MAZDA MODEL 6 HATCHBACK 2005 (in English) User Guide

Doors and keys .................................................................................................... page 3-2
Child safety locks ................................................................................................ page 3-9
Power windows ................................................................................................. page 3-22
Hood .................................................................................................................. page 3-26
Trunk lid ............................................................................................................ page 3-18
Fuel-filler lid ...................................................................................................... page 3-24
Moonroof ........................................................................................................... page 3-27
Outside mirror .................................................................................................... page 3-34
Rear window defroster ....................................................................................... page 5-42
Antenna ............................................................................................................. page 6-16
Windshield wiper blades .................................................................................... page 8-23
Tires ................................................................................................................... page 8-29
Light bulbs ......................................................................................................... page 8-33
Your Vehicle at a Glance
Exterior Overview
1-5

The equipment and installation position varies according to model and grade.
Sport Wagon
1-6
Your Vehicle at a Glance
Exterior Overview

Doors and keys .................................................................................................... page 3-2
Child safety locks ................................................................................................ page 3-9
Power windows ................................................................................................. page 3-22
Hood .................................................................................................................. page 3-26
Fuel-filler lid ...................................................................................................... page 3-24
Liftgate .............................................................................................................. page 3-12
Outside mirror .................................................................................................... page 3-34
Rear window defroster ....................................................................................... page 5-42
Antenna ............................................................................................................. page 6-16
Windshield wiper blades .................................................................................... page 8-23
Tires ................................................................................................................... page 8-29
Light bulbs ......................................................................................................... page 8-33
Your Vehicle at a Glance
Exterior Overview
1-7

1-8

2Essential Safety Equipment
Use of safety equipment, including seats, seat belt system, SRS air bags and
child-restraint systems.
Seats ............................................................................................... 2-2Front Seats (Manually Operated Seats) ..................................... 2-2
Front Seats (Electrically Operated Seats) .................................. 2-5
Rear Seat ................................................................................... 2-9
Seat Belt Systems ........................................................................ 2-16 Seat Belt Precautions .............................................................. 2-16
3-Point Type Seat Belt ............................................................ 2-19
Front Seat Belt Pretensioner and Load Limiting Systems ....... 2-21
Rear Center Position Seat Belt ................................................ 2-23
Seat Belt Extender ................................................................... 2-25
Seat Belt Warning Light/Beep ................................................ 2-26
Child Restraint ............................................................................ 2-28 Child Restraint Precautions ..................................................... 2-28
Installing Child-Restraint Systems .......................................... 2-32
LATCH Child-Restraint Systems ............................................ 2-39
SRS Air Bags ............................................................................... 2-44 Supplemental Restraint Systems (SRS) Precautions ............... 2-44
Supplemental Restraint System Components ......................... 2-49
How the Air Bags Work .......................................................... 2-52
2-1

Front Seats (Manually
Operated Seats)
WARNING
Modification of the Front Seats:
Modifying or replacing the front seats
such as replacing the upholstery or
loosening any bolts is dangerous. The
front seats contain air bag
components essential to the
supplemental restraint system. Such
modifications could damage the
supplemental restraint system and
result in serious injury. Consult an
Authorized Mazda Dealer if there is
any need to remove or reinstall the
front seats.
Damaged Front Seats:
Driving with damaged front seats is
dangerous. A collision, even one not
strong enough to inflate the air bags,
could damage the front seats which
contain essential air bag components.
If there was a subsequent collision, the
air bag may not deploy which could
lead to injuries. Always have an
Authorized Mazda Dealer inspect the
front seats, front seat belt
pretensioners and air bags after a
collision.
WARNING
Securing the Seats:
Adjustable seats and seatbacks that
are not securely locked are dangerous.
In a sudden stop or collision, the seat
or seatback could move, causing
injury. Make sure the adjustable
components of the seat are locked in
place by attempting to slide the seat
forward and backward and rocking
the seatback.
qSeat Slide
WARNING
Driver's Seat Adjustment:
Adjusting the driver's seat while the
vehicle is moving is dangerous. The
driver could lose control of the vehicle
and have an accident. Adjust the
driver's seat only when the vehicle is
stopped.
To move a seat forward or backward, raise
the lever and slide the seat to the desired
position and release the lever.
2-2
Essential Safety Equipment
Seats

Make sure the lever returns to its original
position and the seat is locked in place by
attempting to push it forward and
backward.
qSeat Recline
WARNING
Reclining:
Sitting in a reclined position while the
vehicle is moving is dangerous
because you don't get the full
protection from seat belts. During
sudden braking or a collision, you can
slide under the lap belt and suffer
serious internal injuries. For
maximum protection, sit well back and
upright.
Unlocked Seatback:
The seatback plays an important role
in your protection in a vehicle.
Leaving the seatback unlocked is
dangerous as it can allow passengers
to be ejected or thrown around and
baggage to strike occupants in a
sudden stop or collision, resulting in
severe injury. After adjusting the
seatback at any time, even when there
are no other passengers, rock the
seatback to make sure it is locked in
place. To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position and
release the lever.
Make sure the lever returns to its original
position and the seatback is locked in
place by attempting to push it forward and
backward.
CAUTION
When returning a rear-reclined seatback
to its upright position, make sure you
support the seatback while operating
the seatback lever. If the seatback is not
supported, it will flip forward suddenly
and could cause injury.
Essential Safety Equipment
Seats
2-3

qHeight Adjustment (Driver's
Seat)
By moving the seat lever up or down, the
seat bottom height can be adjusted.
DownUp
q
Head Restraint
WARNING
Head Restraints Adjustment:
Driving with the head restraints
adjusted too low or removed is
dangerous. With no support behind
your head, your neck could be
seriously injured in a collision. Always
drive with the head restraints inserted
when seats are being used and make
sure they are properly adjusted.
Height adjustment
To raise a head restraint, pull it up to the
desired position.
To lower the head restraint, press the stop-
catch release, then push the head restraint
down.
Adjust the head restraint so that the top is
parallel with the top of the passenger's
ears, never the passenger's neck.
q Seat Warmerí
The front seats are electrically heated. The
ignition switch must be in the ON
position.
Press the switch to turn the seat warmer
on or off. When the switch is in the ON
position, the indicator light will come on.
ON
OFF
2-4
Essential Safety Equipment
íSome models.
Seats

NOTE
The thermostat regulates seat
temperature by turning the current on
and off.
Front Seats (Electrically
Operated Seats)
WARNING
Modification of the Front Seats:
Modifying or replacing the front seats
such as replacing the upholstery or
loosening any bolts is dangerous. The
front seats contain air bag
components essential to the
supplemental restraint system. Such
modifications could damage the
supplemental restraint system and
result in serious injury. Consult an
Authorized Mazda Dealer if there is
any need to remove or reinstall the
front seats.
Damaged Front Seats:
Driving with damaged front seats is
dangerous. A collision, even one not
strong enough to inflate the air bags,
could damage the front seats which
contain essential air bag components.
If there was a subsequent collision, the
air bag may not deploy which could
lead to injuries. Always have an
Authorized Mazda Dealer inspect the
front seats, front seat belt
pretensioners and air bags after a
collision.
Essential Safety Equipment
Seats
2-5

CAUTION
lThe seat-bottom power adjustment is
operated by motors. Avoid extended
operation because excessive use can
damage the motors.
lTo prevent the battery from running
down, avoid using the power
adjustment when the engine is
stopped. The adjuster uses a large
amount of electric power.
lDon't use the switch to make more
than one adjustment at a time.
qSeat Slide (Driver's Seat)
To slide the seat, move the slide lifter
switch on the outside of the seat to the
front or back and hold it. Release the
switch at the desired position.
q Seat Recline (Driver's Seat)
WARNING
Reclining:
Sitting in a reclined position while the
vehicle is moving is dangerous
because you don't get the full
protection from seat belts. During
sudden braking or a collision, you can
slide under the lap belt and suffer
serious internal injuries. For
maximum protection, sit well back and
upright.
Change the seatback angle by pressing the
front or rear side of the reclining switch.
Release the switch at the desired position.
2-6
Essential Safety Equipment
Seats
