fuel type MAZDA MODEL 6 2019 (in English) User Guide

▼Control Status Display
The operation status of the cyli
nder deactivation is displayed.
Indication on display Control status
The condition of each cylinder is displayed by col‐
ors. The operating cylinders are displayed in red.
Calculates the average fu el economy every minute
after vehicle travel b egins, and displays it.
Instrument Cluster (Type A)
Synchronized (linked) with the average fuel econo‐
my displayed in the trip meter (TRIP A).
Refer to Average Fuel Economy on page 4-21.
To reset, press the icon in the menu. (The aver‐
age fuel economy and TRIP A displayed in the trip
meter (TRIP A) reset at the same time.)
Instrument Cluster (Type B)
Synchronized (linked) with the average fuel econo‐
my displayed in the trip meter (TRIP A).
Refer to Average Fuel Economy on page 4-37.
To reset, press the icon in the menu. (The aver‐
age fuel economy and TRIP A displayed in the trip
meter (TRIP A) reset at the same time.)
Instrument Cluster (Type C)
Synchronized (linked) with the average fuel econo‐
my displayed in the trip computer.
Refer to Trip Computer on page 4-51.
To reset, press the icon in the menu. (The aver‐
age fuel economy displayed in the trip computer re‐
sets at the same time.)
▼ Ending Screen Display
If the ending display
on the fuel economy m onitor is on when the ignition is switched from
ON to OFF, the information regarding the fuel economy is displa yed.
When Driving
Fuel Economy Monitor
4 - 111
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Except U.S.A., Canada
Use SAE 5W-30 engine oil.
Oil container labels provide important
information.
A chief contribution this type of oil makes
to fuel economy is reducing the amount of
fuel necessary to overcome engine
friction.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol
® (Mexico only).


(ILSAC)
(Mexico)
80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
SKYACTIV-G 2.5
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 5W-20
engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.

SKYACTIV-G 2.5T
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 0W-30
or SAE 10W-30 engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.

Maintenance and Care
Owner Maintenance
6-25
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Tires
For reasons of proper performance, safety,
and better fuel economy, always maintain
recommended tire inflation pressures and
stay within the recommended load limits
and weight distribution.
WA R N I N G
Using Different Tire Types:
Driving your vehicle with different types of
tires is dangerous. It could cause poor
handling and poor braking; leading to loss
of control.
Except for the limited use of the temporary
spare tire, use only the same type tires
(radial, bias-belted, bias-type) on all four
wheels.
Using Wrong-Sized Tires:
Using any other tire size than what is
specified for the vehicle (page 9-8) is
dangerous. It could seriously affect ride,
handling, ground clearance, tire clearance,
and speedometer calibration. This could
cause you to have an accident. Use only
tires that are the correct size specified for
the vehicle.
▼ Tire Inflation Pressure
WA R N I N G
Always
inflate the tires to the correct
pressure:
Overinflation or underinflation of tires is
dangerous. Adverse handling or
unexpected tire failure could result in a
serious accident.
Refer to Tires on page 9-8.
Use only a Mazda-genuine tire valve cap:
Use of a non-genuine part is dangerous as
the correct tire air pressure cannot be
maintained if the tire valve becomes
damaged. If the vehicle is driven under this
condition, the tire air pressure will decrease
which could result in a serious accident. Do
not use any part for the tire valve cap that
is not a Mazda-genuine part.
Inspect all tire pressures monthly
(including the spare) when the tires are
cold. Maintain recommended pressures for
the best ride, handling, and minimum tire
wear.
Refer to the specification charts (page
9-8).
NOTE
Always check tire pressure when tires
are cold.
Warm tires normally exceed
recommended pressures. Do not release
air from warm tires to adjust the
pressure.
Underinflation can cause reduced fuel
economy, uneven and accelerated tire
wear, and poor sealing of the tire bead,
which will deform the wheel and cause
separation of tire from rim.
Overinflation can produce a harsh ride,
uneven and accelerated tire wear, and a
greater possibility of damage from road
hazards.
Keep your tire pressure at the correct
levels. If one frequently needs inflating,
have it inspected.
Maintenance and Care
Owner Maintenance
6-39
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.5 SKYACTIV-G 2.5T
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 2,488.5 ml (2,488.5 cc)
Compression ratio 13.010.5
▼Electrical System
Battery
Classification
Specification
SKYACTIV-G 2.5,
SKYACTIV-G 2.5T 12V-60Ah/20HR or 12V-65Ah/20HR
Spark-plug
Classification
Specification
SKYACTIV-G 2.5 Mazda Genuine spark plug
*1PE5R-18-110 or PE5S-18-110
SKYACTIV-G 2.5T Mazda Genuine spark plug
*1PY8V-18-110
*1 The spark plugs provide the SKY ACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The
fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-23.
Coolant FL-22 type
Manual transaxle oil Mazda Long Life Gear Oil G7
*1
Automatic transaxle fluid Mazda Genuine ATF FZ
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
*1 Mazda Long Life Gear Oil G7 is superior oil for low fuel cost and optimum shift-feel. Using Mazda Long Life
Gear Oil G7 is recommended.
If Mazda Long Life Gear Oil G7 cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-80)).
Specifications
Specifications
9-4
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Warning light............................... 4-97
Break-In Period.......... ....................... 3-39
C
Capacities............................................ 9-5
Cell Phones....................................... 8-21
Center Console.................................. 5-93
Child Restraint Categories of child-restraint
systems.........................................2-35
Child-restraint system
installation................................... 2-35
Child-restraint system suitability for
various seat positions table..........2-37
ISOFIX child-restraint systems
(Mexico)...................................... 2-47
LATCH child-restraint systems
(Except Mexico).......................... 2-47
Child-Restraint Child-restraint precautions.......... 2-30
Installing child-restraint
systems.........................................2-40
Climate Control System...................... 5-2 Fully Automatic Type....................5-5
Gas specifications.......................... 9-7
Operating Tips............................... 5-2
Vent Operation...............................5-3
Collision warning.............................. 7-46
Coming Home Light......................... 4-77
Control Status Display.................... 4-111
Courtesy Lights................................. 5-84
Cruise Control................................. 4-215 Cruise control switc h.................4-215
Cruise main indication (white)/cruise
set indication (green)................. 4-216
Cup Holder........................................ 5-90
Customer Assistance.... ....................... 8-2
Cylinder Deactivation... .................... 4-11
D
Daytime Running Lights................... 4-78
Defogger
Mirror...........................................4-84
Rear window........... .................... 4-83
Dimensions.......................................... 9-5
Display.............................................. 4-12
Distance Recognition Support System
(DRSS)............................................ 4-136 Indication on display................. 4-136
Door Locks........................................3-10
Drive Selection................................ 4-112
Driving In Flooded Ar ea...................3-43
Driving on Uneven Road.................. 3-45
Driving Tips...................................... 3-39
Automatic transaxle.....................4-72
Break-in period............................ 3-39
Driving in flooded a rea............... 3-43
Driving on uneven road...............3-45
Floor mat..................................... 3-40
Hazardous driving.. ..................... 3-40
Overloading............. .................... 3-44
Rocking the vehicle. .................... 3-41
Saving fuel and protection of the
environment................................. 3-39
Turbocharged vehicles.................3-46
Winter driving............................. 3-41
Dynamic Stability Control (DSC)... 4-107 DSC OFF indicator light........... 4-107
DSC OFF switch....................... 4-108
TCS/DSC indicator light........... 4-107
E
Electric parking brake (EPB)............ 4-95
Electric Parking Brake (EPB) Warning
Beep...................................................7-44
Emergency Starting
Push-starting................................ 7-17
Starting a flooded engine............ 7-17
10-3
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Emergency TowingTiedown hooks......... ................... 7-21
Towing description...................... 7-20
Emission Control System (SKYACTIV-
G 2.5, SKYACTIV-G 2.5T).............. 3-20
Ending Screen Display.................... 4-111
Engine
Coolant.........................................6-26
Engine compartment overview.... 6-22
Exhaust gas.................................. 3-21
Hood release............................ .... 6-20
Oil................................................ 6-23
Starting...........................................4-5
Essential Information.......................... 6-2
Event Data Recorder......................... 8-22
Excessive Speed Warning................. 7-46
Exterior Care..................................... 6-54 Aluminum wheel maintenance.... 6-59
Bright-metal maint enance........... 6-58
Maintaining the finish................. 6-55
Plastic part maintenance.............. 6-59
F
Flasher Hazard warning........................... 4-85
Headlights.................................... 4-74
Flat Tire............................................... 7-3 Mounting the spare tire............... 7-11
Removing a flat tire...................... 7-7
Floor Mat.......................................... 3-40
Fluid Brake/Clutch................................ 6-28
Washer......................................... 6-28
Fluids Classification................................. 9-4
Foot Brake.........................................4-94
Forward Sensing Camera (FSC)..... 4-204
Fuel Filler lid and cap......................... 3-22
Requirements (SKYACTIV-G 2.5,
SKYACTIV-G 2.5T)....................3-19
Tank capacity.................................9-5
Fuel Consumption Display..............4-110
Fuel Economy Monitor. .................. 4-109
Control Status Display...............4-111
Ending screen display................ 4-111
Ending Screen Display.............. 4-111
Fuel consumption display.......... 4-110
Fuel Consumption Display........ 4-110
Fuses.................................................. 6-47 Panel description......................... 6-49
Replacement................................ 6-47
G
Gauges............................................... 4-12
Glove Compartment.......................... 5-93
H
Hazardous Driving............................ 3-40
Hazard Warning Flasher....................4-85
HeadlightsComing home light......................4-77
Control......................................... 4-74
Flashing....................................... 4-77
Headlight flashing....................... 4-77
High-low beam............................ 4-77
Leaving home light..................... 4-78
Leveling....................................... 4-78
Head Restraint................................... 2-17
High Beam Control System
(HBC).............................................. 4-119 High Beam Control System (HBC)
indicator light (green)................4-120
Hill Launch Assist (HLA).......... .... 4-103
HomeLink Wireless Control System
(Type A)............................................ 4-86
HomeLink Wireless Control System
(Type B)............................................ 4-89
Hood Release............. ....................... 6-20
10-4
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Horn...................................................4-85
I
If a Warning Light Turns On or
Flashes............................................... 7-23
If the Active Driving Display Does Not
Operate.............................................. 7-48
IgnitionSwitch............................................ 4-4
Ignition Not Switched Off (STOP)
Warning Beep.................................... 7-43
Illuminated Entry System................. 5-87
Immobilizer System.......................... 3-35
Inside Trunk Release Lever.............. 3-18
Inspecting Brak e/Clutch Fluid
Level.................................................. 6-28
Inspecting Coolant Leve l.................. 6-26
Inspecting Engine Oil Level............. 6-26
Inspecting Washer Fluid Level......... 6-28
Instrument Cluster...... ....................... 4-12
Instrument Cluster (Type A)........4-13
Instrument Cluster (Type B)........4-30
Instrument Cluster (Type C)........4-46
Instrument Cluster (Type A)............. 4-13 Average Fuel Economy............... 4-21
Blind Spot Monitoring (BSM)
Display......................................... 4-21
Compass Display......................... 4-23
Cruise Control Set Vehicle Speed
Display......................................... 4-23
Current Fuel Econo my................ 4-21
Dashboard Illumina tion............... 4-19
Distance Recognition Support System
(DRSS) Display........................... 4-22
Distance-to-empty....................... 4-20
Engine Coolant Temperature
Gauge........................................... 4-18
Fuel Gauge.................................. 4-18
Indication/Indicator Lights.......... 4-26
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-22
Maintenance Monitor.................. 4-21
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) D isplay.......4-22
Message Indicated in Multi-
information Display (Type A)..... 7-40
Multi-information Display (Type
A)................................................. 4-14
Odometer..................................... 4-17
Outside Temperature Display...... 4-20
Speedometer................................ 4-13
Speed Unit Selector..................... 4-19
Tachometer.................................. 4-13
Traffic Sign Recognition System
(TSR) Display..............................4-22
Trip Meter....................................4-17
Warning Indication/Warning
Lights........................................... 4-24
Warning (Display Indication)...... 4-23
Instrument Cluster (Type B)............. 4-30 Average Fuel Economy............... 4-37
Blind Spot Monitoring (BSM)
Display......................................... 4-38
Compass Display......................... 4-39
Cruise Control Set Vehicle Speed
Display......................................... 4-39
Current Fuel Econo my................ 4-37
Dashboard Illumina tion............... 4-35
Distance Recognition Support System
(DRSS) Display........................... 4-38
Distance-to-empty....................... 4-36
Engine Coolant Temperature
Gauge........................................... 4-34
Fuel Gauge.................................. 4-34
Indication/Indicator Lights.......... 4-42
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-38
10-5
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Maintenance Monitor.................. 4-37
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display.......4-38
Message Indicated in Multi-
information Display (Type B)..... 7-40
Multi-information Display (Type
B)................................................. 4-31
Odometer..................................... 4-33
Outside Temperature Display...... 4-36
Speedometer................................ 4-30
Tachometer.................................. 4-30
Traffic Sign Recognition System
(TSR) Display..............................4-38
Trip Meter....................................4-33
Warning Indication/Warning
Lights........................................... 4-40
Warning (Display Indication)...... 4-39
Instrument Cluster (Type C)............. 4-46
Cruise Control Set Vehicle Speed
Display......................................... 4-53
Dashboard Illuminati on............... 4-50
Engine Coolant Temperature
Gauge........................................... 4-49
Fuel Gauge.................................. 4-49
Indication/Indi cator Lights.......... 4-56
Multi-information Display (Type
C)................................................. 4-47
Odometer..................................... 4-48
Outside Temperature Display...... 4-51
Speedometer................................ 4-46
Tachometer.................................. 4-46
Trip Computer............................. 4-51
Trip Meter....................................4-48
Warning Indication/Warning
Lights........................................... 4-54
Interior Care...................................... 6-60
Active driving display
maintenance................................. 6-62
Cleaning the floor mats............... 6-63
Cleaning the window interiors.....6-62Instrument panel top (Soft pad)
maintenance................................. 6-62
Leather upholstery
maintenance................................. 6-61
Panel maintenance....................... 6-62
Plastic part maintenance.............. 6-61
Seat belt maintenance..................6-60
Upholstery maintena nce.............. 6-61
Vinyl upholstery maintenance..... 6-60
Interior Lights................................... 5-84
Courtesy lights.............................5-84
Map lights....................................5-84
Overhead lights............................5-84
i-ACTIVSENSE.............................. 4-115 Active safety technology........... 4-115
Adaptive Front Lighting System
(AFS)......................................... 4-118
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-168
Blind Spot Monitoring (BSM) ............
................................................... 4-122
Camera and sensors................... 4-116
Distance Recognition Support System
(DRSS).......................................4-136
Forward Sensing Camera
(FSC)......................................... 4-204
High Beam Control System
(HBC)........................................ 4-119
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-157
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-144
Pre-crash safety technology....... 4-115
Radar sensors (rear)...................4-212
Radar sensor (front)...................4-209
Rear Cross Traffic Alert
(RCTA)...................................... 4-140
Smart Brake Suppor t (SBS)...... 4-174
10-6
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Engine compartment overview.... 6-22
Key battery replacement..............6-36
Opening the hood........................ 6-20
Owner maintenance
precautions................................... 6-18
P
Parking Brake....................................4-95
Parking Sensor System................... 4-232
Park assist sensor system
operation.................................... 4-236
Sensor detection range.............. 4-234
Personalization Features................... 9-10
Power Steering................................ 4-114
Power Steering Warning Buzzer....... 7-44
Power Windows................................ 3-29
R
Radar Sensors (Rear)...................... 4-212
Radar Sensor (Front).......................4-209
Rearview Mirror................................3-26
Rear Coat Hooks............................... 5-94
Rear Cross Traffic Alert (RCTA).... 4-140
Rear Door Child Safet y Locks.......... 3-15
Rear Seat........................................... 2-15
Rear View Monitor......................... 4-224
Displayable range on the
screen......................................... 4-226
Picture quality adjustment......... 4-231
Rear view monitor operation..... 4-227
Rear view parking camera
location...................................... 4-225
Switching to the rear view monitor
display........................................4-225
Variance between actual road
conditions and displayed
image......................................... 4-230
Viewing the display................... 4-227
Rear Window Defogger.................... 4-83
Recommended Oil.............................6-23
Recording of Vehicle Data................ 8-23
Recreational Towing......................... 3-47
Registering Your Vehicle in A Foreign
Country.............................................. 8-19
Replacement Fuse..............................................6-47
Key battery.................................. 6-36
Light bulbs...................................6-43
Tires............................................. 6-40
Wheel........................................... 6-42
Wiper........................................... 6-30
Request Switch Inoperable Warning
Beep (With the advanced keyless
function)............................................ 7-44
Rocking the Vehicle.......................... 3-41
S
Safety Defects, Reporting................. 8-15
Saving Fuel and Protection of the
Environment...................................... 3-39
Scheduled Maintenance...................... 6-4
Seat Seat position memory.................. 2-11
Seats Front seat....................................... 2-5
Head restraint.............................. 2-17
Rear seat...................................... 2-15
Seat ventilation............................ 2-20
Seat warmer................................. 2-19
Seat Belt System Automatic locking....................... 2-24
Emergency locking...................... 2-24
Extender....................................... 2-28
Pregnant women.......................... 2-24
Seat belt precautions................... 2-22
3-point type................................. 2-25
Seat Belt Warning Beep.................... 7-42
Security System Immobilizer system..................... 3-35
Theft-deterrent system.................3-37
10-8
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
