Reducing glare from headlights
Manual day/night mirror
Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Day/Night lever
Day
Night
Auto-dimming mirror
The auto-dimming mirror automatically
reduces the glare of headlights from
vehicles at the rear w hen the ignition is
switched ON.

(With Homelink wireless control
system)
(Type A)
Press the OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto -dimming function,
press the ON button (
). The indicator
light will illuminate.
Indicator lightOFF button
ON button

(Type B)
Press the ON/OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto-dimming function,
press the ON/ OFF button (
). The
indicator light will illuminate.
Indicator light
ON/OFF button
NOTE
Do not use glass cleaner or suspend
objects on or around the light sensor.
Otherwise, light sensor sensitivity will
be affected and may not operate
normally.
(With Homelink wireless control
system)
(Type A)
Light sensor
(Type B)
Light sensor
Before Driving
Mirrors
3-32
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

(Without Homelink wireless control
system)

Light sensor
(With Homelink wireless control
system)
For information regarding the 3 buttons
(Type A
,,/Type B , , )
on the auto-dimming mirror.
Refer to HomeLink Wireless Control
System on page 4-92.
The auto-dimming function is canceled
when the ignition is switched ON and
the selector lever is in the R position.
Before Driving
Mirrors
3-33
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Blind Spot Monitoring
(BSM)....................................... 4-126
Traffic Sign Recognition System
(TSR)
*...................................... 4-132
Distance Recognition Support
System (DRSS)
*....................... 4-140
Driver Attenti on Alert (DAA)
*..........
.................................................. 4-144
Rear Cross Traffic Alert
(RCTA)..................................... 4-146
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
*............... 4-150
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)
*.................................. 4-164
Advanced Smart City Brake Support
(Advanced SCBS)
*...................4-175
Smart City Brake Support [Forward]
(SCBS F)
*.................................4-178
Smart City Brake Support [Reverse]
(SCBS R)
*................................ 4-182
Smart Brake Support (SBS)
*.... 4-186
360° View Monitor
*................. 4-188
Forward Sensing Camera (FSC)
*......
.................................................. 4-215
Radar Sensor (Front)
*.............. 4-220
Radar Sensors (Rear)............... 4-223
Ultrasonic Sensor (Rear)*.........4-225
Front Camera/Side Cameras/Rear
Camera
*.................................... 4-226
Cruise Control............................... 4-227 Cruise Control
*.........................4-227
Tire Pressure Monitoring
System.............................................4-232 Tire Pressure Monitoring
System...................................... 4-232
Diesel Particulate Filter................ 4-236 Diesel Particulate Filter
(SKYACTIV-D 2.2)..................4-236
Selective Catalytic Reduction (SCR)
System.............................................4-237 Selective Catalytic Reduction (SCR)
System (SKYACTIV-D 2.2)..... 4-237
Rear View Monitor....................... 4-240 Rear View Monitor
*................. 4-240
Parking Sensor System................. 4-248 Parking Sensor System
*........... 4-248
4-2*Some models.
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

The direction of the arrow () indicates
that the fuel-filler lid is on the left side
of the vehicle.
▼ Dashboard Illumination
When the lights are turned on with the
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
not dim.
NOTE
When the ignition is switched ON in the
early evening or at dusk, the dashboard
illumination is dimmed for several
seconds until the light sensor detects the
brightness of the surrounding area,
however, the dimming may cancel after
the brightness is detected.
When the lights are turned on, the
lights-on indicator light in the
instrument cluster turns on.
Refer to Headlights on page 4-78.
The brightness of the instrument cluster
and dashboard illuminations can be
adjusted by rotating the knob.
The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for canceling illumination
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
heard while the instrument cluster is
dimmed with the ignition switched ON. If
the instrument cluster's visibility is
reduced due to glare from surrounding
brightness, cancel the illumination
dimmer.
NOTE
When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
When Driving
Instrument Cluster and Display
4-20
