MAZDA MODEL CX-30 2022 Owners Manual

Canada
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-40
CX-30_8KN2-EA-21L_Edition1_new2021-9-15 19:39:56

Customer Information and Reporting Safety Defects
Declaration of Conformity
8-41
CX-30_8KN2-EA-21L_Edition1_new2021-9-15 19:39:56

▼Front Radar Sensor System
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-42
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

▼Front Side Radar Sensor System/Rear Side Radar Sensor System
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-43
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

Customer Information and Reporting Safety Defects
Declaration of Conformity
8-44
CX-30_8KN2-EA-21L_Edition1_new2021-9-15 19:39:56

9Specifications
Technical information about your Mazda.
Identification Numbers.............. 9-2
Vehicle Information Labels...........
............................................ 9-2
Specifications ........................... 9-4
Specifications........................ 9-4
9-1
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Vehicle InformationLabels
▼Ve h i c l e
Identification Number
The vehicle identification number
legally
identifies your vehicle. The
number is on a plate attached to the
cowl panel located on the left corner
of the dashboard. This plate can easily
be seen through the windshield.
▼ Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼
Chassis Number
Open the cover shown in the figure to
check the chassis number.
▼Vehicle Emission Control
Information Label (U.S.A. and
Canada)
▼Tire Pressure Label
Specifications
Identification
Numbers
9-2
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

▼Engine Number
1. Forward
Specifications
Identification
Numbers
9-3
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.0 SKYACTIV-G 2.5 SKYACTIV-G 2.5T
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 ×
3.59 in) 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 1,997.6 ml (1,997.6 cc) 2,488.5 ml (2,488.5 cc)
Compression
ratio 13.0
10.5
▼Electrical System
Item
Classification
Battery
*112V-60Ah/20HR
Spark-plug
number SKYACTIV-G 2.0, SKY-
ACTIV-G 2.5
Mazda Genuine spark
plug
*2PE5R-18-110-A or PE5S-18-110
SKYACTIV-G 2.5T Mazda Genuine spark
plug
*2PY8V-18-110
*1 Check the battery installed on the vehicle and us
e a battery with an equal or higher performance.
However, the performance of the battery may vary even among the same battery types, consult an
Authorized Mazda Dealer for replacement.
*2 This spark plug provides the SKYACTIV-G engine with optimum performance. Contact an Authorized
Mazda Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The
fine particulate
coating on the iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-16.
Coolant FL-22 type
Automatic transmission fluid
*1Mazda Genuine ATF FZ
Transfer case oil
*2Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil
*2Mazda Long Life Hypoid Gear Oil SG1
Brake fluid SAE J1703 or FMVSS116 DOT-3
Specifications
Specifications
9-4
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

*1 Periodic replacement is unnecessary.*2 Replacement is necessary when the component is submerged in water.
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your
investment.
▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil SKYAC-
TIV-G 2.0
With oil filter replacement
4.2 L (4.4 US qt, 3.7 Imp qt)
Without oil filter replacement 4.0 L (4.2 US qt, 3.5 Imp qt)
SKYAC-
TIV-G 2.5 With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil filter replacement 4.3 L (4.5 US qt, 3.8 Imp qt)
SKYAC-
TIV-G 2.5T With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replacement 4.6 L (4.9 US qt, 4.0 Imp qt)
Coolant SKYACTIV-G 2.0
6.2 L (6.6 US qt, 5.5 Imp qt)
SKYACTIV-G 2.5 6.3 L (6.7 US qt, 5.5 Imp qt)
SKYAC-
TIV-G 2.5T For engine
8.2 L (8.7 US qt, 7.2 Imp qt)
For water-cooled charge air cooler 1.6 L (1.7 US qt, 1.4 Imp qt)
Automatic
transmission
fluid SKYACTIV-G 2.0, SKYACTIV-G 2.5
7.6 L (8.0 US qt, 6.7 Imp qt)
SKYACTIV-G 2.5T 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank FWD
51.0 L (13.5 US gal, 11.2 Imp
gal)
AWD 48.0 L (12.7 US gal, 10.6 Imp
gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
Specifications
Specifications
9-5
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56
