▼Dimensions
4-Door
(U.S.A. and Canada)
Item
Vehicle specification
Overall length 4,580 mm (180.3 in)
Overall width 1,795 mm (70.7 in)
Overall height 1,455 mm (57.3 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
(Mexico)
ItemVehicle specification
Overall length 4,580 mm (180.3 in)
Overall width 1,795 mm (70.7 in)
Overall height 1,450 mm (57.1 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
5-Door
(U.S.A. and Canada)
ItemVehicle specification
Overall length 4,470 mm (176.0 in)
Overall width 1,795 mm (70.7 in)
Overall height
*1Type A 1,470 mm (57.9 in)
Type B 1,455 mm (57.3 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
Specifications
Specifications
9-6
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Index
Child-restraint precautions.......... 2-20
Child-restraint system suitability for
various seat positions table..........2-27
Installing child-restraint
systems.........................................2-31
LATCH child-restraint systems... 2-40
Child Safety Locks fo r Rear Doors... 3-19
Climate Control System...................... 5-2 Automatic Climate Control........... 5-9
Dual-Zone Automatic Climate
Control......................................... 5-12
Gas specifications.......................... 9-9
Manual Climate Control................5-5
Operating Tips............................... 5-2
Vent Operation...............................5-3
Clock................................................. 5-29
Collision warning.............................. 7-41
Coming Home Light......................... 4-46
Control Status Display ...................... 4-73
Cruise Control................................. 4-141 Cruise Control Switch............... 4-141
Cruise Control Set Vehicle Speed
Display.............................................. 4-17
Cup Holder...................................... 5-134
Customer Assistance.... ....................... 8-2
D
Dashboard Illumination. ....................4-16
Daytime Running Lights................... 4-47
Defogger Mirror...........................................4-54
Rear window........... .................... 4-53
Dimensions.......................................... 9-6
Distance Recognition Support System
(DRSS).............................................. 4-96 Indication on display................... 4-97
Door Locks........................................ 3-11
Drive selection.................................. 4-74
Driving In Flooded Ar ea...................3-50
Driving on Uneven Road.................. 3-51
Driving Tips
Automatic transaxle.....................4-42
Break-in period............................ 3-45
Driving in flooded a rea............... 3-50
Driving on uneven road...............3-51
Floor mat..................................... 3-46
Hazardous driving.. ..................... 3-46
Overloading............. .................... 3-50
Rocking the vehicle. .................... 3-47
Winter driving............................. 3-48
Dynamic Stability Control (DSC)..... 4-68 DSC OFF Indicator Light............4-69
DSC OFF Switch.........................4-69
TCS/DSC Indicator Light............4-68
E
Electric parking brake (EPB)............ 4-61
Electric Parking Brake (EPB) Warning
Beep...................................................7-42
Emergency StartingPush-Starting............................... 7-19
Starting a Flooded Engine........... 7-19
Emergency Towing Tiedown Hooks........................... 7-23
Towing Description..................... 7-22
Emission Control System..................3-26
Ending Screen Display......................4-73
Engine Coolant.........................................6-25
Engine Compartment
Overview..................................... 6-22
Exhaust gas..................................3-27
Hood release................................ 6-20
Oil................................................ 6-23
Starting...........................................4-5
Essential information.......................... 6-2
Event Data Recorder......................... 8-21
Excessive Speed Warning................. 7-41
Exhaust Gas...................................... 3-27
Exterior Care..................................... 6-63
10-3
