Interior lightLight bulb Category
Wattage ECE R
Trunk light (Sedan) 3―
Overhead light/Map lights 5W5W
Courtesy lights 5W5W
Vanity mirror lights
*Type A 1.2―
Type B 3―
Luggage compartment light 5-Door
5―
Sport Wagon 10―
* Vanity mirror lights
Type B
Type A
q Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 8-39.
Standard tire
Tire size Inflation pressure
Front Rear
P205/60R16 91V 220 kPa
(2.2 kgf/cm
2, 32 psi or lb/po2) 220 kPa
(2.2 kgf/cm2, 32 psi or lb/po2)
P215/50R17 93V
215/45R18 93W 240 kPa
(2.4 kgf/cm
2, 35 psi or lb/po2) 240 kPa
(2.4 kgf/cm2, 35 psi or lb/po2)
Specifications
10-7
Mazda6_8V40-EA-05L_Edition1 Page381
Monday, November 28 2005 6:11 PM
Form No.8V40-EA-05L
Page 382 of 390
Black plate (382,1)
Temporary spare tire
Tire sizeInflation pressure
T115/70D16 420 kPa (60 psi)
qFuses
Refer to the fuse rating on page 8-53.
