If the vehicle's front, side, or rear has been involved in a collision, the alignment of the
rear view parking camera (location, installation angle) may have deviated. Always
consult an Authorized Mazda Dealer to have the vehicle inspected.
If “No Video Signal Available” is indicated in the display, there could be a problem with
the camera. Have your vehicle inspected at an Authorized Mazda Dealer.
▼ Rear View Parking Camera Location
Rear view parking camera
▼Switching to the Rear View Monitor Display
Shift the shift lever/selector leve
r to R with the ignition switched ON to switch the display
to the rear view monitor display.
NOTE
When the shift lever/selector lever is shifted from R to another shift lever/selector lever
position, the screen return s to the previous display.
When Driving
Rear View Monitor
4-230
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

▼Displayable Range on the Screen
The images on the screen may be different from the actual conditions.

(Screen display)
Garnish
Bumper
(Actual view)
Object
NOTE
The displayable range varies depending on the vehicle and road conditions.
The displayable range is limited. Objects under the bumper or around the bumper ends
cannot be displayed.
The distance appearing in the displayed image is different from the actual distance
because the rear view parking camera is equipped with a specific lens.
Some optionally installed vehicle accessories may be picked up by the camera. Do not
install any optional parts that can interfere with the camera view, such as illuminating
parts or parts made of reflective material.
It may be difficult to see the display under the following conditions, however, it does not
indicate a malfunction.
In darkened areas.
When the temperature around the lens is high/low.
When the camera is wet such as on a rainy day or during periods of high humidity.
When foreign material such as mud is stuck around the camera.
When the camera lens reflects sunlight or headlight beams.
Image display may be delayed if the temperature around the camera is low.
When Driving
Rear View Monitor
4-231
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

▼Viewing the Display
Guide lines which indicate the width of the vehicle (yellow) are displayed on the screen as a
reference to the approximate width of the vehicle in comparison to the width of the parking
space you are about to back into.
Use this display view for parking your vehicle in a parking space or garage.
b
a
a) Vehicle width guide lines (yellow)
These guide lines serve as a reference to the approximate width of the vehicle.
b) Distance guide lines. These guide lines indicate the approximate distance to a point measured from the
vehicle's rear (from the end of the bumper).
The red and yellow lines indicate the points about 50 cm (19 in) for the red line and
100 cm (39.3 in) for the yellow lines from the rear bumper (at the center point of each
of the lines).
CAUTION
The guide lines on the screen are fixed lines. They are not synced to the driver's turning of the
steering wheel. Always be careful and check th e area to the vehicle's rear and the surrounding
area directly with your eyes while backing up.
▼ Rear View Monitor Operation
The operation of the rear view monitor when
reversing the vehicle varies depending on the
traffic, road, and vehicle conditions. The amo unt of steering and the timing also varies
depending on conditions, so confirm the surrou nding conditions directly with your eyes and
steer the vehicle in accordance with the conditions.
Be well aware of the above cautions prior to using the rear view monitor.
NOTE
Images displayed on the monitor from the rear view parking camera are reversed images
(mirror images).
When Driving
Rear View Monitor
4-232
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

1. Shift the shift lever/selector lever to R to switch the display to the rear view monitor
display.
2. Confirming the surrounding co nditions, reverse the vehicle.

(Display condition) (Vehicle condition)
3. After your vehicle begins entering the parking space, continue backing up slowly so that
the distance between the vehi cle width lines and the sides of the parking space on the
left and right are roughly equal.
4. Continue to adjust the steering wheel until the vehicle width guide lines are parallel to
the left and right sides of the parking space.
5. Once they are parallel, straighten the whee ls and back your vehicle slowly into the
parking space. Continue checking the vehicl e's surroundings and then stop the vehicle in
the best possible position.

(Display condition) (Vehicle condition)
6. When the shift lever/selector lever is shifted from R to another shift lever/selector lever
position, the screen returns to the previous display.
When Driving
Rear View Monitor
4-233
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

NOTE
If the parking space has division lines, straighten the wheels when the vehicle width
guide lines are parallel to them.
Because there may be a difference between the displayed image, such as indicated
below, and the actual conditions when parking, always verify the safety at the rear of
the vehicle and the surrounding area directly with your eyes.
In the image of the parking space (or garage) displayed on the screen, the back end
and distance guide lines may appear aligned in the monitor, but they may not
actually be aligned on the ground.
When parking in a space with a division line on only one side of the parking space,
the division line and the vehicle width gu ide line appear aligned in the monitor, but
they may not actually be aligned on the ground.

▼ Variance Between Actual Road Conditions and Displayed Image
Some variance occurs between the actual road and the displayed road. Such variance in
distance perspective could lead to an accident. Note the following conditions that may cause
a variance in distance perspective.
When Driving
Rear View Monitor
4-234
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

When the vehicle is tilted due to the weight of passengers and load
When the vehicle rear is lowered, the object displayed on the screen appears farther than the
actual distance.
Variance
Object
When there is a steep grade behind the vehicle
When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the
screen appears farther (downgrade: closer) than the actual distance.
A
AB
B
Appears
farther than
actual
distance
Object at actual
position
Object at actual position
Object on screen
A: Distance between the vehicle and object displayed on the screen.
B: Actual distance between the vehicle and object. Object on screenAppears
closer than
actual
distance
When Driving
Rear View Monitor
4-235
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

Three-dimensional object on vehicle rear
Because the distance guide lines are displayed based on a flat surface, the distance to the
three-dimensional object displayed on the screen is different from the actual distance.
A
A
C B
CB
(Actual distance) B>C=A
Sensed distance on screen A>B>C (Screen display)
(Actual condition)
▼Picture Quality Adjustment
WA R N I N G
Always adjust the picture quality of the rear view monitor while the vehicle is stopped:
Do not adjust the picture quality of the rear vi
ew monitor while driving the vehicle. Adjusting
the picture quality of the rear view monitor such as brightness, contrast, color, and tint while
driving the vehicle is dangerous as it could di stract your attention from the vehicle operation
which could lead to an accident.
Picture quality adjustment must be done while the shift lever/selector lever is in reverse (R).
There are four settings which can be adjusted including, brightness, contrast, tint, and color.
When adjusting, pay sufficient attention to the vehicle surroundings.
1. Select the
icon on the screen to display the tabs.
2. Select the desired tab item.
3. Adjust the brightness, contrast, tint, and color using the slider.
If you need to reset, press the reset button.
4. Select the
icon on the screen to close the tab.
When Driving
Rear View Monitor
4-236
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

▼Sensor Detection Range
The sensors detect obstructions
within the following range.

Front sensor detection range
Front corner sensor detection range Rear sensor detection range
Rear corner sensor detection range
B
A
D
C A: About 55 cm (About 21.7 in)
B: About 55 cm (About 21.7 in)
C: About 100 cm (About 39.3 in)
D: About 150 cm (About 59.1 in)
Viewing distance display
Display
Distance between vehicle and obstruction
Front Sensor/Front Corner Sensor Rear Sensor/Rear Corner Sensor
Green
Front sensor:
Approx. 100 ―60 cm (39.3 ―23.6
in) Rear sensor:
Approx. 150 ―60 cm (59.0 ―23.6
in)
When Driving
Parking Sensor System
4-239
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

DisplayDistance between vehicle and obstruction
Front Sensor/Front Corner Sensor Rear Sensor/Rear Corner Sensor
Yellow
Front sensor:
Approx. 60 ―45 cm (23.6 ―17.7 in)
Front corner sensor:
Approx. 55 ―38 cm (21.7 ―15.0 in) Rear sensor:
Approx. 60 ―45 cm (23.6 ―17.7 in)
Rear corner sensor:
Approx. 55 ―38 cm (21.7 ―15.0 in)
Amber
Front sensor:
Approx. 45 ―35 cm (17.7 ―13.7 in)
Front corner sensor:
Approx. 38― 25 cm (15.0―9.8 in) Rear sensor:
Approx. 45 ―35 cm (17.7 ―13.7 in)
Rear corner sensor:
Approx. 38 ―25 cm (15.0 ―9.8 in)
Red
Front sensor:
Within approx. 35 cm (13.7 in)
Front corner sensor:
Within approx. 25 cm (9.8 in) Rear sensor:
Within approx. 35 cm (13.7 in)
Rear corner sensor:
Within approx. 25 cm (9.8 in)
When Driving
Parking Sensor System
4-240
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.

Rear sensor
Left front
corner sensor
Left rear
corner sensor
Right front
corner sensor
Right rear
corner sensor
Front sensor
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalization Features on page 9-12.
System problem notification
If a problem occurs, the driver
is notified of the problem by the following indications.
Detection Indicator Solution
Disconnection
The system may have a malfunction. Have the
vehicle inspected at an Authorized Mazda Deal-
er as soon as possible.
System mal- function
The system may have a malfunction. Have the
vehicle inspected at an Authorized Mazda Deal-
er as soon as possible.
