SignalWarning
Lane-keep Assist
System (LAS) & Lane Departure
Wa r n i n g S y s t e m
(LDWS) Warning
Indication
*
The message is displayed when the system ha s a malfunction. Have your vehicle inspect-
ed at an Authorized Mazda Dealer.
The system does not operate when the warning message is displayed.
CAUTION
Always use tires for all wheels that are of the specified size, and the same manufacture,
brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the system may not operate
normally.
 When an emergency spare tire is used, the system may not operate normally.
LED Headlight
Warning Light This light illuminates if ther
e is a malfunction in the LED headlight. Have your vehicle
inspected by an Authorized Mazda Dealer.
▼ Taking Action
Take the appropriate action and verify that the warning light turns off.
Signal
Warning Action to be taken
(Amber)
Smart Brake Support/
Smart City Brake Sup- port (SBS/SCBS)
Warning Indication/
Wa r n i n g L i g h t
*
The light turns on if th e windshield or the
radar sensor are dirty, or there is a malfunc-
tion in the system. Verify the reason why the warning light is
illuminated on the center display.
If the reason why the
warning light is illu-
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em-
blem.
For any other reasons, have the vehicle in-
spected at an Authorized Mazda Dealer.
Low Fuel Warning In- dication/Warning Light The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).NOTE
The light illumination timing may vary be-
cause fuel inside the fuel tank moves
around according to
the driving conditions
and the vehicle posture. Add fuel.
Check Fuel Cap Warn-
ing Indication/Warning
Light If the check fuel cap warning light illumi-
nates while driving, the fuel-filler cap may
not be installed properly.
Stop the engine and re
install the fuel-filler
cap.
Refer to Refueling on page 3-34.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-33
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

SignalWarning Action to be taken
Engine Oil Level
Warning Light This warning light indicates that the engine
oil level is around the MIN mark (page
6-27).
Add 1 L (0.3 US gal, 0.2 Imp gal) of en-
gine oil (page 6-25).
Seat Belt Warning
Light (Front seat) Except Mexico
The seat belt warning lig
ht turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig-
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and th e vehicle is driven at
a speed faster than ab out 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re-
mains illuminated.
NOTE
The warning light fla shes for about 6
seconds if the driver's seat belt is not fas-
tened when the ignition is switched ON.
To allow the front passenger occupant
classification sensor to function properly,
do not place and sit on an additional seat
cushion on the front passenger's seat.
The sensor may not function properly be-
cause the additional seat cushion could
cause sensor interference.
If a small child is se ated on the front pas-
senger's seat, the warning light may not
operate. Fasten the seat belts.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-34
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

SignalWarning Action to be taken
Seat Belt Warning
Light (Front seat) Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not
fastened with the ig-
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re-
mains illuminated. If a seat belt remains un-
fastened, the warning light flashes again for
a given period of time.
NOTE
Placing heavy items on the front pas-
senger's seat may cause the front pas-
senger's seat belt warning function to op-
erate depending on the weight of the
item.
To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause sen-
sor interference.
If a small child is seated on the front pas-
senger's seat, the warning light may not
operate. Fasten the seat belts.
(Red)
Seat Belt Warning Light (Rear seat) If the rear seat belts are not fastened while
the ignition is switched
ON , the driver and
the passenger are alerted by the warning
light.
The warning light operates even if there is
no passenger on the rear seat.
NOTE
If a rear seat belt is not fastened by a cer-
tain period of time after the engine has
been started, the warning light turns off. Fasten the seat belts.
Low Washer Fluid
Level Warning Indica-
tion/Warning Light
*
This warning light indicates that little wash-
er fluid remains. Add washer fluid (page 6-31).
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-35
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

NOTE
To allow the front passenger occupant
classification sensor to function
properly, do not place and sit on an
additional seat cushion on the front
passenger's seat. The sensor may not
function properly because the additional
seat cushion could cause sensor
interference.
If a small child is seated on the front
passenger's seat, the warning beep may
not operate.
Mexico
If the vehicle speed exceeds about 20
km/h (12 mph) with the driver or front
passenger's seat belt unfastened, a warning
beep sounds continuously. If the seat belt
remains unfastened, the beep sound stops
once and then continues for about 90
seconds. The beep stops after the driver or
front passenger's seat belt is fastened.
Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).
NOTE
Placing heavy items on the front
passenger's seat may cause the front
passenger's seat belt warning function
to operate depending on the weight of
the item.
To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause
sensor interference.
If a small child is seated on the front
passenger's seat, the warning beep may
not operate.
Rear seat
The warning beep only sounds if a seat
belt is unfastened after being fastened.
▼ Ignition Not Switched Off (STOP)
Warning Beep
If the driver's door
is opened with the
ignition switched to ACC, a beep will be
heard continuously in the cabin to notify
the driver that the ignition has not been
switched OFF (STOP). Under this
condition, the keyless entry system will
not operate, the vehicle cannot be locked,
and the battery voltage will be depleted.
▼ Key Removed from Vehicle Warning
Beep
Vehicles with advanced keyless function
If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, the beep which
sounds outside of the vehicle will be heard
6 times, the beep which sounds inside the
vehicle will be heard 6 times.
Vehicles without advanced keyless
function
If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, a
beep will be heard
in the cabin 6 times.
NOTE
Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key is
carried together with a metal object or it
is placed in a poor signal reception area.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-44
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

NOTE
The volume of the Lane-keep Assist
System (LAS) & Lane Departure
Warning System (LDWS) warning sound
can be changed.
Refer to Personalization Features on
page 9-11.
The type of the Lane-keep Assist System
(LAS) & Lane Departure Warning
System (LDWS) warning sound can be
changed.
Refer to Personalization Features on
page 9-11.
▼Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) System
Wa r n i n g s
*
The Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) system
warnings notify the
driver of system problems and precautions
on use when required. Check after hearing
a warning beep sound.
Warning beep What to check
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func-
tion) system is operating,
a single beep sound is
heard when “Front Ra-
dar Sensor Blocked” is
displayed in the mul-
ti-information display. Cancel the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func-
tion) system if the radar
sensor (front) becomes
dirty. Clean the area
around the radar sensor
(front).
The beep sounds inter-
mittently while the vehi-
cle is being driven. The distance between
your vehicle and the ve-
hicle ahead is too close.
Verify the safety of the
surrounding area and re-
duce vehicle speed.
Warning beep What to check
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func-
tion) system is operating,
a single beep sound is
heard when “ Front Ra-
dar Sensor System Mal-
function” is displayed in
the multi-information
display. A malfunction in the
system may be indicated.
Check the center display
to verify the problem
and then have your vehi-
cle inspected by an Au-
thorized Mazda Dealer.
▼
Excessive Speed Warning*
If the vehicle speed exceeds the speed
limit sign displayed on the active driving
display, the warning sound is activated and
the area around the speed limit sign
displayed on the active driving display
flashes 3 times in amber, and if the vehicle
speed continues to exceed the displayed
speed limit sign, the indication stops
flashing and remains on.
▼
Collision warning*
If there is a possibility of a collision with a
vehicle ahead or an obstruction at the rear
of the vehicle, the warning light in the
instrument cluster flashes at the same time
as the warning indication is displayed in
the multi-information display, and a
warning sound is activated intermittently.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-47
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

ItemFeatureFactory Set-
ting Available
Settings Set-
tings
Chan ge
Meth od
Traffic Sign Recog-
nition System
(TSR)
*3 (page
4-133) The Traffic Sign Recognition System (TSR) can be
set to inoperable.
*1On On/Off A
―
The warning pattern of the excessive speed warning
can be changed. OffOff/
Vi s u a l /
Audio & Vis-
ual A
―
The activation timing for the excessive speed warn-
ing can be changed.00/5/10 A
―
360° View Monitor
(page 4-181) Setting can be changed so
that the 360° view moni-
tor is automatically disp layed when the ignition is
switched to ON. Off On/Off A
―Setting can be changed so that the display of the es-
timated forward line of progress is not displayed. On On/Off A
―
Setting can be changed so that the top view/front
view displayed while the vehicle is moving in the
forward direction after reversing is not displayed. On On/Off A
―
Parking sensor sys-
tem (page 4-241)Display*4/non-display
On On/Off A
―
Ve h i c l e
Door locks (page
3-16)Operation condition of auto lock/unlock function Lock: When
Driving Un-
lock: IGN Off Lock: Out of
Park Unlock: In Park/
Lock: Shift- ing Out of Park/
Lock: When Driving Un-
lock: In Park/ Lock: WhenDriving Un- lock: IGN Off/
Lock: When Driving/ Off AD
Specifications
Personalization Features
9-13
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

*4 When the ultrasonic sensors detect an obstruction, the contents indicated on the center display switches to the
360°View Monitor. (Vehicles with 360°View Monitor)
*5 If the auto-wiper control is set to Off, the wiper lever position is set to intermittent operation.*6 If the setting is changed to Off, the following opera tion is performed according to the headlight switch
position:
At position: Headlights turn off immediately after the ignition is switched off.At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-75.
*7 When set to Off, the lights-on reminder is operable.*8 The lights-on reminder settings can be changed at a nytime, however, the lights-on reminder only operates
when the auto headlight function is set to Of f. Refer to Lights-On Reminder on page 7-43.
*9 Change the ambient light illumination level with the parking lights or headlights turned on.*10 When set to OFF, the ambient lights remain turned off regardless of whether or not the parking lights or
headlights are on or off. However, they will turn on or off in conjunction with the illuminated entry system.
*11 The operation may stop in 15 minutes due to the effect of the outside temperature even if the operation time ofthe rear window defogger has been changed to Continuous.
*12 Available only in display from the center display.
Specifications
Personalization Features
9-17
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

Index
Distance Recognition Support System
(DRSS) Display........................... 4-38
Distance-to-empty....................... 4-36
Engine Coolant Temperature
Gauge........................................... 4-33
Fuel Gauge.................................. 4-34
Indication/Indicator Lights.......... 4-42
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-38
Maintenance Monitor.................. 4-37
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display.......4-38
Multi-information Display (Type
B)................................................. 4-31
Odometer..................................... 4-33
Outside Temperature Display...... 4-36
Remaining Diesel Exhaust Fluid
(DEF) and Maximum Driving
Distance Display..........................4-37
Speedometer................................ 4-30
Tachometer.................................. 4-30
Trip Meter....................................4-33
Warning Indication/Warning
Lights........................................... 4-40
Warning (Display Indication)...... 4-39
Instrument Cluster (Type C)............. 4-46
Cruise Control Set Vehicle Speed
Display......................................... 4-52
Dashboard Illumination............... 4-50
Engine Coolant Temperature
Gauge........................................... 4-48
Fuel Gauge.................................. 4-49
Indication/Indicator Lights.......... 4-55
Multi-information Display (Type
C)................................................. 4-47
Odometer..................................... 4-47
Outside Temperature Display...... 4-50
Speedometer................................ 4-46
Tachometer.................................. 4-46Trip Computer............................. 4-51
Trip Meter....................................4-47
Warning Indication/Warning
Lights........................................... 4-53
Interior Care...................................... 6-71 Active driving display
maintenance................................. 6-73
Cleaning the floor mats............... 6-73
Cleaning the window interiors.....6-73
Instrument panel top (Soft pad)
maintenance................................. 6-72
Leather upholstery
maintenance................................. 6-72
Panel maintenance....................... 6-73
Plastic part maintenance.............. 6-72
Seat belt maintenance..................6-71
Upholstery maintena nce.............. 6-71
Vinyl upholstery maintenance..... 6-71
Interior Lights................................... 5-92
Luggage compartment light.........5-92
Map lights....................................5-92
Overhead lights............................5-92
i-ACTIVSENSE.............................. 4-121 Active safety technology........... 4-121
Adaptive Front Lighting System
(AFS)......................................... 4-124
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-172
Blind Spot Monitoring (BSM) ............
................................................... 4-128
Camera and sensors................... 4-122
Distance Recognition Support System
(DRSS).......................................4-139
Forward Sensing Camera
(FSC)......................................... 4-207
High Beam Control System
(HBC)........................................ 4-125
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-162
10-6
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

Index
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-147
Pre-crash safety technology.......4-122
Radar sensors (rear)...................4-215
Radar sensor (front)...................4-212
Rear Cross Traffic Alert
(RCTA)...................................... 4-143
Smart Brake Support (SBS)...... 4-178
Smart City Brake Support
(SCBS)....................................... 4-175
Traffic Sign Recognition System
(TSR)......................................... 4-133
360°View Monitor..................... 4-181
i-ACTIV AWD Operati on............... 4-118
J
Jack...................................................... 7-4
Jump-Starting.................................... 7-13
K
Keyless Entry System......................... 3-4
Keys.....................................................3-2
Key suspend function.................... 3-9
Transmitter.............. .......................3-5
Key Left-in-luggage Compartment
Warning beep (With the advanced
keyless function)............................... 7-45
Key Left-in-vehicle Warning Beep (With
the advanced keyless function)......... 7-45
Key Removed from Vehicle Warning
Beep...................................................7-44
Key Suspend Function........................ 3-9
L
Label Information............................... 9-2
Lane Departure Warning sound........ 7-46
Lane-change Signals......................... 4-82
Lane-keep Assist System (LAS) & Lane
Departure Warning System
(LDWS)........................................... 4-162
Leaving Home Light......................... 4-79
Liftgate.............................................. 3-20 When Liftgate Cannot be
Opened......................................... 7-48
Lighting Control................................4-75
Lights-on Reminder.......................... 7-43
Light Bulbs Replacement................................ 6-52
Specifications.................................9-8
Lubricant Quality ................................ 9-5
Luggage Compartment....................5-102 Cargo securing loops................. 5-102
Cargo sub-compartment............ 5-102
Luggage Compartment Light............ 5-92
M
Maintenance Information.................................... 6-2
Scheduled.......................................6-4
Maintenance Monitor........................ 6-16
Manual Transaxle Oper ation............. 4-61
Map Lights........................................ 5-92
Mazda Radar Cruise Control with Stop &
Go function (MRCC with Stop & Go
function).......................................... 4-147 Close proximity warning........... 4-151
Cruise control function.............. 4-159
Display indication......................4-149
Setting the system..................... 4-152
Stop hold control....................... 4-158
Mazda Radar Cruise Control with Stop &
Go function (MRCC with Stop & Go
function) System Warnings............... 7-47
Message Indicated on Display.......... 7-41
Message Indicated on Multi-information
Display.............................................. 7-39
Meters................................................ 4-12
10-7
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

Index
MirrorsOutside mirrors............................ 3-36
Rearview mirror.......................... 3-38
Mirror Defogger.......... ...................... 4-87
Moonroof...........................................3-44
Multi-information Display (Type
A).......................................................4-14
Multi-information Display (Type
B)....................................................... 4-31
Multi-information Display (Type
C)....................................................... 4-47
O
Off-Road Traction Assist Off-Road Traction Assist indicator
light............................................ 4-111
Off-Road Traction Assist
switch......................................... 4-112
Outside Mirrors................................. 3-36
Overhead Console..... ...................... 5-100
Overhead Lights................................ 5-92
Overheating....................................... 7-18
Overloading....................................... 3-56
Owner Maintenance Closing the hood......................... 6-21
Engine compartment overview.... 6-23
Key battery replacement..............6-44
Opening the hood.................. ...... 6-21
Owner maintenance
precautions................................... 6-19
P
Parking Sensor System................... 4-239 Park assist sensor system
operation.................................... 4-242
Sensor detection range.............. 4-241
Personalization Features....................9-11
Power Liftgate................................... 3-22
Power Liftgate Warning Beep........... 7-45
Power Steering................................ 4-120
Power Steering Warning Buzzer....... 7-46
Power Windows................................ 3-41
R
Radar Sensors (Rear)...................... 4-215
Radar Sensor (Front).......................4-212
Rearview Mirror................................3-38
Rear Coat Hooks...... ....................... 5-103
Rear Cross Traffic Alert (RCTA).... 4-143
Rear Door Child Safety Locks.......... 3-20
Rear Seat........................................... 2-15
Rear View Monitor......................... 4-231 Displayable range on the
screen......................................... 4-233
Picture quality adjustment......... 4-238
Rear view monitor operation..... 4-234
Rear view parking camera
location...................................... 4-232
Switching to the rear view monitor
display........................................4-232
Variance between actual road
conditions and displayed
Image......................................... 4-236
Viewing the display................... 4-234
Rear Window Defogger.................... 4-86
Rear Window Washer... .................... 4-86
Rear Window Wiper......................... 4-86
Recommended Oil.............................6-25
Recording of Vehicle Data................ 8-22
Recreational Towing......................... 3-67
Registering Your Vehicle in A Foreign
Country.............................................. 8-18
Replacement Fuse..............................................6-58
Key battery.................................. 6-44
Light bulbs...................................6-52
Tires............................................. 6-49
Wheel........................................... 6-51
Wiper........................................... 6-37
10-8
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07
