MAZDA MODEL B-SERIES 2008 (in English) Owner's Manual

7.ON/OFF/Volume:Press to turn
the system ON/OFF. Turn to
adjust the volume levels.
If the volume is set above a
certain level, and the ignition is
turned off, the volume will come
back to a “nominal” listening level when the ignition is turned back
on.
AM/FM stereo single CD/MP3 Satellite Compatible system
(if equipped)
1.CD eject:Press to eject the
CD/MP3.
2.CLK (Clock):Press CLK until
SELECT HOUR or SELECT
MINS is displayed. Press
MENUto adjust the
hours/minutes. Press CLK to display the time when the ignition is
off.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
21

3.MUTE:Press to mute the
playing media. Press again to
return to the playing media.
4.MENU:Press MENU repeatedly
to scroll through the following
modes and use
/to
make an adjustment in those modes.
SATELLITE RADIO MENU (if equipped):Press MENU when satellite
radio mode is active to access. Press SEEK
to enter into the satellite
radio menu. Press
/to cycle through the following options:
•CATEGORY:Press SEEK
to enter category mode. Press
MENUto scroll through the list of available SIRIUS channel
Categories (Pop, Rock, News, etc.) Press SEEK
when the desired
category appears in the display. After a category is selected, press
SEEK to search for that specific category of channels only (i.e.
ROCK). You may also select CATEGORY ALL to seek all available
SIRIUS categories and channels. Press SEEK
to close and return
to the main menu.
•SAVE SONG:Press SEEK
to save the currently playing song in
the system’s memory. (If you try to save something other than a song,
CANT SAVE will appear in the display.) When the chosen song is
playing on any satellite radio channel, the system will alert you with
an audible prompt. Press SEEK
while SONG ALERT is in the
display and the system will take you to the channel playing the
desired song. You can save up to 20 songs. If you attempt to save a
song when the system is full, the display will read REPLACE SONG?
Press SEEK
to access the saved songs and pressMENU
to cycle through the saved songs. When the song appears in the
display that you would like to replace, press SEEK
. SONG
REPLACED will appear in the display.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
22

•DELETE SONG:Press SEEKto delete a song from the system’s
memory. Press
MENUto cycle through the saved songs. When
the song appears in the display that you would like to delete, press
SEEK
. The song will appear in the display for confirmation. Press
SEEK
again and the display will read SONG DELETED. If you do
not want to delete the currently listed song, press
MENUto
select either RETURN or CANCEL.
Note:If there are no songs presently saved, the display will read NO
SONGS.
•DELETE ALL SONGS:Press SEEK
to delete all song’s from the
system’s memory. The display will read ARE YOU SURE ? Press
SEEK
to confirm deletion of all saved songs and the display will
read ALL DELETED.
Note:If there are no songs presently saved, the display will read NO
SONGS.
•ENABLE ALERTS / DISABLE ALERTS:Press SEEK
to
enable/disable the satellite alert status which alerts you when your
selected songs are playing on a satellite radio channel. (The system
default is disabled.) SONG ALERTS ENABLED/DISABLED will appear
in the display. The menu listing will display the opposite state. For
example, if you have chosen to enable the song alerts, the menu
listing will read DISABLE as the alerts are currently on, so your other
option is to turn them off.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.
AUTOSET:Press
MENUto set the strongest local radio stations
for AM/FM1/FM2 without losing your original manually set preset
stations.
When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.
BASS:Press
MENUto decrease/increase the bass setting.
TREBLE:Press
MENUto decrease/increase the treble setting.
BALANCE:Press
MENUto adjust the audio between the left
and right speakers.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
23

FADE:PressMENUto adjust the audio between the front and
rear speakers.
Next/previous directory:In MP3 mode, press
MENUto go to
the previous/next directory.
Flat file/directory mode:In MP3 mode, use
MENUto select
flat file mode or directory mode.
Normal / Track title/ File name:Use
/to scroll through MP3
display options (track #, normal music name or file name).
5.TUNE: Press to manually go
down/up (
/) the radio
frequency and also to select
various settings in menu mode.
6.SHUFF (Shuffle):Press to
play the current CD/MP3 tracks
in random order. In MP3
directory mode, press to play the tracks within the current directory
in random order.
7.REPEAT:Press to repeat the
current CD/MP3 track. The
selection will repeat
continuously until deactivated. Press REPEAT again to deactivate.
8.FF (Fast forward):Press to
manually advance in a CD/MP3
track.
9.REW (Rewind):Press to
manually reverse in a CD/MP3
track.
10.Memory presets:To set a
station: Select frequency band
AM/FM; tune to a station, press
and hold a preset button until sound returns. To recall a previously
set station, press the desired memory preset button briefly. You can
save up to 18 stations, six in AM, six in FM1 and FM2.
In satellite radio mode (if equipped),there are 18 available presets,
six each for SAT1, SAT2 and SAT3. To save satellite channels in your
memory presets, tune to the desired channel then press and hold a
preset control until sound returns.
REW
1
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
24

Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.
11.SEEK/TRACK:Press to access
the previous/next (
/)
strong station. In CD/MP3 mode,
press to advance to the
previous/next (
/) track.
In satellite radio mode (if equipped),press
SEEKto seek to
the previous/next channel.
In CATEGORY MODE,press
SEEKto select a channel within
that category. Press
SEEKto seek to the previous/next channel
in the selected category. Press and hold
SEEKto fast seek
through the previous /next channels.
In TEXT MODE,press
SEEKto view the previous/additional
display text.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.
12.TEXT/SCAN:In radio and CD
mode,press for a brief
sampling of radio stations or CD
tracks. Press again to stop.
In MP3 mode,Press and release to view the next 12 characters in the
MP3 music name/file name of the current MP3 track and directory.
Press and hold to hear a brief sampling of MP3 tracks.
In MP3 directory mode, press and hold to hear a brief sampling of all
tracks in the current directory. Press and hold again to stop.
In satellite radio mode (if equipped),press and release to view the
Satellite text message.
Press and hold to hear a brief sampling of the next channels. Press and
hold again to stop.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.
13.AM/FM:Press to select
AM/FM1/FM2 frequency band.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
25

14.AUX:Press to access AUX
modes.
If equipped with Satellite
Radio, press AUX to cycle through SAT1, SAT2 SAT3
(Satellite Radio mode, if available) and LINE IN (Auxiliary
audio mode, if equipped).
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.
15.ON/OFF/Volume:Press to turn
ON/OFF. Turn to
increase/decrease volume.
If the volume is set above a
certain level and the ignition is
turned off, the volume will come
back on at a “nominal” listening level when the ignition switch is
turned back on.
16.CD:Press to enter CD/MP3
mode. If a CD/MP3 is already
present in the system, the disc
will begin to play.
17.CD slot:Insert a CD/MP3 label
side up.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
26

Premium and Audiophile In-dash CD6/MP3 disc Satellite
Compatible audio systems (if equipped)
1.AM/FM:Press to select
AM/FM1/FM2 frequency bands.
2.CD:Press to enter CD/MP3
mode. If a CD/MP3 is already in
the system, the disc will start
playing.
3.AUX:Press to access AUX
modes. To return to radio mode,
press AM/FM.
If equipped with Satellite
Radio, press AUX to cycle through SAT1, SAT2 SAT3
(Satellite Radio mode, if available) and LINE IN (Auxiliary
audio mode, if equipped).
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
27

4.EJ(CD eject): To eject an
individual CD/MP3, press the
eject control and select the
correct slot number by pressing the corresponding memory preset.
Press and hold to eject all loaded CDs.
5.CLK (Clock):Press CLK until
SELECT HOUR or SELECT
MINS is displayed. Press
MENUto adjust the
hours/minutes. Press CLK to display the time when the ignition is
off.
6.MUTE:Press to mute the
playing media. Press again to
return to the playing media.
7.MENU:Press MENU repeatedly
to toggle through the following
modes and use
/to
make adjustment in those modes.
SATELLITE RADIO MENU (if
equipped):Press MENU when
satellite radio mode is active to
access. Press SEEK
to enter
into the satellite radio menu. Press
/to cycle through the
following options:
•CATEGORY:Press SEEK
to enter category mode. Press
MENUto scroll through the list of available SIRIUS channel
Categories (Pop, Rock, News, etc.) Press SEEK
when the desired
category appears in the display. After a category is selected, press
SEEK to search for that specific category of channels only (i.e.
ROCK). You may also select CATEGORY ALL to seek all available
SIRIUS categories and channels. Press SEEK
to close and return
to the main menu.
•SAVE SONG:Press SEEK
to save the currently playing song in
the system’s memory. (If you try to save something other than a song,
CANT SAVE will appear in the display.) When the chosen song is
playing on any satellite radio channel, the system will alert you with
an audible prompt. Press SEEK
while SONG ALERT is in the
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
28

display and the system will take you to the channel playing the
desired song. You can save up to 20 songs. If you attempt to save a
song when the system is full, the display will read REPLACE SONG?
Press SEEK
to access the saved songs and pressMENU
to cycle through the saved songs. When the song appears in the
display that you would like to replace, press SEEK
. SONG
REPLACED will appear in the display.
•DELETE SONG:Press SEEK
to delete a song from the system’s
memory. Press
MENUto cycle through the saved songs. When
the song appears in the display that you would like to delete, press
SEEK
. The song will appear in the display for confirmation. Press
SEEK
again and the display will read SONG DELETED. If you do
not want to delete the currently listed song, press
MENUto
select either RETURN or CANCEL.
Note:If there are no songs presently saved, the display will read NO
SONGS.
•DELETE ALL SONGS:Press SEEK
to delete all song’s from the
system’s memory. The display will read ARE YOU SURE ? Press
SEEK
to confirm deletion of all saved songs and the display will
read ALL DELETED.
Note:If there are no songs presently saved, the display will read NO
SONGS.
•ENABLE ALERTS / DISABLE ALERTS:Press SEEK
to
enable/disable the satellite alert status which alerts you when your
selected songs are playing on a satellite radio channel. (The system
default is disabled.) SONG ALERTS ENABLED/DISABLED will appear
in the display. The menu listing will display the opposite state. For
example, if you have chosen to enable the song alerts, the menu
listing will read DISABLE as the alerts are currently on, so your other
option is to turn them off.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.
AUTOSET:Allows you to set the strongest local radio stations without
losing your original manually set preset stations for AM/FM1/FM2 . Press
MENU to access. Use
MENUto set.
When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
29

BASS:PressMENUto decrease/increase the bass setting.
TREBLE:Press
MENUto decrease/increase the treble setting.
BALANCE:Press
MENUto adjust the audio between the left
and right speakers.
FADE:Press
MENUto adjust the audio between the front and
rear speakers.
Next/previous directory:In MP3 mode, press MENU
/to go to
the previous/next directory.
Flat file/directory mode:In MP3 mode, press MENU to access this
feature. Use
MENUto select flat file mode or directory mode.
Track #/ normal music name/file name:Press MENU to access and
use
/to scroll through MP3 display options (track #, normal
music name or file name).
8.TUNE/DISC:In radio mode,
press to manually go down/up
(
/) the radio frequency,
or to access another CD/MP3.
Also use in menu mode to select various settings.
9.SHUFF (Shuffle):Press to
play the tracks on the current
CD/MP3 in random order. In
MP3 directory mode, press to play the tracks within the current
directory in random order.
10.COMP (Compression):In
CD/MP3 modes, press to bring
loud and soft passages together
for a more consistent listening level.
11.REPEAT:Press to repeat the
current CD/MP3 track. The
selection will repeat
continuously until deactivated. Press REPEAT again to deactivate.
12.FF (Fast forward):Press to
manually advance in a CD/MP3
track.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Entertainment Systems
30
