rear view mirror MAZDA MODEL B4000 CAB PLUS 4 TRUCK 2009 Owners Manual

WARNING:When closing the power windows, you should verify
they are free of obstructions and ensure that children and/or
pets are not in the proximity of the window openings.
Press and pull the window switches
to open and close windows.
• Push down (to the first detent)
and hold the switch to open.
• Pull up and hold the switch to
close.
One touch down
Allows the driver’s window to open
fully without holding the control
down. Push the switch completely
down to the second detent and
release quickly. The window will
open fully. Momentarily press the
switch to any position to stop the
window operation.
INTERIOR MIRROR
The interior rear view mirror has two pivot points on the support arm
which lets you adjust the mirror UP or DOWN and from SIDE to SIDE.
WARNING: Do not adjust the mirror while the vehicle is in
motion.
EXTERIOR MIRRORS
Power mirror control (if equipped)
WARNING: Do not adjust the mirror while the vehicle is in
motion.
2009 B-Series (mbs)
Owners Guide, 1st Printing
USA (fus)
Driver Controls
59
