FluidMazda Part
NameApplication Capacity
Transmission
fluid
1Mazda
MERCON AT F5-speed manual 2.65L (2.8
quarts)2
Mazda
MERCONV
AT F4x2 vehicles
with automatic
and 2.3L I4
engine9.4L (9.9
quarts)3
4x2 vehicles
with automatic
and 3.0L or 4.0L
engines9.5L (10.0
quarts)3
4x4 vehicles
with automatic
and 3.0L or 4.0L
9.8L (10.3
quarts)3
Engine coolant4Premium Engine
Coolant
2.3 L I4 engine
with manual
transmission10.0L (10.5
quarts)
2.3L I4 engine
with automatic
transmission 9.7L (10.2
quarts)
3.0L V6 engine
with manual
transmission 14.3L (15.1
quarts)
3.0L V6 engine
with automatic
transmission 14.0L (14.8
quarts)
4.0L V6 engine
with manual
transmission 13.0L (13.7
quarts)
4.0L V6 engine
with automatic
transmission 12.5L (13.2
quarts)
2004 Mazda B Series
(mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
241
Page 242 of 256
FluidMazda Part
NameApplication Capacity
Fuel tank N/A Regular cab
(Short wheel
base) 64.4L (17
gallons)
SuperCab 73.8L (19.5 gallons)
Transfer Case
Fluid Mazda
MERCON
AT F4x4 Vehicles 1.2L (1.25
quarts)
Front axle
lubricant Mazda SAE
80W-90
Premium Rear
Axle Lubricant4x4 Vehicles 1.7L (3.6 pints)
Rear axle
lubricant
5Mazda SAE
80W-90
Premium Rear
Axle Lubricant All 2.4-2.5L (5.0-5.3
pints)
Windshield
washer fluid Ultra-Clear
Windshield
Washer
ConcentrateAll 2.6L (2.75
quarts)
1Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCON and MERCONV are not interchangeable. DO NOT
mix MERCON and MERCONV. Refer to the service maintenance
section to determine the correct service interval.
2Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
3Indicates only approximate dry-fill capacity. Some applications may vary
based on cooler size and if equipped with an in-tank cooler. The amount
of transmission fluid and fluid level should be set by the indication on
the dipstick’s normal operating range.
4Add the coolant type originally equipped in your vehicle. DO NOT MIX
different colors or types of coolant. DO NOT USE Mazda Extended Life
Engine Coolant (orange in color). Refer to Adding engine coolant, in
this chapter.
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
242
Page 243 of 256
5Traction-Lok axles use 2.2–2.4L (4.75–5.0 pints) of rear axle lubricant.
Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda
specifications for complete refill of Traction-Lok axles. Service refill
capacities are determined by filling the rear axle 6 mm to 14 mm (1/4
inch to 9/16 inch) below the bottom of the filler hole.
6Brake fluid will drop slowly as the brakes wear and will rise when brake
components are replaced. Fluid levels below the MAX line that do not
trigger the brake warning light are within the normal operating range,
there is no need to add fluid. If the levels are outside the normal
operating range, the performance of your brake system could be
compromised, seek service from your local Mazda dealer immediately.
LUBRICANT SPECIFICATIONS
Item Mazda part name or equivalent
Front axle (4X4) SAE 80W-90 Premium Rear Axle
Lubricant
Rear axle SAE 80W-90 Premium Rear Axle
Lubricant
1
Brake fluid and clutch fluid (if
equipped)High Performance DOT 3 Motor
Vehicle Brake Fluid
4
Door weather strips
Silicone Lubricant
Engine coolant Mazda Premium Engine Coolant3
Engine oil 2.3L I4 and 3.0L V6 engines SAE 5W-20 Motor Oil
Engine oil 4.0L V6 engines SAE 5W-30 Motor Oil
Hinges, door checks, latches, striker
plates, fuel filler door hinge and seat
tracksMulti-Purpose Grease
Transmission /steering/parking brake
linkages and pivots, brake and clutch
pedal shaft, clutch pilot bearing and
input shaft spline (manual
transmission). Premium Long-Life Grease
Power steering fluid, transfer case
fluid (4X4) and transmission fluid
(manual) MERCON
AT F
Automatic transmission (5R44E and
5R55E) MERCONVATF
2
Windshield washer fluid
Ultra-clear Windshield Washer
Concentrate
2004 Mazda B Series
(mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
243
Page 244 of 256
1Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda
specifications for complete refill of Traction-Lok axles. If submerged in
water, the rear axle lubricant should be changed.
2Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCON and MERCONV are not interchangeable. DO NOT
mix MERCON and MERCONV. Refer to your service maintenance
section to determine the correct service interval.
3Do not mix different types or colors of engine coolant.
4Brake fluid will drop slowly as the brakes wear and will rise when brake
components are replaced. Fluid levels below the MAX line that do not
trigger the brake warning light are within the normal operating range,
there is no need to add fluid. If the levels are outside the normal
operating range, the performance of your brake system could be
compromised, seek service from your local Mazda dealer immediately.
ENGINE SPECIFICATIONS
Engine 2.3L I4 engine 3.0L V6 engine 4.0L V6 engine
Cubic inches 138 182 245
Required fuel 87 octane 87 octane 87 octane
Firing order 1-3-4-2 1-4-2-5-3-6 1-4-2-5-3-6
Spark plug gap 1.04-1.19mm
(0.041-0.047
inch)1.07-1.17mm
(0.042-0.046
inch)1.3-1.4 mm
(0.052-0.056
inch)
Ignition system EDIS EDIS EDIS
Compression
ratio 9.7:1 9.14:1 9.7:1
2004 Mazda B Series
(mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
244
Page 245 of 256
VEHICLE DIMENSIONS
Vehicle dimensions Regular Cabmm (in)SuperCab mm
(in)
(1) Overall length 4 786 (188.4) 5 168 (203.4)
(2) Overall width 1 785 (70.3) 1 785 (70.3)
(3) Overall height 4x2/4x4 1 651 (65.0) / 1 727 (68.0)1 651 (65.0) /
1 727 (68.0)
(4) Wheelbase 2 831 (111.4) 3 192 (125.7)
(5) Track - Front 1 486 (58.5) 1 485 (58.5)
(5) Track - Rear 1 455 (57.3) 1 455 (57.3)
2
5
3
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
245
Page 246 of 256
1
4
1
4
2004 Mazda B Series(mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
246
Page 247 of 256
IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety Administration Regulations require
that a Certification Label be affixed to a vehicle and prescribe where the
Certification Label may be located. The Certification Label is located on
the front door latch pillar on the driver’s side.
Vehicle identification number (VIN)
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel. (Please note that
in the graphic XXXX is
representative of your vehicle
identification number.)
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if equipped).
XXXXXXXXXXXXXXXXX
2004 Mazda B Series(mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Maintenance and Specifications
247
Page 248 of 256
CELL PHONES
