key MAZDA MODEL 6 2019 (in English) Workshop Manual

Declaration of Conformity
▼Keyless Entry System/Immobilizer System
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-44
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Personalization Features
▼Changeable System Settings/Equipment List
Safety Equipment (page 9-11)
Advanced Smart City Brake Support (Advanced SCBS)
Smart City Brake Support (SCBS)
Smart Brake Support (SBS)
Lane-keep Assist System (LAS) & Lane Departure Warning System (
LDWS)
Blind Spot Monitoring (BSM)
Distance Recognition Support System (DRSS)
Traffic Sign Recognition System (TSR)
Vehicle Equipment (page 9-13)
Illuminated entry system
Auto-wiper control
Auto headlight off
Auto-light control
High Beam Control System (HBC)
Adaptive Front Ligh ting System (AFS)
Lights-on reminder
Coming home light
Leaving home light
Turn signal indicator
Three-flash turn signal
Ambient lights
Other Equipment/Functions (page 9-14)
Door locks
Keyless entry system
Advanced keyless entry system
Active Driving Display
Fuel Economy Monitor
Display
Sound quality
Clock
Each system
Daytime running lights
Rear window defogger
Specifications
Personalization Features
9-10
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Method for changing functions using the center display
1. Select
on the home screen and display the setting screen.
2. Switch the tab to [Vehicle] and select the setting item you w ant to change.

Function and how it can be changed (underlined item is initial setting)
Door locks (page 3-14)
Operation condition of aut o lock/unlock function Lock: Out of Park
Unlock: In Park/
Lock: Shifting Out of Park/
Lock: When Driving Unlock: In Park/
Lock: When Driving Unlock: IGN Off
/
Lock: When Driving/ Off

Keyless entry system
Method for changing the unloc k functions using the key
1. Switch the ignition off and close all of the doors and the tr unk lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hol d the UNLOCK button on
the key for 5 seconds or longer (the sound of the doors locking /unlocking can be heard).
After this, the system switches the setting of pressing the dri ver's request switch once or
twice to unlock all doors each time the UNLOCK button is presse d (the sound of the
doors locking/unlocking can be heard).
4. The setting change is completed by doing any one of the follo wing:
Switching the ignition to ACC or ON.
Closing the driver's door.
Opening the trunk lid.
Not operating the key for ten seconds.
Pressing any button except the UNLOCK button on the key.
Pressing a request switch.
Specifications
Personalization Features
9-17
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Method for changing functions using the center display
1. Select
on the home screen and display the setting screen.
2. Switch the tab to [Vehicle] and select the setting item you want to change.
Function and how it can be changed (underlined item is initial setting)
Keyless entry system (page 3-3)
Method for un locking door using trans mitter All Doors: Once/Driv er's: Once, All Doors: Twice
Time for locking door automatically 90 seconds/60 seconds/30 seconds

Advanced keyless entry system
Method for changing the unlo ck functions using the key
1. Switch the ignition off and close all of the doors and the tr unk lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hol d the UNLOCK button on
the key for 5 seconds or longer (the sound of the doors locking /unlocking can be heard).
After this, the system switches the setting of pressing the driver's request switch once or
twice to unlock all doors each time the UNLOCK button is presse d (the sound of the
doors locking/unlocki ng can be heard).
4. The setting change is completed by doing any one of the follo wing:
Switching the ignition to ACC or ON.
Closing the driver's door.
Opening the trunk lid.
Not operating the key for ten seconds.
Pressing any button except the UNLOCK button on the key.
Pressing a request switch.
How to change the volume of the door lock/unlock beep sound
1. Switch the ignition off and close all of the doors and the tr unk lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hold the LOCK button on the
key for 5 seconds or longer. (All of the doors and the liftgate are locked and unlocked
when the LOCK button on the key is pressed and held for 5 secon ds.)
The beep sound activates at the currently set volume. The setting changes each time the
LOCK button on the key is pressed and the beep sound activates at the set volume. (If
the beep sound has been set to not activate, it will not activa te.)
4. The setting change is completed by doing any one of the follo wing:
Switching the ignition to ACC or ON.
Closing the driver's door.
Specifications
Personalization Features
9-18
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Opening the trunk lid.
Not operating the key for ten seconds.
Pressing any button except the LOCK button on the key.
Pressing a request switch.
Method for changing functions using the center display
1. Select
on the home screen and display the setting screen.
2. Switch the tab to [Vehicle] and select the setting item you w ant to change.
Function and how it can be changed (underlined item is initial setting)
Advanced keyless entry system (page 3-8)
Method for unlocking door using transmitter All Doors: Once/Driv er's: Once, All Doors: Twice
Time for locking door automatically 90 seconds/60 seconds/30 seconds
Walk-away auto lock function operation/
non-operational ON/OFF
Beep volume when locking/unlocking
High/Medium/Low/Off

Active Driving Display
Method for changing functions using the center display
1. Select
on the home screen and display the setting screen.
2. Switch the tab to [AD-Disp] an d select the setting item you want to change.
Function and how it can be changed (underlined item is initial setting)
Active Driving Display (page 4-59)
Setting can be changed so that the Active Driv‐
ing Display is not displayed. ON
/OFF
The display height (up/down position) can be
changed. –13―0
―+13
(total: 27 steps)
The method for adjusting the display brightness
(automatically/manually) can be changed. Auto
/Man.
The standard brightness while automatic adjust‐
ment is selected can be changed using the bright‐
ness adjustment. –2―0
―+2
(total: 5 steps)
The standard brightness while manual adjust‐
ment is selected can be changed using the bright‐
ness adjustment. –20―0
―+20
(total: 41 steps)
The display angle can be changed. –3―0
―+3
(total: 7steps)
The street name display ti ming can be changed. Always
/At Maneuver/Off
Specifications
Personalization Features
9-19
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
A
Accessory Socket.............................. 5-88
Active driving display....................... 4-59
Active Driving Display..................... 4-59
Adaptive Front Lighting System
(AFS)............................................... 4-118
Add-On Non-Genuine Parts and
Accessories........................................ 8-20
Advanced Key
Advanced keyless entry system..... 3-8
Operational range.......................... 3-9
Advanced Keyless Entry System........ 3-8
Advanced Smart City Brake Support
(Advanced SCBS)........................... 4-168 Collision warning.... .................. 4-170
Stopping the Advanced Smart City
Brake Support (Advanced SCBS)
system operation........................ 4-170
Air Bag Systems............................... 2-52
Air Bag/Seat Belt Pr etensioner System
Warning Beep.................................... 7-42
Antilock Brake System (ABS)........ 4-105
Armrest Box...................................... 5-93
Audio Control Switch Adjusting the Volume.................... 5-9
Seek Switch................................... 5-9
Audio Set Android Auto™........................... 5-37
Apple CarPlay............................. 5-34
Applications................................. 5-69
AUX.............................................5-27
Bluetooth®.................................. 5-41
Radio............................................5-19
Satellite Radio........ ..................... 5-23
Settings........................................ 5-18
Troubleshooting.......... ................. 5-70
USB............................................. 5-28
Voice Recognition.... ................... 5-66
Audio System Antenna........................................5-12
Appendix..................................... 5-76
Audio Control Switch................... 5-9
Audio Set..................................... 5-13
AUX/USB mode..........................5-10
Before Using the Audio System.... 5-9
AUTOHOLD..................................... 4-99
AUTOHOLD Warning Beep.............7-44
Automatic Transaxle......................... 4-64 Active Adaptive Shift (AAS)...... 4-66
Automatic transaxle controls....... 4-64
Direct mode................................. 4-72
Driving tips..................................4-72
Manual shift mode.......................4-67
Shift-lock system......................... 4-65
Transaxle ranges.......................... 4-65
B
Battery............................................... 6-34Maintenance.................................6-36
Replacement................................ 6-36
Specifications.................................9-4
Battery Runs Out.............................. 7-14 Jump-starting............................... 7-14
Blind Spot Monitoring (BSM)........ 4-122 Canceling operation of Blind Spot
Monitoring (BSM).....................4-127
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-45
Bluetooth® Bluetooth® Audio....................... 5-47
Bluetooth® Hands-Free...............5-57
Bluetooth® Preparation............... 5-44
Body Lubrication.............................. 6-29
Bottle Holder..................................... 5-91
Brakes Brake assist.................................. 4-98
Electric parking brake (EPB)...... 4-95
Foot brake....................................4-94
Pad wear indicator....................... 4-97
Parking brake...............................4-95
10-2
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Smart City Brake Support
(SCBS)....................................... 4-171
Traffic Sign Recognition System
(TSR)......................................... 4-128
360°View Monitor..................... 4-177
J
Jack...................................................... 7-4
Jump-Starting.................................... 7-14
K
Keyless Entry System......................... 3-3
Keys.....................................................3-2
Key suspend function.................... 3-7
Transmitter.............. .......................3-4
Key Left-in-trunk Warning Beep (With
the advanced keyless function)......... 7-44
Key Left-in-vehicle Warning Beep (With
the advanced keyless function)......... 7-44
Key Removed from Vehicle Warning
Beep...................................................7-43
Key Suspend Function........................ 3-7
L
Label Information............................... 9-2
Lane Departure Warning sound........ 7-45
Lane-change Signals......................... 4-79
Lane-Change Signals........................ 4-79
Lane-keep Assist System (LAS) & Lane
Departure Warning System
(LDWS)........................................... 4-157
Leaving Home Light......................... 4-78
Lighting Control................................4-74
Lights-on Reminder.......................... 7-42
Light Bulbs
Replacement................................ 6-43
Specifications.................................9-7
Lubricant Quality ................................ 9-4
Luggage Compartment......................5-94
M
Maintenance
Information.................................... 6-2
Scheduled.......................................6-4
Maintenance Monitor........................ 6-15
Map Lights........................................ 5-84
Mazda Radar Cruise Control with Stop &
Go function (MRCC with Stop & Go
function).......................................... 4-144
Close proximity warning........... 4-147
Cruise control function.............. 4-154
Display indication......................4-146
Setting the system..................... 4-148
Stop hold control....................... 4-153
Mazda Radar Cruise Control with Stop &
Go function (MRCC with Stop & Go
function) System Warnings............... 7-45
Message Indicated on Display.......... 7-38
Meters................................................ 4-12
Mirrors Outside mirrors..... ....................... 3-24
Rearview mirror.......................... 3-26
Mirror Defogger......... ....................... 4-84
Moonroof...........................................3-32
Multi-information Display (Type
A).......................................................4-14
Multi-information Display (Type
B)....................................................... 4-31
Multi-information Display (Type
C)....................................................... 4-47
O
Outside Mirrors......... ........................ 3-24
Overhead Console............................. 5-92
Overhead Lights................................ 5-84
Overheating....................................... 7-18
Overloading....................................... 3-44
Owner Maintenance Closing the hood...... ................... 6-21
10-7
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Engine compartment overview.... 6-22
Key battery replacement..............6-36
Opening the hood........................ 6-20
Owner maintenance
precautions................................... 6-18
P
Parking Brake....................................4-95
Parking Sensor System................... 4-232
Park assist sensor system
operation.................................... 4-236
Sensor detection range.............. 4-234
Personalization Features................... 9-10
Power Steering................................ 4-114
Power Steering Warning Buzzer....... 7-44
Power Windows................................ 3-29
R
Radar Sensors (Rear)...................... 4-212
Radar Sensor (Front).......................4-209
Rearview Mirror................................3-26
Rear Coat Hooks............................... 5-94
Rear Cross Traffic Alert (RCTA).... 4-140
Rear Door Child Safet y Locks.......... 3-15
Rear Seat........................................... 2-15
Rear View Monitor......................... 4-224
Displayable range on the
screen......................................... 4-226
Picture quality adjustment......... 4-231
Rear view monitor operation..... 4-227
Rear view parking camera
location...................................... 4-225
Switching to the rear view monitor
display........................................4-225
Variance between actual road
conditions and displayed
image......................................... 4-230
Viewing the display................... 4-227
Rear Window Defogger.................... 4-83
Recommended Oil.............................6-23
Recording of Vehicle Data................ 8-23
Recreational Towing......................... 3-47
Registering Your Vehicle in A Foreign
Country.............................................. 8-19
Replacement Fuse..............................................6-47
Key battery.................................. 6-36
Light bulbs...................................6-43
Tires............................................. 6-40
Wheel........................................... 6-42
Wiper........................................... 6-30
Request Switch Inoperable Warning
Beep (With the advanced keyless
function)............................................ 7-44
Rocking the Vehicle.......................... 3-41
S
Safety Defects, Reporting................. 8-15
Saving Fuel and Protection of the
Environment...................................... 3-39
Scheduled Maintenance...................... 6-4
Seat Seat position memory.................. 2-11
Seats Front seat....................................... 2-5
Head restraint.............................. 2-17
Rear seat...................................... 2-15
Seat ventilation............................ 2-20
Seat warmer................................. 2-19
Seat Belt System Automatic locking....................... 2-24
Emergency locking...................... 2-24
Extender....................................... 2-28
Pregnant women.......................... 2-24
Seat belt precautions................... 2-22
3-point type................................. 2-25
Seat Belt Warning Beep.................... 7-42
Security System Immobilizer system..................... 3-35
Theft-deterrent system.................3-37
10-8
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Turn and Lane-Change Signals......... 4-79
Turn Signals...................................... 4-79
U
USB Power Outlet............................ 5-89
V
Vanity Mirrors................................... 5-83
Vehicle Information Labels................. 9-2
W
Warning Sound is Activated............. 7-42Air bag/seat belt pr etensioner system
warning beep............................... 7-42
AUTOHOLD Warning Beep....... 7-44
Blind Spot Monitoring (BSM)
warning beep............................... 7-45
Collision warning...... .................. 7-46
Electric Parking Brake (EPB)
Warning Beep.............................. 7-44
Excessive speed warning.............7-46
Ignition not switched off (STOP)
warning beep............................... 7-43
Key left-in-trunk warning beep (With
the advanced keyless function).... 7-44
Key left-in-vehicle warning beep
(With the advanced keyless
function).......................................7-44
Key removed from vehicle warning
beep..............................................7-43
Lane Departure Warning sound... 7-45
Lights-on reminder...................... 7-42
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) system
warnings.......................................7-45
Power steering warning buzzer....7-44
Request switch inoperable warning
beep (With the advanced keyless
function).......................................7-44
Seat belt warning beep................ 7-42
Tire inflation pressure warning
beep..............................................7-44
Warning/Buzzer................................. 7-23
Warranty............................................ 8-17
Weights................................................ 9-6
Windows Power windows........................... 3-29
Windshield Washer........................... 4-83
Windshield Wipers............................ 4-80
Windshield Wiper De-icer................ 4-84
Winter Driving.................................. 3-41
Wiper
Replacing windshield wiper
blades........................................... 6-30
0-9
360°View Monitor...........................4-177Front wide view.........................4-191
How to use the system.............. 4-183
Margin of error be tween road surface
on screen and actual road
surface........................................4-200
Rear wide view..........................4-198
Side view................................... 4-192
Top view/Front view................. 4-187
Top view/Rear view.................. 4-194
Types of images displayed on the
screen......................................... 4-181
10-10
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
