change is completed by
doing any one of the following:
ï‚·Switching the ignition to ACC or
ON.
ï‚·Closing the driver's door.
ï‚·Opening the liftgate/trunk lid.
ï‚·Not operating the key for ten
seconds.
ï‚·Pressing any button except the
LOCK button on the key.
ï‚·Pressing a request switch.
ï‚·(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-43.
ï‚·The setting can be changed so that the
doors and the liftgate/trunk lid are
locked automatically without pressing
the request switch.
Refer to Personalization Features on
page 9-12.
(Auto-lock function)
A beep sound is heard when all doors
and the liftgate are closed while the
advanced key is being carried. All doors
and the liftgate/trunk lid are locked
automatically after about three seconds
when the advanced key is out of the
operational range. Also, the hazard
warning lights flas h once. (Even if the
driver is in the operational range, all
doors and the liftgate/trunk lid are
locked automatical ly after about 30
seconds.) If you are out of the
operational range before the doors and
the liftgate/trunk lid are completely
closed or another key is left in the
vehicle, the auto-lock function will not
work. Always make sure that all doors
and the liftgate/trunk lid are closed and
locked before leaving the vehicle. The
auto-lock function does not close the
power windows.
ï‚·Auto re-lock function
After unlocking with the request switch,
all doors and the liftgate/trunk lid will
automatically lock if any of the
following operations are not performed
within about 60 seconds. If your vehicle
has a theft-deterrent system, the hazard
warning lights will flash for
confirmation.
The time required for the doors to lock
automatically can be changed.
Refer to Personalization Features on
page 9-12.
Before Driving
Doors and Locks
3-15
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

ï‚·Opening a door or the liftgate/trunk
lid.
ï‚·Switching the ignition to any position
other than off.
â–¼Locking, Unlocking with
Transmitter
All doors and the liftg
ate/trunk lid can be
locked/unlocked by operating the keyless
entry system transmitt er, refer to Keyless
Entry System (page 3-3).
â–¼ Locking, Unlocking with Door-Lock
Switch
All doors and the liftgate/trunk lid lock
automatically when the lock side is
pressed. They unlock when the unlock
side is pressed.
Driver's door
Unlock
Lock
Front passenger's door
UnlockLock
To lock all the doors and the liftgate/trunk
lid from an open front door, press the lock
side of the door lock switch and then close
the door.
NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.
â–¼
Auto Lock/Unlock Function
WA R N I N G
Do not pull the inner handle on a front
door:
Pulling the inner handle on a front door
while the vehicle is moving is dangerous.
Passengers can fall out of the vehicle if the
door opens accidentally , which could
result in death or serious injury.
ï‚·When the vehicle speed exceeds 20
km/h (12 mph), all doors and the
liftgate/trunk lid lock automatically.
ï‚·When the ignition is switched off, all
doors and the liftgate/trunk lid unlock
automatically.
These functions can also be disabled so
that they do not operate.
Auto lock/unlock f unction setting
change using door-lock switch
The doors and the liftg ate/trunk lid can be
set to lock or unlock automatically by
selecting any one of the functions from the
following table and using the driver's
door-lock switch on the interior door
panel.
Before Driving
Doors and Locks
3-16
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

NOTE
ï‚·Function number 3 in the following
table is the factory setting for your
vehicle.
ï‚·There are only a total of five auto lock/
unlock settings available for automatic
transaxle vehicles, and three for manual
transaxle vehicles. Be sure to press the
unlock side of the driver's door-lock
switch the correct number of times
according to the selected function
number. If the switch is mistakenly
pressed six times on an automatic
transaxle vehicle or four times on a
manual transaxle, the procedure will be
cancelled. If this occurs, start the
procedure from the beginning.
Function number Function*1
1The auto door-lock function is disa-
bled.
2 All the doors and the liftgate/trunk lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more.
3 (Factory Setting) All the doors and the liftgate/trunk lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more. All the doors
and the liftgate/
trunk lid unlock wh en the ignition is
switched from ON to Off.
4 (Automatic transaxle vehicles only)
When the ignition is switched ON
and the shift lever is shifted from park
(P) to any other g
ear position, all the
doors and the lift gate/trunk lid lock
automatically.
Function number Function*1
5(Automatic transaxle vehicles only)
When the ignition is switched ON
and the shift lever is shifted from park
(P) to any other gear position, all the
doors and the liftgate/trunk lid lock
automatically.
When the shift lever is shifted to park
(P) while the ignition is switched ON,
all the doors and the liftgate/trunk lid
unlock automatically.
*1 Other settings for the au
to door lock function are
available at an Authorized Mazda Dealer. For
details consult an Authorized Mazda Dealer.
Refer to Personalization Features on page 9-12.
Settings can be changed using the
following procedure.
1. Safely park the vehicle. All doors must remain closed.
2. Switch the ignition ON.
3. Press and hold the lock side of the driver's door-lock switch within 20
seconds of switching the ignition ON,
and make sure a beep sound is heard
about eight seconds afterwards.
4. Refer to the auto lock/unlock function
setting table, determine the function
number for the desi red setting. Press
the unlock side of the driver's
door-lock switch the same number of
times as the selected function number
(Ex. If you select function 2, press the
unlock side of the switch only 2 times).
5. Three seconds after the function setting has been changed, a beep sound
will beep in the amount of the selected
function number. (Ex. Function
number 3 = 3 beep sounds)
Before Driving
Doors and Locks
3-17
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

(Manual transaxle vehicles)
Press 2 times
Press 3 times
Current Function Number
Function Number 1
Function Number 2
Function Number 3 Press 4 times
Press unlock side of
lock switch once
Cancel setting Cancel setting
Function set (The
number of beeps
heard is the same as
the selected function
number)
Press lock side of
lock switch
Wait for 3 second
(Automatic transaxle vehicles)
Press unlock side of
lock switch once
Press 2 times
Press 3 times
Current Function Number
Function Number 1
Function Number 2 Press 4 times
Function Number 3
Press 5 times
Function Number 4
Press 6 times
Function Number 5
Cancel setting Cancel setting
Function set (The
number of beeps
heard is the same as
the selected function
number)
Press lock side of
lock switch
Wait for 3 second
NOTE
ï‚·The doors cannot be locked or unlocked
while the setting function is being
performed.
ï‚·The procedure can be cancelled by
pressing the lock side of the driver's
door-lock switch.
â–¼
Locking, Unlocking with Door-Lock
Knob
Operation from inside
To lock any door from the inside, press the
door-lock knob.
To unlock, pull it outward.
This does not operate the other door locks.

Lock
Unlock
Unlocked: Red indicator
Before Driving
Doors and Locks
3-18
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Operation from outside
To lock the rear and front passenger doors
with the door-lock knob from the outside,
press the door-lock knob to the lock
position and close the door (holding the
door handle in the open position is not
required).
This does not operate the other door locks.

Door-lock knob
NOTE
When locking the door this way:
ï‚·Be careful not to leave the key inside the
vehicle.
ï‚·The driver's door lock knob cannot be
used while the driver's door is open.
â–¼ Rear Door Child Safety Locks
These locks are intended to help prevent
children from accidentally opening the
rear doors. Use them on both rear doors
whenever a child rides in the rear seat of
the vehicle.

If you slide the chil
d safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can only be opened by pulling
the outside handle.

Lock Unlock
Before Driving
Doors and Locks
3-19
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Liftgate/Trunk Lid
WA R N I N G
Never allow a person to ride in the luggage
compartment/trunk:
Allowing a person to ride in the luggage
compartment/trunk is dangerous. The
person in the luggage compartment/trunk
could be seriously injured or killed during
sudden braking or a collision.
Do not drive with the liftgate/trunk lid
open:
Exhaust gas in the cabin of a vehicle is
dangerous. An open liftgate/trunk lid in a
moving vehicle will cause exhaust gas to be
drawn into the cabin. This gas contains CO
(carbon monoxide), which is colorless,
odorless, and highly poisonous, and it can
cause loss of consciousness and death.
Moreover, an open liftgate/trunk lid could
cause occupants to fall out in an accident.
Do not stack or leave loaded luggage
unsecured in the luggage compartment:
Otherwise, the luggage may move or
collapse, resulting in injury or an accident.
In addition, do not load luggage higher
than the seatbacks. It may affect the side or
rear field of view.
CAUTION
 Before opening the liftgate/trunk lid,
remove any snow and ice accumulation
on it. Otherwise, the liftgate/trunk lid
could close under the weight of the snow
and ice resulting in injury.
Be careful when opening/closing the
liftgate/trunk lid during strong winds. If a
strong gust blows against the liftgate/
trunk lid, it could close suddenly resulting
in injury.
 Fully open the liftgate/trunk lid and
make sure that it stays open. If the
liftgate/trunk lid is only opened partially,
it could slam shut by vibration or wind
gusts resulting in injury.
 When loading or unloading luggage in
the luggage compartment/trunk, turn
off
the engine. Otherwise, you could get
burned by the heat of the exhaust gas.
 Be careful not to apply excessive force to
the damper stay on the liftgate such as
by putting your hand on the stay.
Otherwise, the damper stay may bend
and
affect the liftgate operation.
Damper stay

Do not modify or replace the liftgate
damper stay. Consult an Authorized
Mazda Dealer if a liftgate damper stay is
deformed or damaged for reasons such
as a collision or if there is some other
problem.
Before Driving
Doors and Locks
3-20
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

â–¼Opening and Closing the Liftgate/
Trunk Lid
Opening the liftgate (5–door)
Using the electri
c liftgate opener
Unlock the doors and liftgate, then press
the electric liftgate op ener on the liftgate
and raise it when the latch releases.

Electric liftgate
opener
NOTE
(With the advanced keyless function)
ï‚·A locked liftgate can also be opened
while the key is being carried.
ï‚·When opening the liftgate with the doors
and the liftgate locked, it may require a
few seconds for the liftgate latch to
release after the electric liftgate opener
is pressed.
ï‚·The liftgate can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the liftgate can be
opened by pressing the electric liftgate
opener. If the liftgate cannot be opened
despite doing this procedure, first push
the liftgate/trunk lid completely closed,
then press the electric liftgate opener to
fully open the liftgate.
ï‚·When the liftgate latch is released by
pressing the electric liftgate opener, the
liftgate raises slightly. If the liftgate is
not operated for a certain period of
time, the liftgate cannot be raised.
To open
Press the electric liftgate/trunk lid
opener again.
To c l o s e
To close the liftgate/trunk lid from its
slightly raised position, open it first by
pressing the electric liftgate/trunk lid
opener, then close it after waiting at
least 1 second.
ï‚·If the liftgate is not fully closed, the
driver is notified by a warning indicated
in the instrument cluster.
ï‚·If the vehicle battery is dead or there is
a malfunction in the electrical system
and the liftgate cannot be unlocked, the
liftgate can be opened by performing the
emergency procedure.
Refer to When Liftgate/Trunk Lid
Cannot be Opened on page 7-43.
Opening the trunk lid (4–door)
Using the remote release button
Push the release button.

Before Driving
Doors and Locks
3-21
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Using the electric trunk lid opener
(With the advanced keyless function)
A trunk lid can also be opened while the
key is being carried.
Press the electric trunk lid opener on the
trunk lid, then raise the trunk lid when the
latch releases.

Electric trunk lid
opener
NOTE
ï‚·When opening the trunk lid with the
doors locked, it may require a few
seconds for the trunk lid latch to release
after the electric trunk lid opener is
pressed.
ï‚·The trunk lid can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the trunk lid can be
opened by pressing the electric trunk lid
opener. If the trunk lid cannot be opened
despite doing this procedure, press the
electric trunk lid opener to fully open
the trunk lid after pushing the trunk lid
completely closed.
ï‚·If the vehicle battery is dead or there is
a malfunction in the electrical system
and the trunk lid cannot be unlocked,
the trunk lid can be opened by
performing the emergency procedure.
Refer to When Liftgate/Trunk Lid
Cannot be Opened on page 7-43.
Closing the liftgate/trunk lid
Lower the liftgate/trunk lid slowly using
the liftgate/trunk lid grip recess, then push
the liftgate/trunk lid closed using both
hands.
Do not slam it. Pull up on the liftgate/
trunk lid to make sure it is secure.
(5–door)

Liftgate grip
recess
(4–door)

Trunk lid grip recess
Before Driving
Doors and Locks
3-22
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
