▼Taking Action
Take the appropriate action and verify that the warning light t
urns off.
SignalWarning Action to be taken
(Amber)
Smart Brake Support/
Smart City Brake Sup‐ port (SBS/SCBS)
Warning Indication/
Wa r n i n g L i g h t
*
The light turns on if the windshield or the
radar sensor are dirty, or there is a malfunc‐
tion in the system. Verify the reason why the warning light is
illuminated on the center display.
If the reason why the warning light is illu‐
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em‐
blem.
For any other reasons, have the vehicle in‐
spected at an Authorized Mazda Dealer.
Low Fuel Warning In‐
dication/Warning Light The light turns on when
the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).NOTE
The light illumination timing may vary be ‐
cause fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture. Add fuel.
Check Fuel Cap Warn‐
ing Indication/Warning Light If the check fuel cap warning light illumi‐
nates while driving, the fuel-filler cap may
not be installed properly.
Stop the engine and reinstall the fuel-filler
cap.
Refer to Refueling on page 3-22.
Engine Oil Level
Warning Light This warning light indicates that the engine
oil level is around t
he MIN mark (page
6-26). Add 1 L (0.3 US gal, 0.2 Imp gal) of en‐
gine oil (page 6-23).
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-32*Some models.
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Index
Maintenance Monitor.................. 4-37
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display.......4-38
Message Indicated in Multi-
information Display (Type B)..... 7-40
Multi-information Display (Type
B)................................................. 4-31
Odometer..................................... 4-33
Outside Temperature Display...... 4-36
Speedometer................................ 4-30
Tachometer.................................. 4-30
Traffic Sign Recognition System
(TSR) Display..............................4-38
Trip Meter....................................4-33
Warning Indication/Warning
Lights........................................... 4-40
Warning (Display Indication)...... 4-39
Instrument Cluster (Type C)............. 4-46
Cruise Control Set Vehicle Speed
Display......................................... 4-53
Dashboard Illuminati on............... 4-50
Engine Coolant Temperature
Gauge........................................... 4-49
Fuel Gauge.................................. 4-49
Indication/Indi cator Lights.......... 4-56
Multi-information Display (Type
C)................................................. 4-47
Odometer..................................... 4-48
Outside Temperature Display...... 4-51
Speedometer................................ 4-46
Tachometer.................................. 4-46
Trip Computer............................. 4-51
Trip Meter....................................4-48
Warning Indication/Warning
Lights........................................... 4-54
Interior Care...................................... 6-60
Active driving display
maintenance................................. 6-62
Cleaning the floor mats............... 6-63
Cleaning the window interiors.....6-62Instrument panel top (Soft pad)
maintenance................................. 6-62
Leather upholstery
maintenance................................. 6-61
Panel maintenance....................... 6-62
Plastic part maintenance.............. 6-61
Seat belt maintenance..................6-60
Upholstery maintena nce.............. 6-61
Vinyl upholstery maintenance..... 6-60
Interior Lights................................... 5-84
Courtesy lights.............................5-84
Map lights....................................5-84
Overhead lights............................5-84
i-ACTIVSENSE.............................. 4-115 Active safety technology........... 4-115
Adaptive Front Lighting System
(AFS)......................................... 4-118
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-168
Blind Spot Monitoring (BSM) ............
................................................... 4-122
Camera and sensors................... 4-116
Distance Recognition Support System
(DRSS).......................................4-136
Forward Sensing Camera
(FSC)......................................... 4-204
High Beam Control System
(HBC)........................................ 4-119
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-157
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-144
Pre-crash safety technology....... 4-115
Radar sensors (rear)...................4-212
Radar sensor (front)...................4-209
Rear Cross Traffic Alert
(RCTA)...................................... 4-140
Smart Brake Suppor t (SBS)...... 4-174
10-6
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Engine compartment overview.... 6-22
Key battery replacement..............6-36
Opening the hood........................ 6-20
Owner maintenance
precautions................................... 6-18
P
Parking Brake....................................4-95
Parking Sensor System................... 4-232
Park assist sensor system
operation.................................... 4-236
Sensor detection range.............. 4-234
Personalization Features................... 9-10
Power Steering................................ 4-114
Power Steering Warning Buzzer....... 7-44
Power Windows................................ 3-29
R
Radar Sensors (Rear)...................... 4-212
Radar Sensor (Front).......................4-209
Rearview Mirror................................3-26
Rear Coat Hooks............................... 5-94
Rear Cross Traffic Alert (RCTA).... 4-140
Rear Door Child Safet y Locks.......... 3-15
Rear Seat........................................... 2-15
Rear View Monitor......................... 4-224
Displayable range on the
screen......................................... 4-226
Picture quality adjustment......... 4-231
Rear view monitor operation..... 4-227
Rear view parking camera
location...................................... 4-225
Switching to the rear view monitor
display........................................4-225
Variance between actual road
conditions and displayed
image......................................... 4-230
Viewing the display................... 4-227
Rear Window Defogger.................... 4-83
Recommended Oil.............................6-23
Recording of Vehicle Data................ 8-23
Recreational Towing......................... 3-47
Registering Your Vehicle in A Foreign
Country.............................................. 8-19
Replacement Fuse..............................................6-47
Key battery.................................. 6-36
Light bulbs...................................6-43
Tires............................................. 6-40
Wheel........................................... 6-42
Wiper........................................... 6-30
Request Switch Inoperable Warning
Beep (With the advanced keyless
function)............................................ 7-44
Rocking the Vehicle.......................... 3-41
S
Safety Defects, Reporting................. 8-15
Saving Fuel and Protection of the
Environment...................................... 3-39
Scheduled Maintenance...................... 6-4
Seat Seat position memory.................. 2-11
Seats Front seat....................................... 2-5
Head restraint.............................. 2-17
Rear seat...................................... 2-15
Seat ventilation............................ 2-20
Seat warmer................................. 2-19
Seat Belt System Automatic locking....................... 2-24
Emergency locking...................... 2-24
Extender....................................... 2-28
Pregnant women.......................... 2-24
Seat belt precautions................... 2-22
3-point type................................. 2-25
Seat Belt Warning Beep.................... 7-42
Security System Immobilizer system..................... 3-35
Theft-deterrent system.................3-37
10-8
