Recording of Vehicle Data
▼Recording of Vehicle Data
This vehicle is equipped with a computer
which records the fo
llowing main vehicle
data related to vehicle controls, operation,
and other driving conditions.

Recorded data
Vehicle conditions such as engine speed
and vehicle speed
Driving operation conditions such as
accelerator and brake pedals, and
information related to the environmental
circumstances while the vehicle is
driven
Malfunction diagnosis information from
each on-vehicle computer
Information related to controls of other
on-vehicle computers
NOTE
The recorded data may vary depending on
the vehicle grade and optional equipment.
Voice and images are not recorded.

Data handling
Mazda and its subcontracting parties may
obtain and use the recorded data for
vehicle malfunction diagnosis, research
and development, and quality
improvement.
Mazda will not disclose or provide any of
the obtained d ata to a third party unless:
An agreement from the vehicle owner
(agreements from lessor and lessee for
leased vehicle) is obtained
Officially requested by the police or
other law enforcem ent authorities
For statistical processing by a research
institution after processing the data so
that identification of the owner or the
vehicle is impossible
Customer Information and Reporting Safety Defects
Recording of Vehicle Data
8-20
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

GVW (Gross Vehicle Weight) is the
Vehicle Curb Weight + cargo +
passengers.

GVWR (Gross Vehicle Weight Rating)
is the maximum allowable weight of the
fully loaded vehicle (including all options,
equipment, passengers and cargo). The
GVWR is shown on the Safety
Compliance Certification Label located
on the driver's door frame or door
pillar. The GVW must never exceed the
GVWR.

SAMPLE
WA R N I N G
Never Exceed Axle Weight Rating Limits:
Exceeding the Safety Certification Label
axle weight rating limits is dangerous and
could result in death or serious injury as a
result of substandar d vehicle handling,
performance, engine, transmission and/or
structural damage, serious damage to the
vehicle, or loss of control.
Always keep the vehicle within the axle
weight rating limits.

GCW
GCW (Gross Combination Weight) is
the weight of the loaded vehicle (GVW).

GCWR (Gross Combination Weight
Rating) is the maximum allowable weight
of the vehicle - including all cargo and
passengers - that the vehicle can handle
without risking damage. The GCW must
never exceed the GCWR.

WA R N I N G
Never Exceed GVWR or GAWR
Specifications:
Exceeding the GVWR or the GAWR specified
on the certification label is dangerous.
Exceeding any vehicle rating limitation
could result in a serious accident, injury, or
damage to the vehicle.
Do not use replacement tires with lower
load carrying capacities than the originals
because they may lower the vehicle's
GVWR and GAWR limitations. Replacement
tires with a higher limit than the originals
do not increase the GVWR and GAWR
limitations.
Never exceed the GVWR or the GAWR
specified on the certification label.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-33
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

▼Engine Number
1. Forward
Specifications
Identification Numbers
9-3
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.0 SKYACTIV-G 2.5
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 × 3.59 in) 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 1,997.6 ml (1,997.6 cc) 2,488.5 ml (2,488.5 cc)
Compression ratio 13.0
▼Electrical System
Item
Classification
Battery 12V-60Ah/20HR or 12V-65Ah/20HR
Spark-plug number Mazda Genuine spark plug
*1PE5R-18-110 or PE5S-18-110
*1 This spark plug provides the SK YACTIV-G engine with optimum performance. Contact an Authorized Mazda
Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-15.
Coolant FL-22 type
Manual transmission oil Mazda Long Life Gear Oil G7
Automatic transmission f luid Mazda Genuine ATF FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
Specifications
Specifications
9-4
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil SKYAC‐
TIV-G 2.0
With oil filter replacement
4.2 L (4.4 US qt, 3.7 Imp qt)
Without oil filter replacement 4.0 L (4.2 US qt, 3.5 Imp qt)
SKYAC‐
TIV-G 2.5 With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil filter replacement 4.3 L (4.5 US qt, 3.8 Imp qt)
Coolant Manual transmission
6.3 L (6.7 US qt, 5.5 Imp qt)
Automatic
transmission SKYACTIV-G 2.0
6.5 L (6.9 US qt, 5.7 Imp qt)
SKYACTIV-G 2.5 6.6 L (7.0 US qt, 5.8 Imp qt)
Manual transmis‐
sion oil SKYACTIV-G 2.0
1.70 L (1.80 US qt, 1.50 Imp qt)
SKYACTIV-G 2.5 1.65 L (1.74 US qt, 1.45 Imp qt)
Automatic trans‐
mission fluid SKYACTIV-G 2.0
7.6 L (8.0 US qt, 6.7 Imp qt)
SKYAC‐
TIV-G 2.5 U.S.A. and
CanadaWith Cylinder Deactiva‐
tion
7.9 L (8.3 US qt, 7.0 Imp qt)
Without Cylinder Deacti‐
vation 7.6 L (8.0 US qt, 6.7 Imp qt)
Mexico 7.6 L (8.0 US qt, 6.7 Imp qt)
Transfer case oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank U.S.A. and
Canada2WD
50.0 L (13.2 US gal, 11.0 Imp gal)
AWD 48.0 L (12.7 US gal, 10.6 Imp gal)
Mexico 51.0 L (13.5 US gal, 11.2 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
Specifications
Specifications
9-5
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

SKYACTIV-G 2.5
(4-Door)
ItemWe i gh t
Manual transmission Automatic transmission
GVW (Gross Vehicle Weight) 1,861 kg (4,103 lbs)1,870 kg (4,123 lbs)
(5-Door)
Item We i gh t
Manual transmission Automatic transmission
GVW (Gross Vehicle Weight) 1,848 kg (4,074 lbs)1,870 kg (4,123 lbs)
▼Air Conditioner*
The type of refrigerant used is indicated on a label attached t
o the inside of the engine com‐
partment. Check the label befo re recharging the refrigerant.
Refer to Operating Tips on page 5-2.
Item Specification
Refrigerant Type HFC134a (R-134a)
▼Light Bulbs
Exterior light
Light bulb Category
Wattage UN-R*1 (SAE)
Headlights LED
*2― (―)
Daytime running lights LED
*2― (―)
Parking lights LED type
LED
*2― (―)
Bulb type 5 WY5W (―)
Front turn signal lights LED
*2― (―)
Front side-marker lights LED type
LED
*2― (―)
Bulb type 5 WY5W (―)
Side turn signal lights
*LED*2― (―)
High-mount brake light LED
*2― (―)
Rear turn signal lights LED
*2― (―)
Rear side-marker lights LED
*2― (―)
Brake lights LED
*2― (―)
Taillights LED
*2― (―)
Reverse lights LED
*2― (―)
License plate lights LED
*2― (―)
Specifications
Specifications
9-8*Some models.
