Flash to pass
Pull toward you slightly to activate
and release to deactivate.
Daytime running lamps (DRL) (if equipped)
Turns the headlamps on with a reduced output.
To activate:
•the ignition must be in the on position and
• the headlamp control is in the off or parking lamp.
WARNING: Always remember to turn on your headlamps at
dusk or during inclement weather. The Daytime Running Lamp
(DRL) (if equipped) system does not activate the parking lights or side
marker lights and generally may not provide adequate lighting during
these conditions. Failure to activate your headlamps under these
conditions may result in a collision.
PANEL DIMMER CONTROL
Use to adjust the brightness of the
instrument panel and all applicable
switches in the vehicle during
headlamp and parking lamp
operation.
Move the control up or down to
adjust the intensity of the panel
lighting.
Move the control to the full upright
position, past detent, to turn on the
interior lamps.
Note: If the battery is disconnected, discharged, or a new battery is
installed, the dimmer switch requires re-calibration. Rotate the dimmer
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Lights
45
Page 46 of 288
Page 47 of 288
Page 48 of 288
Page 49 of 288
•Large water droplets, drip marks or streaks present on the interior of
the lens
Take your vehicle to dealer for service if any of the above conditions of
unacceptable moisture are present.
Using the right bulbs
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized “D.O.T.” for North America and an
“E” for Europe to ensure lamp performance, light brightness and pattern
and safe visibility.
NOTE: The correct bulbs will not damage the lamp assembly or void the
lamp assembly warranty and will provide quality bulb burn time.
Function Number of bulbs Trade number
Park/turn/side marker
lamps (front) 2
3157 A (amber)
Headlamps 29007
Fog lamps (if
equipped) 2
9006
Hi-mount brake lamp 1922
Rear stop/tail lamps 24157K or 3157K
Rear turn lamps 23156
Rear license plate
lamps 2
194
Backup lamps 23155
Dome lamp 1912
Map/dome-SuperCab
(if equipped) 2
904
Map/dome-Regular
Cab (if equipped) 1
904
All replacement bulbs are clear in color except where noted.
To replace all instrument panel lights - see your authorized dealer.
Replacing interior bulbs
Check the operation of the following interior bulbs frequently:
• Courtesy/Reading lamp
For bulb replacement, see an authorized Mazda dealer.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Lights
49
Page 50 of 288
Replacing exterior bulbs
Check the operation of all the bulbs frequently.
Replacing headlamp bulbs
NOTE:The procedure can be difficult. Your Mazda dealer has the proper
tools, training and parts to perform this task. If you have difficulty with
this, visit your local Mazda dealer.
WARNING: Handling Halogen Bulbs: When a halogen bulb
breaks, it is dangerous. These bulbs contain pressurized gas. If
one is broken, it will explode and serious injuries could be caused by
the flying glass. If the glass portion of the bulb is touched with bare
hands, body oil could cause the bulb to overheat and explode when lit.
Never touch the glass portion of the bulb with your bare hands and
always wear eye protection when handling or working around halogen
bulbs.
WARNING: Children and Halogen Bulbs: Playing with a halogen
bulb is dangerous. Serious injuries could be caused by dropping
a halogen bulb or breaking in some other way. Always keep halogen
bulbs out of the reach of children.
To remove the headlamp bulb:
1. Make sure headlamp switch is in the off position, then open the hood. 2. Reach behind the lamp assembly for access and disconnect the electrical connector.
3. Locate the bulb retaining ring behind the headlamp assembly.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Lights
50
