fuse MAZDA MODEL 6 2021 User Guide

▼Fuse Panel Description
Fuse block (Engine compartment)
DESCRIPTION FUSE
RATING PROTECTED COMPONENT
1 AUDIO
DCDC REG 30 A Audio system
2 IG2 30 A For protection of various circuits
3 INJECTOR
ENG. SUB 30 A
Engine control system
*
4 SCR1
EVVT 20 A Engine control system
5 P.WINDOW1 30 A Power windows
6 IG1 2 30 A For protection of various circuits
7― ― ―
8 ADD FAN DE 50 A Cooling fan
*
9DEFOG 40 A Rear window defogger
10 DCDC DE 40 A ―
11 EPB R 20 A Electric parking brake (EPB) (RH)
12 EPB L 20 A Electric parking brake (EPB) (LH)
Maintenance and Care
Owner Maintenance
*Some models.6-55
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
13 CABIN.+B 50 A For protection of various circuits
14 FAN GE 30 A Cooling fan
*
15 ENG.MAIN 40 A Engine control system
16 ABS/DSC M 50 A ABS, Dynami c stability control system
17 HEATER 40 A Air conditioner
18 WIPER 20 A Front window wiper and washer
19 FAN DE 50 A
Cooling fan
*
20 ADD FAN GE 30 A Cooling fan*
21 ENGINE3 15 A Engine control system
22 ENGINE2 15 A Engine control system
23 AUDIO27.5 A Audio system
24 METER2 10 A ―
25 SRS1 7.5 A Air bag
26 METER1 10 A Instrument cluster
27 ENGINE.IG1 7.5 A Engine control system
28 AT 15 A Transaxle control system, Ignition switch
29 H/CLEAN 20 A ―
30 A/C 7.5 A Air conditioner
31 AT PUMP 15 A ―
32 HORN 15 A Horn
33 R.WIPER 15 A Theft-deterrent system
*
34H/L HI 20 A Headlight high beam
35 ― ― ―
36 WIPER.DEI 20A Windshield wiper de-icer
*
37 ENG.+B7.5 A Engine control system
38 H/L LOW L 15 A Headlight low beam (LH)
39 GLOW SIG 5 A ―
40 ENGINE1
ENGINE4 15 A Engine control system
41 C/U IG1 15 A For protection of various circuits
42 ST.HEATER 15 A Heated steering wheel
*
43― ― ―
44 AUDIO1 25 A Audio system
45 ABS/DSC S 30 A ABS, Dynami c stability control system
46 FUEL PUMP 15 A Fuel system
*
Maintenance and Care
Owner Maintenance
6-56*Some models.
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
47 FUEL WARM 25 A Fuel warmer
*
48TAIL 15 A Taillights, License plate lights
49 SCR2
FUEL PUMP2 25 A
Engine control system
*
50 HAZARD 25 A Hazard warning flashers, Turn signal lights, Parkin g lights
51 H/L LOW R 15 A Headlight low beam (RH)
52 OUTLET 25 A Accessory sockets
53 STOP 10 A Brake lights
54 ROOM 25 A For protection of various circuits
Fuse block (Left side)
DESCRIPTION FUSE
RATING PROTECTED COMPONENT
1 P.SEAT D 30 A Power seat
*
2 P.SEAT P1 30 APower seat*
3 R.SEAT W1 20 ASeat warmer*
4 P.WINDOW2 25 A Power windows
5 SRS2/ESCL 15 A ―
Maintenance and Care
Owner Maintenance
*Some models.6-57
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
6 D.LOCK 25 A Power door locks
7 SEAT WARM 20 A Seat warmer
*
8 SUNROOF 10 AMoonroof*
9 R.OUTLET1 15 A ―
10 MIRROR 7.5 A Power control mirror 11 AT IND 7.5 A AT shift indicator
12 INTERIOR1 15 A For protection of various circuits
13 INTERIOR2 10 A For protection of various circuits
14 R.OUTLET2 15 A Accessory sockets
15 USB 7.5 A
USB power outlet
*
16 SCR3 15 A
Engine control system*
17 SCR4 15 A
Engine control system*
18 AUDIO3 15 A Audio system
19 R.SHADE 7.5 A ―
20 M.DEF 7.5 A
Mirror defogger
*
21 ― ― ―
Maintenance and Care
Owner Maintenance
6-58*Some models.
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

(Mexico)
Tire sizeInflation pressure
Up to 3 persons ―Full load
225/55R17 97V Front
230 kPa (2.3 bar, 33 psi) 250 kPa (2.5 bar, 36 psi)
Rear 230 kPa (2.3 bar, 33 psi) 320 kPa (3.2 bar, 46 psi)
225/45R19 92W
*2Front 230 kPa (2.3 bar, 33 psi) 250 kPa (2.5 bar, 36 psi)
Rear 230 kPa (2.3 bar, 33 psi) 320 kPa (3.2 bar, 46 psi)
1 person's weight: About 75 kg*1P225/45R19 92W
(SKYACTIV-G 2.5, SKYACTIV-G 2.5T)
Before driving at high speeds, in crease the pressure of the front tires. For speeds above 200 km/h (124 mph),
increase the pressure of the fr ont tires by 20 kPa (0.2 bar, 2. 9 psi).
(SKYACTIV-D 2.2)
Before driving at high speeds, in crease the pressure of the front tires. For speeds above 180 km/h (111 mph),
increase the pressure of the fr ont tires by 40 kPa (0.4 bar, 5. 8 psi).
*2225/45R19 92W (SKYACTIV-G 2.5T)
Before driving at high speeds, in crease the pressure of the front tires. For speeds above 210 km/h (130 mph),
increase the pressure of the fr ont tires by 20 kPa (0.2 bar, 2. 9 psi).
Temporary spare tire
(U.S.A. and Canada)
Tire size Inflation pressure
T125/70R17 98M 420 kPa (60 psi)
T135/80D17 103M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/55R16 87M 320 kPa (3.2 bar, 46 psi)
T125/70R17 98M 420 kPa (4.2 bar, 60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following to rque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼ Fuses
Refer to Fuses on page 6-52.
Specifications
Specifications
9-9
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27
