▼Instrument Panel Top (Soft pad)
Maintenance
Extremely soft material
is used for the soft
pad surface. If the soft pad surface is
rubbed harshly with a dry cloth, it could
result in the surface being damaged and
leaving white scratch marks.
1. Wipe the soiled area with a soft cloth
soaked in a mild detergent (approx.
5%) diluted with water.
2. Wipe off the remaining detergent using
a cloth soaked in clean water and
wrung out well.
▼Active Driving Display
Maintenance*
The dust-proof sheet has a coating. When
cleaning, do not use a hard or
rough-surface cloth, or cleaning detergent.
In addition, if a chemical solvent gets on
the active driving display, wipe it off
immediately. The dust-proof sheet could
be damaged and the surface coating could
be scratched. Use a fine, soft cloth such as
those used for cleaning eyeglasses.
NOTE
Use of compressed air when cleaning the
dust-proof sheet is recommended.
▼ Panel Maintenance
If a panel becomes soil
ed, wipe it off with
a soft cloth soaked in clean water and
thoroughly wrung out.
If some areas require f urther cleaning, use
the following procedure:
1. Wipe the soiled area with a soft cloth soaked in a mild detergent (approx.
5 %) diluted with water.
2. Wipe off the remaining detergent using a cloth soaked in clean water and
wrung out well.
NOTE
Be particularly careful when cleaning
shiny surface panels and metallic parts
such as plating as they can be scratched
easily.
▼Cleaning the Window Interiors
If the windows become covered with an
oily, greasy, or waxy film, clean them with
glass cleaner. Follow
the directions on the
container.
CAUTION
 Do not scrape or scratch the inside of the
window glass. It could damage the
thermal filaments and the antenna lines.
 When washing the inside of the window
glass, use a soft cloth dampened in
lukewarm water, gently wiping the
thermal filaments and the antenna lines.
Use of glass cleaning products could
damage the thermal filaments and the
antenna lines.
Maintenance and Care
Appearance Care
6-62*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

SignalWarning
(Red)
Brake Pedal Opera‐
tion Demand Warn‐
ing Light
*
When only flashing
Flashes if there is the possibility of the vehicle not being he ld in the stopped position by
the AUTOHOLD function, such as on steep slopes. Depress and hol d your foot on the
brake pedal.
When flashing and beep sound is activated at the same time
The warning light flashes and the beep sound is activated for a bout 5 seconds if there is a
problem with the system. If the warning light flashes and the warning sound is activated,
immediately depress the brake pedal and stop using the AUTOHOLD function then con‐
tact an Authorized Mazda Dealer.
WA R N I N G
Immediately depress the brake pedal if the warning light flashes and the beep sound is acti‐
vated while using the AUTOHOLD function:
Because the AUTOHOLD function is canceled forcibly, the vehicle may move unexpectedly
and result in an accident.
Check Engine Light If this light illuminates while d
riving, the vehicle may have a problem. It is important to
note the driving conditions whe n the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:
The engine's electrical system has a problem.The emission control system has a problem.The fuel tank level being ve ry low or approaching empty.The fuel-filler cap is missing or not tightened securely.
If the check engine light remains on, or it flashes continuously , do not drive at high
speeds and consult an Authorized Mazda Dealer as soon as possible.
WA R N I N G
If the check engine light turns on, do not disconnect the battery cables.
If the battery cables are disconnected and th en reconnected, the engine could be damaged
and catch on fire.
Automatic Trans‐
axle Warning Indi‐ cation/Warning
Light
*
The indication/light illuminates when the transaxle has a problem.
CAUTION
If the automatic transaxle warning indication/lig ht illuminates, the transaxle has an electri‐
cal problem. Continuing to drive your Mazda in this condition could cause damage to your
transaxle. Consult an Authorized Mazda Dealer as soon as possible.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-28*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

If the warning light flashes/message is
displayed and the beep sound is activated
simultaneously, have your vehicle
inspected at an Authorized Mazda Dealer.
▼ Blind Spot Monitoring (BSM)
System Warning Beep*
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Monit
oring (BSM) warning
light is illuminated.
NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Safety Equipment on page 9-11.
Reversing
The Blind Spot Monitoring (BSM)
warning sound is activated if there is a
possibility of collision with a vehicle
approaching from behind and from the
rear on the left and right sides of the
vehicle.
▼ Lane Departure Warning Sound*
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
The volume of the Lane-keep Assist
System (LAS) & Lane Departure
Warning System (LDWS) warning sound
can be changed.
Refer to Safety Equipment on page
9-11.
The type of the Lane-keep Assist System
(LAS) & Lane Departure Warning
System (LDWS) warning sound can be
changed.
Refer to Safety Equipment on page
9-11.
▼Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) System
War ni ng s
*
The Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) system warnings notify the
driver of system pr
oblems and precautions
on use when required. Check after hearing
a warning beep sound.
Warning beep What to check
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system is operating,
a single beep sound is
heard when “Front Ra‐
dar Sensor Blocked” is
displayed in the mul‐
ti-information display. Cancel the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system if the radar
sensor (front) becomes
dirty. Clean the area
around the radar sensor
(front).
The beep sounds inter‐
mittently while the vehi‐
cle is being driven. The distance between
your vehicle and the ve‐
hicle ahead is too close.
Verify the safety of the
surrounding area and re‐
duce vehicle speed.
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system is operating,
a single beep sound is
heard when “ Front Ra‐
dar Sensor System Mal‐
function” is displayed in
the multi-information
display. A malfunction in the
system may be indicated.
Check the center display
to verify the problem
and then have your vehi‐
cle inspected by an Au‐
thorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-45
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

▼STEP 2: Contact Mazda No
rth American Operations
If for any reason you feel the need for further assistance afte r contacting your dealership
management or it becomes necessary to have the components or wi ring system for the
supplementary restraint system m odified to accommodate a person with certain medical
conditions in accordance with a certified physician, you can re ach Mazda North American
Operations by one of the following ways.

Log on: at www.MazdaUSA.com

Answers to many questions, including how to locate or contact a local Mazda dealership in
the U.S., can be found here.

E-mail: click on “Contact Us” lo cated on the bottom of the page at www.mazdausa.com
under “Help”

By phone at: 1 (800) 222-5500

By letter at:
ATTN: Customer Experience Center
Mazda North American Operations
200 Spectrum Center Drive Suite 100
Irvine, California 92618
P.O. Box 19734
Irvine, CA 92623-9734

In order to serve you efficiently and effectively, please help us by providing the following
information:
1. Your name, address, and telephone number
2. Year and model of vehicle
3. Vehicle Identification Number (17 digits, noted on your regis tration or title or located on
the upper driver's side corner of the dash)
4. Purchase date and current mileage
5. Your dealer's name and location
6. Your question(s)

If you live outside the U.S.A., please contact your nearest Maz da Distributor.
Customer Information and Reporting Safety Defects
Customer Assistance
8-3
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Customer Assistance (Canada)
▼Satisfaction Review Process
Your complete and permanent satisfaction is of primary concern
to Mazda. All Authorized
Mazda Dealers have both the know ledge and tools to keep your Mazda in top condition. In
our experience, any questions, problems, or complaints regardin g the operation of your
Mazda or any other general service transactions are most effect ively resolved by your
dealer. If the cause of your dissatisfaction cannot adequately be addressed by normal
dealership procedures, we recommend that you take the following steps:
▼STEP 1: Contact the Mazda Dealer
Discuss the matter with
a member of dealership management. If t he Service Manager has
already reviewed your concerns, contact the owner of the dealership or its General Manager.
▼ STEP 2: Contact the Mazda Regional Office
If you feel that you still require assistance, ask the dealer S
ervice Manager to arrange for
you to meet the local Mazda Service Representative. If more exp edient, contact Mazda
Canada Inc. Regional Office nearest you for such arrangements. Regional Office address
and phone numbers are shown (page 8-10).
▼ STEP 3: Contact the Mazda Customer Relations Department
If still not substantially satisfi
ed, contact the Customer Rela tions Department, Mazda
Canada Inc., 55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Ca nada TEL: 1 (800)
263-4680.
Provide the Department with the following information:

1. Your name, address and telephone number
2. Year and model of vehicle
3. Vehicle Identification Number ( VIN). Refer to the Vehicle Identification Number on
page 9-2 for the location of the VIN.
4. Purchase date
5. Present odometer reading
6. Your dealer's name and location
7. The nature of your problem and/or cause of dissatisfaction

The Department, in cooperation w ith the local Mazda Service Representative, will review
the case to determine if everything possible has been done to e nsure your satisfaction.

Please recognize that the resolu tion of service problems in mos t cases requires the use of
your Mazda dealer's service facilities, personnel and equipment . We urge you to follow the
above three steps in sequence for most effective results.
Customer Information and Reporting Safety Defects
Customer Assistance
8-8
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Customer Assistance (Puerto Rico)
Your complete and permanent satisfaction is our business. That is why all Authorized
Mazda Dealers have the knowledge and the tools to keep your Maz da vehicle in top
condition.
If you have any questions or recommendations for improvement re garding the service of
your Mazda vehicle or servicing by Mazda Dealer personnel, we r ecommend that you take
the following steps:
▼ STEP 1
Discuss the matter with an Authorized Mazda Dealer. This is the
quickest and best way to
address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS,
SALES, SERVICE, or PARTS MANAGER, then please contact the GENER AL
MANAGER of the dealer ship or the OWNER.
▼STEP 2
If, after following STEP 1, you feel the need for further assis
tance, please contact your
area's Mazda representative.
Refer to Importer/Distributor on page 8-14.

Please help us by providing the following information:

1. Your name, address, and telephone number
2. Year and model of vehicle
3. Vehicle Identification Number (17 digits, noted on your regis tration or title or located on
the upper driver's side corner of the dash)
4. Purchase date and current mileage
5. Your dealer's name and location
6. Your question(s)
Customer Information and Reporting Safety Defects
Customer Assistance
8-11
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Light bulbCategory
Wat t a ge UN-R*1
Vanity mirror lights*Bulb type 2―
LED type LED
*2―
Courtesy lights LED
*2―
Ambient lights
*LED*2―
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
▼ Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label fo
r tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-39.
Standard tire
(U.S.A. and Canada)
Tire size Inflation pressure
Front Rear
P225/55R17 95V 250 kPa (36 psi)250 kPa (36 psi)
P225/45R19 92W
*1240 kPa (35 psi) 240 kPa (35 psi)
(Mexico)
Tire size Inflation pressure
Up to 3 persons ―Full load
225/55R17 97V Front
230 kPa (2.3 bar, 33 psi) 250 kPa (2.5 bar, 36 psi)
Rear 230 kPa (2.3 bar, 33 psi) 320 kPa (3.2 bar, 46 psi)
225/45R19 92W
*2Front 230 kPa (2.3 bar, 33 psi) 250 kPa (2.5 bar, 36 psi)
Rear 230 kPa (2.3 bar, 33 psi) 320 kPa (3.2 bar, 46 psi)
1 person's weight: About 75 kg*1P225/45R19 92W
Before driving at high speeds, increase the pressure of the fro nt tires. For speeds above 200 km/h (124 mph),
increase the pressure of the front tires by 20 kPa (0.2 bar, 2. 9 psi).
*2225/45R19 92W (SKYACTIV-G 2.5T)
Before driving at high speeds, increase the pressure of the fro nt tires. For speeds above 210 km/h (130 mph),
increase the pressure of the front tires by 20 kPa (0.2 bar, 2. 9 psi).
Specifications
Specifications
9-8*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Function and how it can be changed (underlined item is initial setting)
Display/non-display of the navigation guidance ON
/OFF

Fuel Economy Monitor
Method for changing functions using the center display
1. Select
on the home screen to display the application screen.
2. Select the [Fuel Economy Monitor].
3. Select
to display the Menu screen.
4. Select
on the screen and select the setting item you want to change.
Function and how it can be changed (underlined item is initial setting)
Fuel Economy Monitor (page 4-109)
Display/non-display of ending display ON/OFF
Link/non-link with fuel economy reset and trip‐
meter (TRIP A)*ON/OFF

Display
Method for changing functions using the center display
1. Select
on the home screen and display the setting screen.
2. Switch the tab to [Display] and select the setting item you want to change.
Function and how it can be changed (underlined item is initial setting)
Screen setting
Turn Display Off ON/OFF
Turn Display Off and Show Clock ON/OFF
ModeAuto/Day/Night
Brightness –5―0
―+5
Contrast –5―0
―+5
Turn Display Off
When you select
, the display turns off.
Turn Display Off and Show Clock
When you select
, the screen turns off and the clock is displayed.
Specifications
Personalization Features
9-20*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
A
Accessory Socket.............................. 5-88
Active driving display....................... 4-59
Active Driving Display..................... 4-59
Adaptive Front Lighting System
(AFS)............................................... 4-118
Add-On Non-Genuine Parts and
Accessories........................................ 8-20
Advanced Key
Advanced keyless entry system..... 3-8
Operational range.......................... 3-9
Advanced Keyless Entry System........ 3-8
Advanced Smart City Brake Support
(Advanced SCBS)........................... 4-168 Collision warning.... .................. 4-170
Stopping the Advanced Smart City
Brake Support (Advanced SCBS)
system operation........................ 4-170
Air Bag Systems............................... 2-52
Air Bag/Seat Belt Pr etensioner System
Warning Beep.................................... 7-42
Antilock Brake System (ABS)........ 4-105
Armrest Box...................................... 5-93
Audio Control Switch Adjusting the Volume.................... 5-9
Seek Switch................................... 5-9
Audio Set Android Auto™........................... 5-37
Apple CarPlay............................. 5-34
Applications................................. 5-69
AUX.............................................5-27
Bluetooth®.................................. 5-41
Radio............................................5-19
Satellite Radio........ ..................... 5-23
Settings........................................ 5-18
Troubleshooting.......... ................. 5-70
USB............................................. 5-28
Voice Recognition.... ................... 5-66
Audio System Antenna........................................5-12
Appendix..................................... 5-76
Audio Control Switch................... 5-9
Audio Set..................................... 5-13
AUX/USB mode..........................5-10
Before Using the Audio System.... 5-9
AUTOHOLD..................................... 4-99
AUTOHOLD Warning Beep.............7-44
Automatic Transaxle......................... 4-64 Active Adaptive Shift (AAS)...... 4-66
Automatic transaxle controls....... 4-64
Direct mode................................. 4-72
Driving tips..................................4-72
Manual shift mode.......................4-67
Shift-lock system......................... 4-65
Transaxle ranges.......................... 4-65
B
Battery............................................... 6-34Maintenance.................................6-36
Replacement................................ 6-36
Specifications.................................9-4
Battery Runs Out.............................. 7-14 Jump-starting............................... 7-14
Blind Spot Monitoring (BSM)........ 4-122 Canceling operation of Blind Spot
Monitoring (BSM).....................4-127
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-45
Bluetooth® Bluetooth® Audio....................... 5-47
Bluetooth® Hands-Free...............5-57
Bluetooth® Preparation............... 5-44
Body Lubrication.............................. 6-29
Bottle Holder..................................... 5-91
Brakes Brake assist.................................. 4-98
Electric parking brake (EPB)...... 4-95
Foot brake....................................4-94
Pad wear indicator....................... 4-97
Parking brake...............................4-95
10-2
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
