MAZDA MODEL 6 2021 Owners Manual

Front passenger door request switch
To unlock all doors, press the request
switch. A beep sound will be heard twice
and the hazard warning lights will flash
twice.
NOTE
The system can be set to unlock all
doors by performing a single operation.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Confirm that all doors are securely
locked.
For the trunk lid, move it without
pressing the electric trunk lid opener to
verify that the trunk lid has not been left
ajar.
All doors cannot be locked when any
door is open.
It may require a few seconds for the
doors to unlock after the request switch
is pressed.
A beep sound is heard for confirmation
when the doors are locked/unlocked
using the request switch. If you prefer,
the beep sound can be turned off.
The volume of the beep sound can also
be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-42.
The setting can be changed so that the
doors are locked automatically without
pressing the request switch.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
(Walk-away auto lock function)
A beep sound is heard when all doors
are closed while the advanced key is
being carried. All doors are locked
automatically after about 3 seconds
when the advanced key is out of the
operational range. Also, the hazard
warning lights flash once. (Even if the
driver is in the operational range, all
doors are locked automatically after
about 30 seconds.) If you are out of the
operational range before the doors and
the trunk lid are completely closed or
another key is left in the vehicle, the
walk-away auto lock function will not
work. Always make sure that all doors
and the trunk lid are closed and locked
before leaving the vehicle. The
walk-away auto lock function does not
close the power windows.
(Auto re-lock function)
After unlocking with the request switch,
all doors will automatically lock if any
of the following operations are not
performed within about 30 seconds. If
your vehicle has a theft-deterrent
system, the hazard warning lights will
flash for confirmation.
The time required for the doors to lock
automatically can be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Opening a door or the trunk lid.
Switching the igniti on to any position
other than off.
Before Driving
Doors and Locks
3-15
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

▼Locking, Unlocking with
Transmitter
All doors can be locked/unlocked by
operating the keyless entry system
transmitter, refer to Keyless Entry System
(page 3-4).
▼Locking, Unlocking with Door-Lock
Switch
All doors lock automatically when the
lock side is pressed. They unlock when the
unlock side is pressed.
Driver's door
Unlock
Lock
Front passenger's door
Unlock
Lock
To lock all the doors from an open front
door, press the lock side of the door lock
switch and then close the door.
NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.
▼
Auto Lock/Unlock Function
WA R N I N G
Do not pull the inner handle on a front
door:
Pulling the inner handle on a front door
while the vehicle is moving is dangerous.
Passengers can fall out of the vehicle if the
door opens accidentally , which could
result in death or
serious injury.
When the vehicle speed exceeds 20
km/h (12 mph), all the doors lock
automatically.
When the ignition is switched off, all the
doors unlock automatically.
The auto lock/unlock function settings can
be changed.
Refer to the Settings section in the Mazda
Connect Owner's Manual.
▼ Locking, Unlocking with Door-Lock
Knob
Operation from inside
To lock any door from the inside, press the
door-lock knob.
To unlock, pull it outward.
Before Driving
Doors and Locks
3-16
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

This does not operate the other door locks.

Lock
Unlock
Unlocked: Red indicator
Operation from outside
To lock any door using its door-lock knob
from the outside, press the door-lock knob
to the lock position and close the door
(holding the door handle in the open
position is not required).
This does not operate
the other door locks.

Door-lock knob
NOTE
When locking the door this way:
Be careful not to lea ve the key inside the
vehicle.
The doors cannot be locked using the
driver's door lock knob if any door is
open when the ignition is switched to
ACC or ON.
▼ Rear Door Child Safety Locks
These locks are intended to help prevent
children from accidentally opening the
rear doors. Use them on both rear doors
whenever a child rides in the rear seat of
the vehicle.

If you slide the chil
d safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can only be opened by pulling
the outside handle.

Lock Unlock
Before Driving
Doors and Locks
3-17
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

Trunk Lid
WA R N I N G
Never allow a person to ride in the trunk:
Allowing a person to ride in the trunk is
dangerous. The person in the trunk could
be seriously injured or killed during sudden
braking or a collision.
Do not drive with the trunk lid open:
Exhaust gas in the cabin of a vehicle is
dangerous. An open trunk lid in a moving
vehicle will cause exhaust gas to be drawn
into the cabin. This gas contains CO
(carbon monoxide), which is colorless,
odorless, and highly poisonous, and it can
cause loss of consciousness and death.
Moreover, an open trunk lid could cause
occupants to fall out in an accident.
CAUTION
Before opening the trunk lid, remove any
snow and ice accumulation on it.
Otherwise, the trunk lid could close
under the weight of the snow and ice
resulting in injury.
 Be careful when opening/closing the
trunk lid during strong winds. If a strong
gust blows against the trunk lid, it could
close suddenly resulting in injury.
 Fully open the trunk lid and make sure
that it stays open. If the trunk lid is only
opened partially, it could slam shut by
vibration or wind gusts resulting in
injury.
When loading or unloading luggage in
the trunk, turn off the engine. Otherwise,
you could get burned by the heat of the
exhaust gas.
▼ Opening and Closing the Trunk Lid
Opening the trunk lid
Using the remote release button
Push the remote release button.

Using the electric trunk lid opener
(With the advanced keyless function)
A locked trunk lid c
an also be opened
while the key is being carried.
Press the electric trunk lid opener on the
trunk lid, then raise the trunk lid when the
latch releases.

Electric trunk lid
opener
Before Driving
Doors and Locks
3-18
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

NOTE
When opening the trunk lid with the
doors locked, it may require a few
seconds for the trunk lid latch to release
after the electric trunk lid opener is
pressed.
The trunk lid can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the trunk lid can be
opened by pressing the electric trunk lid
opener. If the trunk lid cannot be opened
despite doing this procedure, press the
electric trunk lid opener to fully open
the trunk lid after pushing the trunk lid
completely closed.
If the vehicle battery is dead or there is
a malfunction in the electrical system
and the trunk lid cannot be unlocked,
the trunk lid can be opened by
performing the emergency procedure.
Refer to When Trunk Lid Cannot be
Opened on page 7-50.
Closing the trunk lid
To close, lower the trunk lid slowly using
the trunk lid grip recess, and then push the
trunk lid closed using both hands.
Do not slam it. Pull up on the trunk lid to
make sure it is secure.

Trunk lid grip recess
Before Driving
Doors and Locks
3-19
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Inside Trunk ReleaseLever
*
Your vehicle is equipped with an inside
trunk release lever that provides a means
of escape for children and adults in the
event they become locked inside the trunk.

No matter how careful adults might be
with keys and locki ng their cars, parents
should be aware that children may be
tempted to play around vehicles and use
the trunk as a hiding place.

Adults are advised to familiarize
themselves with the operation and location
of the inside trunk release lever so that all
children can be told about it in an
appropriate way, keeping in mind that
most vehicles do not have such levers.
WA R N I N G
Close the trunk lid, be sure the seat backs
are latched and do not allow children to
play inside the vehicle:
Leaving the trunk lid open or leaving
children in the vehicle with the keys is
dangerous. Children could open the trunk
lid and climb inside resulting in possible
injury or death from heat exposure.
Always keep the car from being a tempting
place to play by latching the rear seats,
doors and the trunk, and keeping the keys
where children can not play with them:
Leaving children or animals unattended in
a parked vehicle is dangerous. Babies left
sleeping and children who lock themselves
in cars or trunks can die very quickly from
heat prostration. Do not leave your
children or pets alone in a car at any time.
Do not leave the car, the rear folding seats
or the trunk unlocked.
▼ Opening the Trunk Lid from the
Inside
Slide the inside trunk release lever in the
direction of the arrow. The lever is made
of material that will
glow for hours in the
darkness of the trunk following a brief
exposure to ambient light.

The inside trunk release lever is located on
the inside of the trunk lid.
Before Driving
Doors and Locks
3-20*Some models.
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Fuel and Engine Exhaust Precautions
▼Fuel Requirements (SKYACTIV-G 2.5, SKYACTIV-G 2.5T)
Vehicles with catalytic converters or oxygen sensors must use O
NLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.

To achieve maximum engine performance, use the specified fuel.
Fuel Octane Rating*1 (Anti-knock index)
Regular unleaded fuel 87 [(R+M)/2 method] or above (91 RON or ab ove)
*1 U.S. federal law requires that octane ratings be posted on gas station pumps.
Fuel with a rating lower than 87 octane (91 RON) will negativel y affect the emission control
system performance and could also cause engine knocking and ser ious engine damage.
CAUTION
USE ONLY UNLEADED FUEL.
Leaded fuel is harmful to the catalytic co nverter and oxygen sensors and will lead to
deterioration of the emission control system and or failures.
 This vehicle can only use oxygenated fuels containing no more than 10 % ethanol by
volume. Damage to the vehicle may occur when ethanol exceeds this recommendation, or
if the gasoline contains any methanol. Stop us ing gasohol of any kind if your vehicle engine
is performing poorly.
 Never add fuel system additives other than a Mazda genuine product, otherwise the
emission control system could be damaged. Consult an Authorized Mazda Dealer for
details.
Gasoline blended with oxygenates such as alcohol or ether compo unds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10 %. Gasoline conta ining alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".

Vehicle damage and drivability problems resulting from the use of the following may not be
covered by the warranty.
Gasohol containing mo re than 10 % ethanol.
Gasoline or gasohol containing methanol.
Leaded fuel or leaded gasohol.
Before Driving
Fuel and Emission
3-21
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

▼Fuel Requirements
(SKYACTIV-D 2.2)
The vehicle will operate efficiently on diesel fuel with specif ication Ultra-Low Sulfur Diesel
(ULSD, 15 ppm sulfur or less) f uel that meets the ASTM D975 standard or the equivalent.
Fuel grade labels are visible on fuel-filler lid, therefore, ve rify the fuel grade before
refueling. If the fuel grade cannot be verified, ask the gas st ation attendant.
CAUTION
Never use fuel other than specification Ultra-Low Sulfur Diesel (ULSD, 15 ppm sulfur or less)
fuel that meets the ASTM D975 standard or the equivalent for your vehicle. Use of gasoline
or kerosene in diesel engines will resu lt in fuel system and engine damage.
 Never use diesel fuel with concentrations of methyl ester bio-diesel higher than 5 % (B5),
such as B20 or B100.
 Never add fuel system additives other than a Mazda genuine product, otherwise the
emission control system could be damaged. Consult an Authorized Mazda Dealer for
details.
 If any type of incorrect fuel is accidently pu mped into the fuel tank, do not turn on the
engine and drive the vehicle. Consult an Authorized Mazda Dealer for assistance.
Turning on the engine or driving the vehicle with the incorrect fuel could cause damage to
the fuel pump and fuel injectors.
NOTE
Fuel for winter driving is available. Ask the gas station attendant for details.
When refueling, always add at least 10 L (2.6 US gal, 2.2 Imp gal) of fuel.
Low outside temperatures
When the outside temperature is low, diesel fuel (light oil) ma y freeze and clog the fuel
pipe, leading to probl ems such as the engine not starting. When driving to a cold region, add
winter grade diesel fuel as soon as possible.
WA R N I N G
Never use engine starting assist additives:
Using engine starting assist additives is dangerous because they may cause a vehicle
explosion or a vehicle runaway condition, leading to serious injury or death.
Before Driving
Fuel and Emission
3-22
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

▼Emission Control System (SKYACTIV-G 2.5, SKYACTIV-G 2.5T)
This vehicle is equipp
ed with an emission co ntrol system (the catalytic converter is part of
this system) that enables the ve hicle to comply with existing exhaust emissions
requirements.
WARNING
Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.
CAUTION
Ignoring the following precautions could cause lead to accumulate on the catalyst inside the
converter or cause the converter to get very hot. Either condition will damage the converter
and cause poor performance.
 USE ONLY UNLEADED FUEL.
 Do not drive your Mazda with any sign of engine malfunction.
 Do not coast with the ignition switched off.
 Do not descend steep grades in ge ar with the ignition switched
off.
 Do not operate the engine at high idle for more than 2 minutes.
 Do not tamper with the emission control system. All inspections and adjustments must be
made by a qualified technician.
 Do not push-start or pull-start this vehicle.
NOTE
Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.
While the engine is off, the sound of a valve opening and closing can be heard at the rear
of the vehicle, however this does not indicate an abnormality. The vehicle has a
self-checking device and it operates while the engine is off.
Before Driving
Fuel and Emission
3-23
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

▼Emission Control Sys
tem (SKYACTIV-D 2.2)
This vehicle is equipped with an emission control system (the catalytic converter and the
Selective Catalytic Reduction (SCR) system
*1 are part of this system) that enables the
vehicle to comply with existing exhaust emissions requirements.
*1 SCR system is designed to reduce nitrogen oxide (NOx) in the e xhaust gas and purify
the exhaust gas by injecting it w ith Diesel Exhaust Fluid (DEF). For more details, refer
to the Selective Catalytic Reduction (SCR) System (page 4-237).
About the catalytic converter
WA R N I N G
Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.
CAUTION
Ignoring the following precautions could cause le ad to accumulate on the catalyst inside the
converter or cause the converter to get very ho t. Either condition will damage the converter
and cause poor performance.
 Do not drive your Mazda with any sign of engine malfunction.
 Do not coast with the ignition switched off.
 Do not descend steep grades in gear with the ignition switched
off.
 Do not operate the engine at hi gh idle for more than 2 minutes.
 Do not tamper with the emission control syst em. All inspections and adjustments must be
made by a qualified technician.
 Do not push-start or pull-start this vehicle.
Before Driving
Fuel and Emission
3-24
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27
