snow chains MAZDA MODEL B-SERIES 2007 Owners Manual (in English)

SNOW TIRES AND CHAINSWARNING: Driving too fast for conditions creates the
possibility of loss of vehicle control. Driving at very high speeds
for extended periods of time may result in damage to vehicle
components.
NOTE: Snow tires must be the same size and grade as the tires you
currently have on your vehicle.
The tires on your vehicle have all weather treads to provide traction in
rain and snow. However, in some climates, you may need to use snow
tires and chains. If you need to use snow tires and chains, it is
recommended that steel wheels are used of the same size and
specifications as those originally installed.
Follow these guidelines when using snow tires and chains:
• Do not use tire chains on aluminum wheels. Chains may chip the
wheels.
• Use only SAE Class S chains.
• Install chains securely, verifying that the chains do not touch any
wiring, brake lines or fuel lines.
Drive cautiously. Ensure you obtain the proper cables or chains
for you vehicle. Test fit the cables or chains before using them in
snow and/or ice. If you hear the cables or chains rub or bang
against the vehicle, stop and retighten them. If this does not
work, remove the cables or chains to prevent vehicle damage.
Have the cables or chains fitted by a professional before
proceeding.
• If possible, avoid fully loading your vehicle.
• Remove the tire chains when they are no longer needed. Do not use
tire chains on dry roads.
• The suspension insulation and bumpers will help prevent vehicle
damage. Do not remove these components from your vehicle when
using snow tires and chains.
VEHICLE LOADING – WITH AND WITHOUT A TRAILER
This section will guide you in the proper loading of your vehicle and/or
trailer, to keep your loaded vehicle weight within its design rating
capability, with or without a trailer. Properly loading your vehicle will
provide maximum return of vehicle design performance. Before loading
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Tires, Wheels and Loading
124

•Use snow chains on the end of the vehicle with the dissimilar spare
tire
• Use more than one dissimilar spare tire at a time
• Use commercial car washing equipment
• Try to repair the dissimilar spare tire
Use of one of the dissimilar spare tires listed above at any one wheel
location can lead to impairment of the following:
• Handling, stability and braking performance
• Comfort and noise
• Ground clearance and parking at curbs
• Winter weather driving capability
• Wet weather driving capability
For vehicles equipped with 4WD, it is not recommended that the vehicle
be operated in 4WD modes with a temporary emergency spare tire. If
4WD operation is necessary, do not operate above speeds of 10 mph
(16 km/h) or for distances above 50 miles (80 km). 3. Full-size dissimilar spare without label on wheel
When driving with the full-size dissimilar spare tire/wheel, do not:
• Exceed 70 mph (113 km/h)
• Use more than one dissimilar spare tire/wheel at a time
• Use commercial car washing equipment
• Use snow chains on the end of the vehicle with the dissimilar spare
tire/wheel
The usage of a full-size dissimilar spare tire/wheel can lead to
impairment of the following:
• Handling, stability and braking performance
• Comfort and noise
• Ground clearance and parking at curbs
• Winter weather driving capability
• Wet weather driving capability
• All-Wheel driving capability (if applicable)
• Load leveling adjustment (if applicable)
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Roadside Emergencies
176

Starting your
vehicle ........................142–143, 145jump starting ..........................184
Steering wheel tilting .........................................49
T
Tether anchors ............................99
Tilt steering wheel ......................49
Tire Pressure Monitoring
System (TPMS) Roadside Emergencies ...........174
Tires, Wheels and Loading ....120
Tires ...........................105–106, 174 alignment ................................112
care ..........................................109
changing ..........................174, 179
checking the pressure ............109
inflating ...................................107
label .........................................119
replacing ..................................111
rotating ....................................113
safety practices .......................112
sidewall information ...............114
snow tires and chains ............124
spare tire .........................175, 177
terminology .............................106
tire grades ...............................106
treadwear ........................105, 110
Towing .......................................131 recreational towing .................140
trailer towing ..........................131
wrecker ....................................190
Traction-lok rear axle ...............149 Transfer case
fluid checking .........................250
Transmission automatic operation ...............150
brake-shift interlock (BSI) ....150
fluid, checking and adding
(manual) .................................249
lubricant specifications ..........253
manual operation ....................154
Turn signal ..................................41
V
Vehicle Identification Number
(VIN) ..........................................259
Vehicle loading ..........................124 camper bodies ........................141
Ventilating your vehicle ...........145
W
Warning chimes ...........................17
Warning lights (see Lights) .......12
Washer fluid ..............................220
Water, Driving through .............162
Windows power .........................................51
Windshield washer fluid and
wipers ..........................................49 checking and adding fluid .....220
checking and cleaning ............220
replacing wiper blades ...........221
Wrecker towing .........................190
REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002),Market:Canadian_French (fr_can)
Index
266
