▼Tire Rotation
WA R N I N G
Rotate tires periodically:
Irregular tire wear is dangerous. To
equalize tread wear for maintaining good
performance in handling and braking,
rotate the tires every 12,000 km (7,500
miles). However Mazda recommends to
rotate every 8,000 km (5,000 miles) to help
increase tire life and distribute wear more
evenly.
Refer to Scheduled Maintenance on page
6-4.

During rotation, inspect them for correct
balance.

Do not include (TEMPORARY USE
ONLY) spare tire in rotation.
Forward
Also, inspect them for uneven wear and
damage. Abnormal wear is usually caused
by one or a combinati
on of the following:

Incorrect tire pressure
Improper wheel alignment
Out-of-balance wheel
Severe braking

After rotation, inflate all tire pressures to
specification (page 9- 8) and inspect the
lug nuts for tightness.
CAUTION
Rotate unidirectional tires and radial tires
that have an asymmetrical tread pattern or
studs only from front to rear, not from side
to side. Tire performance will be reduced if
rotated from side to side.
▼ Replacing a Tire
WA R N I N G
Always use tires that are in good condition:
Driving with worn tires is dangerous.
Reduced braking, steering, and traction
could result in an accident.
Replace all four tires at the same time:
Replacing just one tire is dangerous. It
could cause poor handling and poor
braking resulting in loss of vehicle control.
Mazda strongly recommends that you
replace all four tires at the same time.
If a tire wears evenly, a wear indicator will
appear as a solid band across the tread.
Replace the tire when this happens.
New tread
Tread wear
indicator
Worn tread
Maintenance and Care
Owner Maintenance
6-40
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

CAUTION
When removing the lens or lamp unit using
a flathead screwdriver, make sure that the
flathead screwdriver does not contact the
interior terminal. If the flathead screwdriver
contacts the terminal, a short circuit may
occur.
NOTE
To replace the bulb, contact an
Authorized Mazda Dealer.
Use the protective cover and carton for
the replacement bulb to dispose of the
old bulb promptly and out of the reach
of children.
▼Replacing Exterior Light Bulbs
The exterior lights
have either LEDs or
normal bulbs.
Only the bulb for a parking light can be
replaced.
LED type
Headlights
Daytime running lights
Parking lights*
Front turn signal lights
Front side-marker lights
Side turn signal lights
High-mount brake light
Rear turn signal lights
Rear side-marker lights
Brake lights
Taillights
Reverse lights
License plate lights
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
Bulb type
Parking lights*
Double-filament light bulb, however, only
5 W filament bulb is used in the parking
lights.
1. Make sure the ignition is switched off, and the headligh t switch is off.
2. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right.
3. Pull the center of each plastic retainer and remove the retainers.
Removal
Installation
Maintenance and Care
Owner Maintenance
6-44*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
36 WIPER.DEI 20A Windshield wiper de-icer
37 ENG.+B 7.5 A Engine control system
38 H/L LOW L 15 A Headlight low beam (LH)
39 GLOW SIG 5 A ―
40 ENGINE1
ENGINE4 15 A Engine control system
41 C/U IG1 15 A Engine control system
42 ST.HEATER 15 A Heated steering wheel
43 ― ― ―
44 AUDIO1 25 A Audio system
45 ABS/DSC S 30 A ABS, Dynamic stability control system
46 FUEL PUMP 15 A Fuel system
*
47 FUEL WARM 25 AFuel warmer*
48TAIL 15 A Taillights, License plate lights
49 SCR2
FUEL PUMP2 25 A
Fuel system
*
50 HAZARD 25 A Hazard warning flashers, Turn signal lights/Front side-marker
lights, Parking lights
51 H/L LOW R 15 A Headlight low beam (RH)
52 OUTLET 25 A Accessory sockets
53 STOP 10 A Brake lights
54 ROOM 25 A Overhead light
Maintenance and Care
Owner Maintenance
*Some models.6-51
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Changing a Flat Tire
NOTE
If the following occurs while driving, it
could indicate a flat tire.
Steering becomes difficult.
The vehicle begins to vibrate
excessively.
The vehicle pulls in one direction.
If you have a flat tire, drive slowly to a
level spot that is well off the road and out
of the way of traffic to change the tire.
Stopping in traffic or on the shoulder of a
busy road is dangerous.
WA R N I N G
Be sure to follow the directions for
changing a tire:
Changing a tire is dangerous if not done
properly. The vehicle can slip off the jack
and seriously injure someone.
No person should place any portion of their
body under a vehicle that is supported by a
jack.
Never allow anyone inside a vehicle
supported by a jack:
Allowing someone to remain in a vehicle
supported by a jack is dangerous. The
occupant could cause the vehicle to fall
resulting in serious injury.
NOTE
Make sure the jack is well lubricated
before using it.
1. Park on a hard, level surface off the right-of-way and firmly set the parking
brake.
2. Put a vehicle with an automatictransaxle in Park (P), a manual
transaxle in Reverse (R) or 1, and turn
off the engine.
3. Turn on the hazard warning flasher.
4. Have everyone get out of the vehicle and away from the vehicle and traffic.
5. Remove the jack, tool, and spare tire (page 7-3).
6. Block the wheel diagonally opposite the flat tire. When blocking a wheel,
place a tire block both in front and
behind the tire.
NOTE
When blocking a tire, use rocks or
wood blocks of sufficient size if
possible to hold the tire in place.
If Trouble Arises
Flat Tire
7-6
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

SignalWarning
Power Steering Mal‐
function Indication*
The message is displayed if the electric power steering has a m alfunction.
If the message is displayed, st op the vehicle in a safe place a nd do not operate the
steering wheel. There is no problem if the message in the displ ay turns off after a
while. Contact an Authorized Mazda Dealer if the message is dis played continuously.
NOTE
If the message is displayed, the power steering will not operate normally. In this
case, the steering wheel can still be operated, however, the operation may feel
heavy compared to normal, or the stee ring wheel could vibrate when turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the po wer steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
Power Steering Mal‐ function Indicator
Light
*
The light illuminates/flashes if the electric power steering ha s a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe pl ace and do not operate the
steering wheel. There is no problem if the light turns off afte r a while. Contact an Au‐
thorized Mazda Dealer if the lig ht illuminates/flashes continuously.
NOTE
If the indicator light illuminates/flashes , the power steering will not operate nor ‐
mally. If this happens, th e steering wheel can still be operated, however, the opera ‐
tion may feel heavy compared to normal, or the steering wheel could vibrate when
turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the po wer steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
▼ Contact Authorized Mazda Deal
er and Have Vehicle Inspected
If any of the following warning lights o r the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.
SignalWarning
ABS Warning LightIf the ABS warning light stays
on while you're driving, the ABS control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an A uthorized Mazda Dealer as soon as possible.
NOTE
When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.
The brake assist system does not operate while the ABS warning light is illuminated.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-26*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Request Switch Inoperable Warning
Beep (With the advanced keyless
function)
If the request switch is pressed with the
door open or ajar, or the ignition is not
switched OFF with a key being carried, a
beep will be heard outside for about 2
seconds to notify the driver that the door
or trunk lid cannot be locked.
▼Key Left-in-trunk Compartment
Warning Beep (With the advanced
keyless function)
If the key is left in the trunk with all the
doors locked and the trunk lid closed, a
beep will be heard outside for about 10
seconds to notify the driver that the key is
in the trunk. In this case, take out the key
by pressing the electric trunk lid opener
and opening the trunk lid. The key taken
out of the trunk may not operate because
its functions have been temporarily
stopped. To restore the key's functions,
perform the applicable procedure (page
3-7).
▼Key Left-in-vehicle Warning Beep
(With the advanced keyless
function)
If all the doors and trunk are locked using
another key while the key is left in the
cabin, the beep which sounds outside of
the vehicle will be heard for about 10
seconds to notify the driver that the key is
in the cabin. In this case, take out the key
by opening the door. A key taken out of
the vehicle using this method may not
operate because its functions have been
temporarily stopped. To restore the key's
functions, perform the applicable
procedure (page 3-7).
▼ Power Steering Warning Buzzer
If the power steer
ing system has a
malfunction, the power steering
malfunction indication/malfunction
indicator light turns on or flashes and the
buzzer operates at the same time.
Refer to Stop Vehicle in Safe Place
Immediately on page 7-23.
▼ Electric Parking Brake (EPB)
Warning Beep
The warning buzzer is activated under the
following conditions:
The vehicle is driven with the parking
brake applied.
The Electric Parking Brake (EPB)
switch is pulled while the vehicle is
driven.
▼Tire Inflation Pressure Warning
Beep
The warning beep sound will be heard for
about 3 seconds if the tire pressures
decrease.
Refer to Tire Pressure Monitoring System
on page 4-220.
▼AUTOHOLD Warning Beep
Warning light flashes/m
essage is displayed
and beep sound is activated
simultaneously for about 5 seconds when
using AUTOHOLD function or when
AUTOHOLD switch is operated.
Because a problem with AUTOHOLD
function has occurred, AUTOHOLD
function does not operate even if
AUTOHOLD switch is operated.

If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-44
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Replacing a Tire
WA R N I N G
Always use tires that are in good condition:
Driving with worn tires is dangerous. Reduced br
aking, steering, and traction could result in
an accident.
If a tire wears evenly, a wear ind icator will appear as a solid band across the tread.
Replace the tire when this happens.
New tread Tread wear indicator
Worn tread
You should replace the tire before the band crosses the entire tread.
NOTE
Tires degrade over time, even when they are not being used on the road. It is recommended
that tires generally be replaced when they are 6 years or older. Heat caused by hot climates
or frequent high loading conditions can accelerate the aging process. You should replace
the spare tire when you replace the other road tires due to the aging of the spare tire. The
period in which the tire was manufactured (both week and year) is indicated by a 4-digit
number.
Refer to Tire Labeling on page 8-26.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-35
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Vehicle Loading
WA R N I N G
Do not tow a trailer with this vehicle:
Towing a trailer with this vehicle is dangerous because it has not been designed to tow a
trailer and doing so will affect the drive sy stem which could result in vehicle damage.
This section will guide you in the proper loading of your vehic le, to keep your loaded
vehicle weight within its desig n rating capability. Properly loading your vehicle will provide
maximum return of vehicle design performance. Before loading yo ur vehicle, familiarize
yourself with the following term s for determining your vehicle's weight ratings, from the
vehicle's Safety Certification La bel and Tire and Load Information Label:
WA R N I N G
Overloaded Vehicle:
Overloading a vehicle is dangerous. The results of overloading can have serious consequences
in terms of passenger safety. Too much weight on a vehicle's suspension system can cause
spring or shock absorber failure, brake failure , handling or steering problems, irregular tire
wear, tire failure or other damage.
Overloading makes a vehicle harder to drive and control. It also increases the distance
required for stopping. In cases of serious overl oading, brakes can fail completely, particularly
on steep grades. The load a tire will carry safely is a combination of the size of the tire, its load
range, and corresponding inflation pressure.
Never overload the vehicle and always observe th e vehicle's weight ratings from the vehicle's
Safety Certification and Tire and Load Information labels.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-37
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Safety Equipment
You can change t
he function settings acco rding to your preference.
Personalization features which c an be changed differ depending on the vehicle specifica‐
tion.
Personalization features which can be changed may change withou t notice depending on
software updates.
The following personalization features can be set or changed by the customer or an Author‐
ized Mazda Dealer. Consult an Authorized Mazda Dealer for detai ls.
Personalization features which can be changed differ depending on the specification.
Setting change method
1. Select on the home screen and display the setting screen.
2. Switch the tab to [Safety] and select the setting item you wa nt to change.
Function and how it can be changed (underlined item is initial setting)
Advanced Smart City Brake Support (Advanced SCBS) (page 4-168)
Smart Brake Support (SBS) (page 4-174)
The system can be changed so that Advanced Smart City
Brake Support (Advanced SCBS)/Smart Brake Support
(SBS) does not operate.
*1On/Off
The distance at which the collision warning activates can be
changed. Far/Med.
/Near
The volume of the collision warning can be changed. High
/Low/Off
Smart City Brake Support (SCBS) (page 4-171)
The system can be changed so that Smart City Brake Sup‐
port (SCBS) does not operate.
*1On/Off
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) (page 4-157)
The system can be changed so that the steering wheel assist
does not operate. On
/Off
The sensitivity of the warning for the Lane-keep Assist Sys‐
tem (LAS) & Lane Departure Warning System (LDWS) can
be changed. High
/Low
When the steering
wheel operation as‐
sistance is turned on The system can be changed so that
the Lane Departure Warning does not
activate.
On
/Off
When the steering
wheel operation as‐
sistance is turned off The warning timing in which the sys‐
tem determines that the vehicle may
be deviating from its lane can be
changed.
At
/Before
The sensitivity of the warning for the
system can be changed. Often
/Rare
Specifications
Personalization Features
9-11
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Index
Engine compartment overview.... 6-22
Key battery replacement..............6-36
Opening the hood........................ 6-20
Owner maintenance
precautions................................... 6-18
P
Parking Brake....................................4-95
Parking Sensor System................... 4-232
Park assist sensor system
operation.................................... 4-236
Sensor detection range.............. 4-234
Personalization Features................... 9-10
Power Steering................................ 4-114
Power Steering Warning Buzzer....... 7-44
Power Windows................................ 3-29
R
Radar Sensors (Rear)...................... 4-212
Radar Sensor (Front).......................4-209
Rearview Mirror................................3-26
Rear Coat Hooks............................... 5-94
Rear Cross Traffic Alert (RCTA).... 4-140
Rear Door Child Safet y Locks.......... 3-15
Rear Seat........................................... 2-15
Rear View Monitor......................... 4-224
Displayable range on the
screen......................................... 4-226
Picture quality adjustment......... 4-231
Rear view monitor operation..... 4-227
Rear view parking camera
location...................................... 4-225
Switching to the rear view monitor
display........................................4-225
Variance between actual road
conditions and displayed
image......................................... 4-230
Viewing the display................... 4-227
Rear Window Defogger.................... 4-83
Recommended Oil.............................6-23
Recording of Vehicle Data................ 8-23
Recreational Towing......................... 3-47
Registering Your Vehicle in A Foreign
Country.............................................. 8-19
Replacement Fuse..............................................6-47
Key battery.................................. 6-36
Light bulbs...................................6-43
Tires............................................. 6-40
Wheel........................................... 6-42
Wiper........................................... 6-30
Request Switch Inoperable Warning
Beep (With the advanced keyless
function)............................................ 7-44
Rocking the Vehicle.......................... 3-41
S
Safety Defects, Reporting................. 8-15
Saving Fuel and Protection of the
Environment...................................... 3-39
Scheduled Maintenance...................... 6-4
Seat Seat position memory.................. 2-11
Seats Front seat....................................... 2-5
Head restraint.............................. 2-17
Rear seat...................................... 2-15
Seat ventilation............................ 2-20
Seat warmer................................. 2-19
Seat Belt System Automatic locking....................... 2-24
Emergency locking...................... 2-24
Extender....................................... 2-28
Pregnant women.......................... 2-24
Seat belt precautions................... 2-22
3-point type................................. 2-25
Seat Belt Warning Beep.................... 7-42
Security System Immobilizer system..................... 3-35
Theft-deterrent system.................3-37
10-8
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
