IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT
2.3L I4 engine1. Windshield washer fluid reservoir
2. Engine coolant reservoir
3. Engine oil dipstick
4. Transmission fluid dipstick (automatic transmission)
5. Engine oil filler cap
6. Brake fluid reservoir
7. Power distribution box
8. Clutch fluid reservoir (manual transmission)
9. Battery
10. Power steering fluid reservoir
11. Air filter assembly
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
217

3.0L V6 engine1. Engine coolant reservoir
2. Windshield washer fluid reservoir
3. Engine oil filler cap
4. Transmission fluid dipstick (automatic transmission)
5. Engine oil dipstick
6. Brake fluid reservoir
7. Power distribution box
8. Clutch fluid reservoir (manual transmission)
9. Battery
10. Power steering fluid reservoir
11. Air filter assembly
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
218

4.0L SOHC V6 engine1. Windshield washer fluid reservoir
2. Transmission fluid dipstick (automatic transmission)
3. Engine oil filler cap
4. Engine oil dipstick
5. Brake fluid reservoir
6. Power distribution box
7. Clutch fluid reservoir (manual transmission)
8. Battery
9. Power steering fluid reservoir
10. Air filter assembly
11. Engine coolant reservoir
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
219

Check the wiper blades for wear at least twice a year or when they seem
less effective. Substances such as tree sap and some hot wax treatments
used by commercial car washes reduce the effectiveness of wiper blades.
Changing the wiper blades1. Pull the wiper arm away from the vehicle. Turn the blade at an
angle from the wiper arm. Push
the lock pin manually to release
the blade and pull the wiper
blade down toward the
windshield to remove it from
the arm.
2. Attach the new wiper to the wiper arm and press it into
place until a click is heard.
Replace wiper blades at least once per year for optimum performance.
Poor wiper quality can be improved by cleaning the wiper blades and the
windshield, refer to Windows and wiper blades in theCleaning
chapter.
To prolong the life of the wiper blades, it is highly recommended to
scrape off the ice on the windshield before turning on the wipers. The
layer of ice has many sharp edges and can damage the micro edge of the
wiper rubber element.
ENGINE OIL
Checking the engine oil
Refer to scheduled maintenance for the appropriate intervals for
checking the engine oil.
1. Make sure the vehicle is on level ground.
2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmission) or 1 (First) (manual
transmission).
4. Open the hood. Protect yourself from engine heat.
5. Locate and carefully remove the engine oil level indicator (dipstick).
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
221

TRANSMISSION FLUID
Checking automatic transmission fluid
•Refer to scheduled maintenance information for scheduled check
and change intervals.
• Transmission does not consume fluid.
• Check fluid when transmission is not operating properly or if you see
a leak.
• Fluid level must be checked at normal operating temperature, 20 miles
(30 km) of driving.
To check and add fluid: 1. Drive the vehicle 20 miles (30 km) to reach normal operating temperatures.
2. If driven in hot weather, city traffic, pulling a trailer, allow transmission to cool for 30 minutes before checking.
3. Engage parking brake, start engine.
4. Put your foot on the brake pedal and move the gearshift lever slowly through all of the gear ranges.
5. Shift to P (Park) and leave the engine running.
6. Remove the dipstick, wipe clean with a dry lint free rag.
7. Install and fully seat the dipstick into the filler tube.
8. Remove the dipstick and inspect the fluid level. Level should be
in the cross-hatched area.
9. If necessary, add fluid in 1/2 pint (250ml) increments through the filler tube until the level is correct at normal operating temperatures.
Refer to the Maintenance product specifications and capacities
section in this chapter for the correct fluid type. The use of any
other non-approved fluid may cause internal transmission damage.
10. Fluid can be checked at ambient temperatures between 50–95°F
(10–30°C). DO NOT ADD fluid
until the transmission is at
normal operating temperatures or the transmission will be overfilled.
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
248

ItemApplicationMazda part name or
equivalent Capacity
Engine coolant 2.3 L I4 engine
with manual
transmission
Premium EngineCoolant
2
10.5 quarts (10.0L)
2.3L I4 engine
with automatic transmission 10.2 quarts (9.7L)
3.0L V6 engine with manual
transmission 15.1 quarts (14.3L)
3.0L V6 engine with automatic transmission 14.8 quarts (14.0L)
4.0L V6 engine with manual
transmission 13.7 quarts (13.0L)
4.0L V6 engine with automatic transmission 13.2 quarts (12.5L)
Engine oil 2.3L I4 engine SAE 5W-20 Motor Oil 4.0 quarts (3.8L)
3.0L V6 engine SAE 5W-20 Motor Oil 4.5 quarts (4.3L)
4.0L V6 engine SAE 5W-30 Motor Oil 5.0 quarts (4.7L)
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
254

ItemApplicationMazda part name or
equivalent Capacity
Power steering fluid All
MERCONAT FFill to range on dipstick
Transfer case fluid (4X4) 4x4 Vehicles
1.25 quarts (1.2L)
Manual transmission fluid 5-speed manual
2.8 quarts (2.65L)
3
Automatic transmission
fluid (5R44E and 5R55E) 4x2 vehicles with
2.3L I4 engine
MERCONVATF
4
9.9 quarts (9.4L)
5
4x2 vehicles with3.0L or 4.0Lengines 10.0 quarts (9.5L)
5
4x4 vehicles with
3.0L or 4.0Lengines 10.3 quarts (9.8L)
5
Front axle fluid (4X4) 4x4 Vehicles
SAE 80W-90 Premium
Rear Axle Lubricant 3.6 pints (1.7L)
Rear axle fluid AllSAE 80W-90 Premium
Rear Axle Lubricant 5.0-5.3 pints (2.4-2.5L)
6
Windshield washer fluid All Ultra-clear Windshield
Washer Concentrate 2.75 quarts (2.6L)
Fuel tank Regular cab
(Short wheel base) —17 gallons (64.4L)
Cab Plus 4 19.5 gallons (73.8L)
REVIEW COPY ——
2007 B-Series(mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
255

1Brake fluid will drop slowly as the brakes wear and will rise when brake components are replaced.
Fluid levels below the MAX line that do not trigger the brake warning light are within the normal
operating range, there is no need to add fluid. If the levels are outside the normal operating range,
the performance of your brake system could be compromised, seek service from your authorized
dealer immediately.2Add the coolant type originally equipped in your vehicle. Do not mix different colors or types of
coolant. Do not use Mazda Extended Life Engine Coolant (orange in color). Refer to Adding
engine coolant, in this chapter.3Service refill capacity is determined by filling the transmission to the bottom of the filler hole with
the vehicle on a level surface.4Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are
indicated on the dipstick or on the dipstick handle. MERCON and MERCON V are not
interchangeable. DO NOT mix MERCON and MERCONV. Refer toscheduled maintenance to
determine the correct service interval.5Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and
if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set
by the indication on the dipstick’s normal operating range.6Traction-Lok axles use 4.75–5.0 pints (2.2–2.4L) of rear axle lubricant. Add 4 oz. (118 ml) of
Additive Friction Modifier meeting Mazda specifications for complete refill of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 1/4 inch to 9/16 inch (6 mm to 14
mm) below the bottom of the filler hole.
If submerged in water, the rear axle lubricant should be changed.
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
256

The Vehicle Identification Number (VIN) contains the following
information:1. World manufacturer identifier
2. Brake system / Gross Vehicle Weight Rating (GVWR) /
Restraint System
3. Vehicle line, series, body type
4. Engine type
5. Check digit
6. Model year
7. Assembly plant
8. Production sequence number
TRANSMISSION/TRANSAXLE CODE DESIGNATIONS
You can find a
transmission/transaxle code on the
Safety Compliance Certification
Label . The following table tells you
which transmission or transaxle
each code represents.
Description Code
Five-speed automatic (5R44E/5R55E) D
Five-speed manual (HD) J
Five-speed manual (R1) R
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XX RC: XXDSO:
WB BRK INT TR TP/PS R AXLE TR SPR XXXXX
XXX X XX X XX X XX \
XXX
XXXXXXXXXXXXX XXX XXXX-XXXXXXX-XX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN
EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
VIN: XXXXXXXXXXXXXXXXX XXXXX
TYPE: XXX XXXXX
DATE: XX/XX GVWR:XXXXXLB/ XXXXXKG
FRONT GAWR: XXXXL REAR GAWR: XXXXLB
AT XXX kPa/XX PSI COLD AT XXX kPa/XX PSI COLD XXXXKG
WITH
XXXX/XXXXXXX TIRES
XXXX.XX RIMSXXXXKG
WITH
XXXX/XXXXXXX TIRES
XXXX.XX RIMS
FOR MAZDA MOTOR CORPORATION
REVIEW COPY ——
2007 B-Series(mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Maintenance and Specifications
260

A
ABS (see Brakes) .....................146
Airbag supplemental
restraint system ....................82–83and child safety seats ..............85
description ................................83
disposal ......................................88
driver airbag ........................83, 86
indicator light ...........................87
operation .............................83, 86
passenger airbag .................83, 86
Ambulance packages ....................7
Antifreeze
(see Engine coolant) ................229
Anti-lock brake system
(see Brakes) ......................146–147
Anti-theft system ........................62
Audio system
(see Radio) ......................19, 21, 25
Automatic transmission ............150 driving an automatic
overdrive .................................152
fluid, specification ..................253
Auxiliary power point .................50
Axle lubricant specifications ..........253
traction lok ..............................149
B
Battery .......................................227 acid, treating emergencies .....227
jumping a disabled battery ....184
maintenance-free ....................227
servicing ..................................227
Bed extender ..............................56
BeltMinder ...................................78 Brakes ........................................146
anti-lock ...........................146–147
anti-lock brake system
(ABS) warning light ...............147
fluid, checking and adding ....246
fluid, specifications .................253
lubricant specifications ..........253
parking ....................................148
shift interlock ..........................150
Break-in period .............................6
Bulbs ............................................42
C
Cell phone warning ...................261
Changing a tire .........................174
Child safety restraints ................92 child safety belts ......................92
Child safety seats ........................95 attaching with tether straps ....99
in front seat ..............................97
in rear seat ................................97
tether anchorage hardware .....99
Chimes (warning) .......................17
Cleaning your vehicle engine compartment ..............202
instrument panel ....................205
interior .....................................205
interior trim ............................205
Mazda car care products .......206
plastic parts ............................204
washing ....................................201
waxing .....................................201
wheels ......................................202
wiper blades ............................204
Clock adjust AM/FM Stereo ...........................19
AM/FM stereo CD .....................21
Premium AM/FM stereo
CD6/MP3 ...................................26
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Index
262
