Interior Equipment (View A)
▼Interior Equipment (View A)
ƒ
High beam control switch..................................................................................... page 4-89
„ Lighting control.....................................................................................................page 4-43
… Turn and lane-change sig nals................................................................................ page 4-49
† Audio remote control switches.................................. ............................................page 5-19
‡ INFO switch.......................................................................................................... page 4-14
ˆ Cruise control switches.....................................................page 4-120, 4-129, 4-141, 4-210
‰ Wiper and washer lever......................................... ................................................ page 4-50
Š i-ACTIVSENSE switch............................................ ............................................ page 4-85
‹ 360° view monitor switch...................................................................................page 4-173
ΠParking sensor switch......................................................................................... page 4-237
 DSC OFF switch................................................................................................... page 4-77
Ž Position memory buttons.......................................................................................page 2-10
 Trunk release button.............................................................................................. page 3-19
 Outside mirror switches........................................................................................ page 3-29
‘ Power window switches........................................................................................ page 3-34
’ Power window lock switch................................................................................... page 3-34
“ Door-lock switch................................................................................................... page 3-15
” Door-lock knob..................................................................................................... page 3-17
Pictorial Index
Interior Overview
1-2The equipment and installatio n position varies by vehicle
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Interior Equipment (View C)
▼Interior Equipment (View C)
ƒ
Head restraint........................................................................................................ page 2-1 7
„ Front seat................................................................................................................. page 2-5
… Seat belt...................................................... ........................................................... page 2-23
† Bottle holder.................................................. ........................................................ page 5-39
‡ Vanity mirror......................................................................................................... page 5-3 3
ˆ Sunvisor.................................................................................................................page 5-33
‰ Overhead light (fr ont)/Map lights.............................. ........................................... page 5-34
Š Overhead console.................................................................................................. page 5-41
‹ Moonroof switch................................................................................................... page 3-36
ΠRearview mirror.................................................................................................... page 3-31
 Vent........................................................... .............................................................. page 5-3
Ž Cup holder..................................................... ........................................................ page 5-38
 Shift lever/Selector lever..................................... ........................................ page 4-30, 4-32
 Drive selection switch......................................... .................................................. page 4-78
‘ Commander switch................................................................................................page 5-17
’ Electric Parking Brake (EPB) switch............................ ........................................ page 4-63
“ AUTOHOLD switch................................................ ............................................. page 4-70
Pictorial Index
Interior Overview
1-4The equipment and installation position varies by vehicle
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Interior Equipment (View D)
▼Interior Equipment (View D)
ƒ
Push knob (5-door)................................................................................................page 2-14
„ Head restraint........................................................................................................ page 2-1 7
… Child safety lock................................................................................................... page 3-18
† Rear coat hook.......................................................................................................page 5-40
‡ Power window switch........................................................................................... page 3-34
ˆ Overhead light (rear).......................................... ................................................... page 5-34
‰ Door-lock knob................................................. .................................................... page 3-17
Š Assist grip.................................................... ..........................................................page 5-39
‹ Center console....................................................................................................... page 5-41
ΠAccessory socket............................................... .................................................... page 5-36
 External input terminal........................................ .................................................. page 5-14
Ž Bottle holder.................................................. ........................................................ page 5-39
 Rear seat...................................................... .......................................................... page 2-14
 Cup holder............................................................................................................. page 5- 38
‘ Armrest..................................................................................................................page 2-17
’ ISOFIX lower anchors (Mexico)/LATCH lower anchors (Except Mexic o)......... page 2-50
“ Seat belt................................................................................................................. page 2-23
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-5
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Interior Equipment (View E)
▼4-Door
ƒ
Remote handles................................................. .................................................... page 2-14
„ Trunk light............................................................................................................. page 5 -34
Pictorial Index
Interior Overview
1-6The equipment and installation position varies by vehicle
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

▼5-Door
ƒ
Luggage compartment cover...................................... ........................................... page 3-21
„ Anchor brackets................................................ .................................................... page 2-42
… Luggage compartment light...................................... ............................................ page 5-34
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-7
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

4.Seat Recline
To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position
and release the lever.
Make sure the lever returns to its
original position and the seatback is
locked in place by attempting to push
it forward and backward.

Power seat
1. Seat Slide
To slide the seat, m ove the slide lifter
switch on the outside of the seat to the
front or back and hold it. Release the
switch at the desired position.
2. Height Adjustment
To adjust the seat height, move the
slide lifter switch up or down.
3.Height Adjustment for Front Edge
of Seat Bottom
To adjust the front height of the seat
bottom, raise or lower the front of the
slide lifter switch.
4. Seat Recline
To change the seatback angle, press the
front or rear side of the reclining
switch. Release the switch at the
desired position.
5. Lumbar Support Adjustment
To increase the seat firmness, press
and hold the front part of the switch to
the desired position, then release it.
Press the rear part of the switch to
decrease firmness.

Before making adjustments to the
driving position recommended by
Mazda
Before making adjustments, move the
steering wheel and s eat to their default
positions.
How to move the steering wheel to its
default position
WA R N I N G
Never adjust the steering wheel while the
vehicle is moving:
Adjusting the steering wheel while the
vehicle is moving is dangerous. Moving it
can very easily cause the driver to abruptly
turn to the left or righ t. This can lead to loss
of control or an accident.
Essential Safety Equipment
Seats
2-6
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

After adjusting the steering wheel position,
make sure it is securely locked by trying to
move it up and down:
Driving with the steering wheel not
securely locked in position is dangerous. If
the steering wheel moves unexpectedly
while driving, you could lose control of the
steering resulting in an accident.
Lower the lever, move the steering wheel
to the lowest position, and then push it
down and all the way back.
How to move a driver’s seat to its
default position
1. Slide the seat all the way back.
2. Lower the seat to its lowest height.
3. Lower the front edge of the seatbottom to its lowest height.
4. Sit squarely in the seat and rest your back against the seatback.
Seat adjustment pr ocedure for the
driving position recommended by
Mazda
Adjusting the seatba ck angle (reclining)
Adjust the seatback to the angle providing
a comfortable seated posture.
1. With your posture slightly slouched, move the seatback forward to the angle
where your waist feels slightly
cramped.
1. Manual Seat
2. Power Seat

Essential Safety Equipment
Seats
2-7
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

2. Move the seatback backward to acomfortable seated posture without any
feeling of cramping in your waist.
1. Manual Seat
2. Power Seat

Adjusting the seat p osition forward and
back (sliding)
Adjust the seat to the position best for
operating the accelerator and brake pedals.
1. Place your left foot on the footrest, your right foot between the accelerator
and brake pedals, and position your
heel to the position allowing easy
switching between the pedals.
2. With your heel set on the floor, set your right foot on the brake pedal and
move the seat forward as far as
possible until you feel a slight
cramping in your ankle.
1. Manual Seat
2. Power Seat

3. With your right foot set on the brake
pedal, move the seat back until you no
longer feel cramping in your ankle.
Essential Safety Equipment
Seats
2-8
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Adjusting the height on the front edge
of the seat bottom
Adjust the height on the front edge of the
seat bottom to the position where the back
of your knees contacts the front edge of
the seat bottom.
1. With your right foot set on the accelerator pedal, adjust the height on
the front edge of the seat bottom so
that the back of your knees lightly
contacts the front edge of the seat
bottom.
2. Depress the accelerator pedal and
make sure that you no longer feel
cramping in the back of your knees.
1. Manual Seat
2. Power Seat

Adjusting the ste ering wheel position
Adjust the steering wh eel to the position
where it can be operated easily and the
gauges can be viewed easily.
1. With your back resting against the seatback, extend both arms, place them
on the top of the steering wheel, and
pull the steering wheel towards you to
the position of your wrists.
2. Adjust the steering wheel height sothat the gauges can be viewed easily.
3. Raise the lever to securely lock the
steering wheel.
Adjusting the head restraint position
To prevent shock to the head and neck,
adjust the head restra ints to their correct
positions.
Refer to Height Adjustment on page
2-17.
▼ Driving Position Memory (Power
Seat)*
The desired driving position can be called
up after programming the position.
The following driving positions can be
programmed.
Essential Safety Equipment
Seats
2-10*Some models.
Mazda3_8HE9-EA-18K_Edition1
2018-10-17 19:05:10

(Manual transmission)
The parking brake is released.
(Automatic transmission)
The selector lever is shifted to a
position other than P.
Erasing programmed driving positions
Erasing the dr iving positions
programmed to the key
1. Switch the ignition OFF.
2. Press the SET button continuously until a sound is activated.
3. Press the lock button on the transmitter within 5 seconds after the sound is
activated.
NOTE
If you do not perform the operation
correctly, a sound indicating that the
programming has failed is activated.
▼Adjusting the Front Passenger's
Seat
1.
Seat Slide
To move a seat forwa rd or backward,
raise the lever and slide the seat to the
desired position and release the lever.
Make sure the lever returns to its
original position a nd the seat is locked
in place by attempting to push it
forward and backward.
2. Seat Recline
To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position
and release the lever.
Make sure the lever returns to its
original position a nd the seatback is
locked in place by attempting to push
it forward and backward.

Essential Safety Equipment
Seats
2-13
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10
