rear view mirror MAZDA MODEL B2300 TRUCK 2008 Owners Manual (in English)

Press and pull the window switches
to open and close windows.
•Push down (to the first detent)
and hold the switch to open.
• Pull up and hold the switch to
close.
One touch down
Allows the driver’s window to open
fully without holding the control
down. Push the switch completely
down to the second detent and
release quickly. The window will
open fully. Momentarily press the
switch to any position to stop the
window operation.
INTERIOR MIRROR
The interior rear view mirror has two pivot points on the support arm
which lets you adjust the mirror UP or DOWN and from SIDE to SIDE. WARNING: Do not adjust the mirror while the vehicle is in
motion.
EXTERIOR MIRRORS
Power mirror control (if equipped)
To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and
rotate the control
counterclockwise to adjust the
left mirror.
2. Move the control in the direction you wish to tilt the
mirror.
3. Return to the center position to lock mirrors in place.
2008 B-Series (mbs)
Owners Guide (post-2002-fmt)
USA (fus)
Driver Controls
56
