Before Driving
Keys
Transmitter

Operation buttons Operation indicator light

NOTE
  (European models)  The headlights turn on/off by
operating the transmitter. Refer
to Leaving Home Light on page
4-65 .
  (With theft-deterrent system)  The hazard warning lights À ash when
the theft-deterrent system is armed or
turned off.
 Refer to Theft-Deterrent System on
page 3-46 .
  (With the advanced keyless
function (European models))
 The setting can be changed so that a
beep sound is heard for con¿ rmation
when the doors and the liftgate are
locked/unlocked using the key.
 (With the advanced keyless
function (Except European
models))
 A beep sound can be heard for
con¿ rmation when the doors and the
liftgate are locked/unlocked using the
key. If you prefer, the beep sound can
be turned off.
 The volume of the beep sound can
also be changed.
 Refer to Personalisation Features on
page 9-13 .
NOTE

Use the following procedure to change
the setting.

1. Switch the ignition off and close
all of the doors and the liftgate.
2. Open the driver's door.
3. Within 30 seconds of opening the
driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.
All of the doors and the liftgate
lock and the beep sound activates
at the currently set volume.
The setting changes each time
the LOCK button on the key
is pressed and the beep sound
activates at the set volume. (If the
beep sound has been set to not
activate, it will not activate.)
4. The setting change is completed
by doing any one of the following:



 Switching the ignition to ACC
or ON.



 Closing the driver's door.



 Opening the liftgate.



 Not operating the key for 10
seconds.



 Pressing any button except the
LOCK button on the key.



 Pressing a request switch.
The operation indicator light À ashes when
the buttons are pressed.

3–37
Before Driving
Mirrors
Rearview Mirror
WARNING
Do not stack cargo or objects higher
than the seatbacks:
Cargo stacked higher than the
seatbacks is dangerous. It can block
your view in the rearview mirror, which
might cause you to hit another car
when changing lanes.
Rearview mirror adjustment
Before driving, adjust the rearview mirror
to centre on the scene through the rear
window.


Reducing glare from headlights
Adjust the mirror with the antidazzle lever
in the day position.
Push the antidazzle lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Antidazzle lever
Day Night

4–2*Some models.
Drive Selection ................................... 4-96
Drive Selection * ........................... 4-96

i-ACTIV AWD ................................... 4-98
i-ACTIV AWD Operation
* ........... 4-98

Power Steering................................. 4-100
Power Steering ........................... 4-100
i-ACTIVSENSE............................... 4-101
i-ACTIVSENSE
* ........................ 4-101
Adaptive Front Lighting System
(AFS)
* ........................................ 4-104
High Beam Control System
(HBC)
* ........................................ 4-105
Adaptive LED Headlights
(ALH)
* ........................................ 4-108
Lane Departure Warning System
(LDWS)
* .................................... 4-111
Blind Spot Monitoring (BSM)
System
* ....................................... 4-117
T r a f¿ c Sign Recognition System
(TSR)
* ........................................ 4-124
Distance Recognition Support System
(DRSS)
* ...................................... 4-131
Driver Attention Alert (DAA) * ... 4-134
Rear Cross Traf¿ c Alert
(RCTA)
* ..................................... 4-137
Mazda Radar Cruise Control
(MRCC)
* .................................... 4-142
Adjustable Speed Limiter * ......... 4-155
Advanced Smart City Brake Support
(Advanced SCBS) (Except Indonesia,
Malaysia, and Thailand)
* ............ 4-162
Smart City Brake Support [Forward]
(SCBS F) (Indonesia, Malaysia, and
Thailand)
* ................................... 4-166
Smart City Brake Support [Reverse]
(SCBS R)
* .................................. 4-170
Smart Brake Support (SBS) * ...... 4-176
Forward Sensing Camera
(FSC)
* ......................................... 4-179
Radar Sensor (Front) * ................. 4-186
Radar Sensors (Rear) * ................ 4-189
Ultrasonic Sensor (Rear) * ........... 4-191

4–28
When Driving
Instrument Cluster and Display
NOTE
  After refuelling, it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve
since the fuel moves in the tank.
  The display indicating a quarter
or less remaining fuel has more
segments to show the remaining fuel
level in greater detail.
  The direction of the arrow ( )
indicates that the fuel-¿ ller À ap is on
the left side of the vehicle.
(SKYACTIV-D 1.5)
If inconsistency in engine performance
or stalling occurs due to low fuel level
conditions, refuel the vehicle as soon as
possible and add at least 10 L (2.7 US gal,
2.2 Imp gal) of fuel.
Instrument Panel Illumination
When the position lights are turned
on with the ignition switched ON,
the brightness of the instrument panel
illumination is dimmed.
NOTE
When the position lights are turned on,
the position lights indicator light in the
instrument cluster turns on.
Refer to Headlights on page 4-59 .
The brightness of the instrument cluster
and instrument panel illuminations can be
adjusted by rotating the knob.



 The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.



 The brightness increases by rotating the
knob to the right.


Dim
Bright

4–37
When Driving
Instrument Cluster and Display
*Some models.
Signal Warning Page

Master Warning Light *1 7-52

Check Engine Light *1 7-52


(Amber) * i-stop Warning Light *1 7-52


(Amber) * i-ELOOP Warning Light 7-52

* Automatic Transaxle Warning Light *1 7-52

Air Bag/Seat Belt Pretensioner System Warning Light *1 7-52

* Tyre Pressure Monitoring System Warning Light *1 Flashing
7-52
Turns on
7-58


(Red) KEY Warning Light *1 Malfunction
7-52
Except
malfunction
7-58


(Amber) * High Beam Control System (HBC) Warning Light *1 7-52


(Amber) * Adaptive LED Headlights (ALH) Warning Light *1 7-52

* Lane Departure Warning System (LDWS) Warning Light *1 Flashing
4-115
Turns on
7-52


(Amber) * Mazda Radar Cruise Control (MRCC) Warning Light 7-52

* LED Headlight Warning Light *1 7-52

4–39
When Driving
Instrument Cluster and Display
*Some models.
Signal Indicator Lights Page

Security Indicator Light *1 3-45

* Glow Indicator Light *1 4-43

* Diesel Particulate Filter Indicator Light *1 4-202

Wrench Indicator Light *1 4-42


(Blue) Low Engine Coolant Temperature Indicator Light 4-43


(Green) * i-stop Indicator Light 4-18


(Green) * i-ELOOP Indicator Light 4-90

* Vehicle Speed Alarm Indication 4-30

Shift Position Indication 4-50

Lights-On Indicator Light 4-59

Headlight High-Beam Indicator Light Headlight High-
Low Beam
4-64
Flashing the
Headlights
4-64

Direction Indicator/Hazard Warning Indicator Lights Turn and Lane-
Change Signals
4-69
Hazard Warning
Flasher
4-77

* Front Fog Light Indicator Light 4-67

4–40
When Driving
Instrument Cluster and Display
*Some models.
Signal Indicator Lights Page

* Rear Fog Light Indicator Light 4-68

* TCS/DSC Indicator Light *1 Traction Control
System (TCS)
4-85
Dynamic
Stability Control
(DSC)
4-87
Turns on
7-52


* TCS OFF Indicator Light *1 4-86


* Select Mode Indicator Light 4-97


(Green) * High Beam Control System (HBC) Indicator Light 4-107


(Green) * Adaptive LED Headlights (ALH) Indicator Light 4-110

* Blind Spot Monitoring (BSM) OFF Indicator Light *1 Malfunction
7-52
Except
malfunction
4-123

* Lane Departure Warning System (LDWS) OFF Indicator Light *1 4-114

* Driver Attention Alert (DAA) Indication 4-136


(Green) * Mazda Radar Cruise Control (MRCC) Indicator Light 4-146

4–59
When Driving
Switches and Controls
Lighting Control
Headlights
Turn the headlight switch to turn the headlights, other exterior lights and instrument panel
illumination on or off.
When the lights are turned on, the lights-on indicator light in the instrument cluster turns on.



NOTE
  To prevent discharging the battery, do not leave the lights on while the engine is off
unless safety requires them.
  Headlights do not blind drivers approaching in the opposite direction no matter
what side of the road you must drive your vehicle (left-hand or right-hand traf¿ c).
Therefore, it is not necessary to adjust the optical axis of the headlights when
switching temporarily to driving on the opposite side of the road (left-hand or right-
hand traf¿ c).

4–60
When Driving
Switches and Controls
*Some models.
Without auto-light control



Switch Position

Ignition Position ON ACC or
OFF O N ACC or
OFF O N ACC or
OFF
Headlights Off Off Off Off On Off
Running lights
* O n *1 Off Off Off Off Off
Tail lights
Position lights
Number plate lights
Instrument panel illumination Off Off On On On On
*2
*1 The lights are turned on while the vehicle is driven.
*2 The lights are turned on continuously if the ignition is switched from ON to any other position with the lights
turned on. The lights are turned off when the driver's door is opened or 30 seconds have elapsed since the lights
turned on.

4–61
When Driving
Switches and Controls
*Some models.
With auto-light control



Switch Position

Ignition Position ON ACC
or OFF O N ACC
or OFF O N ACC
or OFF O N ACC
or OFF
Headlights Off Off Auto
*2 Off Off Off On Off
Running lights * O n *1 Off Auto *3 Off Off Off Off Off
Tail lights
Position lights
Number plate lights
Instrument panel illumination Off Off Auto
*2 On *4 /
Off *5 On On On On *4
*1 The lights are turned on while the vehicle is driven.
*2 The lights are turned on by the auto light function.
*3 The lights are turned on while the vehicle is driven, and turned off when the headlights are turned on by the auto
light function.
*4 While the lights are turned on, they will remain on even if the ignition is switched to a position other than ON .
If the driver’s door is opened or 30 s have elapsed with the lights turned on, the lights turn off.
*5 When the ignition is switched to a position other than ON , the lights will not turn on even if the light switch is
switched to
.
