As an added safety feature, your vehicle has been equipped with a tire pressure monitoring
system (TPMS) that illuminates a low tire pre ssure telltale when one or more of your tires is
significantly under-inflated. Accordingly, when th e low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and inflate them to the proper
pressure. Driving on a significantly under-in flated tire causes the tire to overheat and can
lead to tire failure. Under-inflation also reduce s fuel efficiency and tire tread life, and may
affect the vehicle's handling and stopping ability.
Please note that the TPMS is not a substitute for proper tire maintenance, and it is the
driver's responsibility to maintain correct ti re pressure, even if under-inflation has not
reached the level to trigger illumination of the TPMS low tire pressure telltale.
Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when
the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire pressure telltale. When the
system detects a malfunction, the telltale wi ll flash for approximately one minute and then
remain continuously illuminated. This sequence will continue upon subsequent vehicle
start-ups as long as the malfunction exists. When the malfunction indicator is illuminated,
the system may not be able to detect or signal low tire pressure as intended. TPMS
malfunctions may occur for a variety of reasons, including the installation of replacement
or alternate tires or wheels on the vehicle th at prevent the TPMS from functioning properly.
Always check the TPMS malfunction telltale after replacing one or more tires or wheels on
your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to
continue to function properly.
 To avoid false readings, the system samples for a little while before indicating a problem. As
a result it will not instantaneously regi ster a rapid tire deflation or blow out.
▼System Error Activation
When the warning light flashes, there may
be a system malfunction. Consult an
Authorized Mazda Dealer.
A system error activation may occur in the
following cases:
When there is equipment or a device
near the vehicle using the same radio
frequency as that of the tire pressure
sensors.
When a metallic device such as a
non-genuine navigation system is
equipped near the center of the
dashboard, which may block radio
signals from the tire
pressure sensor to
the receiver unit.
When using the following devices in the
vehicle that may cause radio
interference with the receiver unit.
A digital device such as a personal
computer.
A current converter device such as a
DC-AC converter.
When excess snow or ice adheres to the
vehicle, especially around the wheels.
When the tire pressu re sensor batteries
are exhausted.
When using a wheel with no tire
pressure sensor installed.
When using tires with steel wire
reinforcement in the sidewalls.
When using tire chains.
When Driving
Tire Pressure Monitoring System
4-221
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Selecting the Airflow Mode
Dashboard Vents
Dashboard and Floor Vents
Floor Vents Defroster and Floor Vents
Defroster Vents
* With rear vents
NOTE
The location airflow exits the air vents an d the airflow amount may change depending on
the open or close status of the air vents.
Interior Features
Climate Control System
5-4
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Vehicle InformationLabels
▼Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
▼Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼ Chassis Number
Open the cover shown in the figure to
check the chassis number.
▼Vehicle Emission Control
Information Label (U.S.A. and
Canada)
▼Tire Pressure Label
Specifications
Identification Numbers
9-2
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Index
Horn...................................................4-85
I
If a Warning Light Turns On or
Flashes............................................... 7-23
If the Active Driving Display Does Not
Operate.............................................. 7-48
IgnitionSwitch............................................ 4-4
Ignition Not Switched Off (STOP)
Warning Beep.................................... 7-43
Illuminated Entry System................. 5-87
Immobilizer System.......................... 3-35
Inside Trunk Release Lever.............. 3-18
Inspecting Brak e/Clutch Fluid
Level.................................................. 6-28
Inspecting Coolant Leve l.................. 6-26
Inspecting Engine Oil Level............. 6-26
Inspecting Washer Fluid Level......... 6-28
Instrument Cluster...... ....................... 4-12
Instrument Cluster (Type A)........4-13
Instrument Cluster (Type B)........4-30
Instrument Cluster (Type C)........4-46
Instrument Cluster (Type A)............. 4-13 Average Fuel Economy............... 4-21
Blind Spot Monitoring (BSM)
Display......................................... 4-21
Compass Display......................... 4-23
Cruise Control Set Vehicle Speed
Display......................................... 4-23
Current Fuel Econo my................ 4-21
Dashboard Illumina tion............... 4-19
Distance Recognition Support System
(DRSS) Display........................... 4-22
Distance-to-empty....................... 4-20
Engine Coolant Temperature
Gauge........................................... 4-18
Fuel Gauge.................................. 4-18
Indication/Indicator Lights.......... 4-26
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-22
Maintenance Monitor.................. 4-21
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) D isplay.......4-22
Message Indicated in Multi-
information Display (Type A)..... 7-40
Multi-information Display (Type
A)................................................. 4-14
Odometer..................................... 4-17
Outside Temperature Display...... 4-20
Speedometer................................ 4-13
Speed Unit Selector..................... 4-19
Tachometer.................................. 4-13
Traffic Sign Recognition System
(TSR) Display..............................4-22
Trip Meter....................................4-17
Warning Indication/Warning
Lights........................................... 4-24
Warning (Display Indication)...... 4-23
Instrument Cluster (Type B)............. 4-30 Average Fuel Economy............... 4-37
Blind Spot Monitoring (BSM)
Display......................................... 4-38
Compass Display......................... 4-39
Cruise Control Set Vehicle Speed
Display......................................... 4-39
Current Fuel Econo my................ 4-37
Dashboard Illumina tion............... 4-35
Distance Recognition Support System
(DRSS) Display........................... 4-38
Distance-to-empty....................... 4-36
Engine Coolant Temperature
Gauge........................................... 4-34
Fuel Gauge.................................. 4-34
Indication/Indicator Lights.......... 4-42
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-38
10-5
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Maintenance Monitor.................. 4-37
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display.......4-38
Message Indicated in Multi-
information Display (Type B)..... 7-40
Multi-information Display (Type
B)................................................. 4-31
Odometer..................................... 4-33
Outside Temperature Display...... 4-36
Speedometer................................ 4-30
Tachometer.................................. 4-30
Traffic Sign Recognition System
(TSR) Display..............................4-38
Trip Meter....................................4-33
Warning Indication/Warning
Lights........................................... 4-40
Warning (Display Indication)...... 4-39
Instrument Cluster (Type C)............. 4-46
Cruise Control Set Vehicle Speed
Display......................................... 4-53
Dashboard Illuminati on............... 4-50
Engine Coolant Temperature
Gauge........................................... 4-49
Fuel Gauge.................................. 4-49
Indication/Indi cator Lights.......... 4-56
Multi-information Display (Type
C)................................................. 4-47
Odometer..................................... 4-48
Outside Temperature Display...... 4-51
Speedometer................................ 4-46
Tachometer.................................. 4-46
Trip Computer............................. 4-51
Trip Meter....................................4-48
Warning Indication/Warning
Lights........................................... 4-54
Interior Care...................................... 6-60
Active driving display
maintenance................................. 6-62
Cleaning the floor mats............... 6-63
Cleaning the window interiors.....6-62Instrument panel top (Soft pad)
maintenance................................. 6-62
Leather upholstery
maintenance................................. 6-61
Panel maintenance....................... 6-62
Plastic part maintenance.............. 6-61
Seat belt maintenance..................6-60
Upholstery maintena nce.............. 6-61
Vinyl upholstery maintenance..... 6-60
Interior Lights................................... 5-84
Courtesy lights.............................5-84
Map lights....................................5-84
Overhead lights............................5-84
i-ACTIVSENSE.............................. 4-115 Active safety technology........... 4-115
Adaptive Front Lighting System
(AFS)......................................... 4-118
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-168
Blind Spot Monitoring (BSM) ............
................................................... 4-122
Camera and sensors................... 4-116
Distance Recognition Support System
(DRSS).......................................4-136
Forward Sensing Camera
(FSC)......................................... 4-204
High Beam Control System
(HBC)........................................ 4-119
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-157
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-144
Pre-crash safety technology....... 4-115
Radar sensors (rear)...................4-212
Radar sensor (front)...................4-209
Rear Cross Traffic Alert
(RCTA)...................................... 4-140
Smart Brake Suppor t (SBS)...... 4-174
10-6
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
