MAZDA MODEL 6 2006 Owners Manual (in English)

Black plate (371,1)
Reporting Safety Defects (U.S.A.)
If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should immediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to notifying Mazda Motor
Corporation (Your Mazda Importer/Distributor).
If NHTSA receives similar complaints, it may open an investigation, and if it
finds that a safety defect exists in a group of vehicles, it may order a recall and
remedy campaign. However, NHTSA cannot become involved in individual
problems between you, your dealer, or Mazda Motor Corporation (Your Mazda
Importer/Distributor).
To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1
(800) 424-9393 (or 366-0123 in Washington, D.C. area) or write to: NHTSA,
U.S. Department of Transportation. Washington, D.C. 20590. You can also
obtain other information about motor vehicle safety from the Hotline.
NOTE
If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be
forwarded to:
Mazda North American Operations
7755 Irvine Center Drive
Irvine, California 92618-2922
P.O. Box 19734
Irvine, CA 92623-9734
Customer Assistance Center or toll free at 1 (800) 222-5500
If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown
(page 9-10) in this booklet.
Customer Information and Reporting Safety Defects
Reporting Safety Defects
9-41
Mazda6_8U66-EA-05F_Edition1 Page371
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (372,1)
Reporting Safety Defects (Canada)
Canadian customers who wish to report a safety-related defect to Transport Canada, Defect
Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact
Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330
Sparks Street, Ottawa ON K1A 0N5.
For additional road safety information, please visit the Road Safety website at:
http://www.tc.gc.ca/roadsafety/menu.htm
9-42
Customer Information and Reporting Safety Defects
Reporting Safety Defects
Mazda6_8U66-EA-05F_Edition1 Page372
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (373,1)
Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do
some of their own maintenance and repair.
When requesting any of our publications through an Authorized Mazda Dealer, refer to the
chart below.
If they don't have what you need in stock, they can order it for you.
PUBLICATION ORDER NUMBER PUBLICATION DESCRIPTION
9999-95-063B-06 2006 WORKSHOP MANUAL (English)
9999-95-039G-06 2006 WIRING DIAGRAM (English)
9999-95-078C-06 (U.S.A. only) 2006 OWNER'S MANUAL
9999-EC-078C-06 (Canada only) 2006 OWNER'S MANUAL
9999-PR-078C-06 (Puerto Rico, Mexico only) 2006 OWNER'S MANUAL
qWORKSHOP MANUAL:
Covers recommended maintenance and repair procedures of the drive train, body and
chassis.
qWIRING DIAGRAM:
Provides electrical schematics as well as component location for the entire electrical
system.
qOWNER'S MANUAL:
This booklet contains information regarding the proper care and operation of your vehicle.
This is not a technician's manual.
Customer Information and Reporting Safety Defects
Service Publications
9-43
Mazda6_8U66-EA-05F_Edition1 Page373
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (374,1)
9-44
Mazda6_8U66-EA-05F_Edition1 Page374
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (375,1)
10Specifications
Technical information about your Mazda.
Identification Numbers ............................................................... 10-2
Vehicle Information Labels ..................................................... 10-2
Specifications ............................................................................... 10-4
Specifications .......................................................................... 10-4
10-1
Mazda6_8U66-EA-05F_Edition1 Page375
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (376,1)
Vehicle Information Labels
qVehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on
a plate attached to the left top side of the
dashboard. This plate can easily be seen
through the windshield.
qMotor Vehicle Safety Standard Label
qVehicle Emission Control
Information Label
qTire Pressure Label
10-2
Identification Numbers
Mazda6_8U66-EA-05F_Edition1 Page376
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (377,1)
qEngine Number (3.0-liter engine
only)
Forward
Identification Numbers
10-3
Mazda6_8U66-EA-05F_Edition1 Page377
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (378,1)
Specifications
qEngine
ItemSpecification
2.3-liter engine 3.0-liter engine
Type DOHC-16V in-line, 4-cylinder DOHC-24V 60°V, 6-cylinder
Bore×Stroke 87.5 × 94.0 mm (3.44 × 3.70 in) 89.0 × 79.5 mm (3.50 × 3.13 in)
Displacement 2,261 ml (2,261 cc, 137.9 cu in) 2,967 ml (2,967 cc, 181.0 cu in)
Compression ratio 9.7 10.0
qElectrical System
Item Classification
Battery 12V-50AH/5HR
Alternator2.3-liter engine 12 V - 100 A
3.0-liter engine 12 V - 110 A
Starter 12 V - 1.4 kW
Spark-plug number2.3-liter engineLFG1 18 110
*
L3Y2 18 110
3.0-liter engine AJ57 18 110*
Spark-plug gap2.3-liter engine 1.25―1.35 mm (0.049―0.053 in)
3.0-liter engine 1.29―1.45 mm (0.051―0.057 in)
* ex factory
qLubricant Quality
Lubricant Classification
Engine oilRefer to the recommended SAE viscosity numbers
on page 8-18.
Manual transmission
oil2.3-liter engineAny temperatureAPI Service GL-4 or GL-5
SAE 75W-90
Above 10°C (50°F)API Service GL-4 or GL-5
SAE 80W-90
3.0-liter engineAPI Service GL-4 or GL-5
SAE 75W-90
Automatic transaxle fluid2.3-liter engine ATF M-V
3.0-liter engine ATF T-IV
Power steering fluid ATF M-III, M-V, or equivalent (e.g. Dexron® III)
Brake fluid SAE J1703, or FMVSS116 DOT-3
10-4
Specifications
Mazda6_8U66-EA-05F_Edition1 Page378
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (379,1)
qCapacities
(Approximate Quantities)
ItemUnit
L US qt Imp qt
Engine oil2.3-liter engineWith oil filter
replacement4.3 4.5 3.8
Without oil filter
replacement3.9 4.1 3.4
3.0-liter engineWith oil filter
replacement5.7 6.0 5.0
Without oil filter
replacement5.2 5.5 4.6
Coolant2.3-liter engine 7.0 7.4 6.2
3.0-liter engine 8.5 9.0 7.5
Manual transaxle oil2.3-liter engine 2.87 3.0 2.5
3.0-liter engine 2.3 2.4 2.0
Automatic transaxle fluid2.3-liter engine 8.04 8.5 7.3
3.0-liter engine 7.0 7.4 6.1
Fuel tank 68 18.0 (US gal)15.0
(Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
qDimensions
Item Specification
Overall lengthSedan 4,745 mm (186.8 in)
5-Door 4,745 mm
*3(186.8 in), 4,765 mm*4(187.6 in)
Sport Wagon 4,770 mm*3(187.8 in), 4,785 mm*4(188.4 in)
Overall width 1,780 mm (70.1 in)
Overall heightSedan/5-Door 1,440 mm (56.7 in)
Sport Wagon 1,455 mm (57.3 in)
Track, front 1,540 mm
*1(60.6 in), 1,530 mm*2(60.2 in)
Track, rear 1,540 mm*1(60.6 in), 1,530 mm*2(60.2 in)
Wheelbase 2,675 mm (105.3 in)
*1 16 inch wheel vehicle
*2 17 inch wheel vehicle
*3 Without license plate holder
*4 With license plate holder
Specifications
10-5
Mazda6_8U66-EA-05F_Edition1 Page379
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F

Black plate (380,1)
qWeights
Specification Item Weight
2.3-liter engineGVWR (Gross Vehicle Weight Rating) 1,940 kg (4,279 lbs)
GAWR (Gross Axle Weight Rating)Front 1,005 kg (2,216 lbs)
Rear 936 kg (2,064 lbs)
3.0-liter engineGVWR (Gross Vehicle Weight Rating) 2,052 kg (4,526 lbs)
GAWR (Gross Axle Weight Rating)Front 1,084 kg (2,390 lbs)
Rear 968 kg (2,136 lbs)
qAir Conditioner
Gas complies with SAE J639 Maximum operating charge
HFC134a (R-134a) 0.5 kg (17.6 oz)
qLight Bulbs
Exterior light
Light bulbCategory
Wattage ECER SAE
HeadlightsHigh beam 55 H1―
Low beamHalogen 55 H1―
Xenon
fusion35 D2S―
Front turn signal lights 27―#2357A
Parking lights 5 W5W―
Fog lights
í55 H11 H11
Side-marker lights 5 W5W―
High-mount brake lightSedan 18.4 W16W #921
5-Door/Sport Wagon 21 W21W #7440
Rear turn signal lightsSedan/5-Door 21 WY21W―
Sport Wagon 21 W21W #7440
Brake lights/Taillights 21/5 W21/5W #7443
Taillights 5
*1W21/5W #7443
Reverse lights 18.4 W16W #921
License plate lights 5 W5W―
*1 Use a 21/5W type bulb.
10-6íSome models.
Specifications
Mazda6_8U66-EA-05F_Edition1 Page380
Friday, June 3 2005 8:49 AM
Form No.8U66-EA-05F
